INSTRUCTION MANUAL
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ENGLISH
Drywall Screwdriver
MODEL 6823
MODEL 6824
MODEL 6825
MODEL 6825R
002604
DOUBLE
INSULATION

2
SPECIFICATIONS
• Due to our continuing programme of research and development, the specifications herein are subject to change
without notice.
• Note: Specifications may differ from country to country.
SYMBOLS END201-1
The following show the symbols used for the tool. Be
sure that you understand their meaning before use.
...................Read instruction manual.
...................DOUBLE INSULATION
Intended use
The tool is intended for screw driving in wood, metal and
plastic.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
For European countries only
Noise and Vibration
The typical A-weighted sound pressure level is 80 dB (A).
The noise level under working may exceed 85 dB (A).
– Wear ear protection. –
The typical weighted root mean square acceleration
value is not more than 2.5 m/s2.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product
is in compliance with the following standards of stand-
ardized documents, HD400, EN50144, EN55014,
EN61000 in accordance with Council Directives, 73/23/
EEC, 89/336/EEC, 98/37/EC.
Yasuhiko Kanzaki CE 2002
Director
MAKITA INTERNATIONAL EUROPE LTD.
Michigan Drive, Tongwell, Milton Keynes, Bucks MK15
8JD, ENGLAND
Model 6823 6824 6825 6825R
Capacities
Self drilling screw 6 mm 6 mm - -
Drywall screw 6 mm 5 mm 4 mm 4 mm
No load speed (min-1)0 - 2,500 0 - 4,500 0 - 6,000 0 - 6,000
Overall length 301 mm 290 mm 290 mm 290 mm
Net weight 1.5 kg 1.4 kg 1.4 kg 1.4 kg
Safety class /II

3
SAFETY INSTRUCTIONS ENA001-2
WARNING:
When using electric tools, basic safety precautions, including the following,
should always be followed to reduce the risk of fire, electric shock and
personal injury. Read all these instructions before operating this product
and save these instructions.
For safe operations:
1. Keep work area clean.
Cluttered areas and benches invite injuries.
2. Consider work area environment.
Do not expose power tools to rain. Do not use
power tools in damp or wet locations. Keep work
area well lit. Do not use power tools where there is
risk to cause fire or explosion.
3. Guard against electric shock.
Avoid body contact with earthed or grounded sur-
faces (e.g. pipes, radiators, ranges, refrigerators).
4. Keep children away.
Do not let visitors touch the tool or extension cord.
All visitors should be kept away from work area.
5. Store idle tools.
When not in use, tools should be stored in a dry,
high or locked up place, out of reach of children.
6. Do not force the tool.
It will do the job better and safer at the rate for which
it was intended.
7. Use the right tool.
Do not force small tools or attachments to do the job
of a heavy duty tool. Do not use tools for purposes
not intended; for example, do not use circular saws
to cut tree limbs or logs.
8. Dress properly.
Do not wear loose clothing or jewellery, they can be
caught in moving parts. Rubber gloves and non-skid
footwear are recommended when working out-
doors. Wear protecting hair covering to contain long
hair.
9. Use safety glasses and hearing protection.
Also use face or dust mask if the cutting operation is
dusty.
10. Connect dust extraction equipment.
If devices are provided for the connection of dust
extraction and collection facilities ensure these are
connected and properly used.
11. Do not abuse the cord.
Never carry the tool by the cord or yank it to discon-
nect it from the socket. Keep the cord away from
heat, oil and sharp edges.
12. Secure work.
Use clamps or a vice to hold the work. It is safer
than using your hand and it frees both hands to
operate the tool.
13. Do not overreach.
Keep proper footing and balance at all times.
14. Maintain tools with care.
Keep cutting tools sharp and clean for better and
safer performance. Follow instructions for lubrica-
tion and changing accessories. Inspect tool cord
periodically and if damaged have it repaired by an
authorized service facility. Inspect extension cords
periodically and replace, if damaged. Keep handles
dry, clean and free from oil and grease.
15. Disconnect tools.
When not in use, before servicing and when chang-
ing accessories such as blades, bits and cutters.
16. Remove adjusting keys and wrenches.
Form the habit of checking to see that keys and
adjusting wrenches are removed from the tool
before turning it on.
17. Avoid unintentional starting.
Do not carry a plugged-in tool with a finger on the
switch. Ensure switch is off when plugging in.
18. Use outdoor extension leads.
When tool is used outdoors, use only extension
cords intended for outdoor use.
19. Stay alert.
Watch what you are doing. Use common sense. Do
not operate tool when you are tired.
20. Check damaged parts.
Before further use of the tool, a guard or other part
that is damaged should be carefully checked to
determine that it will operate properly and perform
its intended function. Check for alignment of moving
parts, free running of moving parts, breakage of
parts, mounting and any other conditions that may
affect its operation. A guard or other part that is
damaged should be properly repaired or replaced
by an authorized service center unless otherwise
indicated in this instruction manual. Have defective
switches replaced by an authorized service facility.
Do not use the tool if the switch does not turn it on
and off.
21. Warning.
The use of any accessory or attachment, other than
those recommended in this instruction manual or
the catalog, may present a risk of personal injury.
22. Have your tool repaired by a qualified person.
This electric tool is in accordance with the relevant
safety requirements. Repairs should only be carried
out by qualified persons using original spare parts,
otherwise this may result in considerable danger to
the user.

4
ADDITIONAL SAFETY RULES FOR TOOL ENB004-1
1. Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool
may contact hidden wiring or its own cord. Con-
tact with a “live”wire will make exposed metal parts
of the tool “live”and shock the operator.
2. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
3. Hold the tool firmly.
4. Keep hands away from rotating parts.
5. Do not touch the bit or the workpiece immedi-
ately after operation: they may be extremely hot
and could burn your skin.
SAVE THESE INSTRUCTION

5
FUNCTIONAL
DESCRIPTION CAUTION:
•Always be sure that the tool is switched off and unplugged before
adjusting or checking function on the tool.
Depth adjustment
The depth can be adjusted by turning the locking sleeve. Turn it in “A”direction
for less depth and in “B”direction for more depth. One full turn of the locking
sleeve equals 1.5 mm change in depth.
Adjust the locking sleeve so that the distance between the tip of the locator
and the screw head is approximately 1 mm as shown in the figures. Drive a
trial screw into your material or a piece of duplicate material. If the depth is still
not suitable for the screw, continue adjusting until you obtain the proper depth
setting.
Switch action
CAUTION:
•Before plugging in the tool, always check to see that the switch trigger
actuates properly and returns to the “OFF”position when released.
To start the tool, simply pull the switch trigger. Tool speed is increased by
increasing pressure on the switch trigger. Release the switch trigger to stop.
For continuous operation, pull the switch trigger and then push in the lock but-
ton.
To stop the tool from the locked position, pull the switch trigger fully, then
release it.
NOTE:
•Even with the switch on and motor running, the bit will not rotate until you
fit the point of the bit in the screw head and apply forward pressure to
engage the clutch.
1. Locking sleeve
A
B
1
002612
1. Locator
1. Locator
1
1mm
004149
1
1mm
004154
1. Switch trigger
2. Lock button
12
002628

6
Reversing switch action
This tool has a reversing switch to change the direction of rotation. Move the
reversing switch lever to the position (A side) for clockwise rotation or the
position (B side) for counterclockwise rotation.
CAUTION:
•Always check the direction of rotation before operation.
•Use the reversing switch only after the tool comes to a complete stop.
Changing the direction of rotation before the tool stops may damage the
tool.
Hook
The hook is convenient for temporarily hanging the tool.
When using the hook, pull it out in “A”direction and then push it in “B”direction
to secure in place.
When not using the hook, return it back to its initial position by following the
above procedures in reverse.
ASSEMBLY CAUTION:
•Always be sure that the tool is switched off and unplugged before
carrying out any work on the tool.
Installing or removing the bit
To remove the bit, first pull the locator out of the locking sleeve. Then grasp
the bit with a pair of pliers and pull the bit out of the magnetic bit holder. Some-
times, it helps to wiggle the bit with the pliers as you pull.
1. Reversing switch lever
A
B
1
002635
1. Hook
A
1
002644
B
002645
1. Locator
2. Locking sleeve
12
002653

7
To install the bit, push it firmly into the magnetic bit holder. Then install the
locator by pushing it firmly back onto the locking sleeve.
Installing removable cord adapter
For Model 6825R
Insert the Removable Cord Adapter as far as it goes so that the marking on
an end of the Removable Cord Adapter on the side of connecting to power
supply cord is aligned to the marking on the other end of the Removable
Cord Adapter on the side of connecting to the tool.
Turn the Removable Cord Adapter clockwise until it is locked with a lock but-
ton.
And at this time the marking on an end of the Removable Cord Adapter on
the side of power supply cord is aligned to the marking on the other end of
the Removable Cord Adapter on the side of connecting to the tool.
1. Locator
2. Bit
3. Magnetic bit holder
1
23
002661
004178
1. Lock button
1
004179
004180

8
Removing removable cord adapter
Rotate the Removable Cord Adapter counterclockwise until it stops while
pressing the lower part of the lock button.
Then pull the Removable Cord Adapter in that position.
OPERATION
Fit the screw on the point of the bit and place the point of the screw on the sur-
face of the workpiece to be fastened. Apply pressure to the tool and start it.
Withdraw the tool as soon as the clutch cuts in. Then release the switch trig-
ger.
CAUTION:
•When fitting the screw onto the point of the bit, be careful not to push in
on the screw. If the screw is pushed in, the clutch will engage and the
screw will rotate suddenly. This could damage a workpiece or cause an
injury.
•Make sure that the bit is inserted straight in the screw head, or the screw
and/or bit may be damaged.
MAINTENANCE CAUTION:
•Always be sure that the tool is switched off and unplugged before
attempting to perform inspection or maintenance.
To maintain product SAFETY and RELIABILITY, repairs, carbon brush inspec-
tion and replacement, any other maintenance or adjustment should be per-
formed by Makita Authorized Service Centers, always using Makita
replacement parts.
1. Lock button
1
004181
004182
002673

9
ACCESSORIES
CAUTION:
•These accessories or attachments are recommended for use with your Makita tool specified in this manual. The
use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or
attachment for its stated purpose.
If you need any assistance for more details regarding these accessories, ask your local Makita service center.
•Phillips Insert bits
•Magnetic bit holder
•Locator
•Plastic carrying case

Memo
10

Memo
11

Makita Corporation Japan
884237C221
