Lumascape Balitza Mini User manual

INSTALLATION INSTRUCTIONS
Lumascape Lighting Industries Pty Ltd
38-44 Enterprise Street, Cleveland, QLD 4163, Australia
PO Box 1875, Cleveland D.C., QLD 4163, Australia
T 07 3286 2299
F 07 3286 6599
E [email protected]
W www.lumascape.com.au
IN0084 - 27 June 2014
Copyright ©2014 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
Mark and cast/drill holes
Mark location of fixtures and cable entry/
mounting holes. Refer template over for details.
Drill or cast holes as required.
Fit mounting plate
Pull cable through gland and tighten. Connect
leads to terminal block and mount base plate
to surface with screws provided. Seal with
silicone glaze.
Seal fixture
Put lid over the base plate and tighten screws. 1. Open fixture as shown in step 2.
2. Remove old lamp from fixture as shown below.
3. Insert lamp into fixture as shown in step 4.
4. Seal fixture as shown in step 5.
Insert lamp into fixture
Check wattage and insert lamp into fixture.
Test to ensure lamp and fixture is operational.
Open fixture
Loosen all three screws at the base of
the fixture.
Remove lid.
LS582 & LS592: Balitza Mini & Micro (low voltage) A.C.N. 0105 72 773
MODEL: LS582 & LS592
INPUT VOLTAGE: 12 V
BOLLARD & PATHWAY
Warranty voided if not installed as per installation instructions
1. 3.
5.4.
2.
SILICONE
NOTE
Use silicone glaze to seal
the gour screw holes and
achieve IP66.
cable entry
mounting point
fixture outline
mounting point
26.39 mm
RELAMPING
Always check luminaire label to confirm correct supply
voltage, lamp type and wattage
Installations are to comply with local wiring rules
Luminaires can become hot. Use discretion in placement
Do not mount luminaires on combustible surfaces
Do not use power tools to fasten or assemble luminaire
All connections must be kept dry and free from dirt
Do not hose or preassure clean the luminaire
Luminaires and transformers to be installed by licensed
electrical contractors
To achieve IP66 rating, use round cable (size 5-10 mm) to
suit entry gland supplied with fixture
Luminaires to be used for intended purpose only
Keep luminaire free of soil, mulch and other loose debree
The luminaire should only be used complete with its
protective shield (cover)
Do not operate the luminaires with a missing
or damaged parts
Use only genuine Lumascape parts to replace damaged
or missing components
DANGER
ISOLATE LUMINAIRE FROM POWER
Failure to isolate power
supply before installation or
maintenance may result in
fire, serious injury, electric
shock, death and may
damage the luminaire.
WARNING IMPORTANT
SILICONE
Use silicone glaze to seal the four
screw holes and achieve IP66.
It is the installers responsibility
to achieve an adequate seal
against the mounting surface so that
no water can enter the luminaire
To achieve IP66 rating,
use round cable (size
5-10 mm) to suit entry gland
supplied with fixture

IN0084 - 27 June 2014
Copyright ©2014 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
WARNING - To reduce the risk of FIRE or INJURY:
1. Luminaires and transformers to be installed by licensed electrical contractors.
2. Luminaires to be used for intended purpose only.
3. Do not operate the luminaires with a missing or damaged parts.
4. Use only genuine Lumascape parts to replace damaged or missing components.
5. Refer to instructions for installation and operating requirements.
6. Ensure installation complies with local regulations
Voltage insulation test (megger) will permanently damage product and will void warranty.
SAVE THESE INSTRUCTIONS.
SAFETY INSTRUCTIONS
Questions?
Call [phone]
Email [email protected]
www.lumascape.com.au
MOUNTING TEMPLATE
cable entry
mounting point
fixture outline
mounting point
108 mm
Use scale to ensure mounting template is printed 1:1
100 20 30 40 50 mm
