Master BJA70B User manual

PORTABLE
FORCED
AIRHEATERS
®
OWNER’S MANUAL
BJA100C
BJB100C
BJ150
IMPORTANT
Read and understand this manual before assembling, starting or servicing
heater. Improper use of heater can cause serious injury. Keep this manual
for future reference.
BJA70B
BJB70B

2
102331
Safety Information.........................................................................2
Product Identification .................................................................... 4
Unpacking......................................................................................5
Assembly .......................................................................................5
Theory of Operation ......................................................................6
Fuels ..............................................................................................6
Ventilation .....................................................................................7
Operation .......................................................................................7
Storing, Transporting, or Shipping ................................................8
Preventative Maintenance Schedule..............................................8
Troubleshooting.............................................................................9
Service Procedures ........................................................................ 10
Upper Shell Removal ..............................................................10
Fuel Filter (BJA70B and BJB70B) .........................................10
Fuel Filter (BJA100C, BJB100C, and BJ150)........................11
Spark Plug ............................................................................... 11
Air Output, Air Intake, and Lint Filters .................................. 12
Pump Pressure Adjustment .....................................................12
Nozzle .....................................................................................13
Pump Rotor ............................................................................. 14
Fan........................................................................................... 15
Specifications................................................................................. 15
Illustrated Parts Breakdown and Parts List....................................16
BJA70B and BJB70B .............................................................16
BJA100C and BJB100C .........................................................18
BJ150 ......................................................................................20
Wheels and Handles................................................................ 22
Wiring Diagram.............................................................................23
Accessories ....................................................................................23
CONTENTS SECTION PAGE
IMPORTANT: Read this Owner’s Manual carefully and completely
before trying to assemble, operate, or service this heater. Improper
use of this heater can cause serious injury or death from burns, fire,
explosion, electrical shock, and carbon monoxide poisoning.
Carbon Monoxide Poisoning: Early signs of carbon monoxide poisoning
resemble the flu, with headaches, dizziness, and/or nausea. If you have these
signs, the heater may not be working properly. Get fresh air at once! Have
heater serviced. Some people are more affected by carbon monoxide than others.
These include pregnant women, persons with heart or lung disease or anemia,
those under the influence of alcohol, and those at high altitudes.
Make certain you read and understand all Warnings. Keep this manual for
reference. It is your guide to safe and proper operation of this heater.
WARNINGS
SAFETY
INFORMATION
DANGER
Carbon monoxide poisoning may lead to death!

3
102331
SAFETY
INFORMATION
Continued
WARNINGS (Continued)
• Use only kerosene or No. 1 fuel oil to avoid risk of fire or explosion. Never use
gasoline, naphtha, paint thinners, alcohol, or other highly flammable fuels.
• Fueling
a) Personnel involved with fueling shall be qualified and thoroughly familiar with
the manufacturer's instructions and applicable federal, state, and local regula-
tions regarding the safe fueling of heating units.
b) Only the type of fuel specified on the heater's data plate shall be used.
c) All flame, including the pilot light, if any, shall be extinguished and the heater
allowed to cool, prior to fueling.
d) During fueling, all fuel lines and fuel-line connections shall be inspected for leaks.
Any leaks shall be repaired prior to returning the heater to service.
e) At no time shall more than one day's supply of heater fuel be stored inside a
building in the vicinity of the heater. Bulk fuel storage shall be outside the struc-
ture.
f) All fuel storage shall be located a minimum of 25 feet (762 cm) from heaters,
torches, welding equipment, and similar sources of ignition (exception: the fuel
reservoir integral with the heater unit).
g) Whenever possible, fuel storage shall be confined to areas where floor penetra-
tions do not permit fuel to drip onto or be ignited by a fire at lower elevation.
h) Fuel storage shall be in accordance with the federal, state, or local authority hav-
ing jurisdiction.
• Never use heater where gasoline, paint thinner, or other highly flammable vapors are
present.
• Follow all local ordinances and codes when using heater.
• Heaters used in the vicinity of tarpaulins, canvas, or similar enclosure materials
shall be located a safe distance from such materials. The recommended mini-
mum safe distance is 10 feet (305 cm). It is further recommended that these en-
closure materials be of a fire retardant nature. These enclosure materials shall be
securely fastened to prevent them from igniting or from upsetting the heater due
to wind action.
• Use only in well-vented areas. Before using heater, provide at least a three-square-
foot opening of fresh, outside air for each 100,000 Btu/Hr of rating.
• Use only in places free of flammable vapors or high dust content.
• Use only the electrical voltage and frequency specified on model plate.
• Use only a three-prong, grounded extension cord.
• Minimum heater clearances from combustibles:
Outlet: 8 Ft. (250 cm) Sides,Top, and Rear: 4 Ft. (125 cm)
• Locate heater on a stable and level surface if heater is hot or running or a fire may
occur.
• When moving or storing heater, keep heater in a level position or fuel spillage may
occur.
• Keep children and animals away from heater.
• Unplug heater when not in use.
• When used with thermostat, heater may start anytime.
• Never use heater in living or sleeping areas.
• Never block air inlet (rear) or air outlet (front) of heater.
• Never move, handle, refuel, or service a hot, operating, or plugged-in heater.
• Never attach duct work to front or rear of heater.

4
102331
Side Cover
PRODUCT
IDENTIFICATION
Figure 1 - BJA70B and BJB70B
Figure 2 - BJA100C and BJB100C
Fan Guard
Power Cord
Fuel Cap
Air Filter
End Cover
Hot Air Outlet
Upper Shell
Fuel Tank
Lower Shell
Fuel Gauge
Flame-Out Control
Reset Button
Side Cover
ON/OFF Switch
Side Cover
ON/OFF Switch
Upper Shell
Hot Air
Outlet
Fuel Tank
Fan Guard
Fuel Cap
Fuel Gauge
Lower
Shell
Power Cord
Flame-Out Control
Reset Button
Fuel
Tank
Upper Shell
Hot Air
Outlet
Lower
Shell
Fuel Cap
Side Cover
ON/OFF Switch
Flame-Out Control
Reset Button
Power Cord
Fuel Gauge
Figure 3 - BJ150

5
102331
UNPACKING 1. Remove all packing items applied to heater for shipment.
2. Remove all items from carton.
3. Check items for any shipping damage. If heater is damaged, promptly inform
dealer where you bought heater.
ASSEMBLY These models are furnished with wheels and handles. Wheels, handles, and the
mounting hardware are found in the shipping carton.
Tools Needed
• Medium Phillips Screwdriver
• 3/8" Open or Adjustable Wrench
• Hammer
1. Slide axle through wheel support frame. Install wheels on axle.
IMPORTANT: When installing wheels, point extended hub of wheels toward
wheel support frame (see Figure 4).
2. Place cap nuts on axle ends. Gently tap with hammer to secure.
3. Place heater on wheel support frame. Line up holes on fuel tank flange with
holes on wheel support frame.
70 Models: Make sure hot air outlet end (front) of heater is over wheels.
100 and 150 Models: Make sure air inlet end (rear) of heater is over wheels.
4. Place handle or handles on top of fuel tank flange. Insert screws through
handle(s), fuel tank flange, and wheel support frame. Attach nut finger tight
after each screw is inserted.
5. After all screws are inserted, tighten nuts firmly.
Nut
Screw
Front
Handle
Cap Nut
Wheel
Axle Extended
Hub
Rear
Handle
Wheel
Support
Frame
Fuel Tank
Flange
Air
Inlet
Hot Air
Outlet Screw Handle
Air
Inlet
Fuel Tank
Flange
Wheel Support
Frame
Nut
Cap
Nut
Axle
Extended
Hub
Wheel
70 Models
100 and 150 Models
Figure 4 - Wheel and Handle Assembly

6
102331
THEORY OF
OPERATION
The Fuel System: The air pump forces air through the air line. The air is then
pushed through the burner head nozzle. This air causes fuel to lift from the tank. A
fine mist of fuel is sprayed into the combustion chamber.
The Air System: The motor turns the fan. The fan pushes air into and around
the combustion chamber. This air is heated and provides a stream of clean, hot air.
The Ignition System: The electronic ignitor sends voltage to the spark plug.
The spark plug ignites the fuel and air mixture.
The Flame-Out Control System: This system causes the heater to shut down
if the flame goes out.
Fan
Fuel
Filter
Air For Fuel
System Air For Combustion And Heating Fuel
Spark
Plug
Combustion
Chamber Intake
Air
Filter
Motor Air Pump
Air line
To Burner Electronic Ignitor
Burner
Head
Clean
Heated
Air Out
Cool
Air
In
Output
Air
Filter
Nozzle
Fuel
Tank
FUELS
Figure 5 - Cross Section Operational View
WARNING
Use only kerosene or No. 1 fuel oil to avoid risk of fire or
explosion. Never use gasoline, naphtha, paint thinners,
alcohol or other highly flammable fuels.
Do not use heavy fuels such as No. 2 fuel oil or No. 2 Diesel. Using heavy fuels
will result in:
• clogged fuel filter and nozzle
• carbon build up on spark plug
• use of non-toxic anti-icer in fuel during very cold weather
IMPORTANT: Use a KEROSENE ONLY container. Be sure storage container is
clean. Foreign matter such as rust, dirt, or water will cause the flame-out control to
shut down heater. Foreign matter may also require you to clean fuel system often.

7
102331
WARNING
Review and understand the warnings in the Safety
Information Section , page 3. They are needed to safely
operate this heater. Follow all local codes when using this
heater.
OPERATION
To Start Heater
1. Follow all ventilation and safety information.
2. Fill fuel tank with kerosene or No. 1 fuel oil.
3. Attach fuel cap.
4. Plug power cord into receptacle with voltage/Hz as specified on heater nameplate.
5. Turn ON/OFF switch to "ON".
Extension Cord Wire Size Requirements
Up to 100 feet (30.5 meters) long, use 16 AWG (1.0 mm2) conductor
101 to 200 feet (30.6 to 61 meters) long, use 14 AWG (1.5 mm2) conductor
If heater does not start, push in flame-out control reset button (see Figures 6
and 7).
Continued
Figure 6 - Flame-Out Control Reset
Button (BJA70B and BJB70B) Figure 7 - Flame-Out Control Reset
Button (BJA100C, BJB100C, and BJ150)
Flame-Out
Control
Reset
Button
Flame-
Out
Control
Reset
Button
Provide a fresh air opening of at least three square feet (2800 square cm) for each
100,000 Btu/Hr rating. Provide extra fresh air if more heaters are being used.
Example: A 150,000 Btu/Hr heater requires one of the following:
• a two-car garage door raised six inches (15.24 cm)
• a single-car garage door raised nine inches (22.86 cm)
• two, thirty-inch (76.20 cm) windows raised twelve inches (30.48 cm)
WARNING
Follow the minimum fresh, outside air ventilation
requirements. If proper fresh, outside air ventilation is not
provided, carbon monoxide poisoning can occur. Provide
proper fresh, outside air ventilation before running heater.
VENTILATION

8
102331
To Stop Heater
1. Unplug power cord from outlet.
To Restart Heater
1. Wait 2 minutes after stopping heater.
2. Repeat steps under To Start Heater, page 7.
Note: If shipping, transport companies require fuel tanks to be empty.
1. Drain fuel tank by removing drain plug on underside of fuel tank.
2. Replace drain plug.
3. If any debris is noted in old fuel, add 1 or 2 quarts of clean kerosene to tank, stir,
and drain again. This will prevent excess debris from clogging filters during
future use.
4. Replace drain plug. Properly dispose of old and dirty fuel. Check with local
automotive service stations that recycle oil.
5. If storing, store heater in dry place. Make sure storage place is free of dust and
corrosive fumes.
IMPORTANT: Do not store kerosene over summer months for use during next
heating season. Using old fuel could damage heater.
OPERATION
Continued
STORING,
TRANSPORTING,
OR SHIPPING
Item How Often How To
Fuel tank Flush every 150-200 hours See Storing, Transporting, or
of operation or as needed. Shipping, above.
Air output and Replace every 500 hours of See Air Output, Air Intake,
lint filters operation or once and Lint Filters, page 12.
a year.
Air intake Wash and dry with soap and See Air Output, Air Intake,
filter water every 500 hours of and Lint Filters, page 12.
operation or as needed.
Fuel filter Clean twice a heating season See Fuel Filter, pages 10
or as needed. and 11.
Spark plug Clean and regap every 600 See Spark Plug, page 11.
hours operation or replace
as needed.
Fan blades Clean every season or as needed. See Fan, page 15.
Motor Not required/permanently
lubricated
WARNING
Never service heater while it is plugged in, operating, or
hot. Severe burns and electrical shock can occur.
PREVENTATIVE
MAINTENANCE
SCHEDULE

9
102331
TROUBLE-
SHOOTING
OBSERVED FAULT POSSIBLE CAUSE REMEDY
Wrong pump pressure
Dirty air output, air intake,
and lint filters
Dirty fuel filter
Dirt in nozzle
Dirty photocell lens
Bad flame-out control
Heater ignites, but
flame-out control
shuts off heater after
a short period of time
See Pump Pressure
Adjustment, page 12.
See Air Output, Air Intake
and Lint Filters, page 12.
See Fuel Filter, pages 10
and 11.
See Nozzle, page 13.
Clean photocell lens.
Replace flame-out control.
Heater will not
ignite, but motor runs
for a short period of
time.
Wrong pump pressure
Carbon deposits on spark
plug and/or improper gap
Dirty fuel filter
Dirt in nozzle
Water in fuel tank
Electronic ignitor not
grounded (earthed)
Bad electronic ignitor
See Pump Pressure
Adjustment, page 12.
See Spark Plug, page 11.
See Fuel Filter, pages 10
and 11.
See Nozzle, page 13.
Drain and flush fuel tank
with clean kerosene. See
Storing, Transporting, or
Shipping, page 8.
Make sure electronic
ignitor mounting is tight.
Replace electronic
ignitor.
Motor does not start
when heater is
plugged in, fan
rotates slowly or
does not turn.
ON/OFF switch in “OFF”
position
Flame-out control not reset
Binding pump rotor
Switch to “ON” position
Reset flame-out control
button, see Figures 6 and
7, page 7.
If fan is hard to turn, see
Pump Rotor, page 14.
WARNING
Never service heater while it is plugged in, operating, or hot.
Severe burns and electrical shock can occur.
WARNING: High voltage!

10
102331
SERVICE
PROCEDURES
Upper Shell Removal
1. Remove screws along each
side of heater using 5/16"
nut-driver. These screws
attach upper and lower
shells together.
2. Lift upper shell off.
3. Remove fan guard.
Figure 10 - Fuel Filter Removal (BJA70B and BJB70B)
Side Cover
Fuel Filter
(BJA70B and BJB70B)
1. Remove side cover screws
using 5/16" nut-driver.
2. Remove side cover.
3. Pull rubber fuel line off
fuel filter neck.
4. Carefully pry bushing and
fuel filter out of fuel tank.
5. Wash fuel filter with clean
fuel and replace in tank.
6. Attach rubber fuel line to
fuel filter neck.
7. Replace side cover.
Figure 8 - Upper Shell Removal (BJA70B and BJB70B)
WARNING
Never service heater while it is plugged in, operating, or
hot. Severe burns and electrical shock can occur.
Upper
Shell
Figure 9 - Upper Shell Removal (BJA100C, BJB100C, and BJ150)
Fan
Guard
Upper
Shell
Fuel Line
Fuel Filter

11
102331
Fuel Filter
(BJA100C, BJB100C and
BJ150)
1. Remove side cover screws
using 5/16" nut-driver.
2. Remove side cover.
3. Pull upper fuel line off fuel
filter neck.
4. Carefully pry bushing,
lower fuel line, and fuel
filter out of fuel tank.
5. Wash fuel filter with clean
fuel and replace in tank.
6. Attach upper fuel line to
fuel filter neck.
7. Replace side cover.
Figure 11 - Fuel Filter Removal (BJA100C, BJB100C, and BJ150)
Spark Plug
1. Remove upper shell (see
page 10).
2. Remove fan (see page 15).
3. Remove spark plug wire
from spark plug.
4. Remove spark plug from
burner head using 13/16"
open-end wrench.
5. Clean and regap spark plug
electrodes as follows:
BJA70B and BJB70B:
.055" (1.4 mm) gap,
BJA100C and BJB100C:
.075" (1.9 mm) gap,
BJ150: .085" (2.2 mm) gap.
6. Install spark plug in burner
head.
7. Attach spark plug wire to
spark plug.
8. Replace fan (see page 15).
9. Replace fan guard and
upper shell.
Figure 12 - Spark Plug Removal
Burner
Head
Spark
Plug
Figure 13 - Spark Plug Gap
Bend Here
to Adjust
Gap
Gap
Spark Plug Wire
and Rubber Cap
Side Cover
Fuel Filter, Bushing,
and Lower Fuel Line
Upper
Fuel Line

12
102331
Air Output, Air Intake,
and Lint Filters
1. Remove upper shell (see
page 10).
2. Remove filter end cover
screws using 5/16" nut-
driver.
3. Remove filter end cover.
4. Replace air output and lint
filters.
5. Wash or replace air intake
filter (see Preventative
Maintenance Schedule,
page 8).
6. Replace filter end cover.
7. Replace fan guard and
upper shell.
IMPORTANT: Do not oil
filters.
Figure 14 - Air Output, Air Intake, and Lint Filters (BJA70B and BJB70B)
Air Intake Filter
Filter End
Cover
Lint Filter
Air Output
Filter
Figure 15 - Air Output, Air Intake, and Lint Filters
(BJA100C, BJB100C, and BJ150)
Figure 16 - Pressure Gauge Plug Removal
Figure 17 - Adjusting Pump Pressure
Pump
Model Pressure (PSI)
BJA70B 4.0
BJB70B 4.0
BJA100C 4.0
BJB100C 4.5
BJ150 5.0 @ 50Hz
5.3 @ 60Hz
Pump Pressure
Adjustment
1. Remove pressure gauge
plug from filter end cover.
2. Install accessory pressure
gauge (part number
HA1180).
3. Start heater (see Operation,
page 7). Allow motor to
reach full speed.
4. Adjust pressure. Turn relief
valve to right to increase
pressure. Turn relief valve
to left to decrease pressure.
See specifications at right
for correct pressure for
each model.
5. Remove pressure gauge.
Replace pressure gauge
plug in filter end cover.
Fan Guard
Air Intake Filter
Lint Filter
Filter End
Cover
Air Output
Filter
Pressure
Gauge
Relief
Valve
Pressure
Gauge
Plug

13
102331
Nozzle
1. Remove upper shell (see
page 10).
2. Remove fan (see page 15).
3. Remove fuel and air line
hoses from burner head.
4. Remove spark plug wire
from spark plug.
5. Remove spark plug from
burner head using 13/16"
open-end wrench.
6. Remove three screws
using 5/16" nut-driver and
remove burner head from
combustion chamber.
7. Place burner head into vise
and lightly tighten.
8. Carefully remove nozzle
from burner head using
5/8" socket wrench (see
Figure 19).
9. Blow compressed air
through face of nozzle.
This will free any dirt in
nozzle area.
10.Inspect nozzle seal for
damage.
11.Replace nozzle into burner
head and tighten firmly
(80-110 inch-pounds/9.1-
12.4 n-m).
12.Attach burner head to
combustion chamber.
13.Install spark plug in burner
head.
14.Attach spark plug wire to
spark plug.
15.Attach fuel and airline
hoses to burner head.
16.Replace fan (see page 15).
17.Replace fan guard and
upper shell.
Figure 18 - Removing Burner Head
Spark
Plug
Combustion
Chamber
Burner Head
Air Line Hose Fuel Line Hose
Screw
Figure 19 - Removing Nozzle
Nozzle
Face
Nozzle
Burner
Head
Air line
Fitting Fuel line
Fitting
Nozzle
Seal
Spark Plug Wire
and Rubber Cup

14
102331
Pump Rotor
(Procedure if rotor is binding)
1. Remove upper shell (see
page 10).
2. Remove filter end cover
screws using 5/16" nut-
driver.
3. Remove filter end cover
and air filters.
4. Remove pump plate
screws using 5/16" nut-
driver.
5. Remove pump plate.
6. Remove rotor, insert, and
blades.
7. Check for debris in pump.
If debris is found, blow
out with compressed air.
8. Install insert and rotor.
9. Check gap on rotor.
Adjust to .003"/.004"
(.076/.101 mm) if needed
(see Figure 22).
Note: Rotate rotor one
full turn to insure the gap is
.003"/.004" (.076/.101 mm) at
tightest position. Adjust if
needed.
10.Install blades, pump plate,
air filters, and filter end
cover.
11.Replace fan guard and
upper shell.
12.Adjust pump pressure (see
page 12).
Note: If rotor is still binding,
proceed as follows.
13.Perform steps 1 through 6
above.
14.Place fine grade sandpaper
(600 grit) on flat surface.
Sand rotor lightly in
“figure 8” motion four
times (see Figure 23).
15.Reinstall insert and rotor.
16.Perform steps 10 through
12 above.
Figure 20 - Rotor Location (BJA70B and BJB70B)
Sandpaper
Figure 23 - Sanding Rotor
.003"/.004"
(.076/.101 mm) Gap
Measured With
Feeler Gauge
Rotor
Gap Adjusting
Screw
Gap
Adjusting
Screw
Blade
Figure 22 - Gap Adjusting
Screw Locations
Figure 21 - Rotor Location (BJA100C, BJB100C, and BJ150)
Insert
Blade
Rotor
Pump
Plate
Filter End
Cover
Air
Intake
Filter
Air
Output
Filter
Fan Guard
Insert Rotor
Filter End
Cover
Air
Intake
Filter
Air Output
Filter
Blade
Pump
Plate

15
102331
BJB70B BJA70B BJB100C BJA100C BJ150
Heat Output
(Kcal/hr) 16,500 16,500 22,000 24,000 38,000
Fuel Consumption
(liters/hr) 2.0 2.0 2.6 2.9 4.2
Fuel Tank Capacity
(liters) 16 16 32 32 47
Run Time per Tank
(hours) 8 8 12 11 11
Hot Air Output
(m3/min) 7.1 7.1 10.9 12.0 12.4@50Hz
13.7@60Hz
Voltage 100 100 100 100 100
Frequency (Hz) 50 60 50 60 50/60
Wattage (W) 190 200 240 260 300
Pump Pressure
(kg/cm) 0.28 0.28 0.32 0.28 0.35@50Hz
0.37@60Hz
(PSI) 4.0 4.0 4.5 4.0 5.0@50Hz
5.3@60Hz
Fan
IMPORTANT: Remove fan
from motor shaft before
removing motor from heater.
The weight of the motor
resting on the fan could
damage the fan pitch.
1. Remove upper shell (see
page 10).
2. Use 1/8" allen wrench to
loosen setscrew which
holds fan to motor shaft.
3. Slip fan off motor shaft.
4. Clean fan using a soft cloth
moistened with kerosene or
solvent.
5. Dry fan thoroughly.
6. Replace fan on motor
shaft. Place fan hub flush
with end of motor shaft
(see Figure 25).
7. Place setscrew on flat of
shaft. Tighten setscrew
firmly (40-50 inch-pounds/
4.5-5.6 n-m).
8. Replace fan guard and
upper shell.
SPECIFICATIONS
Figure 25 - Fan Cross Section
Setscrew
Motor
Shaft
Fan
Flush
Motor
Shaft
Setscrew Fan
Figure 24 - Fan, Motor Shaft, and Setscrew Location

16
102331
ILLUSTRATED
PARTS
BREAKDOWN
BJA70B and BJB70B
18-2
Motor and Pump Assembly
18-5
18-16
18-4
18-8
18-3
18-6 18-7
18-9
18-10
18-11
18-1218-13
18-14
18-15
10-2
10-3 10-4
10-5
10-6
10-7
10-1
18-1
18-18
Burner Head Assembly
18-17
40
41
43
547 46
2
4
3
67
8
10
11
12
12
14
18
21
22
24
27
28
29
30
31
32
34
38
37 19
13 9
33
35 36
42
39
23
44
45
1
26
15 17
20
16
25

17
102331
PARTS LIST
BJA70B and BJB70B
This list contains replaceable parts used in your heater. When ordering parts,
besuretoprovidethecorrectmodelandserialnumbers(fromthemodelplate),
then the part number and description of the desired part.
**Not available as an assembly, order parts separately.
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
19 M50050 Rubber Cap 1
20 NTC-4C Hex locknut 2
21 M50104-02 Bushing (wires) 1
22 M11084-26 Screw, #10-16 x 3/8" 6
23 098511-12 Lower Shell 1
24 M11271-8 Clip Nut 6
25 097061-01 Relay (motor start) 1
26 079010-18 Wire Assembly (red 16") 1
27 M10908-14 Screw, #8-32 x 3/8" 1
28 M29652-04 Rubber Airline 1
29 079973-01 Fuel Line 1
30 M16841-57 Wire Assembly (red 8 1/2") 1
31 M10990-3 Rubber Bushing 1
32 M50876-05 Fuel Filter Assembly 1
(Includes bushing)
33 101901-03 Electronic Ignitor 1
34 M11084-29 Screw, #10-16 x 3/4" 2
35 099125-03 Terminal Board 1
36 099157-01 Rivet 1
37 097702-01 Fuel Tank Cap 1
38 097997-02 Flame-Out Control 1
39 098513-57 Fuel Tank 1
40 097194-02AA Side Cover 1
41 M11084-26 Screw, #10-16 x 3/8" 2
42 099177-01 Hex Nut 1
43 097274-01 Jumper Plug 1
44 M9900-162 Wire Assembly (green 16") 1
45 M27417 Drain Plug 1
46 098226-01 ON/OFF Switch 1
47 097196-01 Switch Seal 1
PARTS AVAILABLE - NOT SHOWN
HA2210 Filler Neck Screen 1
102415-01 Wiring Decal 1
M51295-06 Tradename Decal 1
097208-27 Nameplate Decal (BJA70B) 1
097208-28 Nameplate Decal (BJB70B) 1
098070-01 Warning Decal 1
M9900-170 Wire Assembly (Black 7”)1
M9900-170 Wire Assembly (Black 12”)1
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
1 097190-01 Fuel Gauge 1
2 098511-128 Upper Shell 1
3 100647-01 Screw, #10-16 x 1/2" 6
4 098512-12 Combustion Chamber 1
5 097202-01 Receptacle 1
6 M16660 Photocell Bracket 1
7 M10908-2 Screw, #6-32 x 3/8" 2
8 HA3019 Photocell Assembly 1
9 102330-01 Power Cord 1
10 ** Burner Head Assembly 1
10-1 M50880-01 Nozzle 1
10-2 M10659-1 Nozzle Seal Washer 2
10-3 M10809-1 Nozzle Seal Spring 1
10-4 M8882 Nozzle Seal Sleeve 1
10-5 M51098-02 Burner Head Body 1
10-6 M50820-01 Barb Fitting 2
10-7 M10962-2 Spark Plug 1
11 M11084-27 Screw, #10-16 x 1/2" 3
12 M30865-02 Bushing 2
13 099492-01 Strain Relief Bushing 1
14 M50893-01 Fan (BJA70B) 1
097200-01 Fan (BJB70B) 1
15 M50631 Rubber Bumper 2
16 M15823-39 Screw, #8-18 x 1/2" 2
17 101205-01 Motor and Relay Bracket 1
18 ** Motor and Pump Assembly 1
18-1 097286-02 Motor 1
18-2 079975-02 Pump Body 1
18-3 M22009 Insert 1
18-4 M22456-1 Rotor 1
18-5 M29608 End Pump Cover 1
18-6 M29632 Lint Filter 1
18-7 M29633 Intake Filter 1
18-8 M29609 End Filter Cover 1
18-9 M12461-31 Screw, #10-32 x 1" 3
18-10 M8940 Steel Ball (1/4" Dia.) 1
18-11 M10993-1 Pressure Relief Spring 1
18-12 M27694 Adjusting Screw 1
18-13 M22997 Plug 1
18-14 M29612-01 Output Filter 1
18-15 M12461-31 Screw, #10-32 x 1" 6
18-16 M50016 Elbow, 90˚(Barb Fitting) 1
18-17 M8643 Blade 4
18-18 FHPF3-5C Screw, #10-32 x 5/8" 2

18
102331
ILLUSTRATED
PARTS
BREAKDOWN
BJA100C and BJB100C
13-1
13-2 13-3
13-4
13-5
13-7
13-8
13-9 13-10
13-11
13-12
13-13
13-15
13-16
13-17
13-18
13-14
Motor and Pump Assembly
8-2
8-6
8-5
8-4
8-3
8-1
Burner Head Assembly
8-7
13-6
1
2
3
45
7
8
9
10 11
18
20
17
19
1615
12 13
14
25
29
30
31
32
33
34
35
36
37
38 39
40
41
6
50
21
22
23
24
45
27
28
26
42
43
49 48 46
47
44

19
102331
This list contains replaceable parts used in your heater. When ordering parts,
besuretoprovidethecorrectmodelandserialnumbers(fromthemodelplate),
then the part number and description of the desired part.
PARTS LIST
BJA100C and BJB100C
**Not available as an assembly, order parts separately.
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
1 098511-138 Upper Shell 1
2 100647-01 Screw, #10-16 x 1/2" 8
3 098512-07 Combustion Chamber 1
4 M16660 Photocell Bracket 1
5 HA3019 Photocell Assembly 1
6 M27417 Drain Plug 1
7 M10908-2 Screw, #6-32 x 3/8" 2
8 ** Burner Head Assembly 1
8-1 M51120-01 Nozzle (BJA100C) 1
M23103 Nozzle (BJB100C) 1
8-2 M10659-1 Nozzle Seal Washer 2
8-3 M10809-1 Nozzle Seal Spring 1
8-4 M8882 Nozzle Seal Sleeve 1
8-5 M50924-03 Burner Head Body 1
8-6 M50820-02 Barb Fitting 2
8-7 M10962-2 Spark Plug 1
9 M11084-27 Screw, #10-16 x 1/2" 3
10 M50814-06 Air Line 1
11 M51345-01 Fuel Line 1
12 M51153-01 Fan (BJA100C) 1
097293-01 Fan (BJB100C) 1
13 ** Motor and Pump Assembly 1
13-1 098644-02 Motor 1
13-2 079975-02 Pump Body 1
13-3 FHPF3-5C Screw, #10-32 x 5/8" 2
13-4 M22009 Insert 1
13-5 M22456-1 Rotor 1
13-6 M50545 End Pump Cover 1
13-7 M12179 Intake Filter 1
13-8 M16545 End Filter Cover 1
13-9 M8940 Steel Ball (1/4" Dia.) 1
13-10 M10993-1 Pressure Relief Spring 1
13-11 M27694 Adjusting Screw 1
13-12 M22997 Plug 1
13-13 M12461-31 Screw, #10-32 x 1" 4
13-14 M12244-1 Output Filter 1
13-15 M12461-31 Screw, #10-32 x 1" 6
13-16 M11637 Lint Filter 1
13-17 M50820-02 Barb Fitting 1
13-18 M8643 Blade 4
14 M51114-01 Fan Guard 1
15 M50631 Rubber Bumper 2
16 M15823-39 Screw, #8-18 x 1/2" 2
17 101206-01 Motor and Relay Bracket 1
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
18 097061-01 Relay (motor start) 1
19 079010-20 Wire Assembly (red 18") 1
20 NTC-4C Hex locknut 2
21 101901-03 Electronic Ignitor 1
22 M11084-29 Screw, #10-16 x 3/4" 2
23 099125-03 Terminal Board 1
24 099157-01 Rivet 1
25 M50104-03 Bushing 2
26 M9900-192 Wire Assembly (green 16") 1
27 M50104-01 Bushing 2
28 099213-01 Button Plug 1
29 M11084-27 Screw, #10-16 x 1/2" 6
30 098511-140 Lower Shell 1
31 M11271-8 Clip Nut 8
32 M10908-14 Screw, #8-18 x 1/2" 1
33 M51150-01 Fuel Filter 1
34 M10990-3 Rubber Bushing 1
35 M51151-01 Fuel Line 1
36 098513-58 Fuel Tank 1
37 097702-01 Fuel Tank Cap 1
38 M16841-57 Wire Assembly (red 8 1/2") 1
39 097997-02 Flame-Out Control 1
40 099492-01 Strain Relief Bushing 1
41 102330-01 Power Cord 1
42 M51077-07AA Side Cover 1
43 M11084-27 Screw, #10-16 x 1/2" 4
44 M50050 Rubber Cap 1
45 099177-01 Hex Nut 1
46 098226-01 ON/OFF Switch 1
47 097196-01 Switch Seal 1
48 097202-01 Receptacle 1
49 097274-01 Jumper Plug 1
50 097190-04 Fuel Gauge 1
PARTS AVAILABLE - NOT SHOWN
HA2210 Filler Neck Screen 1
102415-01 Wiring Decal 1
M51295-06 Tradename Decal 1
097208-25 Nameplate Decal (BJA100C) 1
097208-26 Nameplate Decal (BJB100C) 1
098070-01 Warning Decal 1
M9900-170 Wire Assembly (Black 7”)2

20
102331
10-2
10-11
Motor and Pump Assembly
10-1
10-4
10-3
10-5
10-6
10-7
10-8
10-9 10-10
10-12
10-13
10-14
10-15
10-16
10-17
10-18
Burner Head Assembly
7-1
7-2
7-3
7-4
7-5 7-7
7-6
ILLUSTRATED
PARTS
BREAKDOWN
BJ150
1
2
3
4
5
6
7
8
23 19
910
16
25
26
27
24
28
20
22
21
30
31
41
33
34
40
17
18
32
37
38
44
46
45
42
29
47
13
35
36
48 43 14
39
49
15
12
11
