Model3001Multi-DetectorSurveyMeter User’s Manual Section1
Ludlum Measurements, Inc. Page 1-1 April 2017
Introduction
The Model 3001 is an ergonomic, lightweight instrument which can be
used for radiation survey purposes. It features the ability to measure
radiation in count rate, exposure rate/dose, activity rate, integrated
exposure/dose, time-averaged rates, and scaler counts. The Model 3001
supports up to four external radiation detectors to detect alpha, beta, or
gamma radiation. Each detector may have its own set of calibration and
user parameters. The DETECTOR button is used to select the active
detector.
The instrument features a large backlit LCD (liquid crystal display), a
piercing audio warning, and easy, intuitive use. The unit body is made of
lightweight but durable plastic. It is intended for outdoor use and can
resist splashing water. The foam grip provides a comfortable,
ergonomic grip but may be removed for ease of decontamination.
Three modes of operation are available for the Model 3001 –RATE,
MAX, and COUNT. RATE mode operation will display the current
count, exposure, or activity rate. MAX mode is used to capture the
highest count, activity, or exposure rate detected –useful for finding a
peak rate, or frisking when the display is not visible. Two sets of units
(primary and secondary) for RATE and MAX modes can be chosen
from among cps, cpm, Bq, dpm, R/h, or Sv/h. The user can switch
between these two units by simply pressing the UNITS button.
COUNT mode allows the user to perform a count for a predetermined
time. Depending on the count units chosen, the result can be a scaler
count (in counts or disintegrations), a time-averaged rate (cpm, dpm,
Bq, cps), a time-averaged exposure or dose (R/h, Sv/h), or an
integrated exposure or dose (R or Sv).
The display will be automatically backlit if light levels are low. The
display backlight can also be configured for “Continuous On”
operation. RATE, MAX, and COUNT modes can be silent or utilize a
“click” audio; the “click” audio is always silent during COUNT mode
by default. A "sigma" audio mode can be enabled (disabling the "click"
Section
1

Model3001Multi-DetectorSurveyMeter User’s Manual Section1
Ludlum Measurements, Inc. Page 1-2 April 2017
audio) in RATE and MAX modes when scintillator detectors are used,
and this mode makes it easy for the user to find small increases above
the background radiation level. In this mode, the instrument measures
background for 8 seconds after power-up, and then beeps whenever the
rate increases by a small amount. Users are freed from watching the
numeric value to "find" something. They can simply listen for multiple
beeps.
Setup of the instrument is accomplished through the front-panel
buttons, or through software available from Ludlum Measurements.
Front-panel setup can be disabled via the internal switch on the Model
3001 in order to protect settings from inadvertent changes. When the
settings are protected, the user can only view the settings, and the
password-protected software must be used to change any of the
settings. The Model 3001 can be configured through software to allow
changes to the alarms and or count time even when in protect mode.
The unit is operated with four alkaline AA batteries for operation from
-20 to 50 °C (-5 to 122 °F). Battery life is approximately 500 hours
under normal usage. A low-battery indicator on the LCD warns when
less than 16 hours of battery life remain.
The Model 3001 may optionally be provided with a 1/8-inch stereo
headphone jack that would allow for headphone use for audio output. It
is located to the left of the detector connector.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-1 April 2017
1. Turn the instrument over so that the bottom of
the instrument is facing up.
2. Use a straight, medium-sized screwdriver to turn
the single screw on the battery cover one-quarter
turn counter-clockwise.
3. Release and remove the battery cover.
4. Replace all four AA batteries.
5. Replace the cover and turn screw one quarter of
a turn clockwise to secure.
Getting Started
Unpacking and Repacking
Remove the calibration certificate and place it in a secure location. Remove
the instrument and ensure that all of the items listed on the packing list are
in the carton. Check individual item serial numbers and ensure calibration
certificates match between instruments and detectors (if applicable). The
Model 3001 serial number is located on a label on the front side of the unit.
To return an instrument for repair or calibration, provide sufficient packing
material to prevent damage during shipment.
Every returned instrument must be accompanied by an Instrument
Return Form, which can be downloaded from the Ludlum website at
www.ludlums.com. Find the form by clicking the “Support” tab and
selecting “Repair and Calibration” from the drop-down menu. Then choose
the appropriate Repair and Calibration division where you will find a link to
the form.
Battery Installation
A low-battery indicator appears at the top of the LCD when less than 16
hours of battery life remain. When this indicator is present, follow these
steps to replace the four standard AA batteries:
Section
2

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-2 April 2017
Instrument Operational Test
Turn the instrument ON by pressing the ON/ACK button for about a
second, and then releasing.
The instrument should activate all the LCD segments and the audio.
Observe the device during this time. If any LCD segments are missing, or
audio fails to work, the device is in need of repair. Please refer to Figure 1
below.
Figure 1: Startupdisplay for Model 3001, with all LCD segments shown.
The instrument then displays the firmware version. Please refer to Figure 2
below.
Figure 2: Firmware version display.
Note: Firmware versions with the Bq units are equipped with auxiliary
communication.
The instrument then displays the battery voltage. Please refer to Figure 3.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-3 April 2017
Figure 3: Battery Voltage display
The instrument then displays the number of stored records if datalogging
is enabled. Please refer to Figure 4 below.
Figure 4: Startup display for Optional Data Logging firmware, showing
155 stored records.
The instrument will then move to normal operation, displaying the current
rate for the Primary units (default: mR/hr).
If the Sigma Audio option is selected, the unit will display a countdown
from :08 to :01 (in seconds) as the unit measures background radiation
levels.
The user may select the Secondary units (default: cpm) by pressing the Units
button.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-4 April 2017
Ensure that the low-battery indicator is not present. If the low-battery
indicator is present, replace the batteries as soon as possible. Should the
instrument detect a battery voltage that is high enough to power on, but too
low to safely operate, the display will blank and the low-battery icon will
flash. Normal operation will not be available until the batteries have been
replaced. Under extreme low-battery conditions, be aware that the unit may
not even turn on or may turn itself off abruptly.
A reference reading with a check source, 1 µCi (37 kBq) of 137Cs for
example, should be obtained at the time the instrument is received in the
field. Small check sources of radiation are available from Ludlum
Measurements. While exempt from many regulations because of their small
size, these sources are large enough to produce a response on this
instrument. If this procedure is done routinely with the same radiation
source, instrument malfunction may be detected when anomalous readings
are observed. If at any time the instrument fails to read within 20% of the
reference reading when using the same check source, it should be sent to a
calibration facility for recalibration and/or repair.
Example log reading:
Check Source # Rate Units
Once this procedure has been completed, the instrument is ready for use.
Sigma Audio
The Ludlum Model 3001 has the standard "click" audio that is widely used
by radiation instruments. However, it also has a Sigma Audio mode that
can be enabled to change the audio sound. This mode is useful for
scintillation detectors because their high count rate makes the "click" audio
less useful.
In the sigma audio mode, the instrument measures the background
radiation alarm for eight seconds on power-up, and then automatically sets a
low threshold rate above the background rate. Then the instrument will
produce a beep any time that the instrument "sees" more than this
threshold value. The user doesn't need to watch the display to find a small
increase over background; the user may just listen for multiple beeps. Thus,
the unit has an audio alarm that, on power-up, adjusts to just above the
current background level and provides a sensitive audio indication to the
user.
Note that this audio alarm can also work in conjunction with the fixed
alarm, i.e. the user can have both a floating audio alarm (resulting in audio
beeps) based on the background level, and a fixed tone audio and a steady
ALARM icon when a predetermined fixed alarm level is exceeded.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-5 April 2017
Detector Failure Diagnostic
Note that the Model 3001 has its own diagnostic tests to ensure that the
detector is functioning correctly. The Model 3001 can detect when the
radiation detector is malfunctioning and will flash the display to indicate a
fault. If the detector stops detecting radiation for a settable number of
seconds, the Model 3001 will flash a zero reading for the currently selected
units. This indication is common if the unit is powered up without a
detector connected. If this indication is observed with a connected detector,
remove the unit from service and have it evaluated by a qualified repair and
calibration technician.
Figure 5: Detector Failure display (shown for cpm); will also flash.
Detector Over Range
If the detector is exposed to high levels of radiation or has an internal
malfunction that causes it to count high or excessively, the unit flashes the
maximum rate (999) for the currently selected units as a warning. The icon
ALARM is also displayed at the top of the screen. The user should ensure
whether this condition is being caused by a high radiation field, by a shorted
cable, or by internal malfunction. With some detectors, this display could be
an indicator of a light leak, possibly caused by a puncture or tear in the
detector face. If a Maximum Display parameter is set, then it is possible for
the display to flash the Maximum Display value under this condition.
Figure 6: Detector Over Range (shown for kcpm); will also flash.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-6 April 2014
Detector Overload
As another diagnostic test, the Model 3001 monitors the HV supply's
detector current. A current overload threshold can be set via Setup Mode.
(A setting of 0 disables this alarm.) In general, this alarm setting can be used
to detect when there is some detector failure, a cable failure, or a possible
high level of radiation. When this alarm is triggered, the LCD will display
OL and an alarm tone will sound. Once the detector current goes below the
threshold, the Model 3001 will return to normal operation.
Figure 7: Detector Overload Alarm; will also flash.
Instrument Use and Controls
With four front-panel buttons (as seen in front-panel drawing in front of
manual), the Ludlum Model 3001 is simple and easy to use with minimal
training required. Default operation is RATE mode, and the display shows
the current count rate using the Primary units. Long-pressing the UNITS
button will switch between Primary and Secondary units. Long-pressing the
MODE button will switch the instrument to MAX mode, which will display
the highest count rate detected. Long-pressing the MODE button again will
switch it to COUNT mode, which will display the COUNT timer. Note
that either or both of the MAX and COUNT modes can be locked out in
the setup process.
ON/ACK button:Used to power the Model 3001 ON and OFF, reset MAX
mode, start/reset the COUNT Timer, and acknowledge audio alarms.
Power On: Press for approximately one second and release (all
LCD segments will activate, and firmware version will be shown).
Power Off: Press and hold for approximately four seconds. The
display will show a 3, 2, 1 countdown for the final three seconds of
shutdown. Releasing the ON/ACK button during shutdown will
return the device to the previous state of operation. At completion
of the shutdown count, the LCD will go blank.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-7 April 2017
Short Press (tap-pressing the button and releasing in under a half second):
Normal Operation: Will acknowledge/silence alarms in all modes
of operation.
Change Log Location Selected Position (if data logging is enabled).
Will move selection position in the device menu.
Long Press (pressing the button and releasing for at least a half second):
Start/reset COUNT Timer in COUNT mode.
When Sigma Audio is enabled, pressing the ON/ACK button will
take a new background reading and update the Sigma Audio level
(in Rate Mode only).
Reset/Zero: When in Rate mode, a long press of the ON/ACK.
Will reset/zero the averaged rate: the minimum display will be
shown before returning to the exposure rate. When Sigma Audio is
enabled, Rate Reset is disabled.
Will reset MAX mode display.
UNITS button:
Short Tap (pressing the button and releasing under a half second)
Used to switch between Primary and Secondary units in all available
modes.
DETECTOR button:
Short Tap (pressing the button and releasing under a half second)
Used to select the active detector, as evidenced by the
corresponding DET1, DET2, DET3, or DET4 LED. Unit saves
this setting prior to shutting down, so it will power up with the
same detector setting.
Long Press (pressing the button and releasing for at least a half second)
Only used in the device menu. While viewing the Detector
Overload parameter, a long press will allow the user to view the
actual current level. Another long press will return user to overload
setting.
MODE button:
Short Tap (pressing the button and releasing under a half second)

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-8 April 2014
Used to advance between the three operating modes: RATE, MAX,
and COUNT. Note that MAX and/or COUNT mode may be
disabled from use.
The device menu increments selected digit/text to the next available
option.
RATE Mode Operation
In RATE mode, the current count rate will be displayed.
Long-pressing the ON/ACK button for at least a half second will reset the
averaged rate before releasing the button. The Reset feature must be
enabled through Lumic Calibration software (see parameter: RateResetBtn)
and will be disabled when Sigma Audio is enabled.
Tapping the UNITS button will switch the displayed value between the
Primary and Secondary Units.
Tapping ON/ACK button will turn the “click” audio on/off. When Sigma
Audio is enabled, tapping the ON/ACK button will toggle the Sigma Audio
beep on/off. If dual Level audio is enabled, it will toggle between “Hi, LO,
and OFF.”
If an alarm condition is present, tapping the ON/ACK button will
acknowledge and turn off the continuous tone alarm audio. Under an alarm
condition, the ALARM display indicator will remain on. Alarms are non-
latching in RATE mode. When Sigma Audio is enabled, and an alarm
condition is not present, a long press (at least a half second) of the
ON/ACK button will reset the Sigma Audio alarm level. The Sigma count
can only be reset in RATE mode.
Figure 8: RATE mode display showing typical background radiation
rate and the low-battery icon.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-9 April 2017
MAX Mode Operation
While in MAX mode, the highest detected count rate (since the last reset) is
displayed. The word MAX will be displayed when in MAX mode.
Tapping the UNITS button will switch the displayed value between the
Primary and Secondary Units.
Tapping the ON/ACK button will turn the “click” audio on/off. When
Sigma Audio is enabled, tapping the ON/ACK button will toggle the Sigma
Audio beep on/off.
Under a non-alarm or alarm condition, a long press of the ON/ACK button
will reset the display. When Sigma Audio is enabled, the Sigma Audio alarm
level cannot be reset in Max Mode.
If an alarm condition is present, tapping the ON/ACK button once will
acknowledge and turn off the continuous tone alarm audio. (The “click”
audio will remain as selected under non-alarm conditions.) Tapping the
ON/ACK button a second time will toggle the audio setting. Under an
alarm condition, the ALARM display indicator will remain on until the
display is reset. Alarms in MAX mode latch with the display.
If other operational modes are available, tapping the MODE button will
move to the next available operational mode.
Figure 9: MAX mode operation display with ALARMindicator.

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-10 April 2017
COUNT Mode Operation
When entering COUNT Mode from another operational mode, the
currently selected COUNT Unit will be displayed for approximately one
second. The purpose of COUNT mode is to count for a predetermined
amount of time, and to display the results on the display. Note that the
predetermined count time can be from 1 second to 10 minutes, or can be set
to zero to enable continuous counting until stopped by the user.
Count mode operation is very flexible, depending on the units chosen. A
common choice is for the count mode to just perform a scaler count for a
specified time, with a resulting answer in counts (equaling detected radiation
events).
There are two different options for COUNT mode, which can be set
through software.
Go to “Device Count DisplayMode” in the Device or Others tab
(depending on software version). Enter the desired option into the “Value”
field.
0 - will only show the countdown timer while the timer is active
(default selection).
1 - will cycle between showing the countdown timer and the current
reading.
2 - will only show the current gathered reading.
Note:
If the Data Logging Option is installed, tapping the LOG button
will start a count and automatically log the result. A long press of
the LOG button during the count will toggle the display between
the timer and reading. Audio ‘clicks’ are disabled in COUNT mode
by default
Device Count Mode AudioMode will enable\disable click audio during a
COUNT
0 –Disabled (Mute icon will always be illuminated in COUNT
mode.)
1- Enabled

Model3001Multi-DetectorSurveyMeter User’s Manual Section2
Ludlum Measurements, Inc. Page 2-11 April 2017
Note:
Sigma audio is disabled in Count Mode. If Sigma Audio and Count
Mode Audio are enabled, click audio will be utilized in Count
Mode. If a result in terms of activity is desired, the scaler count can
also be in units of "d" or disintegrations. But if the count units are
chosen to be cpm or cps, then the resulting answer is an averaged
count rate over the time interval. Similarly, if count units of Bq or
dpm are chosen, the resulting answer is an averaged disintegration
rate.
Note:
If the user desires the instrument to show results in terms of
disintegrations/area (eg. dpm/100cm2or Bq/cm2), then the
appropriate factor should be placed in the Efficiency parameter.
Other choices are to have count mode units of R/h or Sv/h, in which case
the COUNT mode result is an averaged exposure or dose rate. But if count
mode units of R or Sv are chosen, the result is shown in accumulated
exposure or accumulated dose over the chosen count time. The following
tables lists the possibilities:
UNITS RESULT
c counts per count time
d disintegrations per count time
cpm, cps count rate averaged over the count time
dpm, Bq disintegration rate, averaged over the count time
R/h, Sv/h exposure or dose rate, averaged over the count time
R, Sv integrated exposure or dose over the count time
