Magicard Avalon 100 User manual

colour ID Card Printer
HoloPatch™ works with
HoloKote™ to produce a
highly-visible gold seal on the
card, printed using special
card stock.
www.ultramagicard.com
HoloKote™ is an anti-
copying watermark across
the entire card surface, that
becomes visible when the
card is viewed at an angle.
With the Avalon, a standard
design is printed.
option option
Proven Magicard security and
reliability in a great value package.
If you want to print great quality cards,
again and again and again, then the
Magicard Avalon is for you. It’s easy to
setup and use, with all Windows drivers
supplied, and will provide you with reliable
printing for years to come.
The Magicard Avalon features our patented
HoloKote™ and HoloPatch™ card security
which protects your cards against
unauthorised copying.
100 card capacity input hopper and 50
card capacity output hopper for batch
printing. Competitively priced high-quality
colour and monochrome ribbons.
Security |Reliability |Value
Mag stripe encoding
Avalon 105 includes built-in
magstripe encoder.
Edge-to-edge full
colour printing
High quality 300dpi
image, printed right to the
edge of the card in only
35 seconds.

Ultra Electronics Card Systems Inc.
North American Sales & Support Center
6711 - 176th Avenue NE, Redmond WA 98052
Tel: [phone] Fax: [phone]
email: [email protected]
Ultra Electronics Card Systems
Waverley House, Hampshire Road, Granby Estate
Weymouth, Dorset DT4 9XD, United Kingdom
Tel: [phone] Fax: [phone]
email: [email protected]
www.ultramagicard.com
Consumables:
Magicard Secure colour ID Card Printers
colour ID Card Printer
Drop in ribbon
Simple drop-in ribbon comes in 250 shot colour.,
350 shot colour or 1000 shot monochrome (black,
red, blue, green, gold, silver or white) types.
Magicard Rio, Tango, Prima, Alto, Avalon, Opera, Sicura UltraCoverplus, HoloKote and UltraSecure are trademarks of Ultra Electronics Limited. Windows ‘98 ME, NT4, 2000 and XP are trademarks of Microsoft Corporation.The information contained in this
document reflects the current state of design and we reserve the right to change the specification without notice or obligation
Specifications: Avalon 100 ID Card Printer (Part No. M9006-644)
Print Speed Prints a full colour edge-to-edge image in 35 seconds, and a monochrome image in 6 seconds.
Card security The user can choose whether to print a HoloKote™ anti-copying watermark across entire face of card.
When used with HoloPatch™ cards one area of the HoloKote™ watermark is highlighted as a high visibility
security seal.
Warranty Two years limited warranty.
Data Interface to PC USB rev1.1 (USB 2.0 compatible).
Software drivers Windows 98, ME, 2000, XP (all supplied with printer).
Dyefilm types AV1: Full colour, resin black, & overcoat (YMCKO) 250 shots per roll (Part No. M9006-566).
LC1: YMCKO 5 panel dye film 350 shots per roll (Part No. M9005-751).
LC3 : Monochrome resin black 1000 shots per roll (Part No. M9005-753).
Range of colour ribbons (red, blue, green, gold, silver or white) 1000 shots per roll.
Card types Prints on all standard PVC ISO CR80 sized cards. HoloPatch™ cards available.
Card thickness 0.38mm to 1.6mm (0.015” to 0.063”).
Card capacity 100 cards feed hopper, 50 cards output stacker.
Printhead 300dpi field replaceable.
Power Source Internal power supply 90-265V 47-63Hz autoranging.
Dimensions 445mm L x 200mm W x 220mm H (7.5ins L x 7.9ins W x 8.7ins H).
Weight 7.2kg (15.8lbs).
Colour Metallic Silver/Purple.
Operating environment Sheltered Office environment 10°C to 30°C (50°F to 85°F).
Avalon 105 ID Card Printer with HiCo Magstripe Encoder (Part No. M9006-654)
Print Speed Prints a full colour, edge-to-edge image and magnetically encodes and verifies HiCo magnetic stripe
in around 40 seconds.
Card stock types HiCo magnetic stripe PVC ISO CR80 sized cards. HoloPatch™ magnetic stripe cards available.
Security |Reliability |Value
