Ltech Artnet-DMX-2 User manual

Artnet-DMX converter is the Ethernet Control System based on the Artnet protocol, used to convert
the Artnet network data package into DMX512 data, adopting high-speed ARM processor, stable and
reliable working. Following Artnet standard protocol, it supports RJ45 network interface and standard
DMX512 output interface.
Artnet-DMX-2
Artnet-DMX Converter
1
Artnet-DMX-2 Artnet-DMX Converter
12Vdc (with a power adaptor) RJ45
Network Connection:
XLR-3
warranty
5 years
Artnet-DMX-2
Output signal: DMX512
IP: Indoor use only
Power input:
Input signal: Artnet
Current: 30mA@12Vdc
DMX channels: 512 × 2CH
DMX Output Connection:
1. Technical Specs
It is compatible with all the effects lighting control software which support Artnet protocol, widely used
in the LED dot matrix and the stage lighting control network in needing lots of DMX512 data,
especially for TV station recorded scene, stage performances, entertainment and so on.
Artnet-DMX-2 has two standard DMX512 data output port, output 1024 data in total.
L120×W73×H45mm
L198×W78×H50mm
290g
-30 ~65℃ ℃
Working temperature:
Dimension:
Package Size:
Weight (G.W):
Isolation Ethernet Port: Transformer isolation
1
2
ON
Sub- Net
Univer se
Fun
Ether net
DC12 V
3. Product Dimension:
Artnet input
Power Input
Universe Dip Switch
Mode Switcher
(Operation as follows)
Subnet Dip Switch
Status lamp
4. Interface Instruction:
120mm
45mm
73mm
IP Address Setting: 2.0.36.Address
IP Address Setting: 10.0.36.Address
Testing function, OUT1 generates 170 pixels full color jumping DMX data,
OUT2 generates 170 pixels full color smooth float DMX data.
12
OFF
ON
OFF
OFF
ON OFF
1 2
ON
1 2
ON
1 2
ON
Diagrams
Switching modes operation instruction:
Functions
1
2
ON
Sub -Net
Uni verse
Fun
Eth erne t
DC12 V
4
5
6
3
7
2
8
1
9
0
A
F
B
E
D
C
4
5
6
3
7
2
8
1
9
0
A
F
B
E
D
C
Universe
Sub-Net
1 2
Fun
ON
2
2.1 Based on Artnet protocol network data communication, accept network DMX data;
2.2 IP address is bound to Subnet, no need to reset, plug and play.
2.3 Manage Artnet on broadcast mode or unicast mode.
2.4 Output 2 group DMX512 data.
2.5 Set different network segments to avoid multiple sets Artnet data interference.
2.6 Compatible with the light software based on Artnet Protocol, control stage lighting and LED
lighting simultaneously.
2.7 Connect up to 256 DMX Universes to one network.
2.8 10BaseT Ethernet Port.
2.9 Data activity indicators
2.10 Configurable DMX output refresh rates.
2. Performance Features
Artnet-DMX-2 Artnet-DMX Converter
www.ltechonline.com

5. Conjunction Diagram:
Artnet-DMX-2 Lighting Control System Diagram
Artnet-DMX-2
Router
Computer
XLR-3
cable
XLR-3
cable
XLR-3
cable
RJ45
cable
RJ45
cable
RJ45
cable
RJ45
cable
Artnet-DMX-2
Artnet-DMX-2
Moving head light
Moving head light
Moving head light
Par light
Par light
Par light
1
3
2
PUSH
PUSH
1
3
2
Address setting instruction:
DMX Output1
DMX Output2
Status lamp
Status lamp
Universe/SubNet Dip Switch
1 2 345678 9 A B C D E F
0
Value 1 2 345678 9 10 11 12 13 14 150
Calculating method: Group address= Subnet×16 + Universe, IP Address=2.0.36.Group Address,
MAC Address=00-1B-14-20-24-Group Address
For example: Subnet: 2, Universe: B, Group Address=2×16 + 11 = 43, so the 2 channels DMX
output group address is 43,44; Corresponding IP address is 2.0.36.43 and 2.0.36.44, MAC
address is 00-1B-14-20-24-43.
1 2
3
DMX OUT1
1
3
2
PUS H
PU SH
1
3
2
GND
DATA-
DATA+
DMX OUT2
1 2
3
1
2
3
3
1
3
2
PUSH
PUSH
1
3
2
1
3
2
PUSH
PUSH
1
3
2
Artnet-DMX-2 Artnet-DMX Converter
4
Artnet-DMX-2 Artnet-DMX Converter
7. Warranty Agreement:
7.1 We provide lifelong technical assistance with this product:
★This manual only applies to this model. We reserve the right to make changes without prior notice.
7.4 Any amendment or adjustment to this warranty must be approved in writing by our company
only.
7.3 Repair or replacement as provided under this warranty is the exclusive remedy to the
customer. We shall not be liable for any incidental or consequential damages for breach
of any stipulation in this warranty.
7.2 Warranty exclusions below:
For faults beyond the 5-year warranty, we reserve the right to charge for time and parts.
A 5-year warranty is given from the date of purchase. The warranty is for free repair or
replacement if cover manufacturing faults only.
Any man-made damages caused from improper operation, or connecting to excess voltage
and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
6. Attention:
6.1 The product shall be installed and serviced by the qualified person.
6.7 If a fault occurs please return the product to your supplier. Do not attempt to fix this product
by yourself.
6.6 Ensure all wire connections and polarities are correct before applying power to avoid any
damages to the LED lights.
6.5 Please ensure that adequate sized cable is used from the controller to the LED lights to carry
the current. Please also ensure that the cable is secured tightly in the connector.
6.4 Please check if the output voltage of the LED power supply used comply with the working
voltage of the product.
6.3 Good heat dissipation will prolong the working life of the controller. Please ensure good
ventilation.
6.2 This product is non-waterproof. Please avoid the sun and rain. When installed outdoors, please
ensure it is mounted in a water proof enclosure.
Update Time: 2016.05.13
