Marway Optima 529 Series User manual

Optima™529 Series
Power Distribution Units
Operating Guide and Reference
Aug 2022 : P/N 501036-000 Rev D
Group C Group B Group A
Group C Group B Group A
OFFONOFFON OFFON
Group C Group B Group A
Group C Group B Group A
Group A
Group A
Group C
Group C
OFFON OFFON OFFON
Main
Group C Group B Group A
OFFON
Group C Group B Group A
Group C
Group C
Group B
Group B
Group A
Group A
OFFONOFFON OFFON
Main
Group C
Group C
Group B
Group B
Group A
Group A
OFFON
Main
OFFON

Page 2
Optima 529 Series
1General 3
1.1 Documentation Symbols (EN)................................................ 3
1.2 Safety Notices (EN)................................................................. 3
1.3 Symboles de Documentation (FR)......................................... 4
1.4 Avis de sécurité (FR)............................................................... 4
1.5 General Description ............................................................... 5
1.6 Product Models....................................................................... 5
1.7 Product Ratings ...................................................................... 6
2Installation 7
2.1 Installation Notes.................................................................... 7
3Operation 8
3.1 Startup .................................................................................... 8
3.2 Breakers.................................................................................. 8
4 Specications 9
5Contact and Support 10
5.1 Repairs ..................................................................................10
5.2 Contact Options....................................................................10
5.3 Two Year Warranty................................................................ 10

Page 3
Optima 529 Series
1 General
1.1 Documentation Symbols (EN)
Safety and warning notices as well as general notices in this document are shown in a box with a symbol as follows:
Symbol for a life threatening danger.
Symbol for general safety notices (instructions and damage protection bans) or important
information for operation.
Symbol for general notices.
1.2 Safety Notices (EN)
Mortal danger - Hazardous voltage
• This product is classied as pluggable equipment. The mains inlet plug serves as the disconnect
device. The mains inlet plug shall be installed so that it is easily accessible.
• This product is equipped with a safety ground connection through the mains inlet plug, as well as
a redundant chassis ground screw on the rear panel. Ensure that the product is properly grounded
before applying power.
• Disconnect all power to the product prior to servicing control signal cabling.
• Do not open this product as it contains no user serviceable parts inside. All service concerns
should be directed to Marway Power Solutions.
• If this product is used in a manner which does not comply with this instruction manual, the
protection provided by the equipment may be impaired.
• All work on connections must be carried out under zero voltage (output disconnect), and may only
be performed by qualied and informed persons. Improper actions can cause fatal injury as well as
serious material damage.
• This product is intended for indoor use only and should not be exposed to excess moisture. Avoid
any use of liquids near the equipment, and condition which cause condensation.
• This product is intended for installation in a restricted access location by a skilled person.
• This product is intended for use by an instructed person.
• The equipment is only approved for use within the connection limits stated on the product label.
• The ratings for all output receptacles are marked on the chassis. Be sure to observe the ratings for
all connected load equipment.

Page 4
Optima 529 Series
1.3 Symboles de Documentation (FR)
Les consignes de sécurité et avertissements, ainsi que les avis généraux gurant dans ce document sont présentés dans
un encadré avec un symbole, comme illustré ci-dessous.
Symbole pour les avis de danger potentiellement mortel.
Symbole pour les avis de mise en garde pour la sécurité personnelle ou pour la protection de
l’équipement.
Symbole pour les avis importants concernant le fonctionnement.
1.4 Avis de sécurité (FR)
Danger de mort – Tension dangereuse
• Ce produit est classé comme un équipement enchable. La prise d’alimentation secteur sert de
dispositif de déconnexion. La prise d’alimentation secteur doit être installée de manière à être
facilement accessible.
• Ce produit est équipé d’une mise à la terre de sécurité via la prise d’alimentation secteur,
ainsi que d’une vis redondante de mise à la terre du châssis. Assurez-vous que le produit est
correctement mis à la terre avant de le mettre sous tension.
• Débranchez toute alimentation électrique du produit avant d’effectuer l’entretien du câblage des
signaux de commande.
• N’ouvrez pas ce produit, car il ne contient aucune pièce réparable par l’utilisateur. Tous les
problèmes de service doivent être adressés à Marway Power Solutions.
• Si ce produit est utilisé d’une manière non conforme au présent manuel d’instructions, la
protection fournie par l’équipement peut être compromise.
• Tous les travaux sur les connexions doivent être effectués sous une tension nulle et ne doivent
être effectués que par des techniciens qualiés et compétents. Des actions inappropriées peuvent
entraîner des blessures mortelles et des dommages matériels graves.
• Ce produit est conçu pour une utilisation à l’intérieur uniquement et ne doit pas être exposé à
une humidité excessive. Évitez toute utilisation de liquides à proximité de l’équipement et les
conditions susceptibles de provoquer de la condensation.
• Ce produit est destiné à être installé par une personne qualiée dans un endroit à accès restreint.
• Ce produit est destiné à être utilisé par une personne qui a reçu des instructions appropriées.
• L’utilisation de l’équipement est approuvée uniquement dans les limites de connexion indiquées
sur l’étiquette du produit.
• Les valeurs nominales de toutes les prises de sortie sont indiquées sur leur boîtier. Assurez-vous
de respecter les valeurs nominales de tous les équipements de charge raccordés.

Page 5
Optima 529 Series
1.5 General Description
The Optima 529 Series (model numbers MPD 529XXX) is a family of 16 power distribution units (PDUs) designed for use
with a single-phase supply power of either 120 Vac, 110–240 Vac, or 200–240 Vac.
Each PDU receives mains power through an inlet located at the bottom. Power is distributed to all outlets on one, two, or
three branches depending on the model. A variety of inlet and outlet connectors is available.
All models include a circuit breaker with indicator. All models are constructed of a steel chassis, are designed for xed
mounting within a 0U rack space in an EIA-310 compliant rack enclosure, and include tool-less buttons and congurable
mounting brackets for exibility in mounting.
1.6 Product Models
Models are primarily organized by size (full height and half height), then by the outlet congurations. Marway’s Standard
Products Catalog includes more detailed tables with exact model number congurations with inlets, outlets, and options
identied.
Chassis Style Model* Inlet Configuration Outlet Configuration
IEC
C13
IEC
C19
NEMA
5-15R
NEMA
5-20R
Full Height (66”)
IEC
529001 C20 chassis 36 6
529002 C20 cord 36 6
529003 L6-20P cord 36 6
529004 L6-30P cord 36 6
Full Height (66”)
NEMA
529005 5-15P cord 36
529006 5-20P cord 36
529007 L5-20P cord 36
529008 L5-30P cord 36
Short Height (40”)
IEC
529009 C20 chassis 18 3
529010 C20 cord 18 3
529011 L6-20P cord 18 3
529012 L6-30P cord 18 3
Short Height (40”)
NEMA
529013 5-15P cord 18
529014 5-20P cord 18
529015 L5-20P cord 18
529016 L5-30P cord 18
* Each model number begins with MPD and is followed by a –000 (allowing for future variations).

Page 6
Optima 529 Series
1.7 Product Ratings
By model number, the following are the corresponding inlet and outlet ratings.
Model Inlet Rating Outlet Ratings
529001
529002
529009
529010
100–240 Vac, 1ɸ, 50/60 Hz
16 A continuous
(20 A maximum)
• 100–240 Vac, 1ɸ, 12 A continuous (15 A max.) per C13 receptacle
• 100–240 Vac, 1ɸ, 16 A continuous (20 A max.) per C19 receptacle
• 16 A continuous (20 A max.) total per unit (regardless of receptacle
count used)
529003
529011
200–240 Vac, 1ɸ, 50/60 Hz
16 A continuous
(20 A maximum)
• 200–240 Vac, 1ɸ, 12 A continuous (15 A max.) per C13 receptacle
• 200–240 Vac, 1ɸ, 16 A continuous (20 A max.) per C19 receptacle
• 16 A continuous (20 A max.) total per unit (regardless of receptacle
count used)
529004
529012
200–240 Vac, 1ɸ, 50/60 Hz
24 A continuous
(30 A maximum)
• 200–240 Vac, 1ɸ, 12 A continuous (16 A max.) per C13 receptacle
• 200–240 Vac, 1ɸ, 16 A continuous (20 A max.) per C19 receptacle
• 16 A continuous (20 A max.) total per outlet group (regardless of
receptacle count used)
• 24 A continuous (30 A max.) total per unit (regardless of receptacle
count used)
529005
529013
100–120 Vac, 1ɸ, 50/60 Hz
12 A continuous
(15 A maximum)
• 100–120 Vac, 1ɸ, 12 A continuous (15 A max.) per 5-15R receptacle
• 12 A continuous (20 A max.) total per unit (regardless of receptacle
count used)
529006
529007
529014
529015
100–120 Vac, 1ɸ, 50/60 Hz
16 A continuous
(20 A maximum)
• 100–120 Vac, 1ɸ, 12 A continuous (15 A max.) per 5-15R receptacle
• 16 A continuous (20 A max.) total per unit (regardless of receptacle
count used)
529008
529016
100–120 Vac, 1ɸ, 50/60 Hz
24 A continuous
(30 A maximum)
• 100–120 Vac, 1ɸ, 16 A continuous (20 A max.) per 5-20R receptacle
• 16 A continuous (20 A max.) total per outlet group (regardless of
receptacle count used)
• 24 A continuous (30 A max.) total per unit (regardless of receptacle
count used)

Page 7
Optima 529 Series
2 Installation
2.1 Installation Notes
The following guidance must be followed for proper
installation of the product.
1. Mounting: This product is designed for mounting
in an EIA-310 compliant 19” rack. The user is
responsible for ensuring the mounting method
provides adequate structural support for the
product, and any attached cables. The user
is also responsible for ensuring the mounting
location provides adequate ventilation to
dissipate heat generated during operation of the
product. Ensure the product is securely mounted
before applying power.
2. There are multiple mounting congurations
derived from the relocatable positioning of the
optional mounting plates, or the use of tool-less
mounting buttons without plates (concentric
circles shown in red). Model-specic details are
available from the web site Product Selector.
3. Chassis ground: The rear of the chassis includes
a redundant chassis ground screw and ground
wire. If desired for your installation location,
connect the chassis ground wire to the rack
cabinet using an appropriate fastener.
4. Optionally, connect the appropriate cables between the PDU outlets and the equipment being powered by the PDU.
This may be done later according to the startup procedures suitable to the end-user’s equipment and application.
5. If applicable, connect the cabling between the PDU and remote EPO control panel.
6. PDU Main Breaker: Ensure the Main Breaker on the front of the PDU is in the off position before connecting the
PDU’s inlet cable to the facility power source. (It is best to switch all breakers to the off position.)
7. Facility Power Source: The single-phase facility power source for this product must include an overcurrent protective
device capacity as dened in the table below.
Main Inlet
Continuous
Current
Rating
Mains
Protection
Required
NEMA 5-15P 12 A 15 A
NEMA 5-20P 16 A 20 A
NEMA L5-20P 16 A 20 A
NEMA L6-20P 16 A 20 A
IEC C20 16 A 20 A
NEMA L5-30P 24 A 30 A
NEMA L6-30P 24 A 30 A

Page 8
Optima 529 Series
3 Operation
3.1 Startup
Switch the breaker(s) on the PDU chassis to the off position.
Insert the PDU’s inlet connector into the facility mains power source. If there is a facility power disconnect, switch that to
the On position. At this point, the PDU is energized, though the indicator lamps will be off.
Switch the PDU’s breaker(s) to the On position, and the indicator(s) will be lit. All outlets are now powered.
3.2 Breakers
Various models have one breaker or three breakers.
When there is a single breaker, in effect this behaves like a main breaker, protecting the whole unit, and providing on/off
control for the whole unit.
When there are three breakers, each breaker protects one group of outlets. Outlets are organized into identical groups.
Following the length of the PDU from the inlet, the rst breaker operates the rst group of outlets, etc.
Each breaker has it’s own indicator. When lit, power is being supplied to the correlating outlet group.
All models use 2-pole breakers with both line and neutral routed through the breaker.

Page 9
Optima 529 Series
4 Specications
Inlet Voltage Options
• 120 Vac, 50/60 Hz, single phase
• 100–240 Vac, 50/60 Hz, single phase
• 200–240 Vac, 50/60 Hz, single phase
• All voltages are listed as nominal input sources.
Current Capacity Options
• 12 A continuous load / 15 A maximum
• 16 A continuous load / 20 A maximum
• 24 A continuous load / 30 A maximum
• Based on NEC regulations, traditional load ratings are de-rated to
80% for continuous duty. For example, a traditional 30 A maximum
rating is now interpreted and labeled as a 24 A continuous duty
rating. Optima current ratings are shown with continuous/maxi-
mum rating values.
Overload Protection (standard)
• All models include UL 489 two-pole circuit breakers.
• All single-phase models are wired with both line and neutral
passing through the two-pole circuit breaker.
• All multi-breaker models are wired with one outlet group per
breaker.
Environment
• Operating Temperature: 32°F to 122°F
• Maximum Altitude: 6,562 feet
• Relative Humidity: 5% to 85% non-condensing
Dimensions
• Typical for all outlet types
• Download detailed drawings from web site
• Mounting by brackets or tool-less buttons, see “Installation”
3.50"
2.50"
2.50"
63.75"
37.25"
66.00"
Group C Group B Group A
40.00"
2.50"
37.25"
24.50"
Group C
Group C
Group B
Group B
Group A
Group A

Page 10
Optima 529 Series
5 Contact and Support
5.1 Repairs
If not otherwise arranged between Marway and the customer, repairs must be carried out by Marway. The unit must be
returned to Marway clearly labeled with a Return Materials Authorization (RMA) number. Contact Marway Support to
obtain an RMA. Package the equipment adequately and send it, together with a detailed description of the problem, and if
still under warranty, a copy of the invoice, to the address below.
5.2 Contact Options
Problems with or questions about operation of the unit, use of optional components, with the documentation or software,
can be addressed to technical support either by telephone or email.
Address Email Telephone
Marway Power Solutions
1721 S. Grand Ave.
Santa Ana, CA 92705
Technical support:
[e-mail]
All other issues:
[e-mail]
714-917-6200
5.3 Two Year Warranty
Marway Power Solutions warrants each of its manufactured units to be as described in its specications, made with
quality materials and good workmanship, but also limited by this warranty and no other.
Two Year Warranty — For a period of two years following the date of shipment, Marway will repair or exchange, at Marway’s
sole discretion, any unit purchased shown to be defective in materials or workmanship when used for its intended
purpose. This will be done at no charge to the purchaser. Purchaser will return unit(s) at its own expense and only with
prior autorization from the factory. Instructions will be given by an authorized factory representative at the time an inquiry
is made. All repairs will be made at Marway Power Solutions’ corporate headquarters.
Transferability — This warranty is fully transferable to the end user if the purchaser is an original equipment manufacturer
and the Marway unit is a component of their product or system sold to an end user.
Further Limitations — Marway’s liability under the terms of this warrenty and the purchase and sale of its units is limited
to the repair or replacement of its units. Marway shall in no situation be liable for any special, consequential damages
or other damages of any kind or nature. Marway’s warranty does not cover units damaged by accident, abuse, misuse,
unauthorized repair and such-the-like occurences out of Marway’s control.
Exclusion of all Implied Warranties — There are no warranties which extend beyond description on the face hereof. There
are no warranties that any unit is t for any particular purpose nor that they are merchantable.

Optima™529 Series Power Distribution Units
Operating Guide P/N 501036-000 Rev D
© 2021–2022, Marway Power Systems, Inc. All rights reserved.
Optima™, Optima RCM™, Commander™, TwinPower™, mPower™, and mPower DC™ are trademarks of Marway Power
Systems, Inc. All other trademarks are the property of their respective owners.
Global Support Contacts
Web: www.marway.com
Email: [e-mail]
[e-mail]
Phone: [phone] (7am–5pm PST)
ere may be updates to this documentation at:
http://www.marway.com/docs
Marway Power Solutions
1721 S. Grand Ave., Santa Ana, CA 92705
800-462-7929 •[e-mail]
