Mahlkonig E65S GbW User manual

www.mahlkoenig.de
E65S GbW
INSTRUCTION MANUAL

1
2
3
5
6
9
11
12
13
14
15
16
8
17
4
7
A
10
Overview
ESPRESSO GRINDER
2

C
B
2
18
19
20
8
10
3
E65S GbW | EN

D
E
13
13
21
ESPRESSO GRINDER
4

F
G
F
4
16
23
3
22
15
5
E65S GbW | EN

H
I
13
24
26
25
25
ESPRESSO GRINDER
6

J
27
28
30
31
32
31
34
29
29
28
33
7
E65S GbW | EN

L
37
36
K
35
ESPRESSO GRINDER
8

M
N
41
42
44
40
39
43
38
9
E65S GbW | EN

Scope of delivery
No. DesignaƟon
1Bean hopper (with lid)
2Bean hopper intake
3Controller
4Grinding degree lock
5On/Offswitch
6Release buon (Thermal
overcurrent circuit-breaker)
7Power cable
8Screw for adjusting the porta-
filter support (left and right),
2×
9Weighing scale cover
10 Collecng tray
11 Portafilter support
12 Portafilter intake
13 Spout
14 Display
15 Grinding degree slider
16 Grinding degree scale
17 Clip for the type of bean used
18 Slider
19 Rubber ring
20 Locking screw for the bean
hopper
21 Spout guide
22 Lower buon
23 Upper buon
24 Rescue buon
25 Locking screws grinder lid
No. DesignaƟon
26 Lock/unlock grinder lid
27 Grinder lid
28 Screws to the fixed burr
29 Screws to the rotary burr
30 Rotary burr
31 Locking screws for the fix burr
flange
32 Burr carrier
33 Fixed burr
34 Fix burr flange
35 Flapper
36 Locking tool for changing
burrs
37 Removal tool for changing
burrs
38 Adjustment ring lock
39 Adjustment ring
40 Adjustment ring marker
41 Vernier scale
42 Dial zero adjustment burr
43 Intermediate plate
44 Intermediate plate marker
ESPRESSO GRINDER
10

Contents
Overview ............................. 2
Scope of delivery ............... 10
General.............................. 12
Reading and retaining
the operang manual ................. 12
Explanaon of symbols used ...... 12
Safety................................. 14
Intended use ............................... 14
Safety informaon ...................... 14
Before using for the first me 17
Funconing and basic sengs ... 17
Checking the grinder and
scope of delivery......................... 17
Seng up the grinder and inserng
the bean hopper ......................... 18
Seng up the portafilter support
and spout .................................... 19
Acvang portafilter detecon .. 19
Recording portafilters ................ 20
Operaon .......................... 22
Adding espresso beans............... 23
Switching on the grinder ............ 23
Seng the grinding degree ........ 23
Selecng recipes based on
weight/me................................. 24
Assigning recipes based on
weight/me................................. 24
Seng or changing the grinding
weight/me................................. 24
Starng grinding ......................... 26
Interrupng grinding .................. 27
Rescue buon grinding............... 27
Changing the type of espresso beans 27
Using the main menu ........ 29
Display/navigaon symbols ........ 29
Accessing and leaving
the main menu............................ 30
Cleaning............................. 31
Cleaning the grinder installaon
surface......................................... 32
Cleaning the casing..................... 32
Cleaning the spout system.......... 32
Cleaning the bean hopper .......... 33
Cleaning the grinding mechanism
with GRINDZTM............................. 34
Cleaning the grinding mechanism
manually...................................... 35
Cleaning the flapper ................... 36
Maintenance ..................... 37
Changing the burrs ..................... 37
Adjusng the burrs ..................... 38
Changing the flapper .................. 38
Calibrang the weighing scale.... 39
Troubleshoong ................ 40
Technical data.................... 45
Disposal ............................. 46
Disposing of the packaging......... 46
Disposing of the grinder ............. 46
Maintenance and service .. 46
11
E65S GbW | EN

General
Reading and retaining the operaƟng manual
Before you start using the E65S GbW espresso grinder, carefully
read through this operang manual and the safety informaon.
Only then will you be able to use the E65S GbW espresso grinder
safely and without danger. The operang manual is based on the
standards and regulaons in force in the European Union. Please also ob-
serve the guidelines and laws of the respecve country if abroad.
For beer clarity, the E65S GbW espresso grinder shall be referred to herein-
aer simply as “grinder”.
Please keep the operang manual safe for later queries.
Please also hand the operang manual on to subsequent owners and
users of the grinder.
ExplanaƟon of symbols used
The following symbols and signal words are used in this operang manual, on
the grinder and on the packaging.
WARNING!
This signal word/symbol indicates a danger with a moderate
degree of risk, which can lead to death or serious injury if
not avoided.
CAUTION!
This signal word/symbol indicates a danger with a low de-
gree of risk, which can lead to minor or moderate injury if
not avoided.
NOTE!
This signal word warns of possible material damage.
ESPRESSO GRINDER
12

This symbol provides you with important informaon concerning
operaon or handling.
Declaraon of Conformity:
Products marked with this symbol fulfil all applicable community
provisions of the European Economic Area.
ETL Listed seal of approval:
Products marked with this symbol meet the requirements of
electrical product safety in the United States of America.
Products marked with this symbol meet the criteria required by
the NSF (Naonal Sanitaon Foundaon) regarding cleanliness
and hygiene in the food industry.
Products marked with this symbol are only permied for use
indoors.
This symbol indicates a risk of electric shock.
This symbol indicates that the grinder conforms to protecon
class I.
13
E65S GbW | EN

Safety
Intended use
The grinder is only suitable for grinding whole roast espresso beans. Do not
use the grinder to grind other products or objects.
The grinder is intended for commercial use but not for connuous mass
producon. The grinder may only be serviced by trained personnel. It may,
however, be operated by other persons in a place where use is supervised.
Any other use is not considered to comply with the intended use and can
result in material damage or even personal injury. Do not make any modifi-
caons to the grinder. The manufacturer or supplier cannot be held liable for
any injury or damage resulng from failure to comply with the safety instruc-
ons.
Safety informaƟon
WARNING!
Danger of electric shock!
Improper use, incorrect electrical installaon or an excessively high
voltage can all lead to electric shock.
– Connect the grinder only if the mains voltage of the socket com-
plies with the informaon indicated on the type plate.
– Connect the grinder only to a socket with good accessibility, so
that you can disconnect it quickly from the power supply in the
event of a fault.
– Do not use the grinder if you noce any visible damage or if the
power cable or plug is faulty.
– If the grinder power cable is damaged, it must be replaced by
the manufacturer or by qualified personnel in order to avoid
hazards.
– Do not operate the grinder without an earthed connecon.
– Connect the grinder only to a power supply with a 16 A-slow
back-up fuse or a 15 A load fuse (USA). Have the 16 A-slow
back-up fuse or 15 A load fuse fied by a qualified electrician if
the power connecon at the installaon locaon of the grinder
is not protected in this way.
ESPRESSO GRINDER
14

– Install the grinder only in locaons where handling of the grind-
er can be supervised by trained personnel.
– Do not operate the grinder above an altude of 2000 metres.
– Do not immerse the grinder or the power cable/mains plug in
water or any other liquids.
– Do not clean the grinder with a water jet.
– Do not clean the grinder with compressed air
(e.g. with a compressed air gun).
– Never touch the mains plug with wet hands.
– Never unplug the mains plug from the wall socket by pulling on
the power cable; always grip the plug itself.
– Never use the power cable as a handle to carry the grinder.
– Keep the grinder and power cable/mains plug away from open
flames and hot surfaces.
– Do not lay the power cable in such a way that it could create a
tripping hazard.
– Do not bend the power cable and do not place it over sharp
edges.
– Use the grinder in indoor areas only. Never operate the grinder
in damp rooms or in the rain.
– Keep children away from the grinder.
– Ensure that children do not insert any objects into the grinder.
– If you are not currently using the grinder, if you are cleaning it
or if a fault occurs, switch the grinder offand remove the mains
plug from the socket.
– Do not open the grinder casing; leave repairs to the experts. If
repairs are required, please contact a specialist workshop. In
the event of unauthorised repairs, faulty connecon or incor-
rect operaon, all liability and guarantee claims are excluded.
Only parts that comply with the original appliance specificaons
may be used for repairs. This grinder contains electrical and me-
chanical parts that are essenal for protecon against potenal
hazards.
15
E65S GbW | EN

WARNING!
Danger for children and persons with reduced physical, sensory or
mental capaciƟes (e.g. some disabled persons, older persons with
limited physical and mental abiliƟes) or a lack of experience and
knowledge (e.g. older children).
– The grinder is not intended for use by children or people with
limited physical, sensory or mental abilies or a lack of experi-
ence and knowledge. Children are not permied to play with
the grinder.
– Do not leave the grinder unsupervised when in operaon.
– Do not let children play with the packaging film. Children can
become entangled in it while playing and may suffocate.
– Do not let children play with the small parts. They can be
life-threatening if swallowed.
CAUTION!
Risk of Ɵpping and injury!
Incorrect handling of the grinder can result in injury.
– Posion the power cable so that nobody can become entangled
in it and cause the grinder to fall.
– Place the grinder on a level and stable surface to prevent it from
falling off.
ESPRESSO GRINDER
16

Before using for the first Ɵme
FuncƟoning and basic seƫngs
The grinder has grind-by-weight (GbW) technology for dosing by weight
control in real-me. It also has a Disc Distance Detecon (DDD) funcon,
which enables the grinding degree to be set based on the distance between
the burrs. Portafilter Detecon (PFD) allows different portafilters to be
automacally recognised by their weight aer inseron into the grinder
(see chapter “Detecng portafilters”). Once the grinder has recognised the
portafilter, you can select the dosage quanty.
The quanty of ground coffee dispensed per shot, i.e. the dosage quanty, is
determined by the grinder based on the grinding weight or the grinding me.
The user can specify up to six different recipes (grinding weights/mes) and
also has the opon of controlling the grinding weight/me manually (manual
grinding).
The grinding process starts automacally when the portafilter is inserted and
ends either automacally aer the specified grinding weight/me has been
reached or when the portafilter is removed.
2 shots and manual grinding are set as the default on delivery.
Single shot: 12 g (approx. 3 seconds*)
Double shot: 18 g (approx. 4.5 seconds*)
Manual grinding: ends automacally when the
portafilter is removed from the portafilter intake.
*The grinding me depends on the selected espresso
bean type, the grinding degree selected and the mains frequency
(see the secon “Technical data”).
Checking the grinder and scope of delivery
NOTE!
Risk of damage!
The grinder may be damaged if the packaging is opened carelessly with
a sharp knife or other pointed objects.
– Be very careful when opening.
17
E65S GbW | EN

1. Remove the grinder from its packaging.
2. Check if the delivery is complete (see Fig. A, B, E, G, H, I, J, K, L, M, and
N).
3. Check for damage to the grinder or any of the individual parts.
If damage is present, do not use the grinder. Contact your supplier (see
the secon “Maintenance and service”).
Please note that the grinder is subject to an extensive funconal
test before delivery and may therefore sll contain coffee pow-
der residue.
Seƫng up the grinder and inserƟng the bean hopper
You will need a flat-head screwdriver (not supplied) for fixing the
bean hopper.
1. Place the grinder on a level, stable surface that does not shake or wob-
ble.
2. Make sure that the spout (13) is pushed up as far as possible and is se-
curely locked into the spout locking mechanism (see Fig. D).
3. Make sure that the grinder is switched off(On/Offswitch (5) to “0”) and
connect the grinder to the power supply by inserng the power plug into
a properly installed safety socket.
4. Place the collecng tray (10) into the corresponding recess in the casing
under the spout.
5. Make sure that the rubber ring (19) has been properly posioned in the
bean hopper intake (2) and is lying flat (see Fig. B).
6. Place the bean hopper (1) onto the bean hopper intake.
When placing the bean hopper on, make sure that you place the nose
of the bean hopper into the corresponding recess in the bean hopper
intake.
7. Push the bean hopper down into the bean hopper intake and turn the
bean hopper clockwise to fix it to the grinder.
If the bean hopper cannot be fixed in place by turning it, it may not be
posioned correctly. In this case, align the bean hopper correctly (see
step 6) and then try again by pressing it down and turning it (see also the
“Troubleshoong” chapter).
8. Use a flat-head screwdriver to ghten the locking screw (20) for the bean
hopper by turning it clockwise.
ESPRESSO GRINDER
18

The grinder automacally switches offif the bean hopper is not
aached.
Seƫng up the portafilter support and spout
You will need a flat-head screwdriver to adjust the portafilter
support (not included in the scope of delivery).
Adjust the portafilter support (11) to the size of your espresso machine’s
portafilter (see Fig. C):
1. Make sure that the grinder is switched off(On/Offswitch (5) to posion
“0”).
2. Turn anclockwise using a flat-head screwdriver to loosen the screws (8)
for adjusng the portafilter support (leand right).
The portafilter support is lowered as far as it will go.
3. Insert the portafilter into the portafilter support (12).
4. Push the portafilter support upwards unl the portafilter fits exactly
between the portafilter support and the portafilter intake.
If the portafilter support does not fit, contact your supplier (see
chapter “Maintenance and service”).
5. Hold the portafilter support in posion and fix it by turning the screws
for adjusng the portafilter support (leand right) clockwise unl ght
using a flat-head screwdriver.
6. Push the spout guide (21) up or down in the lock to align the spout (13)
in the opmal posion for your portafilter (see Fig. E).
Align the spout so that the ground coffee falls from the spout into the
centre of the portafilter.
AcƟvaƟng portafilter detecƟon
Grinding using Portafilter Detecon (PFD) requires this feature to
be acvated in advance of grinding.
1. Switch on the grinder by switching the On/Offswitch (5) to “I”.
The grinder is ready for operaon as soon as the last selected recipe /
the start screen appears on the display (14).
19
E65S GbW | EN

2. Press the controller (3) two mes to call up the main menu on the dis-
play.
3. Turn the controller to select the “Sengs” menu item and confirm your
selecon by pressing the controller.
4. Turn the controller to select the “Portafilter management” submenu
item and confirm your selecon by pressing the controller.
You are now in the “Portafilter management” submenu.
5. To use Portafilter Detecon, acvate the detecon mode by pressing the
controller.
The acve symbol lights up green.
6. Leave the submenu by pressing the upper buon (23).
You can now start the portafilter recording process.
Recording portafilters
• In order for the grinder to automacally detect different
portafilters, each portafilter used must be recorded using
Portafilter Detecon (PFD) in a so-called “learning process”.
• You can store up to 6 portafilters on the grinder’s memory.
• As soon as the portafilter is recorded, it can be assigned to a
recipe and acvated (see the “Eding recipes” chapter in the
soware instrucons).
1. Call up the “Portafilter management” submenu and proceed as de-
scribed in chapter “Acvang portafilter detecon” steps 2–4.
2. To record the portafilter, select the “Add portafilter” menu item by turn-
ing the controller (3) and confirm your selecon by pressing the control-
ler.
The message “Please insert portafilter” appears on the display (14).
3. Insert the portafilter between the portafilter support (12) and the porta-
filter intake (11) and let go of the portafilter.
4. If the weight of the portafilter appears on the display with a green
background, detecon has been successful and you will automacally be
taken back to the submenu.
If the display shows the “PF scan failed” message, turn the controller to
select the “Repeat” menu item and confirm your selecon by pressing
the controller. The portafilter will be recorded again.
ESPRESSO GRINDER
20
