Makita PT354D User manual
INSTRUCTION MANUAL
Cordless Pin Nailer
PT354D
ENGLISH: Original instructions
Read before use.
2ENGLISH
SPECIFICATIONS
Model: PT354D
Pin nail size ø0.6 mm x 15, 18, 25, 30, 35 mm
Pin nail magazine capacity 100 pcs.
Dimensions without hook (L x W x H) 231 mm x 80 mm x 226 mm
Rated voltage D.C. 10.8 V - 12 V max
Battery cartridge BL1016, BL1021B BL1041B
Net weight 1.8 kg 2.0 kg
without notice.
-
Symbols
-
ment. Be sure that you understand their meaning before
use.
Read instruction manual.
Cd
Ni-MH
Li-ion
Only for EU countries
battery pack together with household waste
material!
In observance of the European Directives,
on Waste Electric and Electronic
and their implementation in accordance
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.
Intended use
-
tion materials such as timbers.
Noise
-
ing to EN60745:
WARNING: Wear ear protection.
Vibration
EN60745:
Vibration emission (ah2or less
2
NOTE:
been measured in accordance with the standard test
method and may be used for comparing one tool with
another.
NOTE:
may also be used in a preliminary assessment of
exposure.
WARNING:
use of the power tool can differ from the declared
emission value depending on the ways in which the
tool is used.
WARNING: Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it is
running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
to this instruction manual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings and
all instructions. Failure to follow the warnings and
Save all warnings and instruc-
tions for future reference.
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
3ENGLISH
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
Personal Safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
-
ication.
2. Use personal protective equipment. Always
wear eye protection.
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on.
attached to a rotating part of the power tool may
5. Do not overreach. Keep proper footing and
balance at all times.
of the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing, and gloves
away from moving parts.-
lery or long hair can be caught in moving parts.
7. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application.
rate for which it was designed.
2. Do not use the power tool if the switch does
not turn it on and off.
be controlled with the switch is dangerous and
must be repaired.
3. Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools.-
ventive safety measures reduce the risk of starting
the power tool accidentally.
4. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool. Power tools are dangerous in the
hands of untrained users.
5. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
Battery tool use and care
1.
the manufacturer.
when used with another battery pack.
2. -
nated battery packs. Use of any other battery
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another.-
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
liquid contacts eyes, additionally seek medical
help.
irritation or burns.
4ENGLISH
Service
1.
repair person using only identical replacement
parts.
tool is maintained.
2. Follow instruction for lubricating and chang-
ing accessories.
3. Keep handles dry, clean and free from oil and
grease.
Cordless nailer safety warnings
1. Always assume that the tool contains fasten-
ers. Careless handling of the nailer can result in
2. Do not point the tool towards yourself or any-
one nearby. Unexpected triggering will discharge
3. Do not actuate the tool unless the tool is
If the tool
is not in contact with the workpiece, the fastener
4. Disconnect the tool from the power source
when the fastener jams in the tool. While
accidentally activated if it is plugged in.
5. Use caution while removing a jammed fas-
tener.
and the fastener may be forcefully discharged
6. Do not use this nailer for fastening electrical
cables. It is not designed for electric cable instal-
lation and may damage the insulation of electric
hazards.
7. Always wear safety glasses to protect your
eyes from dust or fastener injury.
WARNING: It is an employer's responsibility
to enforce the use of safety eye protection
equipment by the tool operators and by other
persons in the immediate working area.
8. Keep hands and feet away from the ejection
port area.
9. Follow instruction for lubricating and chang-
ing accessories.
10. Always remove the battery cartridge before
loading the fasteners, adjustment, inspection,
maintenance or after operation is over.
11. Make sure no one is nearby before operation.
Never attempt to drive fasteners from both the
inside and outside of wall at the same time.
-
senting a grave danger.
12. Watch your footing and maintain your balance
with the tool. Make sure there is no one below
when working in high locations.
13. Never use fastener driving tools marked with
the symbol "Do not use on scaffoldings, lad-
another involves the use of scaffoldings,
stairs, ladders, or ladder alike constructions,
e.g. roof laths;
vehicles and wagons.
14.
the like carefully to avoid possible electrical
shock, gas leakage, explosions, etc. caused by
stapling into live wires, conduits or gas pipes.
15.
The use of any other fasteners may cause
malfunction of the tool.
16. Do not tamper with the tool or attempt to use it
for other than driving fasteners.
17. Do not operate the tool without fasteners. It
shortens the service life of the tool.
18. Stop driving operations immediately if you
notice something wrong or out of the ordinary
with the tool.
19. Never fasten into any materials which may
as a projectile.
20. Never actuate the switch trigger and contact
element at the same time until you are pre-
pared to fasten workpieces. Allow the work-
piece to depress the contact element. Never
defeat its purpose by securing the contact
element back or by depressing it by hand.
21. Never tamper with the contact element. Check
the contact element frequently for proper
operations.
22. Always remove fasteners from the tool when
not in use.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
5ENGLISH
A battery short can cause a large current
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
For commercial transports e.g. by third parties,
-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
Please also observe possibly more detailed
national regulations.
battery in such a manner that it cannot move
around in the packaging.
11. Follow your local regulations relating to dis-
posal of battery.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting
also void the Makita warranty for the Makita tool and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: Always switch off the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
cartridge. Failure to hold the tool and the battery
and result in damage to the tool and battery cartridge
1
2
3
1. Red indicator 2. Button 3. Battery cartridge
while sliding the button on the front of the cartridge.
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator on the
upper side of the button, it is not locked completely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Battery protection system
extend battery life.
conditions:
6ENGLISH
Overloaded:
an abnormally high current.
In this situation, turn the tool off and stop the application
the tool on to restart.
If the tool does not start, the battery is overheated. In
this situation, let the battery cool before turning the tool
on again.
Low battery voltage:
will not operate. If you turn the tool on, the motor does
not run or the motor runs again but stops soon. In this
situation, remove and recharge the battery.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
1
2
1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
light up for few seconds.
Indicator lamps Remaining
capacity
Lighted Off
75% to 100%
50% to 75%
25% to 50%
0% to 25%
NOTE: Depending on the conditions of use and the
ambient temperature, the indication may differ slightly
from the actual capacity.
Trigger-lock button
CAUTION: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the "OFF" position when released.
CAUTION: When not operating the tool,
depress the trigger-lock button from B side to
lock the switch trigger in the OFF position.
1
2
1.2.
A
B
the trigger-lock button is provided.
B side.
Adjusting the depth of pin-nailing
WARNING: Always make sure that your
the contact element and the battery cartridge is
removed before adjusting the depth of nailing.
maximum.
7ENGLISH
AB
1
1.
2
13
1.2. Flush 3.
Lighting up the lamp
CAUTION: Do not look in the light or see the
source of light directly.
Pull the switch trigger or actuate the contact element to
-
ing the switch trigger or actuating the contact element.
releasing the switch trigger and the contact element.
1
1. Lamp
NOTE: Use a dry cloth to wipe the dirt off the lens of
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.
NOTE: Even in the lamp lights up when the battery
nails. In this case, charge the battery cartridge.
ASSEMBLY
CAUTION:
are not placed on the switch trigger or the contact
element and the battery cartridge is removed
before carrying out any work on the pin nailer.
Loading the pin nailer
CAUTION: Always make sure that the battery
cartridge is removed before loading the pin nailer.
property damage.
CAUTION: Do not abruptly slide the magazine
of the pin nailer loaded with pin nails.
dropping pin nails especially when working in high
CAUTION:
Load pin nails in the correct direction.
Loading in wrong direction may cause premature wear
and tear of the driver and damage of the other parts.
CAUTION: Do not use deformed connected
pin nails.
1. Remove the battery cartridge.
2. Press the locking lever and slide the magazine
backward.
3.
bottom of the magazine and push the whole part of pin
nails toward the driver guide. (Be careful to place pin
nails in the right direction.)
3
2
4
1
1. Pin nails 2. Magazine 3. Locking lever 4. Driver
guide
8ENGLISH
4.
place until it clicks.
in reverse.
Nose adapter
CAUTION: Always make sure that your
the contact element and the battery cartridge is
removed before installing the nose adapter.
adapter, place it over the driver guide cover so that the
driver guide cover.
You can store the nose adapter on the holder on the
back end of the magazine to keep it from being lost.
4
3
1
2
1. Dent 2. Protrusion 3. Nose adapter 4. Holder
Hook
CAUTION: Do not hang the hook from the
waist belt. Dropping the pin nailer, which is caused
by the hook accidentally coming out of place, may
housing on either side and then secure it with a screw.
1
2
3
1. Groove 2. Hook 3.
Hex wrench storage
When not in use, store the hex wrench as shown in the
1
1. Hex wrench
OPERATION
Testing the safety system
WARNING: Make sure all safety systems are
in working order before operation. Failure to do
so may cause personal injuries.
4
1
3
2
1.2.3. Contact
element 4. Magazine
9ENGLISH
as follows.
1. Unload pin nails from the tool and keep the maga-
zine opened.
2. Install the battery cartridge and release the trigger
lock.
3. Only pull the switch trigger without touching the
contact element against the material.
4. Only touch the contact element against the mate-
rial without pulling the switch trigger.
If the tool operates in the case of 3 and 4 above, the
-
ately and ask your local service center.
Driving pin nails
WARNING: Continue to place the contact
driven completely.
1. Release the trigger lock.
2.
3. Pull the switch trigger fully to drive a pin nail.
4.
the switch trigger once, and then repeat the step 2 and
3 above.
1
2
1.2. Contact element
You can also drive the pin nails when dragging the
tool to the next area with the contact element pressed
against the material and pulling the switch trigger.
If the head of the pin nail remains above the workpiece
surface, drive the pin nail while holding the pin nailer
NOTE: If the head of the pin nail still remains above
the workpiece even you hold the pin nail head,
the material may not be suitable for the pin nailer.
Continuing to use the pin nailer on such material may
WARNING: Always make sure that your
the contact element and the battery cartridge is
removed before loading the pin nailer.
When the number of remaining pin nails in the maga-
zine are 0 - 3 pieces, the switch trigger can no longer be
magazine and the switch trigger can be pulled again.
NOTE:
insert a new strip of pin nails into the magazine and
Checking remaining pin nails
You can check the amount of remaining pin nails
through the sight window.
the amount of remaining pin nails become smaller.
1
2
1.2. Indicator
10 ENGLISH
Removing jammed pin nails
WARNING: Always make sure that the battery
cartridge is removed before removing jammed
pin nails.
Remove three screws with the hex wrench that are
securing the driver guide cover.
has appeared.
remove two screws with the hex wrench that are secur-
1
2
3
1. Driver guide cover 2.3. Contact top cover
MAINTENANCE
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Centers, always using Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
accessories or attachments might present a risk of
for its stated purpose.
If you need any assistance for more details regard-
Center.
NOTE:
differ from country to country.
11
www.makita.com
Makita Europe N . V.
Makita C or por at i on
3-11- 8, S um i y os hi - c ho,
Anjo, Aichi 446- 8502 J apa
n
Jan-Baptist Vinkstraat 2,
3070 Kortenberg, B el gi um
885563-916
EN
20161125
Other manuals for PT354D
6
Table of contents
Other Makita Nail Gun manuals
Makita
Makita DFN350ZJ User manual
Makita
Makita AN711H User manual
Makita
Makita GF600 User manual
Makita
Makita AF505N User manual
Makita
Makita DBN600 Operating instructions
Makita
Makita XTP01 User manual
Makita
Makita PT001GZ01 User manual
Makita
Makita GN420C User manual
Makita
Makita AF633 User manual
Makita
Makita AN902 User manual
Makita
Makita AN924 User manual
Makita
Makita DBN500 User manual
Makita
Makita AN711H User manual
Makita
Makita GN420C User manual
Makita
Makita PT354DSMJ User manual
Makita
Makita GN900 User manual
Makita
Makita AN250HC User manual
Makita
Makita GTP01 User manual
Makita
Makita GN420C User manual
Makita
Makita PT354D User manual
