Lumio InnovaPlas Aquarius Deck 5010 User manual

REV. 02/26/2020 PN: PG:1
2257 route 139
Drummondville, Québec
J2A 2G2
1 year on pool step.
1 year on hardware.
MANUFACTURER WARRANTY
WWW.INNOVAPLAS.COM
WARNING
Install the step on a flat surface.
Do not jump or dive from the step.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer’s instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
AQUARIUS DECK 5010
A
Contents of Aquarius box SKU # 5010
x2 x1
x2
x2
x3
x1
x2
SCREW BAG 140-0028
Contents riser kit box
x2
x1
2X
GUSSET
INSERT NUT
1) Insert the two gussets in the slots and slide them
toward the corners.
2) Assemble the two main modules with the six screws,
nuts and washers provided.
3) Snap the door between the top and bottom module
within the slots provided.
Required tools (not included)
Sand
5 lbs
Sand
(not included)
x6 x6 x6
(1 IN.)
(1 ¹⁄2 IN.)
(³⁄4 IN.)
x2
(³⁄4 IN.)
x17 x12
A B C D E F
SCREW BAG 140-0010
x6 x6 x6
A B C
Phillips #2 Phillips #3
7/16 wrench
Phillips bit
x2 x4
x2
(3/4 IN.)
x4
D

REV. 02/26/2020 PN: PG:2
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
AQUARIUS DECK 5010
B
E
C
D
1 year on pool step.
1 year on hardware.
MANUFACTURER WARRANTY
1) Snap the three post ends into the
step, making sure that the cylindrical
part is vertical and that the ends are
snapped properly in their respective
housings.
2) Snap the filler post end into the step
as shown.
3) Snap the two feet to the bottom of
the step.
FILLER
1) Fill the bag provided with sand.
The approximate weight should
be 5 lbs.
*SAND
1) Slide the two tie
wraps in place and
place the sand bags
into the riser.
2) Fasten the tie wraps.
Do not overtighten.
1) Insert the two step cups in the riser.*
2) Place the riser on the ground, install the step
on top of the riser and fasten with the four
screws and plastic screw caps provided.
3) Snap the screw caps covers in place.
FG
1) Insert the two posts into the post ends and
secure them in place with the screws provided
(as seen in step H).
2) Insert the deck support over the rear post.
3) Insert the handrail on the two posts and
secure in place.
4) Fasten the access panel with the screws
provided.
3
1
/
4
”
1/4”
align screws from
center of plate
1) Slowly submerge the
step into the pool. Make
sure you do not damage
the pool liner in the process.
2) Angle the whole step
so that it is entirely under
water. Purge all the air from
under the steps.
*Sand not included
x13
D
x2
E
D
4x
4x
* View step cups installation tips on YouTube:
https://www.youtube.com/watch?v=W5RH1VNxpu0

REV. 02/26/2020 PN: PG:3
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
AQUARIUS DECK 5010
HI
J
1 year on pool step.
1 year on hardware.
MANUFACTURER WARRANTY
2) Once the step is in the pool,
measure as illustrated.
3) Insert the short post into the
post end and screw together
with the screw provided.
4) Cut the short post based on
the measurement taken in step
#2. BE SURE TO CUT 3/4”
SHORTER THAN THE
MEASUREMENT TO ALLOW
INSTALLATION OF THE POST
COVER.
x3
MEASURE
3/4”
MEASURE
CUTTING
LINE
1) Once the step has been entirely submerged, put it in place, with the
deck supports resting on the deck.
1) Slide the second
deck support onto
the short post.
2) Affix the deck
supports to the deck
with the screws
supplied.
3) Install the post covers
on both the short post
and handrail assembly.
1) Pull the deck supports (already fixed to the deck)
upwards to create a spring effect on the step.
2) Fasten the supports to the two rear posts while
pushing the entire step downwards.
x4
D
D
D
F
F
x12
