Makita UB401MP User guide

UB401MP
EN Blower Attachment ORIGINAL INSTRUCTION
MANUAL 5
PTBR Implemento Soprador MANUAL DE INSTRUÇÕES
ORIGINAL 12
ES Accesorio de Soplado MANUAL DE
INSTRUCCIONES ORIGINAL 19
ZHCN 吹风附件 原版使用说明书 27
ZHTW 吹風機組 原始操作手冊 34
KO 브로어 어테치먼트 취급 설명서 41
ID Perangkat Tambahan Blower PETUNJUK PENGGUNAAN
ASLI 47
MS Alat Tambahan Penghembus MANUAL ARAHAN ASAL 55
VI   63
TH   70
AR   84
FA   90

15 m
Fig.1
Fig.2
2
1
3
Fig.3
1
2
Fig.4
1
Fig.5
1
2
3
4
5
Fig.6
1
Fig.7
Fig.12
3
1
2
Fig.8
2

1
Fig.9
2
1
Fig.10
3
1
2
Fig.11
Fig.12
Fig.13
1
Fig.14
Fig.15
3

Fig.16
4

5ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: UB401MP
Capacities *1 Air volume 0 - 14.6 m3/min
Air speed (average) 0 - 48.3 m/s
Air speed (max.) 0 - 58.1 m/s
Capacities *2 Air volume 0 - 12.4 m3/min
Air speed (average) 0 - 41.2 m/s
Air speed (max.) 0 - 49.7 m/s
Capacities *3 Air volume 0 - 15.6 m3/min
Air speed (average) 0 - 51.7 m/s
Air speed (max.) 0 - 62.1 m/s
Capacities *4 Air volume 0 - 14.1 m3/min
Air speed (average) 0 - 46.7 m/s
Air speed (max.) 0 - 56.1 m/s
Overall length 895 mm
Net weight 2.1 kg
*1. Capacities of blower attachment in conjunction with DUX60 Cordless Multi Function Power Head
*2. Capacities of blower attachment in conjunction with DUX18 Cordless Multi Function Power Head
*3. Capacities of blower attachment in conjunction with UX01G Cordless Multi Function Power Head (with battery
BL4040)
*4. Capacities of blower attachment in conjunction with EX2650LH Multi Function Power Head
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydi󰀨erfromcountrytocountry.
Approved power unit
This attachment is approved to use only with the follow-
ing power unit(s):
• DUX60 Cordless multi function power head
• DUX18 Cordless multi function power head
• UX01G Cordless multi function power head
• EX2650LH Multi function power head
WARNING: Never use the attachment with
non-approved power unit. Non-approved combi-
nation may cause serious injury.
NOTE: In European countries, UK, Russia, Australia,
New Zealand, Korea, China, South Africa, etc. which
have EMI regulation, this attachment cannot be used
in conjunction with DUX60 manufactured before
October 2020.
Symbols
The followings show the symbols which may be used
for the equipment. Be sure that you understand their
meaning before use.
Take particular care and attention.
Read instruction manual.
Keep hands away from rotating parts.
Keep bystanders away.
Wear eye and ear protection.
Long hair may cause entanglement
accident.
Keep distance at least 15 m.
Ni-MH
Li-ion
Only for EU countries
Do not dispose of electric equipment or
battery pack together with household waste
material!
In observance of the European Directives,
on Waste Electric and Electronic
Equipment and Batteries and Accumulators
and Waste Batteries and Accumulators
and their implementation in accordance
with national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.

6ENGLISH
Intended use
This attachment is designed for only the purpose of
blowing dust in conjunction with an approved power
unit. Never use the attachment for other purposes.
Abusing the attachment may cause serious injury.
SAFETY WARNINGS
Blower Safety Instructions
WARNING: Read all safety warnings,
-
vided with this machine as well as the instruction
manual of the power unit before using. Failure to
follow all instructions listed below may result in elec-
tricshock,re,and/orseriousinjurytotheoperator
and/or bystanders.
Save all warnings and instruc-
tions for future reference.
The term “blower” and “machine” in the warnings and
precautions refer to the combination of the attachment
and the power unit.
The term “motor” in the warnings and precautions refers
to the engine or electric motor of the power unit.
Training
1. Read the instructions carefully. Be familiar
with the controls and the correct use of the
blower.
2. Never allow children, persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge or people
unfamiliar with these instructions to use the
blower. Local regulations may restrict the age
of the operator.
3. Never operate the blower while people, espe-
cially children, or pets are nearby.
4. Keep in mind that the operator or user is
responsible for accidents or hazards occurring
to other people or their property.
Preparation
1. Always wear substantial footwear and long
trousers while operating the blower.
2. Do not wear loose clothing or jewellery that
can be drawn into the air inlet. Keep long hair
away from the air inlets.
3. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
4. To prevent dust irritation the wearing of a face
mask is recommended.
5. While operating the machine, always wear
non-slip and protective footwear. Non-skid,
closed-toed safety boots and shoes will reduce the
risk of injury.
6. 󰀨
Exposure to noise can cause hearing loss.
7. Start and operate the engine only outdoors in
a well ventilated area.Operationinaconnedor
poorly ventilated area can result in death due to
su󰀨ocationorcarbonmonoxidepoisoning.
Operation
1. Clear the area of children, bystanders, and
pets. At a minimum, keep all children, bystand-
ers, and pets outside a 15 m radius; outside
the 15 m zone, there is still a risk of injury
from thrown objects. Bystanders should be
encouraged to wear eye protection. If you are
approached, stop the engine or machine.
►Fig.1
2. 󰀨
cartridge or the spark plug cap, and make sure
that all moving parts have come to a complete
stop
• whenever you leave the blower.
• before clearing blockages.
• before checking, cleaning or working on
the blower.
• if the blower starts to vibrate abnormally.
3. Operate the blower only in daylight or in good

4. Do not overreach and keep proper balance and
footing at all times.
5. Always be sure of your footing on slopes.
6. Walk, never run.
7. Keep all cooling air inlets clear of debris.
8. Never blow debris in the direction of
bystanders.
9. Operate the blower in a recommended position

10. Do not operate the blower at high places.
11. Never point the nozzle at anyone in the vicinity
when using the blower.

7ENGLISH
12. Never block suction inlet and/or blower outlet.
• Be careful not to block suction inlet or
blower outlet with dust or dirt when oper-
ating in dusty area.
• Do not use nozzles other than the nozzles
provided by Makita.
• 
rubber boat or the similar.
13. Do not operate the blower near open window,
etc.
14. Operating the blower only at reasonable hours
is recommended - not early in the morning or
late at night when people might be disturbed.
15. Using rakes and brooms to loosen debris
before blowing is recommended.
16. Before blowing, slightly dampen surfaces in
dusty conditions or use water mist sprayer if
necessary.
17. Adjust the length of the blower nozzle so that
the air stream can work close to the ground.
18. If the blower strikes any foreign objects or
should start making any unusual noise or
󰀨
to stop it. Remove the battery cartridge or the
spark plug cap, and inspect the blower for
damage before restarting and operating the
blower. If the blower is damaged, ask Makita
Authorized Service Centers for repair.
19. 
suction inlet or blower outlet.
20. Prevent unintentional starting. Ensure the
󰀨
battery cartridge, picking up or carrying the

on the switch or energizing the blower that has
the switch on invites accidents.
21. Never blow dangerous materials, such as
nails, fragments of glass, or blades.
22. 
materials.
23. Avoid operating the blower for a long time in
low temperature environment.
24. Before assembling or adjusting the machine,
󰀨
plug cap or the battery cartridge.
25. Wear the personal protective equipments
before starting the motor.
26. Before starting the motor, inspect the machine
for damages, loose screws/nuts or improper
assembly. Check all control levers and
switches for easy action. Clean and dry the
handles.
27. Never attempt to start the motor if the machine
is damaged or not fully assembled.
28. Adjust the shoulder harness and hand grip to
suit the operator's body size.
29. With the engine running only at idle, attach the
shoulder harness.
30. During operation, use the shoulder harness.

►Fig.2
31. Hold the front handle with the left hand and the
rear grip with the right hand, no matter you are

and thumbs around the handles.
32. Never attempt to operate the machine with one
hand. Loss of control may result in an injury.
33. If the machine gets heavy impact or fall, check
the condition before continuing work. Check
the fuel system for fuel leakage and the con-
trols and safety devices for malfunction. If
there is any damage or doubt, ask our autho-
rized service center for the inspection and
repair.
34. Follow the instruction manual of the power
unit for proper use of the control lever and
switch.
35. During or after operation, do not put the
hot machine onto dry grass or combustible
materials.
36. Refer to the instruction manual of the power
unit for how to start and control the machine.
Refueling
1. Stop the engine before refueling. Keep away

during refueling.Otherwisereand/orexplosion
may result.
2. Refuel outdoors. Refueling in a closed room can
cause explosion of fuel vapor.
3. Avoid contact with fuel or engine oil. Do not
󰀨
of the machine and/or ground immediately. If
fuel spills on your clothes, change it immedi-

4. After refueling, carefully tighten the fuel tank
cap and check for fuel leak. Move at least 3 m
(10 feet) away from the fueling source and site
before starting engine.
5. Only transport and store fuel in approved con-
tainers. Keep children away from the stored
fuel.
Transportation
1. Stop the motor during transportation.
Otherwise unintentional start-up may cause injury.
2. Ensure safe position of the machine during car
transportation to avoid fuel leakage.
3. Lift the entire machine from the ground when
carrying the machine. Dragging the machine
causes fuel tank damage and fuel leakage, result-
inginre.
4. When transporting the equipment, carry it in a
horizontal position by holding the shaft. Keep
󰀪
Vibration
1. Exposing to excessive vibration injures blood
vessels or nervous system of the operator and

hands or wrists: “Falling asleep” (numbness),
tingling, pain, stabbing sensation, alteration of
skin color or of the skin. If any of these symp-
toms occur, see a physician.

keep your hands warm during operation and
well maintain the machine and accessories.

8ENGLISH
Maintenance and storage
1. Keep all nuts, bolts and screws tight to be sure
the blower is in safe working condition.
2. If the parts are worn or damaged, replace them
with parts provided by Makita.
3. Store the blower in a dry place out of the reach
of children.
4. When you stop the blower for inspection, ser-
vicing, storage, or changing accessory, switch
󰀨
parts come to a complete stop, and remove the
battery cartridge or the spark plug cap. Cool
down the blower before making any work on
the blower. Maintain the blower with care and
keep it clean.
5. Always cool down the blower before storing.
6. Do not expose the blower to rain. Store the
blower indoors.
7. When you lift the blower, be sure to bend your
knees and be careful not to hurt your back.
8. 

9. 󰀨
Never use gasoline, benzine, thinner, alcohol
or the like for the purpose. Discoloration, defor-
mation or cracks of the plastic components may
result.
10. After each use, tighten all screws and nuts,
except for the carburetor adjustment screws.
11. Do not attempt any maintenance or repair not
described in this instruction manual or the
instruction manual of the power unit. Ask our
authorized service center for such work.
12. Follow instructions for lubricating and chang-
ing accessories.
13. Always use the genuine spare parts and acces-
sories only. Using parts or accessories supplied
by a third party may result in the equipment break-
down, property damage and/or serious injury.
14. Request our authorized service center to
inspect and maintain the machine at regular
interval.
15. Before storing the machine, perform full clean-
ing and maintenance. Remove the spark plug
cap or the battery cartridge. Drain the fuel after
the engine gets cold.
16. Do not prop the equipment against something,
such as a wall. Otherwise it may fall suddenly
and cause an injury.
Battery tool use and care
1. 
the manufacturer. A charger that is suitable for
onetypeofbatterypackmaycreateariskofre
when used with another battery pack.
2. -
nated battery packs. Use of any other battery
packsmaycreateariskofinjuryandre.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nalstogethermaycauseburnsorare.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-

liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause
irritation or burns.
5. Do not use a battery pack or tool that is dam-
Damagedormodiedbatteries
may exhibit unpredictable behaviour resulting in
re,explosionorriskofinjury.
6. 
excessive temperature.Exposuretoreortem-
perature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
-
tions. Charging improperly or at temperatures
outsidethespeciedrangemaydamagethe
batteryandincreasetheriskofre.
Electrical and battery safety
1. 
The cell may explode. Check with local codes for
possible special disposal instructions.
2. Do not open or mutilate the battery(ies).
Released electrolyte is corrosive and may cause
damage to the eyes or skin. It may be toxic if
swallowed.
3. Do not charge battery in rain, or in wet
locations.
4. Do not charge the battery outdoors.
5. Do not handle charger, including charger plug,
and charger terminals with wet hands.
Service
1. 
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
First Aid
1. 
box is available in the vicinity of the opera-
tions. Immediately replace any item taken from

2. When asking for help, give the following
information:
— Place of accident
— What happened
— Number of injured persons
— Kind of injuries
— Your name
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product.
MISUSE or failure to follow the safety rules stated
in this instruction manual may cause serious
personal injury.

9ENGLISH
WARNING: Use of this product can create
dust containing chemicals which may cause
respiratory or other illnesses. Some examples of
these chemicals are compounds found in pes-
ticides, insecticides, fertilizers and herbicides.
Your risk from these exposures varies, depend-
ing on how often you do this type of work. To
reduce your exposure to these chemicals: work
in a well ventilated area, and work with approved
safety equipment, such as those dust masks that

particles.
PARTS DESCRIPTION
►Fig.3: 1. Cap 2. Pipe 3. Front nozzle
ASSEMBLY
WARNING: Before assembling or adjusting
󰀨
remove the spark plug cap or battery cartridge.
Otherwise, the fans may move and result in an injury.
WARNING: When assembling or adjusting
the equipment, always put it down. Assembling or
adjusting the equipment in an upright position may
result in serious injury.
WARNING: Follow the warnings and precau-
tions in the chapter “SAFETY WARNINGS” and
the instruction manual of the power unit.
Mounting the attachment pipe
CAUTION: Always check that the attach-
ment pipe is secured after installation. Improper
installationmaycausetheattachmentfallingo󰀨from
the power unit and cause personal injury.
Mount the attachment pipe to the power unit.
1. Remove the cap from the end of the pipe.
►Fig.4: 1. Pipe 2. Cap
NOTICE: Do not dispose of the cap since the
cap is necessary for storing the attachment.
2. Turn the lever toward the attachment.
►Fig.5: 1. Lever
3. Align the pin with the arrow mark on the power
unit. Insert the pipe until the release button pops up.
Make sure that the position line is on the tip of the arrow
mark on the power unit, and the arrow mark on the
power unit and the arrow mark on the pipe are facing
each other.
►Fig.6: 1. Release button 2. Arrow mark on the
power unit 3. Pin 4. Position line 5. Arrow
mark on the pipe
4. Turn the lever toward the power unit.
►Fig.7: 1. Lever
Make sure that the surface of the lever is parallel to the
pipe.
NOTICE: Do not tighten the lever without the
attachment pipe inserted. Otherwise the lever may
tighten the entrance of the drive shaft too much and
damage it.
To remove the pipe, turn the lever toward the attach-
ment and pull the pipe out while pressing down the
release button.
►Fig.8: 1. Release button 2. Lever 3. Pipe

extension nozzle
Optional accessory
1. Remove the front nozzle by turning it as shown in
thegure.
►Fig.9: 1. Front nozzle
2. Attach the adapter pipe to the attachment, and
then turn it to lock it into place.
►Fig.10: 1. Adapter pipe 2. Attachment
3. Attachtheatnozzleorextensionnozzletothe
adapter pipe, and then turn it to lock it into place.
►Fig.11: 1. Flat nozzle 2. Extension nozzle
3. Adapter pipe
NOTICE: The grooves on the deep side of the



OPERATION
WARNING: Follow the warnings and precau-
tions in the chapter “SAFETY WARNINGS” and
the instruction manual of the power unit.
WARNING: Adjust the hanger position and
shoulder harness to your comfortable position
before operating.
CAUTION: Do not place the machine on the
ground while it is switched on. Sand or dust may
enter from suction inlet and cause a malfunction or
personal injury.
Holdthemachinermlywithbothhandsandperform
the blowing operation by moving it around slowly. When
blowing around building, big stone or vehicle, direct the
nozzle away from them. When performing an operation
in a corner, start from the corner and then move to wide
area.
Adjust the air speed with the switch trigger or throttle
lever of the power unit according to the environment or
conditions of your usage.
►Fig.12

10 ENGLISH
MAINTENANCE
WARNING: Before inspecting or main-
󰀨
remove the battery cartridge, or stop the engine
and remove the spark plug cap. Otherwise, the fans
may move and result in serious injury.
WARNING: When inspecting or maintaining
the equipment, always put it down. Assembling or
adjusting the equipment in an upright position may
result in serious injury.
WARNING: Follow the warnings and precau-
tions in the chapter “SAFETY WARNINGS” and
the instruction manual of the power unit.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
Cleaning the machine
Cleanthemachinebywipingo󰀨dustwithadryclothor
one dipped in soapy water and wrung out.
►Fig.13
Remove dust or dirt from the suction inlet at the rear of
the attachment.
►Fig.14: 1. Suction inlet
Overall inspection
Check for damaged parts. Ask our authorized service
center to replace them if necessary.
Lubricating moving parts
NOTICE: Follow the instruction of the fre-
quency and amount of grease supplied. Otherwise
insu󰀩cientlubricationmaydamagemovingparts.
Drive axle:
Apply grease (Makita grease N No.2 or equivalent)
every 30 hours of operation.
►Fig.15
NOTE: Genuine Makita grease may be purchased
from your local Makita dealer.
Storage
When storing the attachment separated from the power
unit, put the cap onto the end of the pipe.
►Fig.16
Interval of inspection and maintenance
Operating hour Before
Operation
Daily (10 hours) 30 hours
Whole unit Visually inspect for damaged parts - -
Drive axle Supply grease - -
Power unit Refer to the instruction manual of the power unit

11 ENGLISH
TROUBLESHOOTING
Beforeaskingforrepairs,conductyourowninspectionrst.Ifyoundaproblemthatisnotexplainedinthemanual,
do not attempt to disassemble the machine. Instead, ask Makita Authorized Service Centers, always using Makita
replacement parts for repairs.
State of abnormality Probable cause (malfunction) Remedy
Motor or engine does not start. -Refer to the instruction manual of the power unit.
Motor or engine stops soon. -Refer to the instruction manual of the power unit.
Motor or engine speed does not
increase.
-Refer to the instruction manual of the power unit.
Fans do not rotate.
Stop the motor or engine
immediately.
The pipes of the power unit and the
attachment are not connected properly.
Connect the pipes in the correct way.
Abnormal drive system Contact an authorized service center for repairs.
Power unit vibrates abnormally.
Stop the motor or engine
immediately.
Abnormal drive system Contact an authorized service center for repairs.
Fans continue to rotate even if the
switch trigger/lever is released.
Stop the motor or engine
immediately.
The power unit does not work properly. Adjust the idle speed if the power unit is engine-op-
erated. Contact an authorized service center for
repairs.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attach-
ments are recommended for use with your Makita
 The use of any
other accessories or attachments might present a risk
of injury to persons. Only use accessory or attach-
ment for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Adapter pipe
• Extension nozzle
• Flat nozzle
• Gutter nozzle set
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
product package as standard accessories. They may
di󰀨erfromcountrytocountry.

91

Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi 446-8502 Japan
www.makita.com
885865-910
EN, PTBR, ES,
ZHCN, ZHTW, KO,
ID, MS, VI, TH, AR,
FA
20201120
