M-system M8XV2 User manual

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-5469 Rev.4 P. 1 / 4
INSTRUCTION MANUAL
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.
■PACKAGE INCLUDES:
Signal conditioner ...............................................................(1)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
The unit is programmable using the PC Configurator Soft-
ware. For detailed information on the PC configuration,
refer to the JXCON users manual. The JXCON PC Con-
figurator Software is downloadable at M-System’s web site:
http://www.m-system.co.jp.
POINTS OF CAUTION
■POWER INPUT RATING & OPERATIONAL RANGE
• Locate the power input rating marked on the product and
confirm its operational range as indicated below:
24V DC rating: 24V ±10%, approx. 50mA
(70mA for current output)
■GENERAL PRECAUTIONS
• Before you remove the unit or mount it, turn off the power
supply and input signal for safety.
■ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within 0 to 55°C (32
to 131°F) with relative humidity within 30 to 95% RH in
order to ensure adequate life span and operation.
• Be sure that the ventilation slits are not covered with ca-
bles, etc.
■WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
■AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
COMPONENT IDENTIFICATION
Specifications Mounting Screw
Body
INSTALLATION
Use Installation Base (model: M8BSx).
SIGNAL CONVERTER
(PC programmable) MODEL M8XV2

M8XV2
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-5469 Rev.4 P. 2 / 4
TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■EXTERNAL DIMENSIONS unit: mm (inch)
I/O PINS
17.5 (.69)
48 (1.89)
75 (2.95)
83 (3.27)
■CONNECTION DIAGRAM
+
–
Installation Base
OUTPUT 1
6
7
8
9
10
11
+
–
+
–
OUTPUT 2
1
2
A
B
POWER
+
–
INPUT
CONFIGURATOR JACK
CHECKING
1) Terminal wiring: Check that all cables are correctly con-
nected according to the connection diagram.
2) DIP switches: Check the input range selector and output
range selector setting.
3) Power input: Check the power input voltage.
4) Input: Check that the input signal is within 0 – 100% of
the full-scale.
5) Output: Check that the load resistance meets the de-
scribed specifications.
6) Status indicator LED: Check that it blinks in a regular
pattern.

M8XV2
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-5469 Rev.4 P. 3 / 4
CALIBRATION
This unit is calibrated at the factory to meet the ordered
specifications, therefore you usually do not need any cali-
bration.
For matching the signal to a receiving instrument or in case
of regular calibration, adjust the output as explained in the
following.
■ZERO/SPAN & UP/DOWN SWITCHES
Fine zero and span adjustments can be done with the ZERO/
SPAN Selector and UP/DOWN switches. Calibrated values
are stored in the non-volatile memory, which will not be lost
even when you turn off power supply to the unit.
The output 1 and output 2 can be independently adjustable.
Zero and span are respectively set to 0% and 100% at the
factory, and field calibration can be reset to ex-factory set-
ting if necessary.
Adjustable range: ±5%
Zero/Span Selector
ZERO: UP/DOWN switches usable for zero adjustment.
OFF: UP/DOWN switches unavailable.
SPAN: UP/DOWN switches usable for span adjustment.
UP/DOWN Switches
UP: Pressing UP increases adjusted values.
DOWN: Pressing DOWN decreases adjusted values.
■FRONT VIEW
UP Switch
Status Indicator LED
Configurator Jack
DOWN Switch
■BOTTOM VIEW
Zero/Span Selector
SZ
OFF
Z
S
Zero/Span Selector
MODE SW POSITION
SPAN S
OFF ■
ZERO Z
■HOW TO CALIBRATE THE ZERO & SPAN
Use a signal source and measuring instruments of sufficient
accuracy level. Turn the power supply on and warm up for
more than 10 minutes.
The output 1 and output 2 adjustments are linked except
for (2) and (6).
1) Apply 0% input.
2) Select the Output 1 Zero: Slide the Zero/Span Selector to
the position Z.
Select the Output 2 Zero: Slide the Zero/Span Selector to
the position Z while pressing UP switch.
3) Press UP or DOWN switch and adjust the output to 0%.
Incrementing speed will be doubled when you keep press-
ing a switch.
4) Put the Zero/Span Selector back to the position OFF.
5) Apply 100% input.
6) Select the Output 1 Span: Slide the Zero/Span Selector to
the position S.
Select the Output 2 Span: Slide the Zero/Span Selector to
the position S while pressing UP switch.
7) Press UP or DOWN switch and adjust the output to
100%. Incrementing speed will be doubled when you
keep pressing a switch.
8) Put the Zero/Span Selector back to the position OFF.
9) Check Zero and Span adjustments again with 0% and
100% input respectively.
10) If the output value is changed, repeat the above proce-
dure (1) – (9).
■HOW TO RESET
After you calibrated manually with these switches, you
can reset them to its ex-factory state by pressing both UP/
DOWN switches at once.

M8XV2
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-5469 Rev.4 P. 4 / 4
I/O RANGE MODIFICATION
Configurator Software is used to change input ranges over
the described range of the selected suffix code. For chang-
ing out of this range, set the Input Range Selectors before
software adjustment.
For changing output ranges, set the Output Range Selector
and then select by Configurator Software.
■SIDE VIEW
Input Range Selector
Output Range Selector
V
V
L
I
I
H
I
I
H
V
L
V
Input Range Selector
INPUT RANGE TOP SW BOTTOM SW
Z1: 0 – 50 mA DC I L
S1: -1 – +1 V DC V L
S2: -10 – +10 V DC V H
Output Range Selector
OUTPUT RANGE SW POSITION
V2Z1: -10 – +10 V / 0 – 20 mA DC I
V2V2: -10 – +10 V / -10 – +10 V DC V
STATUS INDICATOR LED
The unit is provided with a status indicator LED which
blinks in different patterns indicating various status of its
CPU. When it is functioning within normal parameters, the
LED blinks in a regular pattern of ON and OFF.
The following figure indicates typical patterns.
LED PATTERNSSTATUS
Normal
Programming Mode
Out. 1 Calibration Mode
Out. 2 Calibration Mode
200 ms
ON OFF
MAINTENANCE
Regular calibration procedure is explained below:
■CALIBRATION
Warm up the unit for at least 10 minutes. Apply 0%, 25%,
50%, 75% and 100% input signal. Check that the output
signal for the respective input signal remains within accu-
racy described in the data sheet. When the output is out of
tolerance, recalibrate the unit according to the “CALIBRA-
TION” explained earlier.
LIGHTNING SURGE PROTECTION
M-System offers a series of lightning surge protector for
protection against induced lightning surges. Please contact
M-System to choose appropriate models.
