MAGSTIM 3190-00 User manual

FEB 2015
Magstim 2nd Generation Coils
Operating Manual
MOP04-EN
Revision 03

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited i MOP04-EN-03
TABLE OF CONTENTS
Table of Contents ................................................................................................................. i
Guarantee........................................................................................................................... ii
Section 1 Introduction....................................................................................................... 1
1.1 Indications for Use................................................................................................... 1
1.2 Contraindications..................................................................................................... 1
1.3 Devices Covered..................................................................................................... 1
1.4 Frequently Used Functions....................................................................................... 2
Section 2 Warnings and Precautions ................................................................................. 3
Section 3 Product Descriptions.......................................................................................... 5
3.1General................................................................................................................... 5
3.2 Double 70mm Remote Control Coil........................................................................... 5
3.3 Single 90mm Remote Control Coil and Single 90mm Standard Coil............................ 6
3.4 2nd Generation Coil User Interface ............................................................................ 6
Section 4 Operating Instructions........................................................................................ 9
4.1 Preparation ............................................................................................................. 9
4.2 Connection.............................................................................................................. 9
4.3 Operation.............................................................................................................. 10
4.4 Interlocks.............................................................................................................. 13
4.5 Error Codes .......................................................................................................... 13
Section 5 Maintenance ................................................................................................... 14
5.1 User Maintenance and Calibration.......................................................................... 14
5.2 Technical Maintenance.......................................................................................... 14
5.3 Cleaning and Disinfecting* ..................................................................................... 14
5.4 Servicing............................................................................................................... 14
5.5 Device Lifetime...................................................................................................... 14
5.6 Disposal................................................................................................................ 15
Section 6 Specifications.................................................................................................. 16
6.1 Safety Specifications.............................................................................................. 16
6.2 Technical Specifications......................................................................................... 17
6.3 Environmental Conditions*..................................................................................... 19
6.4 Packing Instructions............................................................................................... 19
Section 7 Contact Details................................................................................................ 20
7.1 Product Enquiries.................................................................................................. 20
7.2 Servicing Enquiries................................................................................................ 20
7.3 Sales Enquiries ..................................................................................................... 20
Appendix A - Error Codes................................................................................................... 21
Appendix B - TMS MEDICAL SCREENING QUESTIONNAIRE ............................................ 22
Appendix C - EMC IMMUNITY AND EMMISIONS ................................................................... 26

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited ii MOP04-EN-03
GUARANTEE
Equipment manufactured by The Magstim Company Limited is fully guaranteed, covering both
materials and workmanship, for a period of one year from the date of shipment. The Magstim
Company Limited reserves the right to perform guarantee services in its factory, at an authorised
repair station, or at the customer’s installation.
Any obligations which The Magstim Company Limited has under this guarantee are limited to repairs
or, should the company so choose, replacement of any defective parts of the equipment, except
batteries, without charge provided that the said defects occur during normal service.
Claims for damages during shipment must be filed promptly with the transportation company. All
correspondence concerning the equipment must specify the model name and/or number as well as
the serial number exactly as they appear on the invoice for the equipment.
Improper use, mishandling, tampering with, or operation of the equipment without following specific
operating instructions will void this guarantee and release The Magstim Company Limited from any
further guarantee obligations.
The Magstim Company Limited will only accept responsibility for effects on safety, reliability and
performance of the equipment if:
modifications or repairs are carried out by persons authorised by The Magstim Company
Limited;
the electrical installation of the relevant room complies with local regulations; and
the equipment is used in accordance with the instructions for use.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 1 MOP04-EN-03
SECTION 1 INTRODUCTION
1.1 Indications for Use
The Magstim 2nd Generation Coils are hand held accessories to the Magstim Rapid² systems, 200²
and Bistim² system for the stimulation of cortical and peripheral nerves for diagnostic, research and
therapeutic purposes.
When used together, they are capable of stimulating neuromuscular tissue by inducing small
currents in the nerve using a brief pulse of electromagnetic energy.
This method of stimulation enables deep, and otherwise inaccessible, nerves to be stimulated easily
and relatively painlessly. In addition, no skin preparation is required and stimulation can be achieved
through clothing.
The Magstim 2nd Generation Coils are intended for use by, or under the supervision of, a medical
practitioner or investigator and are to be used in a laboratory or a medical consulting room
environment. The medical practitioner or investigator should have knowledge about the principles of
TMS, physiology and potential side effects of TMS.
The Magstim 2nd Generation Coils are non-sterile reusable medical devices intended for multi-patient
use.
The Magstim 2nd Generation Coils are portable medical devices intended for limited patient
exposure. The coils are not intended to come into contact with any bodily fluids.
USA Only: Federal law restricts this device to sale by or on the order of a practitioner licensed by
the law of the State in which he/she practices to use or order the use of the device.
USA Only: The Magstim 2nd Generation Coils have not been cleared by the FDA for cortical
stimulation. Investigational uses require an IDE
1.2 Contraindications
The Magstim 2nd Generation Coils are accessories to the Magstim Rapid² systems, 200² and Bistim²
system and share the same contraindications. Please see the appropriate stimulator operating
manual.
Magstim recommends that a standard questionnaire is completed to screen a patient’s suitability
prior to using any Magstim product on that patient and concurs with the recommendations given in
the paper titled “Safety, ethical considerations, and application guidelines for the use of transcranial
magnetic stimulation in clinical practice and research” by Rossi et al (2009).
1.3 Devices Covered
This document is applicable to the following devices and it should be read in conjunction with the
appropriate stimulator operating manual.
Magstim Double 70mm Remote Control Coil (P/N: 3190-00)
Magstim 90mm Remote Control Coil (P/N: 3192-00)
Magstim 90mm Standard Coil (P/N: 3193-00)

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 2 MOP04-EN-03
Note: Please also consult any labelling and information accompanying stimulating coils and other
accessories for safety and use information regarding these devices. The stimulator operating manual
reference numbers are shown on the following page;
Magstim Rapid² stimulator - MOP03
Magstim 200² stimulator - MOP01
Magstim BiStim² stimulator - MOP02
1.4 Frequently Used Functions
Frequently used functions as defined during Magstim’s usability process are identified with
(*). Frequently used functions are functions of the 2nd Generation Coils that frequently involve
user interaction.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 3 MOP04-EN-03
SECTION 2 WARNINGS AND PRECAUTIONS
Attention Consult Operating Manual: Consult the operating manual before using this device.
Ensure you are familiar with all sections of this operating manual prior to using the coil.
Operating Manual: Further information can be located in the operating manual.
Type BF Applied Part: Refer to Section 6.1 for further information.
High Voltages: High voltages are present in the2nd Generation Coils during operation. Therefore:
refer servicing to qualified personnel;
if there is any sign of external damage or if any parts are damp or wet, they must not
be used.
ensure that the system is disarmed prior to disconnecting the stimulating coil from the
stimulator.
Magnetic Pulses: The coils generate high intensity magnetic pulses, which induce eddy currents
in any conductive medium, such as the human body, nearby metallic objects or electronic devices.
Therefore, the coils:
must not be used on, or in the vicinity of subjects with cardiac demand pacemakers,
implanted defibrillators, or other electronic or metallic implants;
must not be used in a position where the current can be induced in cables or wires
that are directly connected to the subject;
must not be used in the vicinity of objects that are sensitive to magnetic fields, such as
watches, credit cards and electronic equipment; and
must not be used when in contact with metallic objects, as these objects may be
propelled or damaged by the magnetic field of the coil;
Damage: If there are any signs of damage to the Coils, or if any parts are damp or wet, the coil
must not be used*. If damaged, the coil should be returned to the Magstim Company Limited for
servicing and repair (see Section 7.2 for contact details).
Explosive and Flammable Atmospheres: The Magstim 2nd Generation Coils must not be used
in an explosive atmosphere, around explosive gases or in the presence of flammable
anaesthetics.
Modification: No modification of this equipment is allowed. On no account must either of the
multi-function buttons on the stimulating coil be permanently activated, by taping down, or any
other method of fixing. They are designed as a safety interlock, to disable them could result in a
serious injury as a result of an inadvertent discharge of the coil.
Surface Temperatures: The coil surface temperature will continue to rise following activation of
the stimulator’s coil over temperature function; therefore, the coil must be removed from the
subject as soon as the system indicates that the coil has reached maximum temperature.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 4 MOP04-EN-03
Discharge noise: When the magnetic pulse is delivered, a discharge click is produced that may
startle. The use of ear protection is recommended for the operator and adult patients. Ear
protection is mandatory for children.
Seizures: cortical magnetic stimulation runs the risk of inducing seizures. Magstim concurs with
the advice given in the paper titled “Safety, ethical considerations and application guidelines for
the use of TMS in clinical practice and research” by Rossi et al (2009) in respect to screening
candidates prior to administering TMS.
Environmental Conditions*: The system must not be used or stored under environmental
conditions that fall outside those specified in section 6.3 of this operating manual.
Liquids: The Magstim 2nd Generation Coils must not be immersed in water, placed in an ice
bucket, or refrigerated; not even if first placed in a plastic bag. The coils do not have any
specialised protection against the ingress of liquids; conditions where ingress of liquid, or the
forming of condensation within the coil, can occur must be avoided, as the electrical insulation will
be compromised.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 5 MOP04-EN-03
SECTION 3 PRODUCT DESCRIPTIONS
3.1 General
The coils have four main parts: the coil head, handle, cable and connector (as shown in Figure 3.1).
There is a copper winding in the coil head, through which energy from the stimulator is discharged.
The current that flows through the winding generates a magnetic field and a corresponding electrical
field (as shown in Section 6.2.1).
Figure 3.1: Example Coil illustration (3190-00 –D70mm Remote Control Coil)
3.2 Double 70mm Remote Control Coil
This coil has a figure-of-eight winding in the coil head. Current flow is in opposing directions in each
half of the coil, which is indicated by the current direction label (see Figure 3.2).
Figure 3.2: Double 70mm Remote Control Coil (P/N: 3190-00)
Coil cable
Coil connector
Coil handle
Coil head
Current direction
label

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 6 MOP04-EN-03
3.3 Single 90mm Remote Control Coil and Single 90mm Standard Coil
These coils have a single, circular winding in the coil head. Current flow is in one direction, which is
indicated by the current direction label (see Figure 3.4 & 3.5). The coils can be used on either side (A
or B), which allows the current direction to be changed when required by flipping the coil.
Figure 3.4: 90mm Remote Control Coil (P/N: 3192-00)
Figure 3.5: 90mm Standard Coil (P/N: 3193-00)
3.4 2nd Generation Coil User Interface
3.4.1 Remote control coils
Figure 3.6 shows the different parts of the remote control coils’ user interface and the descriptions
that follow explain their various functions.
Figure 3.6: User interface on a Remote Control Coil
4. Down Button
3. Ready Indicator
2. Stop Button
1. Multi-function
button
5. Multi-function
display
6. Up button
7. Temperature
indicator
Current
direction
label

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 7 MOP04-EN-03
3.4.1.1 Multi-function Button* (1)
Each remote coil has two multi-function buttons located on each side of its handle. These have the
following functions on all stimulators.
Charge the stimulator –engage and hold one of the buttons for two seconds.
Trigger the stimulator –engage both buttons at the same time (when the stimulator is
charged and ready). The stimulator will be triggered repeatedly if the two buttons are held
continuously. Note: the trigger function of these buttons will be disabled if they are being
held when the stimulator is charged.
They also have the following function on a Bistim² system.
Parameter selection –engage one of the buttons twice, in quick succession to change the
parameter indicated on the multi-function display.
Note: On no account must either of the multi-function buttons on the stimulating coil be permanently
activated, by taping down, or any other method of fixing. They are designed as a safety interlock, to
disable them could result in a serious injury as a result of an inadvertent discharge of the coil.
3.4.1.2 Stop Button* (2)
Engaging the stop button will place the stimulator into stopped mode; the stimulator will discharge
safely internally, without delivering a stimulus.
3.4.1.3 Ready Indicator* (3)
The ready indicator will be illuminated when the stimulator is charged and ready to deliver the
stimulus.
3.4.1.4 Down Button* (4)
When used with the Magstim 200² or Bistim² engaging the down button will reduce the selected
parameter by one unit. If the button is held, the parameter will continue to decrease until the button
is released or the minimum value is reached.
3.4.1.5 Up Button* (6)
When used with the Magstim 200² or Bistim² engaging the up button will increase the selected
parameter by one unit. If the button is held, the parameter will continue to increase until the button
is released or the maximum value is reached.
%
3.4.1.6 Multi-function Display* (5)
This display shows information regarding the system, which includes the following:
The stimulator output power (on a Magstim 200² and Rapid²)
The selected parameter (on a Magstim Bistim²)
An error code if a fault is detected by the system (see Appendix A)

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 8 MOP04-EN-03
3.4.2 Standard Coil
Figure 3.7 shows the different parts of the standard coils’ user interface and the descriptions that
follow explain their various functions.
Figure 3.7: User interface on a Standard Coil
3.4.1.7 Temperature Indicator* (7)
The coil temperature indicator will be illuminated when the coil surface temperature has reached
the maximum limit. If this symbol is illuminated, the coil should be removed from the subject and
allowed to cool.
3.4.2.1 Interlock Button* (1)
The Standard Coil has two interlock buttons located on each side of its handle. The roles of the
interlock buttons are to prevent inadvertent triggering of the system.
Note: On no account must either of the multi-function buttons on the stimulating coil be permanently
activated, by taping down, or any other method of fixing. They are designed as a safety interlock, to
disable them could result in a serious injury as a result of an inadvertent discharge of the coil.
3.4.2.2 Ready Indicator* (2)
The ready indicator will be illuminated when the stimulator is charged and ready to deliver the
stimulus.
3.4.2.3 Temperature Indicator* (3)
The coil temperature indicator will be illuminated when the coil surface temperature has reached
the maximum limit. If this symbol is illuminated, the coil should be removed from the subject and
allowed to cool.
2. Ready Indicator
1. Interlock Button
3. Temperature Indicator

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 9 MOP04-EN-03
SECTION 4OPERATING INSTRUCTIONS
Note: for more detailed operating instructions see the Operating Manual for the appropriate
stimulator.
Note: to avoid problems with interference, the stimulating coils should not be used in the vicinity of
any equipment not in compliance with the EMC Standard EN 60601-1-2, including mobile phones.
Note: Please ensure you are familiar with all sections of this operating manual prior to following these
operating instructions.
Note: Following transportation or storage, the user must allow the coil to reach operating ambient
temperature. This is achieved by allowing the coil to acclimatise for a minimum of eight hours.
4.1 Preparation
1. At the start of each session the operator must check the plastic casing surrounding the coil for any
signs of external damage and to identify any cleaning required*. If any cracks are visible in the
plastic covers, or there is damage to the handle or cable, the coil must not be used and should be
returned to The Magstim Company Limited for servicing and repair. (See section 5.4 for servicing
details). If cleaning is required, please follow the instructions provided in Section 5.3.
Note: The contacts in the coil connector and the stimulator coil socket should be checked
regularly for any signs of tarnishing or burning.
4.2 Connection
1. Place the coil into the coil holder situated on the right hand side of the stimulator*. (Coil holder is
situated on the right hand side of the master unit when using the Magstim Bistim²)
Figure 4.1: Attaching the coil to the coil holder
2. Connect the 2nd Generation Coils to the stimulator (Bistim² connecting module when using the
Magstim Bistim²) by aligning the locating key on the coil connector with the corresponding receptor
on the coil output socket. It is then possible to rotate the outer collar of the coil connector
clockwise in order to lock the coil to the stimulator*.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 10 MOP04-EN-03
Figure 4.2: Locating key on the coil connector (left) and the receptor on the stimulator coil output socket (right)
3. Care must be taken to attach the coil connector to the stimulator correctly (see Figure 4.).
Note: Failure to do so can cause damage to the connector pins and in severe cases, internal
damage to the coil and the stimulator.
Figure 4.3: Diagram showing correct and incorrect ways to connect the coil to the stimulator
4. Following an initialisation sequence, the stimulator will recognise the coil and the system will be
ready to use.
4.3 Operation
4.3.1 Use of Remote Control Coils with Magstim 200²
1. When the coil is connected to the stimulator and ready to use, remove the coil from the coil holder
of the right hand side of the stimulator*. The coil will show the output power of the system on the
multi-function display*.
2. Use the up and down buttons* on the remote control coil to adjust the power to the desired level.
3. Use one of the multi-function buttons* to charge the system by engaging the button and holding it
for two seconds. The coil’s ready indicator* will illuminate when the system has charged to the
correct level and is ready to deliver the stimulus.
4. Position the coil over the desired target; Figure 6.3 (90mm) and 6.4 (D70) shows the peak
stimulation points of each coil.
5. Engage both multi-function buttons* at the same time to trigger the stimulator and deliver the
stimulus.
A clicking noise should be heard from both the remote control coil and the stimulator.
Coil locating key
Coil output
socket receptor

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 11 MOP04-EN-03
6. When necessary, reposition the coil and/or modify the output power to suit requirements for the
next stimulus. Meanwhile, the stimulator will recharge and the coil’s ready indicator* will be
illuminated when charging is complete.
7. At the end of the session, use the stop button* on the remote control coil to disarm the stimulator
and place the coil back into the coil holder on the stimulator*.
8. Section 4.2 should be repeated in reverse to disconnect the coil.
Note: Ensure that the system is disarmed prior to disconnecting the stimulating coil from the
stimulator.
4.3.2 Use of Remote Control Coil with Magstim Bistim²
1. When the coil is connected to the stimulator and ready to use, remove the coil from the coil holder
of the right hand side of the master unit*. The coil multi-function display* will show one of the
values listed below. These values indicate the parameter that is currently selected.
P1 = output power (master stimulator)
P2 = output power (slave stimulator)
IP = inter-pulse time
Note: The parameter values will be displayed on the stimulator user interface.
2. Use the up and down buttons* on the remote control coil to adjust the selected parameter to the
desired level, (The parameter value will be displayed on the stimulator user interface).
3. To select a different parameter, engage one of the multi-function buttons* twice, in quick
succession. Repeat this until the desired parameter is shown on the multi-function display.
4. Use one of the multi-function buttons* to charge the system by engaging the button and holding it
for two seconds. The coil’s ready indicator* will illuminate when the system has charged to the
correct level and is ready to deliver the stimulus.
1. Position the coil over the desired target; Figure 6.3 (90mm) and 6.4 (D70) shows the peak
stimulation points of each coil.
5. Engage both multi-function buttons* at the same time to trigger the stimulator and deliver the
stimulus.
A clicking noise should be heard from both the remote control coil and the stimulator.
6. When necessary, reposition the coil and/or modify the output power to suit requirements for the
next stimulus. Meanwhile, the stimulator will recharge and the coil’s ready indicator* will be
illuminated when charging is complete.
7. At the end of the session, use the stop button* on the remote control coil to disarm the stimulator
and place the coil back into the coil holder on the master unit*.
8. Section 4.2 should be repeated in reverse to disconnect the coil.
Note: Ensure that the system is disarmed prior to disconnecting the stimulating coil from the
stimulator

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 12 MOP04-EN-03
4.3.3 Use with Magstim Rapid²
1. When the coil is connected to the stimulator and ready to use, remove the coil from the coil
holder of the right hand side of the stimulator*. The coil will show the output power of the system
on the multi-function display*.
2. Set the desired protocol on the Rapid² UI.
3. Use one of the multi-function buttons* to charge the system by engaging the button and holding it
for two seconds. The coil’s ready indicator* will illuminate when the system has charged to the
correct level and is ready to deliver the stimulus.
4. Position the coil over the desired target; Figure 6.3 (90mm) and 6.4 (D70) shows the peak
stimulation points of each coil.
5. Engage both multi-function buttons* at the same time to trigger the stimulator and deliver the
stimulus.
A clicking noise should be heard from both the remote control coil and the stimulator.
6. When necessary, reposition the coil and/or modify the protocol to suit requirements for the next
stimulus. Meanwhile, the stimulator will recharge and the coil’s ready indicator* will be illuminated
when charging is complete.
7. At the end of the session, use the stop button* on the remote control coil to disarm the stimulator
and place the coil back into the coil holder on the stimulator*.
8. Section 4.2 should be repeated in reverse to disconnect the coil.
Note: Ensure that the system is disarmed prior to disconnecting the stimulating coil from the
stimulator
4.3.4 Use of the Standard Coil with Magstim 200², BiStim² and Rapid²
1. When the coil is connected to the stimulator and ready to use, select the desired stimulator output
power/ protocol using the stimulator UI.
2. Use the stimulator UI to arm the system. The coil’s ready indicator* will illuminate when the
system has charged to the correct level and is ready to deliver the stimulus.
3. Remove the coil from the coil holder of the right hand side of the stimulator* and position the coil
over the desired target. Peak stimulation points of the coil can been seen in figures in Section 6.
4. Engage an interlock button in conjunction with either a footswitch or the stimulator UI trigger
button to trigger the stimulator and deliver the stimulus.
A clicking noise should be heard from both the coil and the stimulator.
5. When necessary, reposition the coil and/or modify the output power to suit requirements for the
next stimulus. Meanwhile, the stimulator will recharge and the coil’s ready indicator* will be
illuminated when charging is complete.
6. At the end of the session, use the stimulator UI to disarm the stimulator and place the coil back
into the coil holder on the stimulator.
7. Section 4.2 should be repeated in reverse to disconnect the coil.
Note: Ensure that the system is disarmed prior to disconnecting the stimulating coil from the
stimulator.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 13 MOP04-EN-03
4.4 Interlocks
The multi-function buttons* (Remote control coils) and interlock button (Standard Coil) behave as
trigger interlocks when using one of the central trigger methods (e.g. stimulator footswitch). Therefore,
at least one of the buttons must be engaged in order for the system to be triggered in this mode of
operation.
There is an automatic coil temperature interlock applied by the stimulator. When the maximum
temperature is reached, the coil temperature indicator* will be illuminated and the stimulator will return
to stopped mode. The coil should then be removed from the subject and allowed to cool.
4.5 Error Codes
The 2nd Generation Coils will display the appropriate error code on its display. (See Appendix A for a
list of the error codes for faults relating directly to the operation of the 2nd Generation Coils).
Note: Details on Stimulator error codes can be found in the appropriate Stimulator operating manual.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 14 MOP04-EN-03
SECTION 5 MAINTENANCE
5.1 User Maintenance and Calibration
There are no user maintenance or calibration requirements for the 2nd Generation Coils. However, it is
important that they are checked for any sign of damage at the start of each session*. If any cracks are
visible in the plastic covers, or if there is damage to the handle or cable, the coil must not be used and
should be returned to The Magstim Company Limited for servicing and repair (see Section for
contact details).
5.2 Technical Maintenance
The contacts in the coil connector and the stimulator coil socket should be checked before connecting
to the system for any signs of tarnishing or burning*. Under conditions of exceptionally intense use, it
is possible for localised heating to manifest itself in the connector, which causes damage to the
contacts. Continued use in this condition will eventually cause the contacts to deteriorate and loose
electrical connection, which will cause damage to the system.
Repair is a specialised procedure and can only be undertaken by The Magstim Company Limited or
an authorised service centre. If any pins show damage, however slight, contact The Magstim
Company Limited service department for further advice or to arrange a return (see Section 7.2 for
contact details).
Warning: contact burning is communicable, so any coil with damaged contacts will infect a stimulator
with healthy contacts and vice-versa. Therefore, if damage is noticed on any coil connector or
stimulator coil socket the entire system must not be used until all contacts are carefully examined and
repaired where appropriate. If this is not done thoroughly there is a risk that the cycle of pin damage
will continue.
5.3 Cleaning and Disinfecting*
The 2nd Generation Coils cannot be sterilised; therefore, do not allow them to become contaminated
with bodily fluids. The coils may be cleaned using a cloth moistened with isopropyl alcohol but ensure
that the coils have dried thoroughly before use.
It is the responsibility of the user to ensure the 2nd Generation Coils are cleaned when necessary.
Note: The Magstim Company Ltd recommends that a solution of 70% isopropyl alcohol should be
used.
5.4 Servicing
Servicing of the 2nd Generation Coils must only be carried out by The Magstim Company Limited or
persons authorised by the Magstim Company Limited. To arrange a return or for further information,
contact the service department at The Magstim Company Limited (see Section 7.2 for contact
details).
5.5 Device Lifetime
The lifetime of the 2nd Generation Coils is defined as being five years from the date of shipment. The
Magstim Company Limited will support the products for the duration of their lifetime.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 15 MOP04-EN-03
5.6 Disposal
When a 2nd Generation Coils reaches the end of its serviceable life, it should not be disposed of in
general waste. The Magstim Company Limited should be contacted (see Section 7.2 for contact
details) for advice on its disposal in compliance with the appropriate environmental regulations.
Failure to do so could cause an environmental hazard as a result of decomposition of materials used
in its construction.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 16 MOP04-EN-03
SECTION 6 SPECIFICATIONS
6.1 Safety Specifications
During use and when used with the stimulators specified in 6.2, the type of protection against electric
shock provided by the magnetic stimulator fitted with a 2nd Generation Coil is classified as Class 1.
The degree of protection against electric shock for applied part accessories is classified as type BF
Applied parts. This means that the surfaces of the coil are electrically isolated from the other parts of
the equipment and meet Type BF leakage current limits as required by IEC 60601-1.
The Magstim 2nd Generation Coils comply with the requirements of Safety Standard IEC 60601-1 and
with EMC Standard EN 60601-1-2.
To avoid problems with EMC interference, the 2nd Generation Coils should not be used in the vicinity
of any equipment that does not comply with EMC Standard EN 60601-1-2, including mobile phones.
The Magstim 2nd Generation Coils are classified as IPXO (Not Protected), as there is no specialised
protection provided against the ingress of liquids.
The Magstim 2nd Generation Coils are not protected against flammable anaesthetic mixtures. They
are not suitable for use in the presence of a flammable anaesthetic mixture with air, oxygen or nitrous
oxide.
The mode of operation of the 2nd Generation Coils is classified as continuous.

Magstim 2nd Generation Coils
Operating Manual
© The Magstim Company Limited 17 MOP04-EN-03
6.2 Technical Specifications
Stimulator compatibility: Magstim 200², Magstim Bistim², Magstim Rapid²
Coil
D70mm Remote Control
Coil (3190-00)
90mm Remote Control
Coil (3192-00)
90mm Standard Coil
(3193-00)
Average
Inductance
15.50µH
23.47µH
23.47µH
Coil Cable
Length
2m
2m
2m
Peak Magnetic
Field
2.2T
2.0T
2.0T
Max Number of
Pulses
50%
Power
340
50%
Power
505
50%
Power
505
80%
Power
110
80%
Power
260
80%
Power
260
100%
Power
60
100%
Power
145
100%
Power
145
When used with a Magstim 200², at an ambient temperature of 20°C.
Table 6.1: Coil specifications
6.2.1 Electric Field Plot
Figure 6.1: Approximate electric field profile for 90mm Remote Coil and 90mm Standard Coil measured
using a Magstim Rapid²
