Matco Tools UTL12 User manual

Page 1
PRODUCT INFORMATION:
INTENDED USE OF THE TOOL
WARNING
DO NOT DISCARD – GIVE TO USER
The manufacturer warrants this product to the original user against
defective material or workmanship for a period of 1 year from the
date of purchase.
The manufacturer reserves the right to determine whether the part
or parts failed because of defective material, workmanship or other
causes. Failures caused by accident, alteration or misuse are not
covered by this warranty.
The manufacturer, at its discretion, will repair or replace product
covered under this warranty free of charge. Repairs or replacements
of products covered under this warranty are warranted for the
remainder of the original warranty period.
The manufacturer or its authorized service representatives must
perform all warranty repairs. Any repair to the product by
unauthorized service representatives voids this warranty. The rights
under this warranty are limited to the original user and may not be
transferred to subsequent owners.
The warranty is in lieu of all other warranties, expressed or implied,
including warranties of merchantability and fitness for a particular
purpose. Some states do not allow the exclusion or limitations of
incidental or consequential damages, so the above limitations may
not apply to you.
1 YEAR LIMITED WARRANTY
1901012-14
UTL12
When unpacking, check the parts diagram and part number
listing on page 2 to make sure all parts are included. If any
parts are missing or damaged, please call your distributor.
BEFORE USE
Study, understand and follow all instructions provided with
this product. Read these instructions carefully before
installing, operating, servicing or repairing this tool. Keep
these instructions in a safe, accessible place.
The UTL12 Ultra Thin Rechargeable Light is designed as a
hand-held portable electric powered light source which
provides direct light to work areas. Do not modify or replace
any pieces of this kit with foreign parts. Do not use these
tools outside of the designed intent. Never modify the tools
for any other purpose or use.
Made in China
to Matco specifications
Caution: To help prevent personal injury
• Use of this product can expose you to chemicals including
ethylene glycol, gasoline vapors and engine exhaust, which
are known to the State of California to cause cancer, birth
defects, or reproductive harm. For more information, visit
www.P65Warnings.ca.gov. Always wear ANSI approved
safety equipment, safety glasses and clothing when using
this product. Study, understand, and follow all instructions
provided with this product. Failure to read and follow all
warnings and operating instructions may result in
damages and serious injury or death.
• Always wear ANSI approved goggles when using this
product. (Users and Bystanders).
• Never use this tool for any application other than for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with accessories
not designed for it could result in serious injury or death.
• Always select the correct accessories of the correct size
and design for the job that you are attempting to perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
WARNING
Specifications:
Powerful, bright light. 400 lumen inspection light with
80 lumen top flashlight for 3 to 5 hours of use.
Durable design. Robust yet slim construction with
an IP66 waterproof rating.
Adapts for full access. 1/2" thick design features two rear
magnets and a clip on a swivel base magnet with hook.
ULTRA THIN
RECHARGEABLE LIGHT
2600mAH 3.7V Lithium-Ion
3 hrs
3 hrs / 5 hrs
400LM / 230LM
Green (high) / Red (low)
2 neodymium on back of light body,
1 on swivel base
IP 66
Battery:
Charge time:
Work time:
LED light intensity:
Battery indicator:
Magnets:
Waterproof grade:

PRODUCT LAYOUT
TOOL USE INSTRUCTIONS
Battery RunTime Indicator Light
• Green light: full power
• Red light: low power
(Estimated run time left is 20 minutes);
light needs charging.
Magnetic Base Removal
1: Push the tab with your thumb
along the "A" direction to release lock
2: Pull the magnetic base clip along
the "B" direction
A
B
Page 2 1901012-14
UTL12
ULTRA THIN
RECHARGEABLE LIGHT
On/Off Switch
• Press switch once: top flashlight on
• Press switch a second time: full brightness
• Press switch a third time: low brightness
• Press switch a fourth time: off
UTL12-04
WALL ADAPTER
UTL12-05
USB CABLE
LAMP
TOP LIGHT
INDICATOR LIGHT
SWITCH
MAGNET
MAGNET
• UTL12-01 Buckle Clip
• UTL12-02 Adjust Nut
• UTL12-03 Magnetic Base & Hook
MICRO USB CHARGING
HOLDER
HOOK
• The micro USB charging outlet is located on the bottom below the rubberized protective cover. The charging process is
indicated by a red LED light on the charge control indicator. When fully charged, the light will change to green.
• For first time use, charge your light for 3 - 4 hours before use, and allow 3 - 5 cycles of charging and discharging the
battery for optimum performance.
• Store the light in a dry place away from direct sunlight.
• Remove the charger adapter plug from the wall AC outlet when moving, otherwise it may cause damage to the power
cord, resulting in a fire.
• Unplug the charger adapter plug from the AC outlet for safety purposes when cleaning or leaving the unit unused for
more than a day. Doing otherwise may cause a fire or electric shock.
