Matrix Connexus CXR50 User manual

CXR50CONNEXUS HOME

2

3
ENGLISH
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Inspect Hardware Monthly
Inspect Frame/Accessories Monthly
Clean Machine As Needed
PRODUCT SPECIFICATIONS
Class H (Home) equipment for indoor use only.
Max User Weight,
Max Pull-up/Training Bar Load 159 kg / 350 lbs.
Max Resistance Band Training Load 91 kg / 200 lbs.
Product Weight 139 kg / 306.5 lbs.
Resistance Band Max Stretch/Load Gray: 3x length, 25 lbs.
Black: 3x length, 50 lbs.
Orange: 3x length, 100 lbs.
Overall Dimensions
(L x W x H)
228 x 114 x 216 cm /
90 x 45 x 85”
1 square foot
TRAINING AREA
45 × 90 in
(114 × 228 cm)
TOTAL AREA
8 × 10 ft (244 × 305 cm)
BEFORE YOU BEGIN
The Connexus Home CXR50 is an innovative platform that provides solutions for functional
training in the home. The CXR50 allows users to do suspension strap training, resistance band
training and numerous body-weight exercises utilizing the platform and weighted training bar.
LOCATION OF THE EQUIPMENT
Place the front of the equipment near a wall and leave a
little space for attaching straps and bands.
TOTAL AREA:
• The recommended free area and training area equals
a total area of 8 x 10 feet (244 x 305 cm).
• The free area surrounding the equipment should be 2 ft (61 cm).
LEVELING THE EQUIPMENT
The equipment should be level for optimum use. Once you have placed
the equipment where you intend to use it, raise or lower one or two of
the four adjustable levelers located on the bottom of the frame.
A carpenter’s level is recommended.
NOTE: There are four levelers on the equipment.
WARNING!
Our equipment is heavy, use care and additional help if necessary when
moving. Failure to follow these instructions could result in injury.
MAINTENANCE
1. DO NOT use any equipment that is damaged and or has worn or broken
parts. Use only replacement parts supplied by Customer Tech Support.
Contact information is located on the information card.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for
any reason. They contain important information. If unreadable or
missing, contact Customer Tech Support for a replacement.
3. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth
operating equipment. Equipment needs to be inspected at regular intervals.
4. Ensure that any person(s) making adjustments or performing
maintenance or repair of any kind is qualied to do so.
front
rear
FREE AREA
2 ft (0.6 m)
WIDE PATH

4
WARNING!
There are several areas during the assembly process where special
attention must be paid. It is very important to follow the assembly
instructions correctly and to make sure all parts are properly tightened.
Failure to correctly follow the assembly instructions provided could
result in loose connections and noise from the equipment.
ASSEMBLY
Before proceeding, nd the serial number located on a barcode sticker and
enter it in the space provided below.
SERIAL NUMBER
MODEL NAME
MATRIX CONNEXUS HOME CXR50
* Use the information above when calling for service.
SERIAL NUMBER LOCATION
UNPACKING
Unpack the equipment where you will be using it.
Place the carton on a level at surface.
TOOLS INCLUDED:
F8 mm Allen Wrench
F10 mm Allen Wrench
PARTS INCLUDED:
F1 Activity Base
F1 Left Frame Upright
F1 Right Frame Upright
F1 Pull-Up Bar
F2 Connection Covers
F1 Upper Crossbar
F1 Lower Crossbar
F1 Power Grid
F2 Base Anchors
F1 Training Bar
F6 Resistance Bands
F1 Foam Roller
F1 Smart Storage Chalkboard
F1 Hardware Kit
NEED HELP?
If you have questions or if there are any missing parts, contact Customer
Tech Support. Contact information is located on the information card.
ENGLISH

5
PULL-UP BAR
SUSPENSION ANCHOR
(STRAPS NOT INCLUDED)
SUSPENSION STRAP HOOKS
(NOT FOR TRAINING USE)
RIGHT FRAME UPRIGHT
POWER GRID
LOWER CROSSBAR
ACTIVITY BASE
LIFTING STRAP (FRONT AND REAR)
CONNECTION COVERS
LEFT FRAME UPRIGHT
UPPER CROSSBAR
TRAINING BAR STORAGE
RESISTANCE BANDS
TRAINING BAR
(WHEN IN STORAGE)
TRAINING BAR
(WHEN IN HOLDER)
TRAINING BAR HOLDER
BASE ANCHORS
LEVELER (4 TOTAL)
ENGLISH
WARNING
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID INJURY!
Keep children under the age of 14 away from
this strength training equipment. Teenagers
must be supervised at all times while using
this equipment.
This equipment is not intended for use by
persons with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given
1
2
supervision or instruction concerning
use of the equipment by a person
responsible for their safety.
All warnings and instructions should be
read prior to use. Use this equipment
for its intended purpose ONLY.
Inspect the equipment and accessories
3
4
before use. DO NOT use equipment or accessories
if they appear damaged or inoperable.
Do not exceed weight capacity of this equipment.
Injuries to health may result from incorrec t or
excessive training. Cease exercise if you feel faint
or dizzy. Obtain a medical exam before beginning
an exercise program.
5
6
Use care with all fitness accessories.
Horizontal adjustable bar is heavy. Support
bar from center of mass when detaching and
reat taching bar to frame structure. Ensure
bar is fully engaged with frame before use.
Proper footwear is required for usage.
Use only with accessories provided.
7
8
9
10
Only one user at a time allowed on equipment.
No climbing on frame.
All exercises should be
performed on the platform.
Do not use barbells
with this equipment.
11
12
13
14
SMART STORAGE CHALKBOARD
• MAGNETIC CHALKBOARD
• MAGNETIC HOLDER
• DEVICE TRAY (DEVICE NOT INCLUDED)

6
C
B
A
E
D
1
Hardware For Step 1
Description Qty
A
B
C
Bolt
Lock Washer
Flat Washer
4
4
4
Torque Value
15 Nm / 11 ft-lb
2
Hardware For Step 2
Description Qty
D
E
Bolt
Lock Washer
4
4
Torque Value
50 Nm / 37 ft-lb
ENGLISH
Tuck lifting straps under the
base after flipping it over
to avoid a tripping hazard.
IMPORTANT: Do not tighten
bolts until step 6 is complete.

7
A
A
B
C
3 4
Hardware For Step 4
Description Qty
A
B
C
Bolt
Lock Washer
Flat Washer
4
4
4
Torque Value
15 Nm / 11 ft-lb
ENGLISH
Hardware For Step 3
Description Qty
A Bolt 2
Torque Value
15 Nm / 11 ft-lb
IMPORTANT: Do not tighten
bolts until step 6 is complete.
IMPORTANT: Do not tighten
bolts until step 6 is complete.

8
A
B
C
A
B
C
5
Hardware For Step 5
Description Qty
A
B
C
Bolt
Lock Washer
Flat Washer
4
4
4
Torque Value
15 Nm / 11 ft-lb
6
Hardware For Step 6
Description Qty
A
B
C
Bolt
Lock Washer
Flat Washer
8
8
8
Torque Value
15 Nm / 11 ft-lb
ENGLISH
IMPORTANT: Do not tighten
bolts until step 6 is complete.
Tighten all bolts from steps 1–6. Tighten
to torque values listed in each step.

9
7 8
ENGLISH
ASSEMBLY COMPLETE!

© 2018 Johnson Health Tech
Rev 1.0 ENGLISH
CXR50
