Martel BetaGauge II User manual

BetaGauge II™
Pressure Calibrator
User Guide

ii
Edition 2.0 (May 2006)
Copyright © 2006, Martel Electronics Corporation
All Rights Reserved.
This documentation is the confidential and proprietary
intellectual property of Martel Electronics Corporation.
Any unauthorized use, reproduction, preparation of
derivative works, performance or display of this
document, hardware, or software represented by this
document, without the express written permission of
Martel Electronics Corporation, is prohibited.
This document is an unpublished work of Martel
Electronics Corporation and is subject to LIMITED
DISTRIBUTION AND RESTRICTED DISCLOSURE
only.
Trademarks
Product or service names used, or referenced in italics,
are trademarks or service marks of their respective
manufacturers. Company names used herein are
trademarks or trade names of their respective
companies or organizations.

iii
Table of Contents
Table of Contents .............................................. iii
About this Guide......................................................xi
Comments...............................................................xii
Factory Sales..........................................................xiii
1- General Description.....................................1-1
Overview................................................................1-1
Carrying Case ........................................................ 1-2
Standard Equipment...............................................1-3
Optional Equipment...............................................1-3
BetaGauge II LCD.................................................1-4
Keypad Description ...............................................1-5
Channel Keys.....................................................1-6
Function Keys....................................................1-6
Number Keys.....................................................1-6
Special Keys ......................................................1-7
Menus .................................................................... 1-8
Setup Menu........................................................1-9
Calib Menu ......................................................1-11
Accessing the Menu Items...............................1-11
Procedure.....................................................1-11
2- Input Modules ..............................................2-1
Overview................................................................2-1
Installing and Removing Modules......................... 2-2
Installation Procedure ........................................ 2-2
Removal Procedure............................................ 2-3
Input Module Connections.....................................2-3
BetaPort–DC Electrical Modules....................... 2-3
Procedure....................................................... 2-4
BetaPort–P Pressure Modules............................2-5
Procedure....................................................... 2-5
Pressure Module Media Compatibility..................2-6
Pressure Module Safety.....................................2-7
Overpressure Protection.................................2-7

iv
3- Basic Operations.........................................3-1
Overview................................................................3-1
Selecting a Channel for Specific Functions ...........3-2
Procedure........................................................... 3-2
Selecting Pre-Programmed Display Units.............. 3-3
BetaPort–DC Module ........................................ 3-3
BetaPort–P Pressure Module............................. 3-4
Selecting a Water Column Measurement.......3-5
Procedure...................................................3-6
Zeroing Modules....................................................3-6
Zeroing Pressure Modules.................................3-7
Zeroing a Gauge Zero Reference Module...... 3-7
Zeroing an Absolute Zero Reference Module 3-8
Zeroing DC Modules .......................................3-10
Zeroing the Volts Input................................3-10
Zeroing the Milliamp Input..........................3-11
Setting the Damping Factor for Ch1/Ch2 ............3-12
Reset Damping Guidelines...............................3-13
Procedure.........................................................3-13
Viewing Module Information ..............................3-14
Procedure.........................................................3-14
Programming Trip Detection...............................3-15
Wet Contacts....................................................3-15
Dry Contacts....................................................3-16
Hints for Accurate Trip Measurements............3-16
Field Instrument Selection...........................3-16
Pressure Source Adjustment ........................3-17
Pressure Signal Ramping.............................3-17
Preliminary Setup ............................................3-18
Procedure.........................................................3-19
4- User Preferences.........................................4-1
Overview................................................................4-1
Programming and Viewing Calibrator Information4-2
Entering Owner Identification ........................... 4-2
Viewing Calibrator Information......................... 4-3
Turning the Keypad Beep On/Off..........................4-3
Procedure........................................................... 4-3

v
Setting LCD Preferences........................................ 4-4
Setting the Backlight Off Delay Time................4-4
Procedure....................................................... 4-4
Setting the LCD Contrast...................................4-5
Procedure....................................................... 4-5
Recovering the LCD Contrast............................4-6
Setting the Automatic Shut Off Delay Time.......... 4-7
Procedure........................................................... 4-7
Setting and Formatting the Time Display .............. 4-8
Setting the Time.................................................4-8
Formatting the Time .......................................... 4-9
Setting and Formatting the Date Display .............4-10
Setting the Date................................................4-10
Formatting the Date .........................................4-11
Procedure.....................................................4-12
5- Advanced Display Modes ...........................5-1
Overview................................................................5-1
Programming a User Defined Pressure Unit.......... 5-1
Procedure........................................................... 5-2
Programming Display Modes for BetaPort-DC
Modules .................................................................5-4
Engineering Unit Display...................................5-4
Defining a Unit Label .................................... 5-5
Defining the Field Instrument Type...............5-6
Defining Engineering Low/High Values........ 5-7
Percent Scale Display ........................................ 5-8
Defining the Field Instrument Type...............5-9
Defining the Expected Low/High Values ....5-10
Percent Error Display ......................................5-11
Defining the Field Instrument Type.............5-12
Defining the Expected Low/High Values ....5-13
Square Root Extraction....................................5-15
Defining a Unit Label ..................................5-15
Defining Output Milliamp Signal Values ....5-16

vi
6- Application Notes........................................6-1
Overview................................................................6-1
Modes of Operation...............................................6-1
Other Necessary Equipment...................................6-2
Calibration Tests....................................................6-3
Electrical to Pressure Test .....................................6-4
Conventional Mode ...........................................6-4
SYS Mode ......................................................... 6-6
Method 1........................................................6-6
Method 2........................................................6-8
Pressure to Electrical Test ...................................6-10
Conventional Mode .........................................6-10
SYS Mode .......................................................6-12
Method 1......................................................6-14
Method 2......................................................6-16
Method 3......................................................6-18
Method 4......................................................6-20
Electrical to Electrical Test..................................6-22
SYS Mode .......................................................6-23
Method 1......................................................6-24
Method 2......................................................6-26
Pressure to Pressure Test.....................................6-28
Conventional Mode .........................................6-28
SYS Mode .......................................................6-30
Method 1......................................................6-32
Method 2......................................................6-34
Method 3......................................................6-36
Temperature to Electrical Test.............................6-38
SYS Mode .......................................................6-39
Method 1......................................................6-40
Method 2......................................................6-42
Electrical Indicator or Loop Test.........................6-44
Conventional Mode .........................................6-44
SYS Mode .......................................................6-46
Pressure Indicator or Loop Test...........................6-48
Conventional Mode .........................................6-48
SYS Mode .......................................................6-50
Method 1......................................................6-50

vii
Method 2......................................................6-52
Temperature Indicator or Loop Test....................6-54
SYS Mode .......................................................6-54
7- Documenting Calibrator (SYS) Mode ........7-1
Overview................................................................7-1
Acquiring Instrument Maintenance Software ........ 7-1
Before You Begin..................................................7-2
Downloading Instrument Tests ..........................7-2
Connecting Necessary Equipment .....................7-3
SYS Mode Levels.................................................. 7-3
Main Level......................................................... 7-3
Back Screen Level.............................................7-4
Execute Level .................................................... 7-4
Accessing the Main Level...................................... 7-5
Tag Status Screen Description........................... 7-5
Menu Items........................................................7-7
Viewing a Specific Tag...................................... 7-7
Viewing the Test Points for a Specific Tag .......7-8
Viewing the Calibration Results for a
Specific Tag....................................................7-9
Accessing the Back Screen Level........................7-10
Back Screen Description..................................7-10
Menu Items......................................................7-11
Erasing Data for a Specific Tag.......................7-12
Accessing the Execute Level ...............................7-13
Test Setup Screen Description.........................7-13
Choosing Appropriate Modules.......................7-15
Example 1: Over-Pressure Protection.........7-15
Example 2: Ensuring Proper Module
Accuracy...................................................7-15
Accessing the Zero Screen...............................7-16
Zero Screen Description ..............................7-16
Zeroing the Display Readings......................7-17
Accessing the Execute Screen..........................7-18
Execute Screen Description.........................7-19
Tag Calibration ............................................7-20
Accessing the Post-Test Status Screen.............7-22
Post-Test Status Screen Description............7-22

viii
Specifying Post-Test Status Information......7-23

ix
A- Battery Care/Maintenance..........................A-1
Overview...............................................................A-1
Battery Packs ........................................................ A-4
Guidelines for Using Batteries..............................A-5
Installing a Battery Pack.......................................A-5
Removing a Battery Pack......................................A-6
Viewing the Battery Voltage.................................A-7
Charging the Batteries ..........................................A-8
Standard Pack...................................................A-8
Procedure......................................................A-8
Quick Charge Pack (optional)...........................A-9
Procedure......................................................A-9
Intrinsically Safe Battery Pack (optional).......A-10
Procedure....................................................A-10
B- Specifications..............................................B-1
Available Pressure Ranges.................................... B-1
Gauge (PSIG) ................................................... B-1
Sealed Gauge (PSIG)........................................ B-1
Vacuum (PSIG) ................................................ B-1
Absolute (PSIA)................................................ B-2
Compound (PSIG) ............................................ B-2
Differential (PSID) **....................................... B-2
Other Pressure Units (Keypad Selectable)........ B-3
Available Electrical Ranges.................................. B-4
Voltage ............................................................. B-4
Current.............................................................. B-4
Accuracy............................................................... B-4
Pressure............................................................. B-4
Electrical........................................................... B-4
Environmental....................................................... B-5
Temperature...................................................... B-5
Relative Humidity............................................. B-5
Effects............................................................... B-5
Overpressure..................................................... B-5
Alarm Trip Detect................................................. B-5
Damping Factor ....................................................B-5
Display.................................................................. B-6

x
Power Supply........................................................ B-6
Circuit Protection..................................................B-6
Pressure Connections............................................B-6
Electrical Connections.......................................... B-6
Weight .................................................................. B-6
Size ....................................................................... B-6
C- Conversion Factors....................................C-1
Overview............................................................... C-1
D- Service Information ....................................D-1
Service Schedule...................................................D-1
Return Information ...............................................D-2
Return Authorization ........................................D-2
Packaging..........................................................D-2
Limited Warranty..................................................D-3
Calibrator Registration..........................................D-4
Manual Registration..............................................D-4

xi


xi
Introduction
The BetaGauge II™Pressure Calibrator is the most
advanced and accurate handheld pressure calibrator
available. This calibrator was engineered to perform in
any industrial environment and is equipped with
everything you need for maintaining your pressure
instruments to your manufacturer’s specifications.
About this Guide
This guide provides complete information on the proper
use and operation of the BetaGauge II. A brief
description of each section follows:
Section 1 provides general information regarding the
BetaGauge II, as well as a description of the keyboard
and menu. In addition, it provides information on
standard and optional equipment.
Section 2 describes the two types of input modules
available for the BetaGauge II. It also explains how to
install and remove modules and how to connect field
devices to both module types.
Section 3 explains how to perform basic BetaGauge II
operations, such as specifying pre-programmed display
units, zeroing displayed values, and programming trip
detection.
Section 4 explains how to set user preferences, such as
viewing and programming owner and calibrator
information, turning the keypad beep on and off, and
setting LCD preferences.
Section 5 explains how to set up user-defined display
modes for both electrical and pressure units.
Section 6 explains how to perform the possible
calibration tests using the BetaGauge II.

xii
Section 7 explains how to use the BetaGauge II with
third party software to provide automated computer
aided calibration.
Appendix A provides the dangers, warnings, and
cautions for using battery packs and explains other
battery related information.
Appendix B lists the detailed specifications for the
BetaGauge II.
Appendix C lists the pressure conversion factors for
converting pounds per square inch (PSI) to other
pressure units.
Appendix D describes the necessary service required
for the BetaGauge II. In addition, it explains how to
contact the factory for technical support and how to
arrange for any needed servicing. This section also
includes the Limited Warranty statement.

xiii
Comments
Martel Electronics Corporation is interested in your
response to our products and to this guide. If you have
any comments or suggestions, you may contact us as
follows:
Mail: Martel Electronics Corporation
1F Commons Drive, #39
P.O. Box 770
Londonderry, NH 03053
Voice: Inside the United States
1-800-821-0023
Outside the United States
1-603-434-1433
E-Mail: [e-mail]
Please tell us how to contact you if we have any
questions or follow-up to your inquiry.
Factory Sales
To purchase optional items or additional modules for
the BetaGauge II, please contact us at the numbers
above.
You can also visit our web site to view our other
calibration products, download product information and
find out how to return calibrators for annual
recertification.
See us at www.martelcalibrators.com.

xiv


1-1 General Description
1-General Description
Overview
The BetaGauge II pressure calibrator is the most
advanced and accurate handheld pressure calibrator
available today. Its 3½ inch diagonal liquid crystal
display (LCD), membrane keypad, and user-prompt
programming make the BetaGauge II easy to operate.
An illustration is shown below:
Figure 1-1 BetaGauge II

General Description 1-2
Carrying Case
The BetaGauge II comes with a two-section padded
vinyl carrying case. It is recommended that you use the
case at all times to protect the calibrator from damage
due to chemicals, dust, and dirt. The carrying case is
described below:
Front Section. The calibrator is secured in the front
section of the case with an elastic strap that fits between
the keypad and the display.
Back Section. The back section of the case provides
space for carrying three modules, this user guide, and
communications cables. There is also space for fittings
or other connectors, if needed.
Bottom Flap. A flap at the bottom of the case is
secured with Velcro™. You can loosen the flap to
install and use modules while the calibrator is in the
case. Keep the flap closed when the calibrator is not in
use to keep foreign material out of the module bays.
Front Flap. The flap at the front of the case has a
pouch for holding the calibrator test leads.
Carrying Strap. The carrying strap on the case may be
adjusted for comfort as a shoulder strap (or you can
remove the strap). It can also be used to hang the
calibrator for use in the field.

1-3 General Description
Standard Equipment
The BetaGauge II is supplied with the following
standard equipment:
One pressure calibrator hand held (HHU) unit
One standard voltage/current DC input module
One battery pack (nickel-cadmium, rechargeable)
One set of test leads
One battery charger
One vinyl carrying case
One 9-pin D shell to 9-pin D shell serial cable
Optional Equipment
The BetaGauge II is available with any of the following
options:
Additional standard input modules (28 pressure
ranges to choose from)
Vacuum and pressure pumps
Quick charge battery pack (with internal
conditioner)
Intrinsically safe battery pack (for CSA Exia rated
main units)
Battery charger for quick charge battery pack
Replacement test leads
Additional battery packs (standard, intrinsically
safe, and quick charge)

General Description 1-4
BetaGauge II LCD
The BetaGauge II liquid crystal display is divided into
four sections. These sections are described below in the
order that they appear on the display from top to
bottom. Refer to the illustration below:
Figure 1-2 BetaGauge II LCD
Time/Date/Battery Indicator. The calibrator’s
current time and date appears to the left of this
section and the approximate battery voltage
indicator appears to the right.
Channel 1 Input Information. This section
displays the current Channel 1 input reading in
pressure units, Volts, or milliamps.
Channel 2 Input Information. This section
displays the current Channel 2 reading in pressure
units, Volts, or milliamps.
Display Screen. This section shows the current
menu, the current menu items associated with the
four function keys (F1 through F4), and other
displays depending on the current function you are
performing.

1-5 General Description
Keypad Description
The keypad on the BetaGauge II allows you to enter
data, scroll through the menus, and select menu items.
A sample keypad is shown below:
Figure 1-3 BetaGauge II Keypad
The BetaGauge II keypad consists of the following key
groups:
Channel keys
Function keys
Number keys
Special keys
Each of the key groups are described on the following
pages.
