Parts Breakdown 6827
Page 1 of 3 2/8/2008

Parts Breakdown 6827
Fig # Part ID Part Name Quantity
1 322120-3 FRONT CAP, 6805BV 1
2 213310-8 O RING 20, 6805BV 1
3 322073-6 ADJUST SLEEVE, 6805BV 1
4 231940-3 RING SPRING 22, 6805BV 1
5 324140-3 CLUTCH COVER, 6827 1
6 213486-1 O RING 35, AG125 1
7 253806-7 F. WASHER 36, 6805BV 1
8 152841-1 RING 36 CPL., 6827 1
9 216008-6 STEEL BALL 4.0, 6820V 1
10 233314-4 COMPRESSION SPRING 4, 6827 1
11 266050-7 P.T. SCREW 4X30, 4304 3
12 317440-8 GEAR HOUSING, 6827 1
15 211014-6 B. BEARING 606, 6826 1
16 226133-5 GEAR CPL.17-35, 6823/23TP 1
17 267017-8 F. WASHER, HK1800L 1
20 212042-4 T. N. BEARING 821, 6830 1
21 261111-8 URETHANE WASHER 8, 6827 1
22 152913-2 GEAR HOUSING COVER CPL., 6827 1
23 210007-0 BALL BEARING 608VV, 6825 1
24 517321-8 ARMATURE ASS'Y 115V, 6824 1
25 681636-0 INSULATION WASHER, 4304 1
26 211021-9 BALL BEARING 607LLB, LS1013 1
27 421479-6 RUBBER RING 19, JN1601 1
28 416993-5 BAFFLE PLATE, 6823 1
29 266147-2 TAPPING SCREW 4X55, 6824 2
30 633441-1 FIELD, 6823 1
31 417625-7 HOOK, 6827 1
32 183285-4 MOTOR HOUSING SET, 6827 1
33 819063-3 MAKITA LABEL, 6992DWDE 1
34 852989-6 NAME PLATE 6827 1
34 860147-0 NAME PLATE, 6827 1
35 643952-8 BRUSH HOLDER, 6823/6823TP 1
36 191927-6 CARBON BRUSH SET CB-407, 6821 1
37 664064-4 CORD (2X18X8 SJ), HR2400 1
37 664891-9 CORD 1
38 682559-5 CORD GUARD 8, 6824 1
39 687063-9 STRAIN RELIEF, 4323K 1
40 265995-6 TAPPING SCREW 4X18, 4323K 2
41 651978-6 SWITCH, 6823 1
41 651978-6 SWITCH, 6823 1
42 151961-8 HANDLE COVER COMPLETE, JS1300 1
43 265999-8 TAPPING SCREW M4X25, HM1800 1
44 253139-0 F. WASHER 8, 6510LVR 1
45 643953-6 BRUSH HOLDER, 6823/6823TP 1
46 262087-2 RING 8, 6824 1
47 265999-8 TAPPING SCREW M4X25, HM1800 2
48 240022-0 FAN 52, JS1300 1
49 421766-3 RING 20, 6827 1
50 232050-9 LEAF SPRING, 6820V 1
51 216001-0 STEEL BALL 3.5, 6800DBV 1
52 134461-3 SPINDLE ASSY, 6805BV 1
53 231278-6 COMP. SPRING 6, 6805BV 1
54 223073-8 CLUTCH CAM, 6805BV 1
55 256226-4 PIN 4, HP2030 1
55 268075-7 PIN 4, 6827 1
56 268075-7 PIN 4, 6827 1
56 256226-4 PIN 4, HP2030 1
57 231423-3 COMP. SPRING 13.6, 6805BV 1
58 253837-6 F. WASHER 14, 2030S 1
59 216014-1 STEEL BALL 3.2, 6805BV 16
Page 2 of 3 2/8/2008

Parts Breakdown 6827
60 324141-1 SLEEVE, 6827 1
60 324209-3 SLEEVE, 6827 1
61 212262-0 THRUST NEEDLE BEARING 1831, 6827 1
62 216011-7 STEEL BALL 5.6, 6222DWE 3
63 152840-3 GEAR COMPLETE, 6827 1
64 442136-3 GASKET , 6827 1
65 256157-7 PIN 3, 6222DWE 1
5,001 810134-9 N/A 1
