marsden M-310 User manual

USER MANUAL
M-310 (MS-4400I)
Please take time to read these
instructions before starting
to use the scale
Version 1.2 10/17

Contents
Introduction 3
Product Specification 3
Safety Instructions 4
Explanation of Graphic Symbols 5
Installing & Replacing the Battery Pack 6
How to Weigh Your Baby Correctly 7
EMC Guidance and Manufacturer’s Declaration 8
Recommended Separation Distance 10
Error Messages 11
Manufacturer’s Declaration of Conformity 12
Manufacturer’s Declaration of Conformity (MDD Directive) 15
Page 2

Thank you for purchasing a Marsden professional medical scale.
This is a precision Class III Weighing Instrument and considerate use
will result in many years of accurate weighing.
The scale has a maximum load capacity of 10kg which must not be
exceeded.
Product Specification
Model
M-310 (MS-4400I)
Accuracy Class
Class III
Capacity/Division
10kg x 10g
Weight of Scale
Approximately 0.45kg
Units of Measure
Kg
Function Keys
ON/OFF, HOLD, TARE
Stabilisation Time
1-2 Seconds
Operating Temperature
5 to 35˚C
Power Supply
6 x AAA batteries
Page 3

Safety Instructions
Before putting the device into use, please read with care the information given in this user
manual, which contains important instructions for proper installation, use and maintenance
of the device.
Marsden/the manufacturer shall not be liable for damages arising from failure to heed the
following instructions:
•When using electrical components under increased safety requirements, always
comply with appropriate regulations.
•Inappropriate installation/use will render the warranty null and void.
•Ensure the voltage marked on the power supply unit matches your mains supply.
•This device is designed for use indoors.
•Observe the permissible ambient temperatures for use.
•The device meets the requirements for electromagnetic capability. Do not exceed
the maximum values specified in the applicable standards.
•Batteries should be kept away from small children. If swallowed, promptly seek
medical assistance.
If you have any problems, contact Marsden/your local dealer/your service partner.
Cleaning
•We recommend using alcohol-based wipes or similar when cleaning the scale.
•Please do not use corrosive liquids, large amounts of water or high pressure washers.
•Always disconnect the scale from the mains power supply before cleaning.
Maintenance
•The scale does not require any routine maintenance. However, we recommend the
scale is serviced on a 12-monthly basis. For information about Marsden Service
Contracts call 01709 364296.
•If any inaccuracies occur, please contact Marsden, your local dealer or your service
partner.
Disposing of the Scale
•This product should not be treated as regular household waste, but should be
handed in to an electrical/electronic equipment recycling centre.
•You can obtain further details from your local council, your municipal waste disposal
company or from where you purchased the product.
Page 4

Explanation of Graphic Symbols
SN-21300100
Designation of the serial number of
every device.
(Number as an example)
“Please note the accompanying
documents” or “Observe operating
instructions”
Charder Electronic Co. Ltd
No.103 Guozhong Rd, Dali Dist,
Taichung City 412, Taiwan (R.O.C)
Identification of manufacturer of
medical product including address.
“Type B applied part”
Dispose of old appliances separately
from your household waste.
This product must be disposed of at a
communal collection point.
Carefully read this operation manual
before setup and commissioning, even
if you are already familiar with Marsden
scales.
Transport and storage temperature limit
indicating the upper and lower limit
(transport and storage temperature on
packaging).
Page 5

Installing & Replacing the Battery Pack
1
Locate the battery cover at the bottom of
the scale and open it.
2
Remove the battery case.
3
Insert 6x AAA batteries...
4
...making sure each battery is aligned
properly in the case, with front edge of
each battery corresponding with the +
marking on the case.
5
Insert the battery case back into the scale
and replace the cover.
Page 6

Operation Instructions
1
The M-310 (MS-4400I) is designed to be
held whilst a baby is being weighed, as
shown in the picture on the left.
2
To begin, switch the scale on by pressing
the ON/OFF/ZERO button. 0.00kg should
show on the display.
3
Lay the sling out on a flat surface.
4
Gently place the baby in the sling.
5
Attach the S hook to the bottom of the
scale and to the hoops on the sling.
6
Holding the M-310 (MS-4400I) as shown
in 1), gently lift the baby off the flat
surface.
(Alternatively, if you need to remove the
weight of the sling or any other item from
the reading, hook the sling/item and sling
to the scale and press TARE. You can then
weigh the baby as normal.)
7
The weight reading will show clearly on the
display.
8
You can also press HOLD to stabilise the
weight reading on the display.
Press ON/OFF/ZERO to switch the scale off.
Page 7

EMC Guidance and Manufacturer’s Declaration
Guidance and manufacturer’s declaration –electromagnet emissions.
The M-310 (MS-4400I) is intended for use in the electromagnetic environment specified below. The customer
or user of this scale should ensure that it is used in such environment.
Emission Test
Compliance
Electromagnetic environment-
guidance
RF emissions
CISPR 11
Group 1
This scale uses RF energy only for
its internal function. Therefore, its
RF emissions are very low and not
likely to cause any interference in
nearby electronic equipment.
RF emissions
CISPR 11
Class B
This scale is suitable for use in all
establishments, including domestic
establishments and those directly
connected to the public low-
voltage power supply network that
supplies buildings used for
domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/flicker
emissions
IEC 61000-3-3
Compliance
Guidance and manufacturer’s declaration –electromagnetic immunity.
The M-310 (MS-4400I) is intended for use in the electromagnetic environment specified below. The customer
or the user of this scale should ensure that it is used in such an environment.
Immunity Test
IEC 60601 Test Level
Compliance Level
Electromagnetic
Environment Guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
6 kV contact
8 kV air
6 kV contact
8 kV air
Floors should be wood,
cement or ceramic tile. If floors
are covered with synthetic
material, the relative humidity
should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
2 kV for power supply
lines +1 kV for
input/output lines
2 kV for power supply
lines not applicable
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge IEC 61000-4-5
1kV line(s) to line(s)
2 kV line(s) to earth
1 kV differential mode
not applicable
Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage Dips, short
interruptions and voltage
variations on power
supply input lines IEC
61000-4-11
<5% UT (>95% dip in UT)
for 0.5 cycle 40% UT
(60% dip in UT) for 5
cycles 70% UT (30% dip
in UT) for 25 cycles <5%
UT (>95% dip in UT) for
<5% UT (95% dip in UT)
for 0.5 cycle 40% UT
(60% dip in UT) for 5
cycles 70% UT (30% dip
in UT) for 25 cycles <5%
UT (>95% dip in UT) for
Mains power quality should be
that of a typical commercial or
hospital environment. If the
user of this scale requires
continued operation during
power mains interruptions, it is
Page 8

5s
5s
recommended that this scale
is powered from an
uninterruptable power supply
or a battery.
Power frequency (50/60
Hz) magnetic field IEC
61000-4-8
3 A/m
3 A/m
The scale’s power frequency
magnetic fields should be at
levels characteristic of a typical
location in a typical
commercial or hospital
environment.
Note UT is the A.C mains voltage prior to application of the test level.
Guidance and manufacturer’s declaration –electromagnetic immunity.
This scale is intended for use in the electromagnetic environment specified below. The customer or the user
of the scale should ensure that it is used in such an environment.
Immunity Test
IEC 60601 test level
Compliance level
Electromagnetic
environment-guidance
Conducted RF
IEC 61000-4-6
3 Vrms
150 KHx to 80 MHz
3 Vrms
Portable and mobile RF
communications equipment
should be used no closer to
any part of the scale including
cables, than the
recommended separation
distance calculated from the
equation applicable to the
frequency of the transmitter.
Recommended separation
distance:
d = 1,2 √ P
d = 1,2 √ P 80MHz to 800 MHz
d = 2,3 √ P 800MHz to 2,5 GHz
Where P is the maximum
output power rating of the
transmitter in watts (w)
according to the transmitter
manufacturer and d is the
recommended separation
distance in meters (m).
Field strengths from fixed RF
transmitters, as determined by
an electromagnetic site
survey, should be less than the
compliance level in each
frequency range.
Interference may occur in the
vicinity of equipment marked
Page 9

Radiated RF
IEC 61000-4-3
3 V/m 80 MHz to 2,5
GHz
3 V/m
with the following symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
A) Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an
electromagnetic site survey should be considered. If the measured field strength in the location in which
the scale is used exceeds the application RF compliance level above, the scale should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be necessary,
such as re-orienting or relocating the scale.
B) Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Recommended separation distance between portable and mobile RF communications
equipment and the M-310 (MS-4400I).
This scale is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. The customer or the user of the scale can help prevent electromagnetic interference by
maintaining a minimum distance between portable and mobile RF communications equipment (transmitters)
and the scale as recommended below, according to the maximum output power of the communications
equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter m
150 kHz to 80 MHz
d = 1,2√ P
80 MHz to 800 MHz
d = 1,2√ P
800 MHz to 2,5 GHz
d = 2,3√ P
0.01
0.12
0.12
0.23
0.1
0.38
0.38
0.73
1
1.2
1.2
2.3
10
3.8
3.8
7.3
100
12
12
23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d
in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where p is
the maximum output rating of the transmitter in watts (w) according to the transmitter manufacturer.
NOTE1) At 80 MHz and 800 MHz, the separation distance for the high frequency range applies.
NOTE2) These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
Page 10

Error Messages
Low Battery
The scale’s alkaline AA type batteries are flat;
please replace the batteries.
Overload
This indicates that the scale’s load sensor(s)
have been overloaded. Reduce the loading
and retry.
Counting Error
1. The signal from the load cells is too
high. Please remove any weight from
the scale and try to power on again. If
the scale continues to show the error
message, it indicates a fault with the
electronics or wiring.
2. The signal from the load cells is too
low. Please remove any weight from
the scale and try again. If the scale
continues to show the error message,
it indicates a fault with the electronics
or wiring.
High/Low Zero Count
1. The scale is above its zero range.
Please remove any weight from the
scale and power on again. If the scale
continues to show the error message,
it indicates a fault with the
electronics.
2. The scale is below its zero range.
Check there is nothing jammed
underneath the scale and power on
again. If the scale continues to show
the error message, it indicates a fault
with the electronics.
EEPROM Error
This indicates there is a fault with the scale’s
software and is normally caused by a fault
with the load cell or wiring. Contact your
local service representative.
Page 11

Manufacturer’s Declaration of Conformity
This product has been manufactured in accordance with the harmonized
European standards, following the provisions of the below stated directives.
93/42/EEC as amended by 2007/47/EC
Medical Device Directive
2014/31/EU
Non-automatic Weighing Instruments Directive
Please see separate document showing on sticker of device for above CE marking.
Authorized EU Representative:
Manufactured by:
Charder Electronic Co., Ltd.
No.103, Guozhong Rd., Dali Dist.,
Taichung City 412,Taiwan (R.O.C.)
Page 12

Notes
Page 13

Notes
Page 14

Page 15

Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Manufacturing and Distribution:
Unit 7, Centurion Business Park,
Coggin Mill Way,
Rotherham,
S60 1FB
Head Office:
Unit 1, Genesis Business Park,
Sheffield Road,
Rotherham
S60 1DX
www.marsden-weighing.co.uk
IN-8417 80001H REV 10/2017
IN-1454 80001H REV 10/2017
