Makita BHR202Z User manual

18V LXT LITHIUM-ION CORDLESS
7/8'' ROTARY HAMMER
HAMMER AND DRILL
2X FASTER DRILLING IN A COMPACT DESIGN THAT WEIGHS ONLY 7.0 LBS.
Makita-Built Motor Delivers 0-1,100 RPM and 0-4,000 BPM for Faster Drilling
3-Mode Operation for Rotation Only, Hammering with Rotation, or
Hammering Only
40 Different Chisel Positions for Increased Comfort and Performance
Built-in Torque Limiter Clutch Disengages should Bit Bind
2X FASTER DRILLING IN A COMPACT DESIGN THAT WEIGHS ONLY 7.0 LBS.
Makita-Built Motor Delivers 0-1,100 RPM and 0-4,000 BPM for Faster Drilling
3-Mode Operation for Rotation Only, Hammering with Rotation, or
Hammering Only
40 Different Chisel Positions for Increased Comfort and Performance
Built-in Torque Limiter Clutch Disengages should Bit Bind
makitatools.com
COMFORT
COMFORT
Compact, ergonomic design with large
2-finger trigger and built-in L.E.D.light
VERSATILITY
VERSATILITY
3-Mode operation for“Rotation Only”,
“Hammering with Rotation”or
“Hammering Only”
Models
BHR202
BHR202Z
Models
BHR202
BHR202Z
PERFORMANCE
PERFORMANCE
LXT Li-Ion batteries charge in 30
minutes,run longer and deliver
2.5X more cycles
SPEED
SPEED
Synchronized RPM and BPM prevents
overlapping impacts for up to 50%
more efficient drilling
Makita’s
Efficient
Hammering
Competitor’s
Inefficient
Hammering

All specifications subject to change without prior notice. All models and accessories subject to stock on hand.
NTF-0908-.4M MA-0797-08 For more information, call 1-800-4MAKITA or visit makitatools.com Makita U.S.A., 14930 Northam St., La Mirada, CA 90638
Model BHR202 / BHR202Z
18V LXT LITHIUM-ION CORDLESS 7/8'' ROTARY HAMMER
For a complete listing of Makita ROTARY HAMMERS and accessories please refer to the Makita General Catalog,
or visit our website at makitatools.com, or call 1-800-4MAKITA.
FEATURES & BENEFITS
FEATURES & BENEFITS
STANDARD EQUIPMENT
STANDARD EQUIPMENT
■Makita-built motor delivers 0-1,100 RPM and 0-4,000 BPM for 2X faster drilling
■3-Mode Operation;“rotation only”, “hammering with rotation”
and “hammering only”
■40 different chisel positions for increased comfort and performance
■Built-in torque limiter clutch disengages motor should bit bind
■Compact design at only 14-1/8'' long and weighs only 7.0 lbs for reduced
operator fatigue
■Compact, ergonomic design with large 2-finger trigger
■Soft grip handle provides increased comfort on the job
■Built-in L.E.D. light illuminates the work area
■Makita Lithium-Ion provides longer run time, 5x lower self-discharge
(for use any time) & 16 firm holding contact terminals (for constant high power)
■30-minute rapid optimum charger communicates with the battery's built-in
memory chip throughout the charging process to optimize battery life
by actively controlling current, voltage and temperature
■30-minute rapid optimum charger has a built-in fan to cool the battery
to produce more lifetime work
■The charger earned the ENERGY STAR label for meeting the strict energy-efficient
guidelines set by the US Environmental Protection Agency (EPA) and US
Department of Energy (DOE)
■3-year warranty on tool and 1-year warranty on battery and charger
■2 ea. 18V LXT Lithium-Ion 3.0Ah battery (BL1830)
■30-minute rapid optimum charger (DC18RA)
■Side handle (158057-6)*
■Depth gauge (324219-0)*
■Contractor bag (821007-X)
Model BHR202Z (tool only) - battery, charger and case not included
* Included as standard equipment for BHR202Z
SPECIFICATIONS
SPECIFICATIONS
Capacities: Wood 1/2"
Steel 1"
Concrete 7/8"
Bit shank SDS-Plus
No load speed 0-1,100 RPM
Blows per minute 0-4,000 BPM
Impact energy 1.9J
Overall length 14-1/8"
Net weight 7.0 lbs. (w/battery)
Shipping weight (BHR202) 17.35 lbs.
(BHR202Z) 7.71 lbs.
Master carton quantity 3
UPC (BHR202) 088381-093248
(BHR202Z) 088381-093262
OPTIONAL ACCESSORIES
OPTIONAL ACCESSORIES
■Thruster style carbide tip penetrates on contact and plows through rebar
■Thruster style reinforced ground flute for efficient dust removal
■Dynamic chisel shaped head keeps bit in contact with the material at all times
■Available individually, 5/pk and 25/pk
■From 5/32" to 1" diameter
Thruster® Carbide-Tipped Bits
BHR202
BHR202Z
