Lumascape LS363 Groundmount Installation instructions manual

IMPORTANT INSTRUCTIONS
For Installation LS363
32
1
MODELS LS363 Groundmount
A
START
HERE
4
5D MR16 LAMPS5C MR16 LAMPS
Rotate gimbal to aim light at
target. Slide gimbal vertically
to minimise glare. Once
positioned tighten locking
screw using Allen Key
provided.
Adjust vertical and
rotational position
of gimbal
SLIDE GIMBAL
VERTICALLY
GIMBAL
GIMBAL
LOCKING
SCREW
ALLEN KEY
SUPPLIED
ROTATE GIMBAL
5E MR16 LAMPS
Aim the light at target by
rotating the angle adjust
screw, with the Allen Key
provided. The lamp has a
maximum adjust of 20 either
side of vertical.
o
Adjust angular
position of light
GIMBAL
ANGLE
ADJUST
SCREW
ALLEN KEY SUPPLIED
20o20o
40o
C737US - 2006_07_REV001
Further
information
over page
Site fixture in proximity to
cabling. Use discretion in
locating fixtures as glass
can become very hot and
may burn.
Locate Fixtures
140MM
(5.51IN)
80MM
(3.15IN)
160MM
(6.3IN)
Mount Bracket to Fixture
Mount bracket supplied to
fixture using the M10 dome
nuts and washers as shown
above.
DOME NUT
SPRING
WASHER
FLAT
WASHER
BRACKET
Mount fixture to secure
surface. Orientate fixture as
required and tighten nuts on
bracket.
Mount Fixture
10o
90o
60o
30o
BRACKET TOP VIEW
75MM (2.95IN)
2 X 8MM
12MM
Mount Junction Box, if
supplied, to the mounting
surface. Connect fixture to
supply cable according to
local wiring rules.
Connect Supply
Insert PL lamp into
lampholder mounted on
gear tray in bottom of fixture.
Insert reflector, locating
bottom into aluminium cup
around lampholder.
5A PL LAMPS
Insert Lamp
LAMP
REFLECTOR
Screw PAR38, or PAR30
lamp into lampholder
mounted on gear tray in
bottom of fixture. Ensure
the lamp bottoms out in
lampholder.
Insert Lamp
5A PAR LAMPS
LAMP
Remove Hood and louvre
from gimbal and insert
MR16 lamp into lampholder.
Replace hood and louvre.
Insert Lamp
GIMBAL
LAMP
HOOD/
LOUVRE
WARNING
DO NOT SHORTEN, INTERFERE OR DISCONNECT CABLE FROM FITTING. WARRANTY WILL BE VOID IF
CABLE ASSEMBLY IS TAMPERED WITH.
CAUTION - HOT BULBS. Keep Away From Curtains And Other Combustible Material.
L
U
R
CUS
SEE OTHER SIDE FOR RE-LAMPING
US Head Office
Telephone
Fax
1300 Industrial Rd., Unit #19
San Carlos, CA 94070
USA
1-(650)-595-LUMA(5862)
1-(650)-595-5820
Free Call
www.lumascape.com
(US & Canada)
1-866-695-LUMA(5862)
LUMASCAPE USA INC.
INC.
SURFACE MOUNT
SPLICE BOX
DISCONTINUED PRODUCT

IMPORTANT INSTRUCTIONS
B
For Installation LS363
5
Test to ensure fixture is
operational. Allow to burn
uncovered for 30 minutes to
allow any moisture in fixture
to evaporate.
Test Fixture
60
1545
30 MIN.
6
LID
Locate lid, complete
with any accessories,
on fixture aligning
screws with clinch nuts
in flange. Tighten
screws with Allen Key
provided.
Reseal Fixture
RE-LAMPING
Ensure fixture is isolated from mains
power. Unscrew lid using Allen Key
provided, or a 3mm Allen Key.
Remove any louvres or reflectors.
Replace lamp and Reseal Fixture.
Open / Re-lamp / Reseal
LID
Ensure fixture is
electrically isolated.
Unscrew lid using
a 3mm Allen key
(provided) and
remove.
Isolate and
Open Fixture
LAMP SOURCE CONVERSION INSTRUCTION
1
Remove any reflectors or louvres.
Unscrew/Pull lamp from lampholder
and remove.
Remove Lamp
2A
REFLECTOR
LAMP
HOOD/
LOUVRE
LAMP
Loosen gimbal locking screw
with 3mm Allen key, (provided).
Remove gimbal and place
beside fixture.
Remove Gimbal
2B MR16 LAMPS
GIMBAL
GIMBAL
LOCKING
SCREW
ALLEN KEY
SUPPLIED
GIMBAL
Unclip and remove
gear tray, gripping via
either the two finger
recesses or the
lampholder.
Remove Gear Tray
3GEAR TRAY 5
Install new gear tray by clipping into
fixture, aligning large clip on can with
large recess on gear tray as shown. Push
down gently untill clips spring over tray.
Install New Gear
4
GEAR TRAY
GEAR TRAY CLIPS
GIMBAL
Test and reseal
fixture according to
installations 4 to 6
on this sheet.
Test and Reseal
Fixture
LID
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS.
instructions pertaining to a risk of fire, or injury to persons
WARNING - To reduce the risk of FIRE or INJURY:
1. Turn Off and allow to cool before replacing lamp.
2. Lamp gets hot quickly! Contact only switch/plug when turning on.
3. Do not touch hot lens, guard, or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch the lamp at any time. Use a soft cloth. Oil from skin
may damage lamp.
MODELS LS363 Groundmount L
U
R
CUS
