Marmitek BOOMBOOM 75 User manual

BoomBoom 75
3
13
23
33
43
53
User manual
Gebrauchsanleitung
Guide utilisateur
Modo de empleo
Manuale d’istruzioni
Gebruiksaanwijzing
ai15819382566_1_20682_20190617_UG_103x145mm_80g_BoomBoom75_front.pdf 1 17-2-2020 12:17:36

© MARMITEK
2

BoomBoom 75
3
ENGLISH
1 Table of contents
1 Table of contents ..............................................................3
2 Safety instructions.............................................................4
3 Your product .....................................................................5
3.1 Introduction.......................................................................5
3.2 Package contents .............................................................5
3.3 Product overview ..............................................................5
3.4 LED status ........................................................................6
3.5 First use............................................................................6
3.6 Connecting to your sound system .....................................6
3.7 Pairing ..............................................................................7
3.8 Turning off ........................................................................7
3.9 Turning on ........................................................................8
3.10 Standby/automatic switch-off ............................................8
3.11 Battery life and standby time .............................................8
3.12 Battery almost empty ........................................................8
3.13 Delete paired devices .......................................................8
4 Product details ..................................................................9
4.1 Technical specifications ....................................................9
5 Frequently asked questions ............................................10
6 Notification......................................................................11
6.1 Declaration of Conformity................................................11
6.2 Recycling........................................................................12
6.3 Copyrights ......................................................................12

© MARMITEK
4
2 Safety instructions
Please read these instructions thoroughly before you use the
device and keep them for future reference.
Only for indoor use.
Do not use the product in a damp environment or near water.
Do not expose the product to extremely high or low
temperatures, strong light sources or direct sunlight.
This product is not a toy. Keep out of reach of children.
Avoid using headphones/speakers with the volume turned up
for an extended period of time. Doing so may damage your
hearing. It is advisable to keep the volume at a moderate
level at all times.
Connect the adapter to the mains only after you have verified
that the line voltage corresponds to the value specified on
the type plates.
Never connect a power adapter if it's damaged. In such
cases, please contact your supplier.
Disconnect the AC/DC power adapter from the mains when
this device is not in use for prolonged time.
The built-in rechargeable battery is not replaceable. Do not
remove or replace the battery. Dispose of unit properly. Do
not dispose unit in trash or fire.
Never open the product: the device may contain parts with
deadly voltage.
Repairs or service should only be performed by qualified
personnel.
Improper use, self-installed modifications or repairs will void
any and all warranties.
Marmitek does not accept any product responsibility for
incorrect use of the product or use other than for which the
product is intended.
Marmitek does not accept liability for any consequential
damage other than the legal product responsibility.

BoomBoom 75
5
ENGLISH
3 Your product
3.1 Introduction
Congratulations on your purchase of the Marmitek BoomBoom 75.
This Bluetooth audio receiver allows you to play music from a
sound source that is equipped with Bluetooth technology on your
sound installation without having to connect the source using
cables. This could involve a PC or a laptop that has a Bluetooth
USB dongle, a mobile telephone that supports Bluetooth, an
Android telephone, an Android Tablet, an iPhone an iPad or a
Mac.
You can then organise your music via the sound source without
having to walk over to the sound system.
The BoomBoom 75 has a range of about 10 metres, allowing you
to organise your music in the same or in an adjoining room.
3.2 Package contents
1 x BoomBoom 75, universal Bluetooth wireless stereo audio
receiver
1 x micro USB cable
1 x USB power adapter
1 x Mini Jack female to RCA converter cable
1 x Mini jack cable
1 x User manual
3.3 Product overview
MFB (Multi Function Button)
LED Indicator
Micro USB Charging Port
3.5 mm Audio Port
Power Switch

© MARMITEK
6
3.4 LED status
LED status
Description
Blue LED ON for 2 seconds
Power ON
Red LED ON for 2 seconds
Power OFF
Blue LED flashing 2 times every 3
seconds
Standby mode
Red and Blue LED flashing alternately
Pairing mode
Blue LED flashing every 5 seconds
Paired
Red and Blue led flash once
Delete paired devices
Red LED flashing
Low battery
Red LED ON
Charging
Blue LED ON
Fully charged
3.5 First use
The BoomBoom 75 has a built-in rechargeable battery.
We recommend completely charging the battery before using for
the first time. Connect the supplied USB cable to the
BoomBoom 75 and the power adapter. The red LED will light up
when you plug the power adapter into the wall socket.
The first charge may take up to about one hour. Once the
BoomBoom 75 battery is completely charged, the red LED will
turn to Blue.
3.6 Connecting to your sound system
Connect the mini jack-plug to the AUX IN on a docking speaker or
radio/CD player, for example.
Use the converter cable supplied to connect the BoomBoom 75 to
the AUX IN coaxial (Cinch/RCA) connection on your sound
system.

BoomBoom 75
7
ENGLISH
3.7 Pairing
1. Locate your Bluetooth music source in the vicinity of the
BoomBoom 75. The best distance is around 1 metre.
2. Ensure that the BoomBoom 75 is off.
3. Switch on the BoomBoom 75.
4. Short press the button on the BoomBoom 75. The LED starts
to blink red and blue. (It will enter pairing mode automatically
when used for the first time)
5. Switch your device’s Bluetooth function on according to the
instructions of your device and go to Bluetooth settings.
6. Scan for new devices and select the name “BoomBoom 75”.
7. If the Bluetooth connection process requires a password,
enter “0000”. The BoomBoom 75 then connects with your
device. The blue LED will flash every 5 seconds. You will
also hear a signal via the connected sound system. The
connection has now been made and your device is linked to
the BoomBoom 75. You can now play and control the music
in your device on your sound system.
! You can link to up to 8 devices however only 1 device can be
connected to the BoomBoom 75 at one time.
! The BoomBoom 75 will exit pairing mode when no connection is
made after 10 minutes. Short press the button to enter pairing
mode again.
! The BoomBoom 75 will power off after 20 minutes when there is
no connection.
3.8 Turning off
Switch the BoomBoom 75’power switch down. The red LED will
light for 2 seconds and then goes out.

© MARMITEK
8
3.9 Turning on
Switch the BoomBoom 75 power switch up. The blue LED will light
for 2 seconds.
The BoomBoom 75 will then automatically link to the last device it
was connected to. Only 1 device can be connected at once with
the BoomBoom 75. If your device does not connect automatically,
go to the device's Bluetooth settings and select the
BoomBoom 75. A connection will then be made.
3.10 Standby/automatic switch-off
If the BoomBoom 75 is in connecting mode and no connection is
made within 10 minutes, the BoomBoom 75 will switch to standby
setting (blue LED blinks 2 times every 3 seconds). If no
connection is made for 20 minutes, the BoomBoom 75 will
automatically switch off. If you wish to use the BoomBoom 75, you
must switch the power switch off and on again.
3.11 Battery life and standby time
Once the battery has been fully charged it will last for about 4
hours at 70% volume. Standby time is around 100 hours. You can
use the BoomBoom 75 with the mains adapter supplied. The
battery then remains charged.
! Please charge the BoomBoom 75 at least once every 2 months
when not in use.
! Press the button and connect with the power supply to reset the
BoomBoom 75 when the BoomBoom 75 is dead during use.
3.12 Battery almost empty
When the BoomBoom 75’s battery is almost empty, the red LED
will blink once every 30 seconds and you will hear a warning
signal 4 times via the sound system. Follow the steps given earlier
to charge the battery.
3.13 Delete paired devices
In standby status, long press the button for 5 seconds. The Blue
and Red LED will flash once to clear all paired devices. Turn
OFF/ON the BoomBoom 75 to pair to a new Bluetooth device.

BoomBoom 75
9
ENGLISH
4 Product details
4.1 Technical specifications
Bluetooth
Supported Bluetooth profiles A2DP
AVRCP
HFP
HSP
Supported codec SBC
Audio Latency SBC, 170 ms - 270 ms
Pair memory up to 8 devices
Bluetooth Version V5.0
Frequency 2402~2480 MHz
Range Up to 10 meters with Class 2> <2
connection
Up to 30 meters with Class 2> <1
connection
Audio
Frequency Response 20 ~ 20 kHz (± 3 dB)
Connections
Interface audio output Jack 3.5 mm stereo
General
Light Indicator 2 color LED (Blue/Red)
Dimension 51 x 26 x 11 mm
Weight 12 grams
Operation temperature -10°C ~ +55°C
Storage temperature -20°C ~ +60°C
Power supply 100 - 240 VAC 50/60 Hz, 5 VDC
micro USB adapter (included) or via
micro USB cable (included)
Power Micro USB or battery

© MARMITEK
10
Battery
Li-ion 3.7 V
- Battery Capacity 160 mAH
-Stand-by Time up to 120 hours
-Working Time up to 8 hours on 70% volume
-Charging Time 1 hours
Energy Saving automatic shutdown when not
connected after 20 minutes
In order to continue improving the product, Marmitek reserves the
right to change specifications and/or designs without prior notice.
5 Frequently asked questions
I can’t connect my BoomBoom 75.
Check the following:
1. Ensure that the power adapter is connected and/or that the
battery is fully charged.
2. Ensure that the Bluetooth function on your mobile telephone
is on (check your phone's manual for reference).
3. Ensure that the distance between your mobile phone and the
BoomBoom 75 is no greater than 10 metres and that there
are no large obstacles in the way.
No sound comes out of the audio installation
Ensure that the audio cable is correctly connected (AUX IN), that
the correct input has been selected on your audio installation and
that your audio system’s volume is set to the desired level.
Can I link numerous devices to my BoomBoom 75?
You can link up to 8 devices to your BoomBoom 75. If the
BoomBoom 75 is switched on, it will automatically connect to the
last connected device.
Do you have other questions that have not been resolved by the
above information? Please go to www.marmitek.com
