Emtek Keypad Deadbolt Locksets Operating instructions

Installation & Programming Guide
Keypad Deadbolt Locksets
ASSA ABLOY, the global leader in door opening solutions

2
4c
4d
2
3
6
6
5
1
8
9
7
4
4b
4a
ITEM NO. DESCRIPTION QTY.
1Key 2
2Outside Trim Plate Assembly 1
3Deadbolt Latch Assembly 2 ⁄”or 2 ¾” Backset 1
4Inside Trim Plate Assembly 1
4a Inside Chassis
1
4b Inside Trim Plate
1
4c
#8-32 x ⁄” Flat Head Machine Screw 2
4d
9V Alkaline Battery - Type 6LR61 1
5#8-32 x 1½” Flat Head Machine Screw 2
6#8 x ¾”Wood Screw 4
7Strike Plate 1
8Security Plate 1
9#10 x 3”Wood Screw 2
What’s in the Box

3
Step 1: Fasten Security Plate using two #10 x 3”Wood Screws (item #9).
Step 2: Fasten Strike Plate using two #8 x ¾”Wood Screws (item #6).
2 ⁄” or 2 ¾” Backset
2 ⁄” Diameter Bore
⁄” Deep
2 ¼”
1 “ 1” Diameter Edge Bore
2. Door Jamb Prep
1. Door Prep
Preparation
2-3/4"
#10 x 3”Wood Screws
⁄” Deep
2 ¾”
1 ⁄”
¾”
#8 x ¾”Wood Screws
1¼”
1¼” Deep

4
Fasten Latch using two #8 x ¾”Wood Screws (item #6).
2. Remove Screws from Inside Trim Plate
1. Install Latch
How to Install
!
REMOVE INSIDE
CHASSIS FROM
TRIM PLATE BEFORE
INSTALLING THE
OUTSIDE TRIM.
THUMBTURN MUST
BE IN UNLOCKED
POSITION.
Unlocked Locked
THE LATCH ASSEMBLY
MUST BE ORIENTED
AS SHOWN AND THE
BOLT MUST BE IN THE
RETRACTED POSITION
FOR INSTALLATION.
!
Crosshairs
at bottom.
Use a Phillips head screwdriver to remove screws (item #4c) shown below and detach
Inside Trim Plate from the Inside Chassis.
screws
(item #4c)

5
3. Install Outside Trim Plate Assembly
4. Install Inside Chassis
Position the Outside Trim Plate Assembly through the bore hole.
!
Flat Shaft
through latch.
Flat Shaft must be
in vertical position
for installation.
ONCE POSITIONED,
OUTSIDE TRIM PLATE
ASSEMBLY REQUIRES
SUPPORT.
Feed wire harness
through the bore hole.
HOLE FOR FLAT
SHAFT MUST BE IN
VERTICAL POSITION
FOR INSTALLATION.
!
Step 1: Conrm the position of Flat Shaft.
√ Correct for Installation.
X Incorrect for Installation.

6
4. Install Inside Chassis
Step 2: Feed the Wire Harness through Inside Chassis.
Step 3: Fasten Inside Chassis using two #8-32 x 1½” Flat Head Machine Screws (item #5).
CHECK ALIGNMENT BEFORE
FULLY TIGHTENING SCREWS.
!

7
Step 4: Connect Wire Harness (A) and tuck Connectors as shown (B).
A
B
Step 5: Install Battery.
For optimal performance, always use a good quality battery.
9V Battery

8
*Unlocked position is required for installation and removal of the Inside
Trim Plate Assembly.
*Unlocked
Correct for installation
Locked
Incorrect for installation
!
!
!
THUMBTURN MUST BE IN
UNLOCKED POSITION FOR
INSTALLATION.
USER CODES
ARE LOCATED
ON THE INSIDE
TRIM PLATE &
ON PAGE 11.
Inside
5. Install Inside Trim Plate
Fasten Inside Trim Plate using two #8-32 x ⁄” Flat Head Machine Screws (item #4c).
Screws (item #4c)

9
Your Emtek lock is shipped with two 4-digit user codes and one 6-digit
programming code. These codes are randomly generated at the factory.
(Turn to next page for Programming Instructions.)
To Unlock:
1. Enter 4-digit user codes.
(See sticker located on the inside
trim plate or on page 11).
2. Rotate Thumbturn.
To Lock:
1. Press EMTEK key or enter a valid
4-digit user code.
2. Rotate Thumbturn.
Your Lock is Ready to Use
How to Use

10
How to Program
Programming Your Lock
In order to perform each of the following six functions, the lock must rst be
placed in Programming Mode:
*If no input within 10 seconds, Yellow LED goes out, Red LED ashes and lock exits Programming Mode.
1. Press and hold EMTEK button for 3 seconds
2. Yellow LED ashes, then remains solid*
3. Enter Programming Code
4. Green LED ashes, then 1 beep
5. Yellow LED remains solid (awaiting button press; see following Table)
Ifyou wIsh to Press
Button
ActIons IndIcAtors
Change
Programming
Code
(6 digits)
1Enter New
Programming
Code
(6 digits)
Re-Enter
New
Programming
Code
(6 digits)
• 1 Green LED ash
• 1 beep
• 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
Add User Code
4 digits
(Store up to
20 User Codes)
2Enter New
User Code
(4 digits)
Re-Enter
New User
Code
(4 digits)
• 1 Green LED ash
• 1 beep
• 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
Delete User Code 3 Enter User
Code to be
Deleted
Re-Enter
User Code to
be Deleted
• 1 Green LED ash
• 1 beep
• 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
**Enable/Disable
All User Codes
4Entering ‘4’ disables all Users
(enables all if disabled)
• 2 Green LED ashes
• 2 beeps
Delete All User
Codes
5Re-Enter Programming Code • 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
Turn Beeper On/
Off
6Entering ‘6’ turns OFF (or ON) • 1 Green LED ash
• 1 beep
• 2 Green LED ashes
• 2 beeps
**Also referred to as “vacation mode”. This command temporarily disables all user codes (metal key
override will still work).

11
IN8-KEYPADDB1 09/27/2010
Restoring the Lock to Factory Default Setting
• Remove power (disconnect 9V battery) from Lock
• Press and Hold EMTEK button
• While continuing to hold EMTEK button, restore power (reconnect 9V battery)
• Continue to hold EMTEK button for 3 seconds
• 1 Green LED Flash and 2 short beeps followed by 1 Green LED Flash and 2 short
beeps indicates the lock has been successfully restored
This procedure clears the lock of all users and restores the Programming Code and
2 User Codes shipped with the lock.
Function Indicators
Valid Code • 1 short beep, EMTEK button ashes
Green.
Invalid Code/Access Denied* • 1 Red LED ash
• 2 short beeps
Lock-Out Mode Error • 2 short beeps
• 1 short beep per second for duration
Access Accepted • 1 short beep
• 1 Green LED ash
Low Battery • 4 Red LED ashes
• 4 short beeps
Blackout Battery** • 1 long Red LED ash
• 4 long beeps
Button Press Accepted • 1 Yellow LED ash
• 1 Short Beep
Outside Thumb Turn Enabled • 2 Green LED ashes
Keypad Operation - Beeper & LED Indicators
Place Sticker Here
* If 3 consecutive incorrect codes are entered, the lock emits 4 short beeps and a ashing Red EMTEK
button. The lock will not accept additional input for 20 seconds (20 beeps).
** Battery voltage has dropped too low; keypad will be disabled but metal key override will still work.
