Magnum XP User manual

S
tampa Novaprint - Tel.[phone] - www.novaprint.it - COD. 10161094600
USER MANUAL
(ORIGINAL INSTRUCTIONS)
MAGNUM XP

page 2
page 5
page 6
page 7
page 8
page 10
page 13
page 14
page 15
page 16
Contents
Description of appliance
Accessories
Safety notices
Preliminary operations
Commissioning
Use of accessories
Accessory Care
Technical data
Troubleshooting
Regulations
Guarantee
page 17
1
Read carefully these instructions before using the machine.
NOTE
page 17
Maintenance & Care

1. Description of appliance
2
6
DET
H2O
5
NOTE
1
2
3
4
5

3
LEGEND
1. Transport handle
2. Accessories box
3.Control panel
4. Pressure Regulator Knob
5. Hose Port
CONTROL PANEL
**3.
A. Boiler on (button)
B. Detergent/hot water on (button)
D.No water
E. Working pressure
F. Working temperature
G. Boiler heating
I. Hot water/Detergent function
**5.
L. Monoblock socket
M. Steam control knob
LEGEND
IMPORTANT! Use only filtered or quality tap water for filling operations.
Distilled water is not suitable for this type of appliance.
LM
**5
**3
IGD
A BF E
NOTE

4
2. Description of accessories
30
32
32a
(1 foro)
22
28
24
29
23
26
27
31
34
35
36
36a
22b
22a
36b
Accessories
22 Rectangular brush
22a Accessory for carpets
22b Cloth
23 Triangular brush
24 Accessory for unblocking
washbasins/sinks
26 Extension wands
27 Extension wands
28 Window-cleaning accessory
29 Medium-sized brush
30 Dress-fit W=265 mm
31 Funnel
32 Dress-fit W=90 mm
32a (1 hole)
34 Round brush for dress-fit
(1 hole)
35 Triangular brush for dress-fit
(3 holes)
36 Brush for dress-fit
(1 hole) (nylon)
36a Brush for dress-fit
(1 hole) (steel)
36b Brush for dress-fit
(1 hole) (brass)
PLEASE NOTE:some items above are optional and not included in
the standard package. Please see product photo presenting all
standard accessories included.
(1 hole)
17
14. Information for users
According to Directives 2011/65/EU and 2012/19/EU on the reduced use
ofhazardoussubstancesinelectricalandelectronicequipment,andtheir
disposal, the barred bin symbol means that at the end of its useful life the
product must be disposed of separately from ordinary waste.
Theusermustthereforetakesuchequipmenttopropercollectioncentres
for electrical and electronic waste, or take it back to the dealer when he
buyssomeequivalentequipment,intheratioof1:1.
A suitably differentiated waste collection, followed by recycling, treatment
and environmentally friendly disposal helps prevent negative effects on health and
the environment and favors the recycling of materials.
Anyunauthorizedequipmentdisposalbytheuserwillbesubjecttosanctionsasprovi-
ded for by current local regulations.
15. Guarantee
The manufacturer guarantees the product in regard to manufacturing defects.
Please visit www.myvaporclean.com/warranty upon receipt of this product to view
the warranty in full and suggestions to maintain your warranty in good standing.

3. Important safety instructions
READ AND FOLLOW ALL INSTRUCTIONS
When using the Cleaning System, always use basic precaution, including the following:
WARNING! –Toreducetheriskoffire,electricalshockorinjury:
1. Do not leave appliance unattended. Unplug the Cleaning System from outlet
when not in use, or before servicing. Do not allow to be used as a toy. Close attention is
necessary when the system is being used around children. Never allow children to use
or play with the system.
3. Use only as described in the manual. Only use original manufacturer attachments.
4. Do not use the Cleaning System with a damaged cord or plug or without ground
plug. If the Cleaning System has been dropped, damaged, left outdoors, or
submersed in water, return the System to the SERVICE .
5. Do not pull or carry the Cleaning System by the cord.
6. Do not use the cord as a handle. Never close a door on the cord. Never pull it around
edges or corners. Never run appliances over the cord. Keep cord away from heated
surfaces.
7. Do not unplug by pulling the cord. To unplug, grasp the plug, not the cord.
8. Do not handle the plug with wet hands.
9. Donotallowobjectstogetintotheoutputnozzles.DonottrytooperatetheClea-
ning System with any of the openings blocked. K
10. Do Not Freeze
11. Extension cords are not recommended and may cause damage.
12. Use extra care when cleaning around water source (swimming pools, spas,
toilets, etc.)
13. Do not continue use if there is any indication of a problem with the machine.
Contact the service center for troubleshooting or advice.
14. Never point the steam toward humans or animals.
15. Turn off all controls before unplugging the Vapor System.
16.DonotfilltheCleaningSystemwithanythingbutcleanquality tapwater. or filtered

17. To reduce the risk of electric shock – use indoors only
18. Always empty boiler and containers if stored for more than 14 days
19. Connect to a properly grounded outlet only. See Grounding Instructions
20. Do Not leave on while not in use for extended periods of time.
WARNING – This hose contains electric wires. To reduce risk of electric shock do not
use or repair a damaged hose.
5
16
13. Troubleshooting
PROBLEM
The appliance does not start up.
After the boiler has been turned on,
the no water icon on the control pa-
nel starts to blink and the appliance
emits a sound signal.
Not emitting steam while
heated
The flexible hose or accessories
smell.
During normal operating conditions
the low water alarm is activated
(icon “D” on).
CAUSE
The power cord has not been cor-
rectly plugged into the power sup-
ply outlet.
The water level in the tank is low.
Possible cause - steam
regulator
Presence of dirt, mould or incrusta-
tions in the hose or accessories.
Air is in the pump circuit.
SOLUTION
Plug the power cord plug into the
power supply outlet correctly.
Fill the tank with water and start up
the appliance once more.
Confirm that the regulator is not
in the off position.
Empty the bin and rinse the tubes
and accessories with clean water.
Set the boiler switch A to the OFF
position, discharge steam for a few
seconds and then set switch A back
to the ON position.

5. Filling the water and hot water
detergent tanks
Identify the two external tanks located behind the appliance.
FILLING TANK WATER
Openthecapandfillthewatertankwithfiltered water if
possible(itholdsabout1,32gal). The hardness of the water used must be less than
30 French degrees. If the main water supply is particularly hard, we recommend using a
mixture of 50% tap water and 50%
distilled water. 6
SAVE THESE INSTRUCTIONS
WARNING! Your Vapor Cleaning System MUST BE PLUGGED INTO A GROUNDED
OUTLET,orelectricalshockcanoccur.Checkwithaqualiedelectricianifyoudonot
know if the outlet is grounded.
DonotmodifytheplugprovidedwiththeVaporSystem,ifitwillnottoutlet,thanhave
aproperoutletinstalledbyaqualiedelectrician.
NOTE:
In Canada, the use of a temporary adaptor is not permitted by the Canadian Electrical
Code.
THIS UNIT MUST BE GROUNDED
If the unit should malfunction or break down, grounding provides a path of least resi-
stanceofelectrical.Currenttoreducetheriskofelectricalshock.Theunitisequipped
with a cord having an equipment grounding conductor and grounding plug. The plug
must be inserted into an appropriate outlet that is properly grounded in accordance with
all local codes and ordinaces.
This appliance is designed for professional use as a steam generator in accordance with
the descriptions and directions of this handbook.
Please read these directions carefully and make sure the handbook is available at all
times. These directions may well be useful at any given time.
4. Correct use of the product
Grounding instructions
WARNING!
This appliance is for use on a nominal 120-V circuit and has a
grounding attachment plug thet looks like the plug illustrated
insketchAingure20.Makesurethattheapplianceiscon-
nectedtoanoutlethavingthesamecongurationastheplug.
No adaptor should be used with this appliance.
15
- Dimensions (mm) 17,3x23x35 in
440 x 585 x 900 mm (La x Lu x h)
- Weight 44lbs 29 Kg
- Voltage 120V 60Hz
- Maximum power 1800W
- Maximum boiler heating
elements power 1000 + 700W
- Stainless steel boiler Aisi 304
- Steam pressure 145psi 1000kPa (10 bar)
- Steam temperature 354°F 179°C
- Capacity of
detergent/hot water tank 1,32gal 5 l
- Capacity of detergent tank 1,32gal 5 l
- Power cord 20ft 6 m
- Flexible hose 10,8 ft 4 m
- Extra low voltage for safety
(on handle) 5 V
12. Technical data
The water tank and the detergent/hot water tank can be readily emptied.
To empty the tanks, proceed as follows:
- Unscrew the caps (5) of the tanks, and empty the tanks. When the tanks have been
emptied, re-position the closure caps.
11. Emptying the tanks

•Putthetanksbackinplaceandreconnectthetwowaterintakettings.Securethetwo
clips.
FILLING HOT WATER/DETERGENT
For detergent function:
•Usethefunneltollthetank(1,32gal)withproperlydiluteddetergent.
For hot water function:
•Usethefunneltollthetank(1,32gal)withproperlynormaltapwater.
• Close the tank caps.
.IMPORTANT! Fill the tanks with filtered tap water only. Distilled water is not


suitable for this type of machine. Do not use well, softened or water that is high in
mineral content. Quality filtered water will keep your machine clear of buildup and
potential avoidable service issues.
PLEASE NOTE: Make sure that the two tanks, respectively, contain the right contents.
Tank H2O mustalways be filledwith water andnever with thedetergent. Use ofthe
detergent in the water tank may seriously damage the product.
Afterfillingthedetergenttankwiththefunnel,rinsethefunnelunderrunningwaterbefor
e usingittofillthewatertank.
Hot water/Detergent/Water Connection tubes
• Never use foaming or acid-based cleaning agents. They may damage the internal
components of the machine.
• Never use muriatic acid- or ammonia-based cleaning agents or cleaning agents based
on products classed as irritants. Use with steam increases the volatility of such substan-
ces, which are harmful if inhaled.
• No guarantee cover is provided for breakdowns arising out of use of detergents not
conforming to the above indications. 7
Detergent connection tubes
Yellow IN
Red OUT
Detergent (optional)
Water connection tubes
Green IN
Blue OUT
DET H2O
14

GENERAL MAINTENANCE
Prior to maintenance be sure the machine is off and unplugged from any outlet.
Regular descaling is necessary to keep your machine running at optimum
efficiency and avoiding unnecessary service of your machine and replacement
of parts due to mineral buildup in your machine.
Start the process by making sure that your machine is cold and the water inside
is also.
Empty the boiler by unscrewing the drain plug located under the machine.
Drain the existing water into a container and replace the drain plug.
Fill the water tank approximately half way with 50% water and 50% white vinegar
or decalcifier - The recommended product is Durgol, made for espresso
machines.
Turn on your machine and fill the boiler as normal, when the pumping stops and
the boiler is full. Turn off the machine, do not heat the decalcifier. Let sit
overnight. Empty any remaining solution in the water tank and refill with clean
water.
Next, drain your boiler into a container again. Refit the drain plug and pump the
clear water into the boiler and shut off before it begins the heating process and
drain the clean water.
Repeat until the water is clear of descaler and any deposits in your boiler.
Fill with clean water, and heat and go!
Onusingthemachineforthefirsttime after thisoperation,dischargesomeof the
steam onto a rag. Discharge repeatedly so that no descaling solution remains in the
steam circuit.
The machine is now ready for use once more!

6. FUNCTION
•Openthebuilt-inpowersocketap.Insertthemoul-
ded plug by pressing (press the button until the cou-
pling mechanism clicks). Check that the moulded plug
isrmlypositioned.
• To disconnect the moulded plug from the appliance,
press the button R, and pull the unit out to remove it
from the appliance.
• Connect the plug to a suitable power outlet.
Steam function
Press button A to turn on the boiler. The
display will turn on to indicate the presence
of voltage. The heating element icon (L) on
the display will blink.
Then (in about 5-6 minutes) it will switch to
non-blinking mode.
The appliance is now ready to generate
steam. At this stage, the display also ena-
bles checking of boiler temperature and
pressure, which shall gradually rise during
heating.
Press steam switch on the control
handle to enable the function. Press trigger
P to dispense steam.
Use control knob (M) to adjust steam ow.
PLEASENOTE:Donotdispensesteamificon(L)isblinkingonturningonfortherst
time. Wait until the icon has switched to no-blinking mode and until the system has sta-
bilised, thus enabling optimal performance.
For further directions, see Chapter 9 USE OF ACCESSORIES. Some drops of water
mayformonrstuse,duetoimperfectthermalstabilisationwithinthesleeve.Aimthe
rststeamjettowardapieceofclothuntilthejetbecomesuniform.
Steam-hot water/detergent function
Press button A to turn on the boiler.
The display will light up to indicate that there is power.
Thelight(E)onthedisplaywillstartashing and then become steady (5-6 minutes);
atthispointthemachineisreadytogeneratesteamandthesystemisstabilized,thus
enabling optimal performance.
IMPORTANT:donotdischargesteamiflightEisashing.
• Press detergent/hot water switch on the control handle. Icon (N) on the display will
light up steady.
The“hotwatermodule”ow-throughcanbeadjusted,bypressingthebuttonBinthree
steps.
This is indicated by LO-ME-HI.
Press trigger (P) to dispense steam mixed with detergent/hot water.
To disable the detergent function, switch off . Display icon (N) will switch off.
8
T1 Steam button
T2 Detergent button
P Steam dispensing trigger
LEGEND
• Before all maintenance operations, make sure that the power cord is not con-
nected to the main power supply.
•After use of the brushes, to prevent undue deformation, allow the bristles to cool in
their normal position.
•Periodically check the state of repair of the moulded plug seals (cap.6). If necessary,
replace with the spare seals. Periodically check the state of repair of the connection
seals of the extension wands and handle.
Usejustadampclothtocleantheexterioroftheappliance.Donotusesolventsorcle-a
ning agents that may harm the plastic surface.
10. General maintenance
13
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functio-
nality of the appliance. Te connections on the extension pipes and the safety handle can
be sprayed with a suitable lubricant or silicone spray as required. This will make it easier
to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the
extension pipes must be checked regularly for damage. The O-rings will last longer if they
are coated regularly with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for da-
mage:
Pos.(1): O-rings on the steam spout
Check the O-rings on the connector for da-
mage:
Pos(2): O-rings on the brass spout
Pos. (2)
Pos. (3)
Pos. (1)
Check the O-rings on all extension pipes for
damage:
Pos.(3): O-rings on the steam spout
Checking O-rings on the extension pipes

9
Water shortage tank
A lack of water in the tank H2Oisindicatedbylowwatericon(D)ashingonthe
controlpanelandbyasimultaneousacousticsignal.Torestartwork,llthetankas
described in the section “5”.
Water shortage hot water/det. module
Visually check the water inside the tank DET .Whenthelevelislowllagain.

Afteruse,rewindthecordonthecordreelfixturesbeforestoringtheMagnum
appliance away.
7. Refilling water and hot water/detergent
8. Cord reel
12
OVEN CLEANING WITH THE ROUND BRUSH WITH BRASS BRISTLES
Please note! Disconnect oven from power supply before cleaning. Please follow the
instructions below for optimal results for ovens. Make sure the oven has cooled entirely.
Dissolve the dirt and incrustations by aiming the steam jet at the part to be cleaned.
Wait a few seconds so that the dirt has time to soften or dissolve before removal with
the brush. Do not apply excessive force when applying the bristles to the oven. Finish
cleaning with a damp cloth.
35. Small triangular brush (use only with one-hole nozzle)
Usethisbrushtocleancornersorrebates.Attachtheone-holedress-ttotheextension
wandandthenattachthebrushtothenozzle.Setthesteambuttontomediumpressure
forcooktops,falseceilings,kitchenandbathroomtaps,dishwashers,breglassbathtubs
and glass shower cubicle doors.Anatural solvent may be used if the surface to be clea-
ned is particularly dirty. Steam increases the solvent’s cleaning capacity.

10
9. Use of accessories
26-27. EXTENSION WANDS
Two rapid-assembly tubes are provided to obtain the length desired. Thermal insulation
rules out the risk of burns. Maximum length: 95 in.
These accessories, used together with the exible hose, enable oor cleaning. Used
together with the brushes and other accessories, they enable cleaning of surfaces which
are hard to reach due to height etc., as well as wardrobes, doors, stairways and so forth.
Please note: since these accessories may heat up after a few minutes’ use, wait for a
few minutes before disconnecting them.
22-22a-22b Rectangular brush
Thisbrushissuitableforoors,parquetooringorwoodensurfaces,carpetsanddoor-
mats.
Tocleandelicateooring,usethebrushwiththeclothprovidedorwitharag.Attachthe
cloth or rag to the brush with the practical clamps.
For cleaning carpets and doormats, attach the accessory with bristles so that the surface
andbrescanbecleanedwithoutunduewearandtear.Makesurethesteamjetisweak.
Then clean with brush wrapped in a cloth.
For satisfactory results in cases of tough stains or stains left by detergents used in the
past, clean repeatedly.
When cleaning once more, repeat the procedure with a dry cloth on the brush.
Cleaning walls and ceilings
Ifrequired,connecttheextensionwandandattachthebrushwithbristlesanddrycloth.
Tousetheoorbrushonchallengingsurfaces,removethebristlescoverandusethe
openside(g.1).Releasethelockingxturesbytappinggently(g.2andg.3)and
removethebristlescovercompletely(g.4).
1 2
3 4
11
Tousethebristlescoverforcarpetcleaning,positionthisaccessoryontheoorbrush
(g.5).Presssothattheaccessoryslidesneatlyinthegrooves(g.6)untilitreaches
thelockingxtures(g.7).Tocompletetheprocedure,taplightly(g.8)untilthebristles
ofthecoverarealignedwiththebrush(g.9).
23. Triangular brush
Uses of the triangular brush are the same as for the rectangular brush. Use the triangular
brush if use of the rectangular brush is inconvenient.
32a. Jet Nozzle(1 hole)
These accessories can be used on their own or mounted on brushes 34, 35 and 36.
They are used for removing dirt and grease from:
-jointsonworktops,orinjoints,groovesorslits
- glass surfaces or wall-mounted range hoods
-steelandglazedceramicsinks
- washbasins, baths, bidets, toilets, showers, taps
- doors, windows and stairways
28. Window cleaner
This accessory is suitable for use on windows or delicate surfaces such as bathrooms
tiles, shower cubicle doors, etc.
34. Small round brush
Attachthesmallroundbrush(34)byplacingontheextremityofthenozzleandpressing.
This small brush (34) is perfect for surfaces of a limited area. All the brushes remove
mould,grease,incrustationsandtoughdirtetc.andareperfectfortoughcleaningjobs
(the brushes are provided with nylon, stainless steel or brass bristles for perfect results
andspeciccleaningtasks).Useforcooktops,refrigeratordoormouldingsandthemore
challenging,inaccessiblepoints,aswellasbathrooms,toilets,showerxturegrooves,
bird cages etc.
5 6 7
8 9

10
9. Use of accessories
26-27. EXTENSION WANDS
Two rapid-assembly tubes are provided to obtain the length desired. Thermal insulation
rules out the risk of burns. Maximum length: 95 in.
These accessories, used together with the exible hose, enable oor cleaning. Used
together with the brushes and other accessories, they enable cleaning of surfaces which
are hard to reach due to height etc., as well as wardrobes, doors, stairways and so forth.
Please note: since these accessories may heat up after a few minutes’ use, wait for a
few minutes before disconnecting them.
22-22a-22b Rectangular brush
Thisbrushissuitableforoors,parquetooringorwoodensurfaces,carpetsanddoor-
mats.
Tocleandelicateooring,usethebrushwiththeclothprovidedorwitharag.Attachthe
cloth or rag to the brush with the practical clamps.
For cleaning carpets and doormats, attach the accessory with bristles so that the surface
andbrescanbecleanedwithoutunduewearandtear.Makesurethesteamjetisweak.
Then clean with brush wrapped in a cloth.
For satisfactory results in cases of tough stains or stains left by detergents used in the
past, clean repeatedly.
When cleaning once more, repeat the procedure with a dry cloth on the brush.
Cleaning walls and ceilings
Ifrequired,connecttheextensionwandandattachthebrushwithbristlesanddrycloth.
Tousetheoorbrushonchallengingsurfaces,removethebristlescoverandusethe
openside(g.1).Releasethelockingxturesbytappinggently(g.2andg.3)and
removethebristlescovercompletely(g.4).
1 2
3 4
11
Tousethebristlescoverforcarpetcleaning,positionthisaccessoryontheoorbrush
(g.5).Presssothattheaccessoryslidesneatlyinthegrooves(g.6)untilitreaches
thelockingxtures(g.7).Tocompletetheprocedure,taplightly(g.8)untilthebristles
ofthecoverarealignedwiththebrush(g.9).
23. Triangular brush
Uses of the triangular brush are the same as for the rectangular brush. Use the triangular
brush if use of the rectangular brush is inconvenient.
32a. Jet Nozzle(1 hole)
These accessories can be used on their own or mounted on brushes 34, 35 and 36.
They are used for removing dirt and grease from:
-jointsonworktops,orinjoints,groovesorslits
- glass surfaces or wall-mounted range hoods
-steelandglazedceramicsinks
- washbasins, baths, bidets, toilets, showers, taps
- doors, windows and stairways
28. Window cleaner
This accessory is suitable for use on windows or delicate surfaces such as bathrooms
tiles, shower cubicle doors, etc.
34. Small round brush
Attachthesmallroundbrush(34)byplacingontheextremityofthenozzleandpressing.
This small brush (34) is perfect for surfaces of a limited area. All the brushes remove
mould,grease,incrustationsandtoughdirtetc.andareperfectfortoughcleaningjobs
(the brushes are provided with nylon, stainless steel or brass bristles for perfect results
andspeciccleaningtasks).Useforcooktops,refrigeratordoormouldingsandthemore
challenging,inaccessiblepoints,aswellasbathrooms,toilets,showerxturegrooves,
bird cages etc.
5 6 7
8 9

9
Water shortage tank
A lack of water in the tank H2Oisindicatedbylowwatericon(D)ashingonthe
controlpanelandbyasimultaneousacousticsignal.Torestartwork,llthetankas
described in the section “5”.
Water shortage hot water/det. module
Visually check the water inside the tank DET .Whenthelevelislowllagain.

Afteruse,rewindthecordonthecordreelfixturesbeforestoringtheMagnum
appliance away.
7. Refilling water and hot water/detergent
8. Cord reel
12
OVEN CLEANING WITH THE ROUND BRUSH WITH BRASS BRISTLES
Please note! Disconnect oven from power supply before cleaning. Please follow the
instructions below for optimal results for ovens. Make sure the oven has cooled entirely.
Dissolve the dirt and incrustations by aiming the steam jet at the part to be cleaned.
Wait a few seconds so that the dirt has time to soften or dissolve before removal with
the brush. Do not apply excessive force when applying the bristles to the oven. Finish
cleaning with a damp cloth.
35. Small triangular brush (use only with one-hole nozzle)
Usethisbrushtocleancornersorrebates.Attachtheone-holedress-ttotheextension
wandandthenattachthebrushtothenozzle.Setthesteambuttontomediumpressure
forcooktops,falseceilings,kitchenandbathroomtaps,dishwashers,breglassbathtubs
and glass shower cubicle doors.Anatural solvent may be used if the surface to be clea-
ned is particularly dirty. Steam increases the solvent’s cleaning capacity.

6. FUNCTION
•Openthebuilt-inpowersocketap.Insertthemoul-
ded plug by pressing (press the button until the cou-
pling mechanism clicks). Check that the moulded plug
isrmlypositioned.
• To disconnect the moulded plug from the appliance,
press the button R, and pull the unit out to remove it
from the appliance.
• Connect the plug to a suitable power outlet.
Steam function
Press button A to turn on the boiler. The
display will turn on to indicate the presence
of voltage. The heating element icon (L) on
the display will blink.
Then (in about 5-6 minutes) it will switch to
non-blinking mode.
The appliance is now ready to generate
steam. At this stage, the display also ena-
bles checking of boiler temperature and
pressure, which shall gradually rise during
heating.
Press steam switch on the control
handle to enable the function. Press trigger
P to dispense steam.
Use control knob (M) to adjust steam ow.
PLEASENOTE:Donotdispensesteamificon(L)isblinkingonturningonfortherst
time. Wait until the icon has switched to no-blinking mode and until the system has sta-
bilised, thus enabling optimal performance.
For further directions, see Chapter 9 USE OF ACCESSORIES. Some drops of water
mayformonrstuse,duetoimperfectthermalstabilisationwithinthesleeve.Aimthe
rststeamjettowardapieceofclothuntilthejetbecomesuniform.
Steam-hot water/detergent function
Press button A to turn on the boiler.
The display will light up to indicate that there is power.
Thelight(E)onthedisplaywillstartashing and then become steady (5-6 minutes);
atthispointthemachineisreadytogeneratesteamandthesystemisstabilized,thus
enabling optimal performance.
IMPORTANT:donotdischargesteamiflightEisashing.
• Press detergent/hot water switch on the control handle. Icon (N) on the display will
light up steady.
The“hotwatermodule”ow-throughcanbeadjusted,bypressingthebuttonBinthree
steps.
This is indicated by LO-ME-HI.
Press trigger (P) to dispense steam mixed with detergent/hot water.
To disable the detergent function, switch off . Display icon (N) will switch off.
8
T1 Steam button
T2 Detergent button
P Steam dispensing trigger
LEGEND
• Before all maintenance operations, make sure that the power cord is not con-
nected to the main power supply.
•After use of the brushes, to prevent undue deformation, allow the bristles to cool in
their normal position.
•Periodically check the state of repair of the moulded plug seals (cap.6). If necessary,
replace with the spare seals. Periodically check the state of repair of the connection
seals of the extension wands and handle.
Usejustadampclothtocleantheexterioroftheappliance.Donotusesolventsorcle-a
ning agents that may harm the plastic surface.
10. General maintenance
13
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functio-
nality of the appliance. Te connections on the extension pipes and the safety handle can
be sprayed with a suitable lubricant or silicone spray as required. This will make it easier
to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the
extension pipes must be checked regularly for damage. The O-rings will last longer if they
are coated regularly with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for da-
mage:
Pos.(1): O-rings on the steam spout
Check the O-rings on the connector for da-
mage:
Pos(2): O-rings on the brass spout
Pos. (2)
Pos. (3)
Pos. (1)
Check the O-rings on all extension pipes for
damage:
Pos.(3): O-rings on the steam spout
Checking O-rings on the extension pipes

•Putthetanksbackinplaceandreconnectthetwowaterintakettings.Securethetwo
clips.
FILLING HOT WATER/DETERGENT
For detergent function:
•Usethefunneltollthetank(1,32gal)withproperlydiluteddetergent.
For hot water function:
•Usethefunneltollthetank(1,32gal)withproperlynormaltapwater.
• Close the tank caps.
.IMPORTANT! Fill the tanks with filtered tap water only. Distilled water is not


suitable for this type of machine. Do not use well, softened or water that is high in
mineral content. Quality filtered water will keep your machine clear of buildup and
potential avoidable service issues.
PLEASE NOTE: Make sure that the two tanks, respectively, contain the right contents.
Tank H2O mustalways be filledwith water andnever with thedetergent. Use ofthe
detergent in the water tank may seriously damage the product.
Afterfillingthedetergenttankwiththefunnel,rinsethefunnelunderrunningwaterbefor
e usingittofillthewatertank.
Hot water/Detergent/Water Connection tubes
• Never use foaming or acid-based cleaning agents. They may damage the internal
components of the machine.
• Never use muriatic acid- or ammonia-based cleaning agents or cleaning agents based
on products classed as irritants. Use with steam increases the volatility of such substan-
ces, which are harmful if inhaled.
• No guarantee cover is provided for breakdowns arising out of use of detergents not
conforming to the above indications. 7
Detergent connection tubes
Yellow IN
Red OUT
Detergent (optional)
Water connection tubes
Green IN
Blue OUT
DET H2O
14

GENERAL MAINTENANCE
Prior to maintenance be sure the machine is off and unplugged from any outlet.
Regular descaling is necessary to keep your machine running at optimum
efficiency and avoiding unnecessary service of your machine and replacement
of parts due to mineral buildup in your machine.
Start the process by making sure that your machine is cold and the water inside
is also.
Empty the boiler by unscrewing the drain plug located under the machine.
Drain the existing water into a container and replace the drain plug.
Fill the water tank approximately half way with 50% water and 50% white vinegar
or decalcifier - The recommended product is Durgol, made for espresso
machines.
Turn on your machine and fill the boiler as normal, when the pumping stops and
the boiler is full. Turn off the machine, do not heat the decalcifier. Let sit
overnight. Empty any remaining solution in the water tank and refill with clean
water.
Next, drain your boiler into a container again. Refit the drain plug and pump the
clear water into the boiler and shut off before it begins the heating process and
drain the clean water.
Repeat until the water is clear of descaler and any deposits in your boiler.
Fill with clean water, and heat and go!
Onusingthemachineforthefirsttime after thisoperation,dischargesomeof the
steam onto a rag. Discharge repeatedly so that no descaling solution remains in the
steam circuit.
The machine is now ready for use once more!

5. Filling the water and hot water
detergent tanks
Identify the two external tanks located behind the appliance.
FILLING TANK WATER
Openthecapandfillthewatertankwithfiltered water if
possible(itholdsabout1,32gal). The hardness of the water used must be less than
30 French degrees. If the main water supply is particularly hard, we recommend using a
mixture of 50% tap water and 50%
distilled water. 6
SAVE THESE INSTRUCTIONS
WARNING! Your Vapor Cleaning System MUST BE PLUGGED INTO A GROUNDED
OUTLET,orelectricalshockcanoccur.Checkwithaqualiedelectricianifyoudonot
know if the outlet is grounded.
DonotmodifytheplugprovidedwiththeVaporSystem,ifitwillnottoutlet,thanhave
aproperoutletinstalledbyaqualiedelectrician.
NOTE:
In Canada, the use of a temporary adaptor is not permitted by the Canadian Electrical
Code.
THIS UNIT MUST BE GROUNDED
If the unit should malfunction or break down, grounding provides a path of least resi-
stanceofelectrical.Currenttoreducetheriskofelectricalshock.Theunitisequipped
with a cord having an equipment grounding conductor and grounding plug. The plug
must be inserted into an appropriate outlet that is properly grounded in accordance with
all local codes and ordinaces.
This appliance is designed for professional use as a steam generator in accordance with
the descriptions and directions of this handbook.
Please read these directions carefully and make sure the handbook is available at all
times. These directions may well be useful at any given time.
4. Correct use of the product
Grounding instructions
WARNING!
This appliance is for use on a nominal 120-V circuit and has a
grounding attachment plug thet looks like the plug illustrated
insketchAingure20.Makesurethattheapplianceiscon-
nectedtoanoutlethavingthesamecongurationastheplug.
No adaptor should be used with this appliance.
15
- Dimensions (mm) 17,3x23x35 in
440 x 585 x 900 mm (La x Lu x h)
- Weight 44lbs 29 Kg
- Voltage 120V 60Hz
- Maximum power 1800W
- Maximum boiler heating
elements power 1000 + 700W
- Stainless steel boiler Aisi 304
- Steam pressure 145psi 1000kPa (10 bar)
- Steam temperature 354°F 179°C
- Capacity of
detergent/hot water tank 1,32gal 5 l
- Capacity of detergent tank 1,32gal 5 l
- Power cord 20ft 6 m
- Flexible hose 10,8 ft 4 m
- Extra low voltage for safety
(on handle) 5 V
12. Technical data
The water tank and the detergent/hot water tank can be readily emptied.
To empty the tanks, proceed as follows:
- Unscrew the caps (5) of the tanks, and empty the tanks. When the tanks have been
emptied, re-position the closure caps.
11. Emptying the tanks

3. Important safety instructions
READ AND FOLLOW ALL INSTRUCTIONS
When using the Cleaning System, always use basic precaution, including the following:
WARNING! –Toreducetheriskoffire,electricalshockorinjury:
1. Do not leave appliance unattended. Unplug the Cleaning System from outlet
when not in use, or before servicing. Do not allow to be used as a toy. Close attention is
necessary when the system is being used around children. Never allow children to use
or play with the system.
3. Use only as described in the manual. Only use original manufacturer attachments.
4. Do not use the Cleaning System with a damaged cord or plug or without ground
plug. If the Cleaning System has been dropped, damaged, left outdoors, or
submersed in water, return the System to the SERVICE .
5. Do not pull or carry the Cleaning System by the cord.
6. Do not use the cord as a handle. Never close a door on the cord. Never pull it around
edges or corners. Never run appliances over the cord. Keep cord away from heated
surfaces.
7. Do not unplug by pulling the cord. To unplug, grasp the plug, not the cord.
8. Do not handle the plug with wet hands.
9. Donotallowobjectstogetintotheoutputnozzles.DonottrytooperatetheClea-
ning System with any of the openings blocked. K
10. Do Not Freeze
11. Extension cords are not recommended and may cause damage.
12. Use extra care when cleaning around water source (swimming pools, spas,
toilets, etc.)
13. Do not continue use if there is any indication of a problem with the machine.
Contact the service center for troubleshooting or advice.
14. Never point the steam toward humans or animals.
15. Turn off all controls before unplugging the Vapor System.
16.DonotfilltheCleaningSystemwithanythingbutcleanquality tapwater. or filtered

17. To reduce the risk of electric shock – use indoors only
18. Always empty boiler and containers if stored for more than 14 days
19. Connect to a properly grounded outlet only. See Grounding Instructions
20. Do Not leave on while not in use for extended periods of time.
WARNING – This hose contains electric wires. To reduce risk of electric shock do not
use or repair a damaged hose.
5
16
13. Troubleshooting
PROBLEM
The appliance does not start up.
After the boiler has been turned on,
the no water icon on the control pa-
nel starts to blink and the appliance
emits a sound signal.
Not emitting steam while
heated
The flexible hose or accessories
smell.
During normal operating conditions
the low water alarm is activated
(icon “D” on).
CAUSE
The power cord has not been cor-
rectly plugged into the power sup-
ply outlet.
The water level in the tank is low.
Possible cause - steam
regulator
Presence of dirt, mould or incrusta-
tions in the hose or accessories.
Air is in the pump circuit.
SOLUTION
Plug the power cord plug into the
power supply outlet correctly.
Fill the tank with water and start up
the appliance once more.
Confirm that the regulator is not
in the off position.
Empty the bin and rinse the tubes
and accessories with clean water.
Set the boiler switch A to the OFF
position, discharge steam for a few
seconds and then set switch A back
to the ON position.

4
2. Description of accessories
30
32
32a
(1 foro)
22
28
24
29
23
26
27
31
34
35
36
36a
22b
22a
36b
Accessories
22 Rectangular brush
22a Accessory for carpets
22b Cloth
23 Triangular brush
24 Accessory for unblocking
washbasins/sinks
26 Extension wands
27 Extension wands
28 Window-cleaning accessory
29 Medium-sized brush
30 Dress-fit W=265 mm
31 Funnel
32 Dress-fit W=90 mm
32a (1 hole)
34 Round brush for dress-fit
(1 hole)
35 Triangular brush for dress-fit
(3 holes)
36 Brush for dress-fit
(1 hole) (nylon)
36a Brush for dress-fit
(1 hole) (steel)
36b Brush for dress-fit
(1 hole) (brass)
PLEASE NOTE:some items above are optional and not included in
the standard package. Please see product photo presenting all
standard accessories included.
(1 hole)
17
14. Information for users
According to Directives 2011/65/EU and 2012/19/EU on the reduced use
ofhazardoussubstancesinelectricalandelectronicequipment,andtheir
disposal, the barred bin symbol means that at the end of its useful life the
product must be disposed of separately from ordinary waste.
Theusermustthereforetakesuchequipmenttopropercollectioncentres
for electrical and electronic waste, or take it back to the dealer when he
buyssomeequivalentequipment,intheratioof1:1.
A suitably differentiated waste collection, followed by recycling, treatment
and environmentally friendly disposal helps prevent negative effects on health and
the environment and favors the recycling of materials.
Anyunauthorizedequipmentdisposalbytheuserwillbesubjecttosanctionsasprovi-
ded for by current local regulations.
15. Guarantee
The manufacturer guarantees the product in regard to manufacturing defects.
Please visit www.myvaporclean.com/warranty upon receipt of this product to view
the warranty in full and suggestions to maintain your warranty in good standing.
