MARKS USA i-Qwik LITE Series Operating instructions

PROGRAMMING GUIDE®
MARKS USA
365BayviewAve., Amityville,NY11701
631-225-5400 •1-800-526-0233 •Fax [phone]

365BayviewAve.,
Amityville,NY11701
LIVE TECH SUPPORT 8am - 8pm EST Mon- Fri
TollFree: 800•526•0233
InNY: 631•225•5400
Fax: 631•225•6136
E-mail: [e-mail]
For more information about the i-Qwik Line, i-Que series,
theComplete MarksUSAProductline,templates& manuals
[e-mail]
Congratulations, you havejust purchased the i-Qwik LITE Series lockset from
Marks USA. This lockset, designed for easy installation, will provide years
of reliable servicewhen properlyinstalled and maintained.
Thismanualisdesignedtoactasaguidethroughthemanyfeatures&
functions ofyouri-QwikLITESeriesStand-AloneAccess Control System.
Please take the time to read it thoroughly and follow the instructions carefully
so that your experience will be positive and trouble free.
Marks USA would like to thank you for selecting the i-Qwik LITE Series for your
accesscontrolneeds.
TableofContents:
Before You Start, Important Definitions . . . . . .. . . . . . ... . . .. . . . . .. . . .. . . . . .. .. . . .. . .. . . .. . . . . .. . . .. . . . . . ... . . .. . . . . . .. . .. . . . . . ..Page i
Important Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .Page 1
LED Indicators . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1
Create MasterCode . . . . . . . .. . . . . . . . . . . . . . . . . . .. . . . . . . . . .. . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . . . . . . . .Page 1
Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1
To Add Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1
To Delete Users . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .Page 1
Pin Only Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2
Change User Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .Page 2
Define Open Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .Page 2
Lock Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2
Terminator On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .Page 2
ManualPassage Mode . . . . . . . . .. . . . . . . . . . . .. . . . . . .. . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . .. . .Page 3
Temporary User Schedule . . . . . .. . . . . . . . . . . .. . . . . .. . .. . . . . .. . . . . . . . . . .. . . . . . .. . . . . . . . . . .. . . .. . . . . . .. .. . . . . .. . . . . . . . . . . . .. . .Page 3
Set Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3
Set Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3
Double Code Entry . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . . . . . . . . . .Page 3
Privacy Mode/Secretary Mode . . . . . . . . . . .. . . . .. . . . . . . . . . .. . . . . .. . . . . . . . . . .. . . .. . . . .. .. . . . . .. . . . . . . . . . .. . . . . .. . . . . . . . . . .. . . . .Page 4
Disable/Enable Three Strike Lockout . . . . .. .. . .. . . . . . .. . .. . . . . . ... . . .. . . . . .. . .. . . . . . .. . .. . . . . . ... . . .. . . . . . .. . . . . . . .. . . . . .. . . ..Page 4
Clear Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 4
Battery Check Status . . . . . . . . . . . . . . . . . . . . . . .. . . . . . .. . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . .Page 4
Battery Information . . . . . . . . . . . . . . .. . . . . . . . . . .. . . . . . . .. . . . . . . . . . . . . .. . . . . . . .. . . . . . . . . . . . .. . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . . . .Page 5
Connection Diagram . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .. . .Page 5
Reset The Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5
BEFORE YOU START! BEFORE YOU START! BEFORE YOU START!
IMPORTANT DEFINITIONS:
FACTORY CODE: 9991234
Thiscodeisonlyusedtoinitializethelockafterreset.ThiscodemustbeenteredtosettheMasterCode.
AftertheMasterCodeisset,theFactoryCodewillnolongerbevaliduntillockisreset.TheFactoryCodewillnotopenthelock.
USER IDENTIFICATION NUMBER (UID):
A unique 3 digit number assigned toeach User.
PERSONAL IDENTIFICATION NUMBER (PIN):
Acombinationof 3 alphanumericcharacters.
(Letters ornumbersmaybe used multiple times to increase the total number of combinations).
MASTER CODE:
Thiscodeis requiredin ordertoperformall programming functions. TheMasterCode replaces the Factory Code. Thiscode
willopenthelock.
USER CODE:
Acombinationof UserID andPIN.

MarksUSA •www.marksusa.com •631-225-5400•800-526-0233 •Fax: [phone]• © 2009,Marks USA
1
IMPORTANT KEYS:
TERMINATOR KEY ():
Actslikethe“Enter” keyonacomputer,andisusedtoconfirmentriesonthekeypad.
PROGRAMMING KEY (#):
After a valid Master Code is entered, this key is depressed to enter the programming mode.
NOTE: At the end of anyprogramming series, replace the last with a # toreturn to function number input.
Thisallowstheprogrammertoperformmultiplefunctionswithouthavingtore-entertheMasterCodeforeachfunction.
LED INDICATOR:
LED INDICATING GREEN (NORMAL MODE):
1. Denotes lock enabled to open. Will flash green after valid entry and terminator key (
LED INDICATING RED (NORMAL MODE):
1. Denotes a wrong code entry.
2. Three consecutive wrong entries will disable keypad for 20 seconds. If another wrong code is entered, the keypad is
disabledfor40seconds.Thisisindicatedbyasolidredlight.
LED INDICATING RED (PROGRAMMING MODE):
1. Denotes incorrect entryand vacates programming mode.
2. Programming mode vacated if no key entry within 5 seconds.
CREATE MASTER CODE
This code is required to perform all programming functions. The number of digits used for the User ID and PIN of each additional
usermustbethesameastheMasterCode.
Enter 9991234
(UserID)
#
(PIN)
#
UserIDandPINfollowedby willopenthelock.
GROUPS
ALL USERS MUSTBE ASSIGNEDTOA GROUP. Users in the same group will have the sameaccess rights.
Eachgroupisassigneda2digitgroupnumberfrom02to99.
The Master Code is automatically assigned to group 01, and has full programming rights.
GROUPS02-08: Managementgroupswith24/7access.
GROUP09: Groupthatallowsthelocktobeplacedinpassagemodewhenthecodeisentered.Thelocksetwillre-lockwhencodeis
enteredagainoratmidnightofthatday.
GROUPS 10-99: Noprogramming rights. They may,however, change their own PIN. (See “Change User PIN” on page2)
TOADDUSERS
EnterMasterCode(UserIDandPIN),the # key,(01),the key,theUserIDyouwishtoadd,the key,the2digitgroupnumber, the
key,thenewPIN,andthe keytwice.
ADD USER CODE
Enter MASTER CODE
#
01
(UserID)
10
(PIN)
User ID and PIN followed by ( ) will open the lock.
TO DELETE USERS
EnterMasterCode(UserIDandPIN),the # key,(01),the key,theUserIDyouwishtodelete,the key,(0),andthe keytwice.
DELETE USER CODE
Enter MASTER CODE
#
01
(User IDto be Deleted)
0

2
MarksUSA •www.marksusa.com •631-225-5400•800-526-0233 •Fax: [phone]• © 2009,Marks USA
PINONLYENTRY
The PIN Only mode will shorten the code required to open the lock.
ENABLE(PIN TOOPENLOCK)
Enter MASTER CODE
#
32
0
DISABLE(USER ID &PINTOOPENLOCK)
Enter MASTER CODE
#
32
1
CHANGE USER PIN
This function gives users the ability to change their PIN. (User must know their User ID & PIN toperform this function)
Enter UID & PIN
#
08
(New PIN)
(Verify PIN)
DEFINE OPEN TIME
ThisfunctionwilladjusttheamountoftimethatthelockwillstayunlockedafteravalidUsercodehasbeenentered.
Theopentimecanbesetfrom1to9seconds.(Defaultsettingis3seconds)
Enter MASTER CODE
#
18
SingleDigit1-9Seconds
LOCK AUDIO
Whentheaudioissetto“ON” thelockwillbeepwitheachkeypressed.(Onbydefault)
AUDIO OFF
Enter MASTER CODE
#
34
0
AUDIO ON
Enter MASTER CODE
#
34
1
TERMINATOR ON/OFF
This function will switch the Terminator On or Off. Selecting off automatically sets lock to PIN Only mode. To gain access with
Terminator Off, simply enter your PIN code. With Terminator On, you are required to enter after your code.
TERMINATOR OFF
Enter MASTER CODE
#
37
0
TERMINATOR ON
Enter MASTER CODE
#
37
1
NOTE:TOENTERPROGRAMMODEWITHTERMINATOROFF,YOUMUSTFIRSTPRESSTHE“#” KEYBEFORETHEMASTERCODE.

MarksUSA •www.marksusa.com •631-225-5400•800-526-0233 •Fax: [phone]• © 2009,Marks USA
3
MANUAL PASSAGE MODE
Thisfunctionputsthelockinanunlockedstate,grantingfreeegress(nocoderequired)toallUsersuntilthelockisreturnedtothelocked
state. The lock will return to the locked state at midnight. This function requires that the time be set (see “Set Time” below).
ENABLE
Enter MASTER CODE
#
30
1
DISABLE
Enter MASTER CODE
#
30
0
TEMPORARY USER SCHEDULE
This function allows you to restrict an existing Users access by a date range. Temporary User Schedules do not delete and must be
maintainedoraccess repeats annually. This function requires settingthe date in the lockset (see “Set Date” below).
Enter MASTER CODE
#
06
(UserID)
MMDD
(Start Date)
MMDD
(EndDate)
SETTIME
Thisfunctionwillsetthetime(HHMM).Timeissetin24hourformat.
(Example 3:30pm= 1530)
Enter MASTER CODE
#
12
HHMM
Daylightsavingstimeisenabledbydefault.Todisabledaylightsavingsadda“0”(zero)attheendofthetimeentry.
(Example3:30pm=15300)
SET DATE
This function will set the Month, Day and Year. There are 2formats available:Standard (default: MM-DD-YY)orEuropean (DD-MM-YY).
Enter MASTER CODE
#
13
MMDDYY
NOTE:FOREUROPEANDATEFORMATSET:DDMMYY“0” (ZERO).
DOUBLE CODE ENTRY
ForhighersecuritythelockcanbesettorequirethattwoUsercodesbeenteredbeforeaccessisgranted.
SINGLE CODE
Enter MASTER CODE
#
33
0
DOUBLE CODE
Enter MASTER CODE
#
33
1

4
MarksUSA •www.marksusa.com •631-225-5400•800-526-0233 •Fax: [phone]• © 2009,Marks USA
PRIVACY MODE/SECRETARY MODE
PrivacyMode/SecretaryMode(SecretaryModeisdefault):
Ani-QwikLITEwiththePrivacyModeoptionwillhaveabuttoninstalledontheinsidehousing.Whenthebuttonispresseditwillblockout
keypad entries (except User Codes from groups 01-03). When the inside lever ispressed the request to exit switch will reset the keypad
backto normal operating mode.
PRIVACY MODE
Enter MASTER CODE
#
39
1
SECRETARY MODE
Enter MASTER CODE
#
39
0
DISABLE/ENABLE THREE STRIKE LOCKOUT
The lock responds to three consecutive incorrect codes by displaying a red light and shutting down the keypad for 20 seconds.
Subsequent attempts with an incorrect code will increase the time to 40 seconds maximum. Disabling this feature allows anunlimited
number of incorrect codes to be entered without a lockout.
DISABLE
Enter MASTER CODE
#
40
0
ENABLE
Enter MASTER CODE
#
40
1
CLEAR MEMORY
If it becomes necessary to reset the memory of the i-Qwik LITE, there are two options other than the Full Reset option.
DELETEALLUSERS&SCHEDULES
Enter MASTER CODE
#
16
16
0
DELETE ONLY SCHEDULES
Enter MASTER CODE
#
16
16
1
BATTERY CHECK STATUS
This function manually checks the battery status of the i-Qwik LITE. The LED on the keypad will display visual indicator.
Enter MASTER CODE
#
17
Watch LED
Green - Green: Two green LED flashes indicate full power 5.25 volts and above.
Yellow-Yellow: TwoyellowLEDflashes5.25to4.75volts.
Yellow-Red: YellowthenredLEDflashes4.75to4.37volts.
Red - Red: Two red flashes indicates below 4.37 volts. Batteries need to be changed.
NOTE:IFTHEVOLTAGEOFTHEBATTERIESFALLSTO4.2vDC,THEi-QwikLITEWILLBEEPEVERYHOURINDICATING
LOW BATTERY STATUS

MarksUSA •www.marksusa.com •631-225-5400•800-526-0233 •Fax: [phone]• © 2009,Marks USA
5
Yellow
Black
BATTERY INFORMATION
THE i-QWIK LITE IS SHIPPED WITH 4 “AA” ALKALINE BATTERIES: The life spanof the batteries has been tested in two different ways. The first test was performed to
seehow many operations could be performed repeatedly before a failure. The test averaged 150 thousand operations. The secondtest was performed over time for normal
operations. This test revealed that the i-Qwik LITE batteries would last approximately 4 years at 80-90 thousand operations. Using the factory settings, the lockset is set for
optimizedpowerusage.
CHANGE THE BATTERIES: The batteries should not bedisconnected longerthan 10 minutesor thereisa risk of affectingthe lock'smemory.
ITISRECOMMENDED TO USE ONLY ALKALINE BATTERIES: The alkaline battery has a gradual curveinthe drop off voltage.This curvedetermines the power settingsfor
thetwostagesofbatterywarningsandtheFailSecuresettings.Alithiumbatterydiffersfromanalkalinebatteryinthelifecycleofthebatterycell.Alithiumbatteryhasavery
sharp drop off voltage, going from fully charged to a dead cell quickly. This makes monitoring the voltage settings impossible.
TWO STAGE LOW BATTERY WARNING: The i-QwikLITE has a two-stage low battery warning. The first warning stagewill add a double beep and Red LED when the user
enters theircode.The secondwarningstagewill be a double beep every hour. BATTERIES SHOULD BECHANGED IMMEDIATELY. Double beeps will occur until the
batteriesfail.
CONNECTION DIAGRAM
RESETTHELOCK
ResetThei-QwikLITEBackToFactory Default:
• Open battery cover (top of housing on inside of door)
• Disconnectthebatteries
• Locate the Yellow and Black cable(behind battery pack)
• Insertbothendsoftheresetwire(orpaperclip)intotheholesoftheconnectorontheyellowandblackcable.
• With the reset wire in place, reconnect the batteries. (The LED will go GREEN)
• Pressthe#key(TheLEDwillgoREDandthenbacktoGREEN)
• Removetheresetwire
• Thelockisnowreset

Formoreinformationaboutthe i-QwikLine,
thei-Que series, the complete Marks USA productline,
templatesandmanuals
[e-mail]
For i-Qwik/i-Que Tech Support Call:
Toll Free: 800 •526 •0233
In N.Y.: 631 •225 •5400
Fax: 631 •225 •6136
LIVE TECH SUPPORT 8am to 8pm EST Mon - Fri
Email: [e-mail]
IP101-IQWIKLITE 03.09
©2009,MARKSUSA
Distributed by:
