StepperOnline Y Series User manual

2
User Manual for
Closed Loop Stepper Drive
Y Series Closed Loop Driver
Version 1.0
STEPPERONLINE®
©2019 All Rights Reserved
Attention: Please read this manual carefully before using the drive.
1 Introductions & Features
The Y series closed-loop drivers are divided according to the driving power, which are CL57Y,
CL86Y.This Closed Loop Stepper Drive offers an alternative for applications requiring higher
performance and higher reliability than open loop stepper system, and it remains cost-effective. The
matched stepper motors are NEMA17, 23 and 24 combined with an internal encoder which is used to
close the position, velocity and current loops in real time. Its great features of quicker response and
no hunting make this closed loop stepper drive ideal for applications such as bonding and vision
systems in which rapid motions with a short distance are required and hunting would be a problem.
And it is ideal for applications where the equipment uses a belt-drive mechanism or otherwise has low
rigidity and you don't want it to vibrate when stopping. And features are showing below:
A new generation of 32-bit DSP control technology
Input voltage range: DC24 ~ 50V, AC20 ~ 80V / DC30 ~ 110V
The highest impulse response frequency is 200KHz
Low torque attenuation, up to 3000rpm
Built-in positioning and alarm output for easy detection and control
Intelligently regulate current, reduce vibration, noise and heat, and increase efficiency by 35%
With single and double pulse selection function, the factory default is: pulse + direction
control
Excellent high-speed performance and rigidity, perfect combination of servo and stepping
advantages
2 Specifications
2.1 Electrical Specifications
Parameters
CL57Y
Min
Typical
Max
Unit
Output Peak Current
0
-
5
A
Input Voltage
24
36
50
VDC
Logic Signal Current
7
10
16
mA
Pulse Input Frequency
0
-
200
kHz
Pulse Width
2.5
-
-
μS
Minimal direction setup
2.5
-
-
μS
Isolation Resistance
500
MΩ

3 4
2.2 Mechanical Specifications(unit: mm [1inch=25.4mm])
Figure 1: Mechanical specifications
Recommend use side mounting for better heat dissipation
2.3 Electrical Specifications
2.4 Mechanical Specifications(unit: mm [1inch=25.4mm])
Figure 2: Mechanical specifications
Recommend use side mounting for better heat dissipation
3 Pin Assignment and Description
3.1 Connector P1 Configurations
Pin Function
Details
PU+
Connected to the signal power supply, +5~+24V can be driven
PU-
The falling edge is valid and the pulse goes one step when the pulse goes from
high to low.
Requirements: Low level: 0~0.5V, high level 5~24V, pulse width greater than 2.5
microseconds.
DR+
Connected to the signal power supply, +5~+24V can be driven
DR-
Used to change the direction of the motor.
Requirements: Low level: 0~0.5V, high level 5~24V, pulse width greater than 2.5
microseconds.
Parameters
CL86Y
Min
Typical
Max
Unit
Output Peak Current
0
-
6
A
Input Voltage
20（30）
-
80（110）
VAC(VDC)
Logic Signal Current
7
10
16
mA
Pulse Input Frequency
0
-
200
kHz
Pulse Width
2.5
-
-
μS
Minimal direction setup
2.5
-
-
μS
Isolation Resistance
500
MΩ

5 6
MF+
Connected to the signal power supply, +5~+24V can be driven
MF-
When it is active
（low level）
, the motor coil current is turned off, the driver stops
working, and the motor is in a free state.
Pend+
When the drive has finished a given pulse, the in-position signal is valid (output
optocoupler is on). Pend+ is connected to the pull-up resistor to the positive
terminal of the output power supply. The maximum current is 50mA.
Pend-
Pend- is connected to the negative terminal of the output power supply.
ALM+
When overcurrent, overvoltage, undervoltage or position error alarm, the alarm
signal is valid (output optocoupler is on). ALM+ is connected to the pull-up
resistor to the positive terminal of the output power supply. The maximum drive
current is 50mA.
ALM-
ALM- is connected to the negative terminal of the output power supply.
PWR
Power Indicator. Power on, green light is always on
ALM
Fault indicator.
Flash once: overcurrent or phase-to-phase short circuit;
Flashing twice: over voltage;
Flashing three times: under voltage;
Flashing five times:following position error
3.2 Connector P2 Configurations
Pin Function
Details
GND
Power ground.
+V
DC24~50V(CL57Y), AC20 ~ 80V / DC30 ~ 110V(CL86Y)
A+, A-
Motor phase A
B+, B-
Motor phase B
3.3 Connector P3 Configurations
Pin Name
Description
EB-
Encoder B- input
EB+
Encoder B+input
EA+
Encoder A+ input
EA-
Encoder A- input
VCC
+5V power output
EGND
Signal ground
4 Wiring
The CL57Y、CL86Y can accept differential and single-ended inputs (including open-collector and PNP
output). The CL57Y、CL86Y has 4、5 optically isolated logic inputs which are located on connector P1 to
accept line drive control signals. These inputs are isolated to minimize or eliminate electrical noises
coupled with the drive control signals. Recommend using line drive control signals to increase noise
immunity for the drive in interference environments.
A complete closed loop stepper system should include a closed loop motor, a drive, a power supply
and a controller (pulse generator). The typical connection is shown as figure 3.
Figure 3: Typical connection

7 8
5 Motor Wiring
5.1 Connections of 4-lead Motor
Figure 4: 4-lead Motor Connections
5.2 Connections of 6-lead Motor
Figure5: 6-lead motor half coil (higher speed)
connections
Figure 6: 6-lead motor full coil (higher torque)
connections
5.3 Connections of 8-lead Motor
Figure 7: 8-lead motor series connections
Figure 9: 8-lead motor parallel connections
Figure10: 8-lead motor half coil
6 Frequently Asked Questions
Symptoms
Possible Problems
Motor is not rotating
No power
Microstep resolution setting is wrong
Fault condition exists
The drive is disabled
Motor rotates in the wrong direction
The Direction signal level is reverse
The drive in fault
Power supply voltage beyond drive’s input range
Something wrong with motor coil
Wrong connection
Erratic motor motion
Control signal is too weak
Control signal is interfered
Wrong motor connection
Something wrong with motor coil
Motor stalls during acceleration
Current setting is too small
Motor is undersized for the application
Acceleration is set too high
Power supply voltage too low
Excessive motor and drive heating
Inadequate heat sinking / cooling
Current is set too high
Motor vibration when power on
Speed loop Kp is too high
7 Warranty
STEPPERONLINE®warrants its products against defects in materials and workmanship for a period
of 12 months from shipment. During the warranty period, STEPPERONLINE will either, at its option,
repair or replace products which proved to be defective. To obtain warranty service, a returned
material authorization number (RMA) must be obtained before returning product for service.
Exclusions: The above warranty does not extend to any product damaged by reasons of improper
or inadequate handlings by customer, improper or inadequate customer wirings, unauthorized
modification or misuse, or operation beyond the electrical specifications of the product and/or
operation beyond environmental specifications for the product.
