Lumio INNOVAPLAS H2O WITH CLASSIC 6003 User manual

REV. 10/12/2015 PN: 110-107 PG:1
2257 route 139
Drummondville, Québec
J2A 2G2
1 year on pool ladder.
1 year on outside ladder.
1 year on hardware.
MANUFACTURER WARRANTY
WWW.INNOVAPLAS.COM
WARNING
Install the step on a flat surface.
Do not jump or dive from the step or ladder.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer’s instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
H2O WITH CLASSIC 6003
Sand
20 lbs
Sand
Contents of ladder box SKU # 7000
Contents of ladder box SKU # 6003
Security strap
x2
x2
x2
x2
x2
x2
105-012
105-005
x2 x2
115-014 (3/4 in.)
x18
115-018 (2 1/2 in.)
x2
125-035
(not included)
Required tools (not included)
A weather-resistant padlock is
recommended.
Maximum functional
width of 1/4 inch.
x4
x2
SCREW BAG 140-0010
115-014 (3/4 in.)
510-005
SCREW BAG 140-0058
Wet Side
Dry Side
A
1) Cut the two posts
included with the H20 to
29.25 inches long.
2) Insert the two posts into
the H2O ladder and fasten
them in place as shown
here with the screws
provided.
3) Slide the platform onto
the posts.
x4
115-014 (3/4 in.)
29.25''
x2

REV. 10/12/2015 PN: 110-107 PG:2
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
H2O WITH CLASSIC 6003
1 year on pool ladder.
1 year on outside ladder.
1 year on hardware.
MANUFACTURER WARRANTY
BC
D
1) Insert the four post
covers into their respective
locations on the handrails.
2) Insert the two handrails
over the two front posts
securing them in place with
the screws provided.
1) Fill the two bags provided with sand.
2) Insert the sand bags into the base
before submerging the step.
1) Slowly submerge the
step into the pool. Make
sure you do not damage
the pool liner in the
process.
x4
Sand
10 lb
Security strap
x2
2) Once the step is in the pool
secure the platform to the top
seat (see illustration) using
the two straps provided.
wet side
dry side
510-005
Sand
10 lb
115-018 (2 1/2 in.)
x2
OPTIONAL:
Once the pool step has been
completely assembled and secured
to the pool, attach the two screws
supplied through the platform to the
top seat of your pool to provided a
more rigid assembly.
115-014 (3/4 in.)
E
x2
115-014 (3/4 IN.)
align for 48''
& 52'' pools
align for 54’’
1) Trace a line on each post at 39 inches from the ground
for 48’’ and 52’’ pools. If you have a 54’’ pool, trace a line
at 40.5 inches from the ground.
2) Slide the pivot blocks onto the posts and line up with
the traced marks. Do NOT secure yet.
3) Slide the two posts through the platoform and handrails.
4) Secure the ladder base to the posts with the screws
provided.
F1) Secure the small handrails and platform to the posts
with the screws provided.
2) Secure the ladder to the
pivot blocks using the
bolts, washers and
nuts provided.
105-012
105-005
x2 x2
125-035
3) Secure the pivot blocks
(FIRST ASSEMBLED TO
THE LADDER) to the posts
with the screws provided.
Make sure the pivot blocks
are lined up with the marks
traced earlier.
115-014 (3/4 in.)
x16
x2
GSWING THE LADDER UP AND LOCK IN PLACE
WHEN THE POOL IS NOT IN USE TO PREVENT
DROWNING AND UNAUTHORIZED ENTRY.
WARNING
USE SLIDING LOCK
AS A GUIDE TO DRILL HOLE
IN LADDER IN UP POSITION
USE A 3/8’’ DRILL BIT
**PADLOCK REQUIRED**
