Lumberjack XP Series Operation instructions

LMS185
Original Manual
185mm Mitre Saw
Read this manual before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

185mm Mitre Saw
Owner’s Manual & Safety Instructions
INDEX
1 - 3. Power Tool & Personal Safety
4. Symbols & Technical
5. Includes
6 . Assembly
7 - 9. Operation
10. Maintenance & Service
11. Declaration

General Power Tool Safety Warnings
:Read all safety warnings and instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
The term ″ power tool ″ in the warnings refers to your mains operated (corded)
power tools or battery operated (cordless) power tools.
1.Work Area Safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2.Electrical Safety
a. Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with grounded power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
b. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your
body is grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of a RCD reduces the risk of
electric shock.
01
Owner’s Manual & Safety Instructions
185mm Mitre Saw

:The term residual current device (RCD) may be replaced by the
term ground fault circuit interrupter (GFCI) or earth leakage circuit breaker
(ELCB).
3.Personal Safety
a. Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust related hazards.
4.Power Tool Use and Care
a. Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
02
Owner’s Manual & Safety Instructions
185mm Mitre Saw

power tools. Such preventive safety measures reduce the risk of starting the
power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons un-
familiar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts,
break- age of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be per-
formed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
5.Battery tool use and care
a. Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with an-
other battery pack.
b. Use power tools only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
c. When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects that can make
a connection from one terminal to another. Shorting the battery terminals together
may cause burns or a fire.
d. Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the battery may cause
irritation or burns.
e. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
f. Always push the gear selector and turn the operating mode selector switch
through to the stop. Otherwise, the machine can become damaged.
03
Owner’s Manual & Safety Instructions
185mm Mitre Saw

Service
Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
6. Symbols
a. Some of the following symbols may appear on this product. Study
these symbols and learn their meanings. Proper interpretation of these
symbols will allow for more efficient and safer operation of this product.
SYMBOL DESCRIPTION
Read the manual before set-up and/or use.
Do not dispose with house-hold waste.
Conforms to relevant safety standards.
04
Owner’s Manual & Safety Instructions
Technical Data:
185mm Mitre Saw
Voltage
No Load Speed
Saw Blade Size
Max Cutting Capacity
20V 30A
3600RPM
185 x 25.4mm
0x90 210mm, 45x90 105mm, 0x45 210mm,
45x45 105mm

05
Owner’s Manual & Safety Instructions
185mm Mitre Saw
1. Sliding Fence
2. Bevel Pointer
3. Mitre Pointer
4. Table Insert
5. Mitre Lock Release
6. Mitre Lock Clamp
7. Blade Guard
8. Laser Guide
9. Plunge Handle
10. Safety Switch
11. Side Extensions
12. Motor Body
13. Sliding Rails
Includes:

Owner’s Manual & Safety Instructions
06
185mm Mitre Saw
Assembly:
Bench Mounting
1. Place the saw onto a level surface.
2. Secure it to the workbench by using the four holes at the base of the saw.
Mounting the extending support plates
1. Attach the extending support plate into each end of the base.
2. Use the screws supplied to fix it in place.
Workpiece vice
To attach the workpiece vice at either side of the table on the rear fence:
1. Insert the rod at either side of the sliding guide.
2. Use the locking knob to select the correct height.
3. For fine height adjustments, turn the knob.

07
Owner’s Manual & Safety Instructions
185mm Mitre Saw
Operation:
Mitre angle adjustment
The mitre angle of the blade can be set between 0º and 45º at left and right
hand positions. It has a main scale of 0º, 15º, 30º and 45º, but can be
adjusted between small scales:
1. Lift the mitre locking trigger to unlock the mitre angle
2. Press the mitre latch while moving the turntable simultaneously
3. Place the blade into the desired angle.
4. Release the mitre latch, the blade should snap in position.
5. Place the locking trigger to its original position to secure it in
place.
90º (0º) mitre pointer adjustment
1. Place the table to the 0º positive stop.
2. Loosen the mitre pointer locking screw.
3. Adjust the pointer and re-tighten the screw.

Owner’s Manual & Safety Instructions
185mm Mitre Saw
08
Cutting depth adjustment
You can adjust the cutting depth for even and
repetitive shallow cuts:
1. Place the cutting head down to the desired
teeth blade depth.
2. While holding the upper arm in that position,
turn the stop knob until it touches the stop
plate.
3. Check the blade depth by moving the cutting
head front to back.
Bevel angle adjustment
The bevel angle can be set from 0º to 45º to the left:
1. Loosen the bevel locking knob.
2. Adjust the bevel angle according to the scale.
3. Tighten the locking knob to secure it in position.
1. Loosen the bevel locking knob and move the cutting head fully to the left.
2. Tighten the bevel locking knob.
3. Check whether the blade is 45º to the miter table with a combination
square.
45º bevel stop adjustment

Owner’s Manual & Safety Instructions
185mm Mitre Saw
09
Sliding bars locking knob
1. Tighten the locking knob to prevent
the sliding bars movement.
1. Open the spring clip.
2. Fit the dust bag over the neck of the dust extraction port.
3. Release the clip.
1. Pinch the spring clip.
2. Remove the bag from the dust extraction port.
3. Open the zipper on the underside of the dust bag.
4. Empty the waste into a container.
To empty the dust bag:
Dust extraction bag
Laser guide battery installation
1. Open the cover located on the switch handle.
2. Insert the two batteries.
3. Close the battery cover.

10
Owner’s Manual & Safety Instructions
Maintenance:
WARNING: Before any work on the machine itself, remove the baery
packfrom the drill.
1.Inspect bolts periodically. If the bolts loosen, ghten them
immediately, or will result in serious accident.
2.Inspect tool cords periodically. If damaged, have repaired at your
nearest Authorised Service Center.
3.Keep the vents clean. Clean all parts of the tool, clean dust
periodically. To prevent debris from entry.
4.All service MUST only be performed by Authorised Service Center.
ALWAYS use only accessories that are recommended for this tool.
5.Cleaning. Use clean cloths and mild soap to remove dirt, dust, etc.
Service:
1.In case ofguarantee repair or purchase ofreplacement parts, always
contact the qualied service center. Please supply them with the
appropriate service card and invoice.
2.It is outside the scope of guarantee when the tool has normal
wear and tear, has been overloaded or improper use of the tool.
185mm Mitre Saw

Owner’s Manual & Safety Instructions
CE DECLARATION OF CONFORMITY
TOOLSAVE
Unit C, Manders Ind. Est.,
Old Heath Road, Wolverhampton,
WV1 2RP.
Tel: [phone]
Declares that the 185MM MITRE SAW (LMS185)
Is in compliance with the regulations included in the
Directives:2006/42/EC
EC DECLARATION OF CONFORMITY
Certificate for EC-type examination delivered by Intertek Testing Services
Ltd.,Shanghai,ETL Semko Building No.86,1198 Qinzhou Road(North),Caohejing
Development Zone,Shanghai 200233,China. (Verification No.:150300747SHA-V1)
Person who declares: Bill Evans
13.04.2021
The
Director
11
185mm Mitre Saw

12
Owner’s Manual & Safety Instructions
185mm Mitre Saw

UNIT C
MANDERS INDUSTRIAL ESTATE,
OLD HEATH ROAD,
WOLVERHAMPTON
www.Lumberjacktools.co.uk
