ENGLISH (Original instructions)
Explanation of general view
1-1. Suction force adjusting knob
1-2. Hose diameter selection dial
1-3. Switch lever
2-1. Suction force adjusting knob
2-2. Hose diameter selection dial
2-3. Switch lever
3-1. Outlet cap
3-2. Power supply cord
3-3. Hose diameter selection dial
3-4. Suction force adjusting knob
3-5. Switch lever
4-1. Suction force adjusting knob
4-2. Hose diameter selection dial
4-3. Switch lever
5-1. Hose band
6-1. Base hook
6-2. Power supply cord
7-1. Front cuffs
8-1. Hose
10-1. FREE position
10-2. LOCK position
10-3. Stopper lever
10-4. Caster
12-1. Filter bag
13-1. Filter bag
14-1. Cap
16-1. Stopper lever
17-1. Stopper lever
20-1. Powder filter
20-2. Damper
20-3. Prefilter
24-1. Level sensors
25-1. Power supply cord
25-2. Multi-hook
26-1. Power supply cord
26-2. Base hook
31-1. Hose
SPECIFICATIONS
Model VC3211H
Countries EU Switzerland UK
Voltage Volt 230-240 230-240 110 230-240
Power consumption Watt 1050 1050 1050 1050
Watt at symbol mode 2400 1100 600 1900
Connected load for appliance
socket Watt at symbol mode 2600 1400 850 2100
Total connected load Watt 3450 2150 1650 2950
Model VC3211H
With φ28 mm X 3.5 m hose 2.0 m3/min
Volume flow (air) With φ38 mm X 2.5 m hose 3.5 m3/min
Vacuum 22 kPa
Type of protection IP X4 (splash-proof)
Dust 32 L
Recoverable capacity Water 27 L
Dimensions (L x W x H) 552 mm x 398 mm x 685 mm
Net weight 17.0 kg
Safety class Class I
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END114-2
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･Read instruction manual.
･Take particular care and attention.
･Warning! The cleaner may contain
hazardous dust.
･Never stand on the cleaner.
･The cleaners are capable of picking up
dust class L,M and H. Follow your
county's regulations relating to dusts
and to occupational health and safety.
Warning! This machine contains dust
hazardous to health. Emptying and
maintenance operations, including
removal of the dust collection means,
must only be carried out by authorised
personnel wearing suitable personal
protection. Do not operate without the
full filtration system fitted.
･Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of the European
Directive, on Waste Electric and
