Marmitek Connect 310 UHD 2.0 User manual

Connect 310 UHD 2.0TM
3
11
19
27
35
43
User manual
Gebrauchsanleitung
Guide utilisateur
Modo de empleo
Manuale d’istruzioni
Gebruiksaanwijzing

2 © MARMITEK

Connect 310 UHD 2.0™3
ENGLISCH
1. Safety instructions
Please read these instructions thoroughly before you use the device
and keep them for future reference.
•Only for indoor use.
•Do not use the product in a damp environment or near water.
•Do not expose the product to extremely high or low
temperatures, strong light sources or direct sunlight.
•This product is not a toy. Keep out of reach of children.
•Keep batteries out of the reach of children. Dispose of batteries
as chemical waste. Never use old and new batteries or different
types of batteries together. Remove the batteries when you are
not using the system for a longer period of time. Check the
polarity (+/-) of the batteries when inserting them in the product.
Wrong positioning can cause an explosion.
•Connect the adapter to the mains only after you have verified
that the line voltage corresponds to the value specified on the
type plates.
•Never connect a power adapter if it's damaged. In such cases,
please contact your supplier.
•Disconnect the AC/DC power adapter from the mains when this
device is not in use for prolonged time.
•Never open the product: the device may contain parts with
deadly voltage.
•Repairs or service should only be performed by qualified
personnel.
•Improper use, self-installed modifications or repairs will void any
and all warranties.
•Marmitek does not accept any product responsibility for
incorrect use of the product or use other than for which the
product is intended.
•Marmitek does not accept liability for any consequential damage
other than the legal product responsibility.

4 © MARMITEK
2. Introduction
Congratulations on your purchase of the Marmitek Connect 310 UHD
2.0™! It allows you to use 1 cable to connect 3 HDMI sources to your TV,
without any loss of signal or encryption. It's ideal when your TV doesn't
have enough HDMI inputs, or if you want to connect the devices to your TV
using just one cable. Examples of HDMI sources are game consoles such
as a PlayStation or Xbox, Blu-ray players, digital TV decoders and all other
HDMI devices. The Connect 310 UHD 2.0™ supports Ultra HD (4k), Full
HD (1080p), HDCP 2.2 and all 3D formats, making it suitable for all your
existing and future equipment.
Marmitek products are manufactured with the utmost care and are
exceptionally high quality. Please read this manual carefully and follow the
instructions in order to get the best from this product.
3. Set content
1 x HDMI Switch
1 x Remote Control (battery included)
1 x IR Receiver
1 x USB Power Cable
1 x Power adapter
1 x User Manual
4. Benefits
•Suitable for simultaneously connecting 3 HDMI devices to your TV
•Switches automatically and/or with remote control
•Includes separate IR receiver for operating the switcher when it is
positioned out of sight
5. HDMI properties
•The maximum throughput speed is 18 Gbit/s (gigabits per second).
This allows HDMI 2.0 to display Ultra HD 4K images at 60 fps (frames
per second).
•Suitable for the latest Ultra HD 4K60 resolution (3840 x 2160 / 60Hz),
High Dynamic Range (HDR), Deep Color and 4:4:4 chroma colours.
•Supports all 3D formats (suitable for use with your own 3D
equipment)

Connect 310 UHD 2.0™5
ENGLISCH
•Deep Color 36-bit (billions instead of millions of colours, better
reproduction of subtle differences in gradation and a higher contrast
ratio).
•Supports Dolby Atmos and DTS:X and all other common audio
formats.
6. Installation
Before installation:
•Turn off all devices (TV and HDMI sources) before connecting them
to the Connect 310 UHD 2.0™. If a device cannot be turned off,
please remove the plug from the socket.
•Only use High Speed HDMI® certified cables for the best picture and
sound quality. Using too much force to connect or disconnect the
HDMI cables may damage them.
1. Use an HDMI cable to connect the HDMI sources (such as game
consoles, Blu-ray players and Digital TV Decoders) to the HDMI ports
marked "HDMI input".
2. Use an HDMI cable to connect the TV to the HDMI port marked
"HDMI output".
3. If required, connect the IR receiver to the "IR" input in order to
continue to operate it when it is positioned out of sight, for example,
in a closed cabinet. Remember to position the IR receiver itself within
the remote control's line of sight.
4. Use the USB power cable to connect the power adapter to the "DC
5V" connector and insert the plug into the wall socket.

6 © MARMITEK
5. Pull the plastic strip from the remote control's battery compartment to
activate the battery and remove the protective film from the top.
7. Use
Switching between connected HDMI devices
The Connect 310 UHD 2.0™ allows you to choose which HDMI source is
displayed on the TV. If you turn on one of the HDMI sources, it will
automatically switch to the correct input. If multiple HDMI sources are
turned on, the Connect 310 UHD 2.0™ will automatically switch to the
HDMI source that was activated last. If you want to select another HDMI
source, please use the remote control or the "Select" button on the front.
Note: Automatic switching must be supported by the HDMI source. If it is
not supported, you should manually select the appropriate HDMI source.
8. Frequently asked questions
No (or poor) image and sound
If you experience poor or no picture after connecting the HDMI switcher,
please try to identify the problem by connecting the devices to your screen
(TV, monitor or projector) one by one. This allows you to determine
whether the problem is with the HDMI sources, the HDMI cables, the HDMI
switcher or the screen.
•For the best picture and sound quality, only use High Speed HDMI®
certified cables.
•Do not use cables longer than 15 meters, but preferably shorter
cables. These reduce the risk of problems.
•Check the HDMI cables and/or connectors for damage.
•Both the HDMI source and your screen should fully support HDMI.
•Check that your HDMI sources and screen support HDCP 2.2 (High
Bandwidth Digital Content Protection) copy protection.
Do you have other questions that have not been resolved by the above
information? Please go to www.marmitek.com

Connect 310 UHD 2.0™7
ENGLISCH
9. Technical data
Connections
HDMI input 3x HDMI (19-pin female)
HDMI output 1x HDMI (19-pin female)
HDMI cable length max. 15 metres
Video
Supported resolutions 480p, 576p, 720p, 1080i, 1080p and
2160p@60hz
HDMI standards HDCP 2.2, CEC, EDID, DVI, all 3D
formats, Deep Colour (36-bit), x.v.Color
HDCP standards HDCP 2.2 and HDCP 1.4
Colour formats RGB and YCbCr 4:4:4, 4:2:0 or 4:2:2.
Video Bandwidth 18 Gbps
Clock frequency 600MHZ
Audio
HDMI audio DTS-HD Master Audio, Dolby TrueHD,
Dolby Atmos, LPCM 7.1, DTS, Dolby-AC3
and 2.0CH
Housing
Dimensions (D x W x H) 87 x 60 x 19mm
Weight 60g
Environment
Ambient temperature +0 to +70° C
Ambient humidity 10% to 85%
Power supply
Power adapter input 100-240VAC @ 50/60Hz
Output 5VDC / 1A
Specifications may change without prior notice.

8 © MARMITEK
Environmental Information for Customers in the European Union and
other European countries with separate collection systems.
This symbol on the product or on its packaging indicates that this product
shall not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic
equipment. It is your responsibility to dispose of this and other electric and
electronic equipment via designated collection facilities appointed by the
government or local authorities. Correct disposal and recycling will help prevent
potential negative consequences to the environment and human health. For
more detailed information about the disposal of your old equipment, please
contact your local authorities, waste disposal service, or the shop where you
purchased the product.
10. Declaration of Conformity
Hereby, Marmitek BV declares that this Connect 310 UHD
2.0™is in compliance with the essential requirements and
other relevant provisions of the following Directives:
Directive 2014/30/EU of the European Parliament and of the Council of 26
February 2014 on the harmonisation of the laws of the Member States
relating to electromagnetic compatibility (recast)
Directive 2014/35/EU of the European Parliament and of the Council of 26
February 2014 on the harmonisation of the laws of the Member States
relating to the making available on the market of electrical equipment
designed for use within certain voltage limits.
Directive (EU) 2017/2102 of the European Parliament and of the Council of
15 November 2017 amending Directive 2011/65/EU on the restriction of
the use of certain hazardous substances in electrical and electronic
equipment.
Commission Regulation (EU) 2019/1782 of 1 October 2019 laying down
Ecodesign requirements for external power supplies pursuant to Directive
2009/125/EC of the European Parliament and of the Council and repealing
Commission Regulation (EC) No 278/2009.
You can read the full Declaration of Conformity at
http://www.marmitek.com

Connect 310 UHD 2.0™9
ENGLISCH
11. Copyrights
Marmitek is a trademark of Germatron B.V. Connect 310 UHD 2.0™ is a
trademark of Marmitek B.V. All rights reserved. Every effort has been made to
ensure that the information in this manual is accurate. Marmitek is not
responsible for printing or clerical errors. Copyright and all other proprietary
rights in the content (including but not limited to model numbers, software,
audio, video, text and photographs) rests with Marmitek B.V. Any use of the
Content, but without limitation, distribution, reproduction, modification, display
or transmission without the prior written consent of Marmitek is strictly
prohibited. All copyright and other proprietary notices shall be retained on all
reproductions. Other company and product names mentioned herein may be
trademarks of their respective companies. Mention of third-party products is for
informational purposes only and constitutes neither an endorsement nor a
recommendation. Marmitek assumes no responsibility with regard to the
performance or use of these products.
Marmitek BV - PO Box 4257 - 5604 EG Eindhoven
The Netherlands
