Mahr Millimar C 1200 User manual

Compact amplifier
Millimar C 1200
Operating instructions
Mahr GmbH
Standort Esslingen
Reutlinger Str. 48, 73728 Esslingen
Tel. [phone], Fax [phone]
[e-mail], www.mahr.com
0315
3722478

2
Mahr GmbH • Millimar C1200
Dear valued customer,
Congratulations on choosing a product from Mahr GmbH. We kindly request that you follow
these instructions in order to ensure the long term accuracy of this measuring instrument.
We operate a policy of continuous improvement and are constantly developing our products,
especially with regard to renaming of type designations. It is possible therefore that there may
be slight differences between the text and illustrations in this document and the measuring
instrument in your possession. We reserve the right to make changes to the design and scope
of supply, the right to undertake further technical developments, and all rights relating to
translation of this documentation.
© by Mahr GmbH, Esslingen
The following symbols are used in these operating instructions:
General information
Important information
Attention - Danger
Failure to follow instructions marked with these symbols can cause inaccurate results
and lead to considerable damage to this product!
Introduction
Intended working conditions
The Millimar C 1200 is a Compact amplifier (compact electronic length measuring and
evaluating instrument) for use in a production environment. An inductive probe can be
connected to the C1200.
The operating, maintenance and repair information specified in these operating instructions
must be observed.
In order to achieve the best use of this measuring instrument it is very important that you first
read these operating instructions.
The scope of supply of this length measuring instrument includes:
- Measuring instrument
- Mains power supply unit with interchangeable adaptors
- Operating instructions
!

3
Mahr GmbH • Millimar C1200
Forfeiture of warranty
Services that are caused to viruses that were introduced via a network connection or another
data carrier, are generally excluded from the warranty services.
Storage temperatures below –10 °C or above +50 °C and relative humidity levels above 85 %
will invalidate the warranty of this instrument.
Safety information
This measuring instrument complies with the relevant safety regulations. It was dispatched
from our production facility in a flawless condition and perfect working order. However, failure
to follow the instructions given below can cause personal injury or death.
1. Before you connect up and use this measuring instrument for the first time, please read
the accompanying documentation (operating instructions).
Follow the safety precautions detailed in the operating instructions.
2. Keep the documentation close to the measuring instrument ready for quick reference.
3. Follow all safety precautions, accident prevention regulations and internal company rules
and guidelines. If necessary you should request further information from your company
safety officer.
4. Before connecting up this measuring instrument, please check the local mains supply
voltage to ensure that it is within the working range of the AC adaptor (100 V - 240 V,
50 Hz - 60 Hz). If they do not match, this measuring instrument must not be connected
under any circumstances!
5. The instrument may only be connected to a protective earth (grounded) power socket
which complies with the respective vacover guidelines and regulations of the local power
supply company. This also applies to any extension cables that are used.
6. Only use the original and intact AC adaptors.
7. When connecting inductive probes make ensure that the plug is firmly screwed onto the
connection sockets.
8. When connecting pneumatic probes make sure that the compressed air is connected
properly.
9. Do not drop the measuring instrument. Always make sure that the measuring instrument
is securely positioned.
10. Do not operate the measuring instrument in areas where there is a risk of explosion.
Also do not expose the measuring instrument to direct sunlight!
11. Do not clean the membrane keypad with solvent-based cleaning agents.
12. Before opening the housing always disconnect the power supply.
13. The test and measuring equipment for which the Millimar is used are subject to
inspection equipment monitoring.
For this reason, regular inspection equipment monitoring performed by either the user or
Mahr Service must ensure compliance to the specified error limits.
!

4
Mahr GmbH • Millimar C1200
Confirmation of traceability
We declare under our sole responsibility that this pro-
duct is in conformity with standards and technical data
as specified in our sales documents (operating instruc-
tions, leaflet, catalogue).
We certify that the measuring equipment used to check
this product, and guaranteed by our Quality Assurance,
is traceable to national standards.
Thank you very much for your confidence in
purchasing this product.
EC Declaration of Conformity
This measuring instrument conforms to
the Low Voltage Directive 2006/95/EG
and the Directive 2004/108/EG which
concerns Electromagnetic compatibility.
Important hints prior to using the Length measuring instrument
• Themeasuringinstrumentmayonlybeusedforitsintendedpurpose.Fordamages
caused by other usage or as a result of the incorrect application of this measuring instru-
ment, no liability will be accepted.
• Shouldyourspecicmeasuringtasknotbesolvedwiththismeasuringinstrument:please
contact us; we can solve your measuring task with a different measuring instrument.
Pleaseinformusofyourmeasuringtasksothatwecanndforyoutheidealmeasuring
solution.
• Battery
• Not rechargeable
• Do not incinerate
• Dispose off as prescribed
!Do not use an electric marking tool
Information regarding RoHS:
Electronic equipment which where bought from Mahr after the 23. March 2006 can be returned
to us for disposal. We will dispose/recycle our products without causing any harm or damage
to the environment in accordance to the EU-Directives 2002/95/EC RoHS (the Restriction
of the use of certain Hazardous Substances) and 2002/96/EC WEEE (Waste Electrical and
Electronic Equipment) as well as German National - Electrical and Electronic Equipment Act,
FRG.

5
Mahr GmbH • Millimar C1200
Declaration of conformity

6
Mahr GmbH • Millimar C1200
Table of Contents
1. Delivery and setting up
1.1 Unpacking the measuring instrument............................................................ 8
1.2 Scope of supply............................................................................................. 9
1.3 Symbols ................................................................................................. 10
1.4 Operating controls and interfaces ............................................................... 12
1.4.1 Display and operating keys ......................................................................... 12
1.4.2 Interfaces ................................................................................................. 12
1.4.3 Battery compartment................................................................................... 13
2. Initial operation (basic configuration)
2.1 Switching ON .............................................................................................. 14
2.2 Select the display language ........................................................................ 14
2.3 Set unit of measurement ............................................................................. 14
2.4 Select probe ................................................................................................ 15
2.5 Scale graduation of the analog display ....................................................... 15
2.6 Connecting the probe.................................................................................. 16
2.7 Select type of probe .................................................................................... 16
2.8 Setting up the selected probe ..................................................................... 17
2.9 Switching OFF............................................................................................. 18
3. Menu Measurement
3.1 Select Master .............................................................................................. 19
3.2 Choose Nominal value ................................................................................ 20
3.3 Select Tolerance.......................................................................................... 21
3.4 Choose the Formula.................................................................................... 23
3.5 Select the Factor ......................................................................................... 24
4. Menu Display
4.1 Select Resolution ........................................................................................ 25
4.2 Choose the Display style............................................................................. 26
4.3 Select the Color scheme ............................................................................. 27
4.4 Set the Brightness....................................................................................... 28
5. Menu Setup
5.1 Select Langauge ......................................................................................... 29
5.2 Choose the Unit of measurement ............................................................... 30
5.3 Select the Probe type.................................................................................. 31
5.4 Select the ECO mode ................................................................................. 32

7
Mahr GmbH • Millimar C1200
6. Menu System
6.1 Select the Absolute mode ........................................................................... 33
6.2 Select Customer calibration ........................................................................ 34
6.2.1 Active customer calibration ......................................................................... 34
6.2.2 Execute a Probe calibration ........................................................................ 35
6.2.3 Conduct a Factory standard calibration ...................................................... 37
6.2.4 Execute a Customer calibration Reset........................................................ 40
6.3 Activate a Factory calibration ...................................................................... 41
6.4 Reset to Factory settings ............................................................................ 42
6.5 Request firmware version and serial number.............................................. 43
7. Description of the interfaces
7.1 Suitable Data connection cables................................................................. 44
7.2 Interfaces: Opto RS232C,Digimatic, USB................................................... 44
7.3 Data transmission parameters .................................................................... 45
8. Technical Data
8.1 Compact amplifier Millimar C1200 .............................................................. 46
8.2 Compatible probes for Millimar C1200........................................................ 47
9. Spare Parts
9.1 Available spare parts................................................................................... 48

8
Mahr GmbH • Millimar C1200
1. Delivery and setting up
1.1 Unpacking the measuring instrument

9
Mahr GmbH • Millimar C1200
1.2 Scope of supply

10
Mahr GmbH • Millimar C1200
1.3 Symbols
– Select Menu
– Set zero point (RESET)
– Reduce the resolution
– Increase resolution
– Start data transmission
– Scroll up
– Scroll down
– Scroll to the right
– Scroll to the left
– Confirm
– Cancel
– Exit menu

11
Mahr GmbH • Millimar C1200
– Battery mode
– Change batteries
– Battery low
– Mains power supply mode
– Formula measuring combination
– Data is been transferred
– Factor is not equal to 1

12
Mahr GmbH • Millimar C1200
1.4 Operating controls and interfaces
1.4.1 Display and operating keys
Display
Operating keys
AC Mains power
supply socket
1.4.2 Interfaces
Data output Probe input A
Battery
compartment

13
Mahr GmbH • Millimar C1200
1.4.3 Battery compartment
The battery compartment is integrated
in the base
– Turn over the measuring instrument
through 180°
– Remove the locking screw 1
– To open the battery compartment
press in Tab 2and lift off the battery
compartment cover
– Correctly insert 5 batteries or
rechargeable batteries, type AA
Observe polarity of the batteries!
– Close the battery compartment cover
in the reverse order.
If connected to the mains power
supply, the measuring instrument
will automatically switch to AC mains
power supply!
Battery compartment
cover
!
Battery
compartment
1
2

14
Mahr GmbH • Millimar C1200
Welcome!
Please select your language:
English
中文
Čeština
English
Français
Italiano
Polski
3q p
Welcome!
Please select the measurement unit:
mm
µm
inch
3q p
2. Initial operation
2.1 Switching ON
– Connect the mains power supply unit
to the measuring instrument via the
AC mains power supply socket and/or
insert the batteries (rechargeable).
– Press the ON / OFF key
=> In the display will appear the:
Start screen
2.3 Set unit of measurement
– Select the required unit the q oder p
keys
– Confirm by pressing the 4key
2.2 Select the display language
– Select the required language with the
q or p keys
– Confirm by pressing the 4key

15
Mahr GmbH • Millimar C1200
+A mm
-0.001
-0.1 0 0.1
ut tu
0
Welcome!
Please select the probe type:
Standard Probe
Long Probe
t3qp
2.5 Scale graduation of the analog
display
– Select the required resolution with the
ut or t
ukeys.
2.4 Select probe
– Select the required probe with q or p
keys
=> For compatible probes, see Chapter
8.2, Page 47
– Confirm by pressing the 4key

16
Mahr GmbH • Millimar C1200
Measurement Display Setup System
Language English
Unit mm
Probe type Standard Probe
ECO mode On
6 3 q p
Measurement Display Setup System
Language English
Unit mm
Probe type Standard Probe
ECO mode On
t u q
6 3 q
Measurement Display Setup System
Probe type
Standard Probe
Long Probe
2.6 Connecting the probe
– Connect the probe to the probe input
A
2.7 Select type of probe
– Press the ON / OFF key
=> The standard menu will appear on
the screen
– Select the Setup menu with the u
or tkeys
– Select the Probe type with the q or
p keys
– Press 4 to select the probe type or
press Óto cancel selection
– Select the required Probe type with
the q or p.
=> For compatible probes, see Chapter
8.2, Page 47
– Press 4 to select the probe type or
press Óto cancel selection
– To exit the menu, press the ON / OFF
key.
Probe input A

17
Mahr GmbH • Millimar C1200
Measurement Display Setup System
Master 0.0000
Nominal value 0.0000
Tolerance Off-0.5000˂0>+0.5000
Formula +A
Factor 1.0000
u q
ABSOLUTE mm
-0.001
-0.1 0 0.1
3ut tu
Measurement Display Setup System
Absolute mode
Customer calibration
Factory calibration
Factory Settings
Info
ü
6 3 q p
Measurement Display Setup System
Absolute mode
Customer calibration
Factory calibration
Factory Settings
Info
t q
ü
2.8 Setting up the selected probe
– Press the ON / OFF key
=> The standard menu will appear on
the screen
In order to guarantee the maximum accuracy, the zero point of the probe should be set
from the mechanical to electrical zero before the first measurement is conducted. Use
the absolute mode setup to show the probe's raw value / the Absolute value.
!
– Select menu System with the ukey
– Select the submenu Absolute mode
with the q key and press 4to confirm
– Set the probe mechanically to "0"
– Use the keys ut and t
uto adjust
the scale
– Press 4 to confirm
– To exit the input menu, press the ON /
OFF key.

18
Mahr GmbH • Millimar C1200
+A mm
-0.001
-0.1 0 0.1
ut tu
0
2.9 Switching OFF
In the Input menu it is not possible to
switch off this measuring instrument
by pressing the ON / OFF key.
– To switch off this measuring
instrument you must firstly exit the
Input menu.
=> The analog display will appear on
the screen
– Press the ON / OFF key for > 2
seconds.
!

19
Mahr GmbH • Millimar C1200
Measurement Display Setup System
Master
+000 . 0000
3 6 u q p
Measurement Display Setup System
Master 0.0000
Nominal value 0.0000
Tolerance Off-0.5000˂0>+0.5000
Formula +A
Factor 1.0000
6 3 q p
Measurement Display Setup System
Master
+000 . 0000
3 6 u q p
3. Menu Measurement
3.1 Select Master
– Press the ON / OFF key
=> The standard menu will appear on
the screen
– Select the submenu Master with the
q p keys
– Press 4 to confirm
– With the q p keys select the required
plus/minus (+/-) symbol
– With the uselect the next position
(digit)
– Use the q p keys to enter the
required value
– By the pressing the Ókey for for than
2 seconds, the input will be reset to
zero "0".
– Press 4 to confirm or press Óto
cancel selection
– To exit the input menu, press the ON /
OFF key.

20
Mahr GmbH • Millimar C1200
Measurement Display Setup System
Master 0.0000
Nominal value 0.0000
Tolerance Aus-0.5000˂0>+0.5000
Formula +A
Factor 1.0000
6 3 q p
Measurement Display Setup System
Nominal value
+100 . 0000
3 6 u q p
Measurement Display Setup System
Nominal value
+000 . 0000
3 6 u q p
3.2 Choose Nominal value
– Press the ON / OFF key
=> The standard menu will appear on
the screen
– Select the submenu Nominal value
with the q p keys
– Press 4 to confirm
– With the q p keys select the required
plus/minus (+/-) symbol
– With the uselect the next position
(digit)
– Use the q p keys to enter the
required value
– By the pressing the Ókey for for than
2 seconds, the input will be reset to
zero "0".
– Press 4 to confirm or press Óto
cancel selection
– To exit the input menu, press the ON /
OFF key.
