Chapter 1. Safety Precautions
■Before using the product
To use the product safely and effectively, please read the contents of this manual thoroughly before use. Please
keep to the safety precaution, for it is to prevent accidents and potential danger from occurring.
Safety precaution is classified into ‘Warning’ and ‘Caution’ and their meanings are as follows. Also the indicated
illustrations on the product and in the manual have the following meanings.
Violating the instruction may result in serious personal injury or death.
Violating the instruction may result in slight personal injury or product damage.
Be cautious, for danger may be present.
Be cautious, for there is a possibility of an electric shock.
■General Precautions
Do not press the screen with a hard or sharp object (awl, screwdriver, pen) with too strong a force.
It may cause malfunction of touch due to damage of the front sheet.
Do not use or store in an environment with high vibration.
Do not allow foreign objects such as water, liquids, or metal powders to enter the product. This may cause
breakage or electric shock.
Do not allow foreign objects such as water, liquids, or metal powders to enter into the front(screen)
protective sheet. The screen may be invisible or may cause a malfunction of the touch.
Use the radio or mobile phone at least 30cm away from the main unit.
Two or fewer bright spots may appear on the LCD screen, and certain areas may appear brighter, but this is
not a defect in LCD characteristics.
Do not store or operate in direct sunlight. Direct sunlight can change the properties of the LCD.
■Design Precautions
Install protection circuit on the outside of Products to protect the entire control system when external power
supply or Products have problems.
As the malfunction & incorrect result of Products could damage the stability of the entire systems
and human body, you must install damage preventing interlock circuit such as emergency stop,
Protective circuits, positioning upper and lower limit switch and interlock for forward/reverse
operation.
When computer or other controllers communicate and exchange data with products or change operation
mode of products, set up protective sequence program in PC or Controller for protecting system from
communication error.
The output signal or communication lines should be separated from the power line or high tension wire.
They should be installed 100mm (3.94 Inch) or more from each other.
■Wiring Precautions
Be sure the wiring is done correctly by checking the product’s rated voltage and the terminal layout.
Incorrect wiring could result in fire, damage or malfunctions.
Tighten the terminal screw with the specified torque. If the screws of terminal are loose, It could result
in short circuit, fire, malfunctions. FG Terminal must be used a dedicated ground. Not doing so could

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
4 / 20
result in malfunctions.
a. Grounding should be the Class 3 grounding. The cable for grounding should be more than 4㎟.
b. grounding point be closed to the products and make short the distance to the ground cable if possible.
Please see below.
■Installation Precautions
Do not install the location which exceeds allowed temperature. Product can be damaged or shorten the life.
Especially Install environment as below should be avoided.
Do not Install product to the place which the ambient temperature is out of limits, from 0℃to 50℃or on the
surface of control board which high pressure equipment is installed.
Do not install to the place where strong shock or vibration continuously have impacted on product.
The space between back of product and back of control board must be more than 100mm for maintenance
and ventilation.
In order to improve water retention and ventilation, the space between the back of the main body and
the console box should be 100mm or more, and install the cooling fan when installed in an enclosed
space.
■Disposal Precautions
When you dispose of product and battery, please treat it as industrial waste. It can create poisonous substances
or explosion.
■Cell Type Battery Specifications
Mounted on mainboard Model MS920SE Battery is not replaced by the user.
Especially, it can be confused with similar battery and there is a danger of explosion. Do not change the battery.
If you have a problem with the battery, please contact our Customer Support Center for replacement and
inspection.
Item
Content
Battery Voltage
DC 3V
Battery Model
MS920SE(Rechargeable lithium / No need for replacement)
Battery lifetime
Permanent(In case of ambient temperature 25℃)
Battery Discharge
Last about 7 days After turn it off
*Depending on the model specifications are subject to change.
■All field-wiring connections to this unit shall be from Limited Voltage / Limited Current,
below 24 Vdc isolated secondary source with an output fuse, or Class 2.

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
5 / 20
Chapter 2. Overview
2.1 Introduction of Products
This industrial HMI touch panel is an industrial control device required in industrial field. It is a device based
on RS-232C and RS-422/485, Ethernet which is used for the basic purpose of communication with another
device(PLC).
2.2 Package Contents
The components of the product are as follows.
Before using the product, please check that all of the following components are included.
Item
Figure
Quantity
Process Module
And
Manual
1
Clamp
4
Power Connector
1
Accessories
(Sold separate)
USB Memory
USB Cable
SD Card
Front Protect Sheet
User Options

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
6 / 20
2.3 Explanation of Model Name
TOPRE
□□
□□
□
□
□□
Series
Display Size
Option
Resolution
Power
Ethernet Port
03 : 3.5”
00 : Standard
Q : QVGA (320*240)
D: DC
NE : No Ethernet
04 : 4.3”
XX : Reserved
V : VGA (640*480)
Blank : Ethernet support
07 : 7.0”
S : SVGA (800*600)
X : XGA (1024*768)
W : WQVGA (480*272)
WVGA (800*480)
*Product Wide model resolution
- TOPRE0400WD: WQVGA
- TOPRE0700WD: WVGA

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
7 / 20
Chapter 3. General Specifications
3.1 Power Specifications
Power
Input Voltage
DC24V
Input Voltage Range
DC 20~28V
Consumption Power
TOPRE0300QD
Under 12W
TOPRE0400WD
Under 12W
TOPRE0700WD
Under 12W
Voltage endurance
DC 24V, Within 10 ㎳
Insulation Resistance
500V DC, 10 ㏁
3.2 Memory Specifications
Screen Memory
64MB
Backup Memory
512KB: System buffer (10K Word),
Including Alarm/Log/Recipe
Backup Period
Permanent
Real Time Clock
Built in(by Battery)
3.3 Environment Specifications
Operation Temperature (℃)
-10 ~ +50
Storage Temperature (℃)
-20 ~ +60
Operation Humidity (%RH)
0 ~ 90 (No dew)
Atmosphere
No corrosive gas
Vibration Endurance
Amplitude: 10≤F＜25 ㎐(2G) X,Y,Z each direction(for 30 minutes)
Noise Immunity
1000Vp-p(Pulse width 1 ㎲)
Static Electricity Discharge
Connective discharge from EN61000-4-2: ±4 ㎸
Shock Endurance
10G X,Y,Z each direction(for 3 times)
Surge Voltage
500V(Line-Line)
Ground Connection
Class 3(Under 100Ω)
Protection Classification
Conform to IP65
3.4 Structure Specifications
TOPRE0300QD
TOPRE0400WD
TOPRE0700WD
Weight
0.28
0.28
0.62
Cooling System
Natural Air Circulation
Case Material
PC(Flameless)

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
8 / 20
Chapter 4. Part Names and General Specifications
4.1 TOPRE0300QD / TOPRE0400WD
4.1.1 External Dimension
Model
F1(mm)
F2(mm)
S1 (mm)
S2 (mm)
R1(mm)
R2(mm)
TOPRE0300QD
TOPRE0400WD
128.6
102.6
38
32
118.7
92.7
4.1.2 Front Part Names and Specifications

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
9 / 20
No.
Part
Description
①
LCD
TFT 16M Color LCD
②
Touch Panel
Analog Touch
③
Front Sheet
Front Cover Sheet for Damp Proof and Dust Proof
④
Operation LED
Product operation status LED
4.1.3 Rear Part Names and Specifications
No.
Part
Form
Description
①
Rubber Packing
-
Silicone Gasket for Impact Buffering and IP Securing
for Wall Mounting
②
COM Connector
(COM1/2)
DSUB9 1EA
COM1: RS-232C, COM2: RS422/485 Serial Comm.
with PLC (Switchable the Comm. Via Software)
③
ETHERNET Connector
RJ45
10BASE-T/100BASE-TX, Auto-MDIX
④
USB Connector
MINI USB Type AB
USB Connectors for Storage Options
⑤
SD Card Slot
SD Card Slot
SD Card Insert Connector
⑥
SD Card LED
LED
SD Card operation status LED
⑦
Power Input Terminal
TB 5mm 3P
Power Supply of Main Unit(DC 24V)
⑧
Reset Switch
Tact Switch
System Reset Switch
⑨
Built-in cover
-
Cover for manufacturer maintenance

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
10 / 20
4.2 TOPRE0700WD
4.2.1 External Dimension
Model
F1(mm)
F2(mm)
S1 (mm)
S2 (mm)
R1(mm)
R2(mm)
TOPRE0700WD
206.5
136.5
44
36.7
194..3
124.3
4.2.2 Front Part Names and Specifications

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
11 / 20
No.
Part
Description
①
LCD
TFT 16M Color LCD
②
Touch Panel
Analog Touch
③
Front Sheet
Front Cover Sheet for Damp Proof and Dust Proof
④
USB Port
USB Download/Upload Port
⑤
Operation LED
Product operation status LED
4.2.3 Rear Part Names and Specifications
No.
Part
Form
Description
①
Rubber Packing
-
Silicone Gasket for Impact Buffering and IP Securing
for Wall Mounting
②
COM Connector
(COM1/2)
DSUB9 1EA
COM1: RS-232C, COM2: RS422/485 Serial Comm.
with PLC (Switchable the Comm. Via Software)
③
ETHERNET Connector
RJ45
10BASE-T/100BASE-TX, Auto-MDIX
④
USB Connector
MINI USB Type AB
USB Connectors for Storage Options
⑤
SD Card Slot
SD Card Slot
SD Card Insert Connector
⑥
SD Card LED
LED
SD Card operation status LED
⑦
Power Input Terminal
TB 5mm 3P
Power Supply of Main Unit(DC 24V)
⑧
Reset Switch
Tact Switch
System Reset Switch
⑨
Built-in cover
-
Cover for manufacturer maintenance

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
12 / 20
Chapter 5. External Device Interface
In order for the main unit to communicate with an external device, it is necessary to connect the two devices
by referring to the following.
5.1 Serial Communication Specifications
5.1.1 RS-232C
Items
Contents
Protocol
Full Duplex
Synch
Asynchronous
Communication Distance
About 15m
Type of Connection
1:1
Control Code
ASCII Code or HEXA Code
Transmission Speed
2400,4800,9600,19200,38400,57600,76800,
115200 bps
Data Type
Data Bit
7, 8 bit
Parity Bit
NONE, ODD, EVEN Parity
Stop Bit
1, 2 bit
Modular Jack
DSUB 9pin
5.1.2 RS-422/485
Items
Contents
Protocol
Full Duplex/Half Duplex
Synch
Asynchronous
Communication Distance
About 500m
Type of Connection
1:N (N ≤31)
Control Code
ASCII Code or HEXA Code
Transmission Speed
2400,4800,9600,19200,38400,57600,76800,
115200 bps
Data Type
Data Bit
7, 8 bit
Parity Bit
NONE, ODD, EVEN Parity
Stop Bit
1, 2 bit
Modular Jack
DSUB 9pin
5.1.3 COM Connector pin number and Signal name
Type
Pin No.
Signal
Direction
Meaning
9Pin Female
1
RDA(RD+)
Input
COM2: RS-422/485 Receive Data (+)
2
RD(RxD)
Input
COM1: RS-232C Receive Data
3
SD(TxD)
Output
COM1: RS-232C Send Data
4
RDB(RD-)
Input
COM2: RS-422/485 Receive Data (-)
5
SG
-
Signal Ground
6
SDA(SD+)
Output
COM2: RS-422/485 Send Data(-)
7
-
-
N/A
8
VCC GND
GND
Power Ground
9
SDB(SD-)
Output
COM2: RS-422/485 Receive Data (-)

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
13 / 20
Be sure to connect the RD and SD to the RS-232C communication line by crossing each other with a
Twisted Pair Cable. Please connect SG directly.
RS-422/485 communication line must use RDA and RDB as Twisted Pair Cable, SDA and SDB
as Twisted Pair Cable.
Do not use shield wire of communication line as signal ground. It may cause communication failure.
5.2 Ethernet Communication Specifications
5.2.1 Ethernet
Item
Specification
Ethernet Method
IEEE802.3i/IEEE802.3u, 10BaseT / 100BaseT
Speed
10M/100Mbps
Communication Method
Base Band
Switching Method
AUTO MDIX
Maximum Segment Length
100m(Hub between product)
Communication Cable
UTP(Unshielded Twisted Pair)
Modular Jack
RJ-45
5.2.2 RJ–45 Pin Layout
Type
Pin No.
Color
Signal
1
Orange/White
TD+
2
Orange
TD-
3
Green/White
RD+
4
Blue
Not Available in 10BaseT
5
Blue/White
Not Available in 10BaseT
6
Green
RD-
7
Brown/White
Not Available in 10BaseT
8
Brown
Not Available in 10BaseT
When HUB is using, Straight cable should be used.
Ex) Straight Cable Wiring: Connect 1:1 according to the wiring diagram above.
In case of do not using HUB,
Do not use HUB, when it is connected directly, Cross Cable should be used.
Ex) Cross Cable Wiring: In the above wiring diagram, TD+ and RD+ are changed,
and TD- and RD- are exchanged.
5.3 USB Communication Specifications
5.3.1 USB Host (*Only TOPRE0700WD)
Type
Item
Specification
USB Interface
EHCI/OHCI Specification Version 1.0, USB2.0/1.1 compatible
Communication Method
Control/Bulk
Transfer Speed
480Mb/s
Support Device
USB Storage (FAT16/FAT32 File Format Available)
Connector Type
Type A(1ch)

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
14 / 20
5.3.2 USB OTG
Type
Item
Specification
USB Interface
USB 2.0
Communication Method
Interrupt/Bulk/Isochronous
Transfer Speed
480Mb/s
Supporting OS
Windows 98SE/2000/XP/VISTA/7/10(32/64bit)
Cable Length
1.5M(recommended to use M2I's Option Cable)
Connect Type
MINI USB AB, Female
Connect Method
Side Connected via USB terminal
Chapter 6. Installation
6.1 Installation Requirements
(1) For the performance, ventilation and safe use of the equipment, keep the distance between the back of
the main unit and each wall of the container at least 100mm and install the cooling fan when installed
in an enclosed space.
(2) It should be installed within -10 ~ 50°C and 10~80% relative-humidity, otherwise the screen may be
changed or cause malfunction and damage.
(3) Be sure that heat from surrounding equipment does not cause product to exceed its standard
operating temperature.
(4) When you don’t see within 30°, you may not see clearly.
When installing the product in a slanted position, The product screen should not incline more than 30°.
(5) In order to minimize external mechanical hazards, please control the mechanical hazards of the
surrounding environment.
IP65
IP2X
-10 ~ 50°C, 10~80%
-10 ~ 50°C, 10~80%

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
15 / 20
6.2 Installation Procedure
In order to install this product, please follow the following procedure.
(1) Panel Cut-out
Make a panel cut which product is mounted and insert the product to the panel form the front side.
The Size of Panel Cut
Making the Panel Cut (Mounting Size) per each TOPRE Series as below Table, Before Installation.
Model
A (mm)
B (mm)
T (mm)
TOPRE0300QD
121
95
1-5
TOPRE0400WD
121
95
TOPRE0700WD
197
127
(2) Fixing
Install clamps with this product should be installed as follows to maintain the IP performance of the device.
a. Insert the clamp into the slot of the product.

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
16 / 20
b. Screw the unit into the panel cut with a screwdriver.
If the screw is over tightened, it may cause the front deformation,
thus resulting the touch sensor can’t work properly Tighten the screws
to a torque of 0.2N.m.
Chapter 7. Wiring
7.1 Power Wiring
(1) The Power cable should have the following specification.
Power Cable Specification
0.75~2.5mm2(18~12AWG)
F.G Cable Specification
Over 4mm2(11AWG)
Conductor Type
Simple or Standard Wire
Bolt tightening force
≥0.2N.m.
Conductor Length
Temperature rating of the
field installed conductors
65℃Only
(2) The Power terminal should have the following specification.
Caution: The use of the Pin Terminal when installing the power supply and ground terminal is
important for maintaining the performance of the device. Failure to install power and ground using the
same Pin Terminal as below may cause explosion due to spark due to abnormal cable loss.
Therefore, please be sure to familiarize yourself with how to use Pin Terminal below.
B
L
F
E
D
d
1.8~2.0
22~18
12~14
5
3.3~3.8
2~2.5

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
17 / 20
(3) Wiring of power is as follows.
7.2 Ground Wiring
(1) The product has enough anti-noise measure, so except that there are many noises.
Specially, the ground is not needed. When doing ground, please refer to the followings.
(2) The ground should be the exclusive ground.
The ground should be type Class 3 ground (ground resistor is less than 100Ω).
(3) When not doing the exclusive ground, do common ground like figure B).
(4) Use the cable more than 4 mm2. Put the point of the ground near product and shorten Ground line.
Chapter 8. Maintenance
8.1 Cleaning the Display
When the surface or frame of the display become dirty, spray the cleaning solution onto a soft cloth and wipe
the device. Do not spray the cleaning solution directly onto the device.
8.2 Periodic Check Points
Check the followings periodically for best condition of the device
(1) Environment
a. Is the operating temperature within the allowable range (-10°C~50°C)?
b. Is the operating humidity within the allowable range (10%~80%RH)?
c. Is the Surrounding pollution no corrosive gas?
(2) Power
Is the input voltage within the change range (-15%~+10%)?
A) Exclusive ground
B) Common ground
C) Common ground
Class 3 ground
Class 3 ground

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
18 / 20
(3) Related Items
a. Check the guarantee duration of LCD Backlight by eye.
b. Check the touch pad there is no damage, scratch or pollution by eye.
8.3 Problems with the Device
a. If there is a problem during operation, stop using it and contact the A/S department of M2I Corporation,
which is indicated on the product label.
b. Only the authorized worker from M2I Corporation can check and repair problems related to malfunction
of the machine.
c. If the problem cannot be solved at the installation site, the equipment can be collected and moved to
M2I Corporation.
d. The manufacturer, M2I Corporation, is not responsible for damage or malfunction of the equipment
caused by the use conditions of the user beyond the installation and use standards described in the
manual.
8.4 Setting System Recovery Mode
a. If the system fails to boot normally due to a problem during operation, the built-in recovery function
can be used to maintain the factory default state. Please note that the built-in project will be deleted
when using the recovery mode.
b. After opening the rear cover, you can adjust the setting switch.
Keep the "Normal" state when booting normally. If the system is recovering, turn off the power and
set it to "Factory Reset".
c. When the recovery is completed, the buzzer sounds, then turn off the power and reset to
"Normal" state.
8.4.1 TOPRE0300QD / TOPRE0400WD

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
19 / 20
8.4.2 TOPRE0700WD
Chapter 9. Products and Warning Label Location
1. TOPRE0300QD / TOPRE0400WD
2. TOPRE0700WD
Product Label
Product Label

TOPRE Series Hardware Manual
M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: [phone], Fax: [phone], www.m2i.co.kr
20 / 20
Chapter 10. Products Label
Manufacture (AS): M2I Corporation
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea
Tel: [phone] www.m2i.co.kr
Product Name: Industrial HMI Touch Panel
Model Name: TOPRE□□ □□ □□
Operating Temp: -10 ℃≤Ta ≤+50 ℃
Power Specifications: TOPRE03/04/07…24Vdc, 12W
KC Certificate No.:
Inside Cell: Model Name MS920SE(Rechargeable lithium Battery/No need for replacement)
Serial Number:
Copyright: M2I corporation 2020.11 www.m2i.co.kr
