MAGNASPHERE HSS-L2S-000 Series User manual

MAGNASPHERE HSS INSTALLATION INSTRUCTIONS: All Models of (L2S & L2D) 000-Series
CAUTION: MAGNASPHERE MAGNET MODULES AND ANTI-REMOVAL MAGNETS ARE EXTREMELY POWERFUL: TAKE PRECAUTIONS TO AVOID THE MAGNETIC ATTRACTION OF
SHARP TOOLS AND TO AVOID INJURY FROM THE PINCHING FORCE BETWEEN THE MAGNET AND FERROUS METALS OR OTHER MAGNETS.
Required Tools and Components
Provided by Manufacturer (per module set)
1 HSS switch module
1 HSS magnet module
7 switch & magnet module self-tapping screws (#10-32 x 2")
2 self-tapping screws (#6, 1" long)
1 HSS switch module template
1 HSS magnet module template
1 anti-rotational threaded stud (set screw)
2 1/16" plastic spacer plates
1 Removal-Tamper magnet
1 Magnet Spacer
2 Removal-Tamper caps
(P/N: SP062)
Provided by Installer
Power drill
Drills bits: #35,#21, 3/16"
Phillips screwdriver or a Phillips bit for use in the drill/bit-driver
Rule (or any linear measuring instrument)
A center punch (& hammer) for more accurate hole locations may be used
A pilot drill bit for screws (3/32" or smaller) may be used
Additional 1/16” SPACERS (10/ BAG – MAGNASPHERE P/N SP062)
Installation Plan: Face-mounted HSS for an
inswinging (ingress) door
Installation Plan: Top-surface-mounted HSS for an
out-swinging (egress) door
SWITCH
MODULE
MAGNET
MODULE
DOOR
SWING
DOOR FRAME
DOOR
UP TO
3/16"
GAP*
SWITCH
MODULE
MAGNET
MODULE
DOOR
SWING
DOOR FRAME
DOOR
UP TO
3/16"
GAP*
Plan to mount the switch module to the door frame, close to the
door/frame gap and without door-swing interference. The
magnet module must be mounted directly below the switch.
Spacers may be used to attain sufficient alignment.
Recommended placement for the set is 8 inches from the latch
side of the door, at the top. The operating gap must not
exceed 3/16". Provided templates may assist locating holes.
*A gap up to 1/8" is required for compliance with UL634
Level 2, C634 high security standard.
Plan to mount the switch module to the door stop, close to the
door but without door-closure interference. The magnet module
must be mounted directly below the switch. Spacers may be
used to attain sufficient alignment. Recommended placement
for the set is 8 inches from the latch side of the door, at the top.
The operating gap must not exceed 3/16". Provided templates
may assist locating holes. *A gap up to 1/8" is required for
compliance with UL634 Level 2, C634 high security
standard.
SWITCH MODULE
#10 SCREW
ANTI-ROTATIONAL
THREADED STUD
MAGNET
SPACER REMOVAL
TAMPER
MAGNET
REMOVAL
TAMPER
CAP
#6 SCREW
#6 SCREW
#10 SCREWS
#6 SCREW
#10 SCREWS
#10 SCREWS
1/16" SPACER
1/16" SPACER
MAGNET MODULE
Specifications
Max Current: 0.25 A Resistive
Max Voltage: 30 VDC
Max Power: .25 W Resistive
Suitable for outdoor use.
The Magnasphere HSS Level 2
series is intended to be connected
to a UL Listed compatible control
panel for US applications and a
ULC Listed compatible control
panel for Canadian applications.
Test the Magnet-Tamper
circuit here with a powerful
magnet
Remove to test
the Pry Tamper
circuit
Supervise
d
Common
Magnet
Tamper
Pry
Tamper
TAMPER
CIRCUT
GRN
YEL
BLU
Closed
Common
ALARM WHT
SC1
MT
PT
Closed
Common
ALARM ORN
SC2
PUR
BLK
Closed
Open
Common
Supervise
d
Common
Magnet
Tamper
Pry
Tamper
ALARM
TAMPER
CIRCUT
WHT
RED
BLK
GRN
YEL
BLU
SC
SC
MT
PT
L2S Series
L2D Series
Attention: modules à aimants Magnasphere et anti-enlèvement aimants sont très puissants: prendre des précautions pour éviter l'attraction magnétique d'outils tranchants
et à éviter les blessures de la force de pincement entre l'aimant et les métaux ferreux ou d'autres aimants.

A clearance hole for the anti-rotational screw must be drilled into the door frame before mounting the switch module; its position is
given on the templates. For anti-tamper purposes, the switch module has two sites for an anti-rotational threaded stud; only one
site will be used depending on which installation plan is chosen. Thread the screw into hole until about 1/4" of the screw remains
outside the module.
(continued) ingress door instructions: (continued) egress door instructions:
SITE OF ANTI-
ROTATIONAL SCREW FOR
OUTSWINGING DOOR
INSTALLATIONS ONLY
SITE OF ANTI-
ROTATIONAL SCREW
FOR INSWINGING DOOR
INSTALLATIONS ONLY
REVERSE SIDE OF THE SWITCH MODULE
DOOR
SWING
^SWITCH MODULE PERIMETER ^
MAGNET MODULE
SWITCH MODULE FACE MOUNT
DOOR
SWING
Mark & pilot-drill all hole locations. The single clearance hole
for the anti-rotational screw must now be drilled to 3/16" or
7/32" diameter. Drill the 3 mounting hole locations for the #10
screw (#21 bit). Drill the Removal-Tamper screw location
for the #6 screw (#35 bit). Hold the switch module in position:
Drive each screw in until seated, securing the device.
CAUTION: Magnasphere's magnet module and anti-
removal magnet are extremely powerful: Take precautions
to avoid the magnetic attraction between the magnet and
ferrous metals (or other magnets). Align the magnet
module directly below the switch module. Determine whether
spacers are needed to achieve mounted alignment of the
modules. Hold the magnet module and any necessary spacers
in position. Drill the 4 hole locations for #10 screws (#21 bit).
Drive each screw in location until each has seated, securing
the device.
Insert the Removal-Tamper magnet and then the Removal-
Tamper plug into the 3/8" hole at the face of the switch module.
NOTE: The Magnet Spacer is not used in this installation.
Check the gap between modules. The mechanical installation
of the set is complete.
#6 screw
MAGNASPHERE 23777 Stone Ridge Dr. Suite 160 Waukesha, WI 53188 tel [phone] fax [phone] www.magnasphere.com
Mark & pilot-drill all hole locations. The single clearance hole
for the anti-rotational screw must now be drilled to 3/16" or
7/32" diameter. Drill the 2 mounting hole locations for the #6
screw (#35 bit). Hold the switch module in position: Drive each
screw in until seated, securing the device.
CAUTION: Magnasphere's magnet module and anti-
removal magnet are extremely powerful: Take precautions
to avoid the magnetic attraction between the magnet and
ferrous metals (or other magnets). Align the magnet
module directly below the switch module. Determine whether
spacers are needed to achieve mounted alignment of the
modules. Hold the magnet module and any necessary spacers
in position. Drill the 4 hole locations for #10 screws (#21 bit).
Drive each screw in location until each has seated, securing
the device.
Insert the Magnet Spacer, the Removal-Tamper magnet, and
then the Removal-Tamper plug into the 3/8" hole at the face of
the switch module. Check the gap between modules. The
mechanical installation of the set is complete.
1-2014 L2X-0XX-INST REV2
Patents #5673021, #6603378 & #8228191, #8314698
Patents Pending
Additional mounting hardware, resistor configurations, cable lengths, and other variants are available.
