USER GUIDE

UNIVERSAL GAMING HEADSET CHARGING MICROPHONE
CONNECTING TO CONSOLE
For: PS4, PS3, Xbox One, and Xbox 360
STEP 1.
Connect the wide end of the optical cable to
the optical port on the rear of the Console. Early
Xbox 360 Consoles may require an HDMI Audio
Adapter (not included).
Connect the thin end of the optical cable to the
optical port on the side of the Base Station.
Plug the Base Station into a USB port on the Console.
STEP 2. STEP 3.
CABLES/PARTS BASE STATION
Game Mute
Rising tone = unmuted
Falling tone = muted
Microphone Mute
Rising tone = unmuted
Falling tone = muted
LED on boom mic
illuminates when muted.
EQ Preset Select
1 beep for Normal
2 beeps for Bass Boost
3 beeps for Treble Boost
Status LED
Solid = ON/Connected
Slow Blink = Searching
Optical Input
Power LED
Solid = ON/Connected
Slow Blink = Searching
Fast Blink = Battery Low
USB Charging Port
Microphone Port
Game Volume
Chat Volume
Power Button
Mobile/Xbox Input
IN
5V
(L) (R)
EQ
Xbox Chat Cable/
Mobile 3.5mm Cable
Xbox 360
Chat Adapter
Boom Mic Mic Port Cover
Optical
Cable
USB Charging
Cable
!
The LS30 includes an optional boom microphone.
When this microphone is removed, an internal
microphone is activated.
To connect the boom microphone, simply insert it
into the port on the bottom of the headset.
When battery has less than 15%
power remaining, unit beeps twice
every 10 minutes.
Connect the small end (micro-USB) of the charging cable to the
headset. Connect the other end to a USB port. The LED on the
headset will pulse while charging and turn solid when charging
is complete.
PLAYSTATION 4 SETUP
Go into Settings > Sound and Screen > Audio Output Settings > Primary
Output Port and select ‘Digital Out (Optical)’.
Make sure that only ‘Linear PCM 44.1kHz and ‘Linear PCM 48kHz’ are checked.
Go into Settings > Audio Output Settings > Audio Format (Priority) and select
‘Linear PCM.’
Go into Settings > Devices > Audio Devices and set both the ‘Input Device’ and
‘Output Device’ to ‘USB Headset(Lucid Sound LS30).
Set the Output to Headphone to ‘Chat Audio’.
Set the ‘Volume Control (Headphones)’ to maximum.
1.
2.
3.
4.
5.
6.
PLAYSTATION 3 SETUP
Go into Settings > Sound Settings > Audio Output Settings > Optical Digital.
Make sure that only ‘Linear PCM 2 CH. 44.1kHz’ and ‘Linear PCM 2 CH. 48kHz’
are checked.
Go into Settings > Accessory Settings > Audio Device Settings and set the
‘Input Device’ and ‘Output Device’ to ‘Lucid Sound LS30’.
1.
2.
3.

XBOX ONE SETUP
XBOX 360 SETUP
PC / MAC SETUP
MOBILE
United States
Lucid Sound, Inc. warrants this product to be free from defects in materials and workmanship for the warranty period. This
non-transferable, 1-year limited warranty is only to you, the rst end-user purchaser. If a defect covered by this warranty occurs
AND you provide proof of purchase, Lucid Sound, Inc., at its option, will repair or replace the product at no charge (excluding
shipping to Lucid Sound).
The Lucid Sound, Inc., 1-year limited warranty is available to customers in the United States. Your sole and exclusive remedy is
repair or replacement of your Lucid Sound product. In no event shall Lucid Sound’s liability exceed the original purchase price of
the product. This warranty does not apply to: (a) normal wear and tear or abusive use; (b) industrial, professional or commercial
use; (c) if the product has been tampered with or modied.
To receive warranty service, please contact us at: lucidsound.com
Australia
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a 1 year
replacement warranty in which you are entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
What you must do:
If a defect has appeared within 30 days from the date of purchase, the product may be returned to the retailer for a replacement.
If a defect has appeared after 30 day from the date of purchase, you must initiate a repair by following the online repair process
at www.lucidsound.com.au/support.
Once all details are completed, you will receive a return authorisation number.
Then label and ship your LucidSound headset – including the return authorisation (RA) number, freight prepaid, to Lucid Sound’s
authorised repair centre.
LucidSound
C/o Tecworks International Pty Ltd
Unit 1 / 12 Tollis Place
Seven Hills NSW 2141
Please ensure the return authorisation (RA) number is prominently displayed on the outside of your packaging.
The cost incurred to return the product to the retailer or to the authorised repair centre as part of a Warranty claim are your
responsibility.
What we will do:
During the Warranty Period, we will, at our option, repair or replace the product or any defective parts. We will also bear the
reasonable costs of standard return shipping. If this cannot be done, then we will refund the purchase price to you.
AU wholesale distributor:
Bluemouth Interactive Pty Ltd, Level 2, 2 Darling Street, South Yarra, Victoria, 3141
Email: [email protected]
Controller with 3.5mm port
Always turn on the headset before turning on the controller.
Connect one end of the Xbox One chat cable to the 3.5mm
port on the headset and the other end to the 3.5mm port on
the Controller.
On the Xbox One, go into All settings > Kinect & devices >
Devices & accessories and choose the Xbox One Wireless
Controller in use.
Select ‘Volume’ and set ‘Headset volume’ to maximum and
‘Mic monitoring’ to minimum.
Make sure that ‘Headset mic’ is turned to ‘On.’
If it appears, set ‘Headset chat mixer’ all the way to the right
for 100% chat.
On the Xbox One, go into All settings > Display & sound.
Under ‘Audio Output’ select ‘Optical audio’ and choose
‘Stereo uncompressed.’
Using Stereo Headset Adapter
If the Xbox One Controller does not have a 3.5mm port, an
Xbox One Stereo Headset adapter is required (not included).
Connect one end of the Xbox One chat cable to the 3.5mm
port on the headset and the other end to the 3.5mm port on
the Stereo Headset Adapter.
Adjust the game/chat balance on the Stereo Headset Adapter
to 100% chat and increase the volume on the adapter to
maximum.
On the Xbox One, go into All settings > Display & sound.
Under ‘Audio output’ select ‘Optical audio’ and choose ‘Stereo
uncompressed.’
Connect one end of the Xbox chat cable to the 3.5mm port on
the headset and the other end to the Xbox 360 adapter. Then
connect the adapter to the 2.5mm port on the Controller.
Go into Settings > System > Console Settings > Audio
and select ‘Digital Stereo.’
1.
2.
3.
4.
5.
6.
Connect the dongle to a USB port on the computer and power on the headset.
In the computer’s sound settings, set the default sound output to “Lucid Sound PC
Gaming Audio Interface” for game audio.
In the chat program being used, choose “Lucid Sound PC Chat Audio Interface” for both
the Input and Output.
1.
2.
3.
Connect one end of the mobile cable to the 3.5mm input on the headset and the
other end to the 3.5mm output on the mobile device.
The headset will only work in passive (OFF) mode. (note that the volume, EQ, and
mute features will not function).
1.
2.
1.
2.
3.
4.
1.
2.
Model No: LS30RX IC: 21203-06302
Model No: LS30TX IC: 21203-06301
