Matrix CXC User manual

CXC CONSOLE
MX18_OM_CXC_console_r1_1_A.indd 1 3/1/18 8:42 AM

2 3
B
C
A
D
SPEED SENSOR
SPEED SENSOR BRACKET
CONSOLE
LEFT ACCESS COVER
INSTALLED
SENSOR AND
MAGNET
Hardware
Description Qty
A
B
C
D
Screw (M5x10L)
Magnet
Screw (M4x6L)
Screw (M5x12L)
1
1
2
3
ENGLISH
ENGLISH
FEATURES
• ANT+ interoperable 2.4Ghz wireless technology
• Best-in-class interference immunity
• Low power consumption for long battery life
• Code memory during battery displacement
• Triple data display; Cadence, Heart rate and Training data
• Automatic Scan function
• Advanced energy expenditure algorithm for personalized Kcals (Calories)
• Bright LED screen light
• Dual mode ANT+ and heritage 5.4Khz analogue Fit1e heart rate receiver
ON SCREEN FEATURES
• Cadence RPM; Current and & session average
• Heart rate; Current, session average and % of maximum heart rate
• Training data; Exercise session time and equivalent distance travelled
• Personalized session Kcals (Calories)
• Console Low battery indicator
MX18_OM_CXC_console_r1_1_A.indd 2-3 3/1/18 8:43 AM

4 5
ENGLISH
USING THE CONSOLE
• The top display (RPM) shows Cadence in RPM, average RPM and Low battery indicator. Cadence in RPM is the
pedalling speed. The AVG (average) indicates the average value since the start of the exercise.
• The Middle display (HEART RATE) shows heart rate, session Average and % of maximum heart rate. The heart
rate is presented in beats per minute. AVG (average) indicates the average value since the start of the exercise.
The % of MHR display indicates exercise intensity using the formula 220-age to represent 100%, and then current
heart rate as a percentage of the maximum.
• The bottom display (TRAINING) shows the following data:
TIME: exercise session time.
DISTANCE: the equivalent distance that would have been covered when cycling on the road. To change which
data is being shown press the Mode key ( ).
• To start and pause the time, press ( ). To reset the timer, press and hold the Mode key ( ). This can be
done when displaying any TRAINING session.
• SCAN feature:
To use the SCAN feature, press the Mode key ( ) 3 times until (SCAN) appears in the TRAINING display. This
will automatically change between TRAINING data in intervals of 3 seconds showing: DISTANCE, TIME and KCAL.
To stop the SCAN feature press the Mode key ( ). The SCAN symbol should have disappeared.
ENGLISH
7) Press Set key ( *) after each digit has been paired to the
transmitter.
PAIRING SPEED TRANSMITTER TO CONSOLE
1) Remove the battery from the console and the display should go blank.
2) Insert the same battery again while pressing and holding any key. The
display will now show the maintenance screen.
3) Press the Set key ( *), which will show (SPD) in the middle display and (E01)
in the top display.
4) Press Set key ( *), which will show (SPD) in the middle display, 0 (RPM) in
the top display and (0000) in the bottom display.
5) To pair automatically, press Mode key ( ). The 4 digit alphanumeric
should match the code on the side of the cadence transmitter.
6) To pair manually, press and hold the Mode key ( ). The rst digit of
the 4 digit code (0000) should be ashing. Adjust the digit using the up/
down keys ( ).
8) Press Set key ( *) and
select distance in (KM) or
(Miles) by using the Up/
Down keys ( ).
9) Press Set key ( *) and
set the Gear Ratio to 1.0
by using the Up/Down
keys ( ).
10) Press Set key ( * ) to nish and begin exercise.
MX18_OM_CXC_console_r1_1_A.indd 4-5 3/1/18 8:43 AM

6 7
PAIRING CHEST TRANSMITTER TO CONSOLE
1) From sleep mode, press any key to activate the console.
2) Press and hold Set key ( *). This will display heart rate and ANT+ symbol.
3) For automatic pairing, press Mode Key ( ), this will display a four digit code
below the stated heart rate. For heart rate pairing, you must be wearing a chest strap
and move to within 12” (30 cm) of the console marked with the ANT+ symbol.
4) Once heart rate has been paired, press Set key ( *) to input personal data settings
and adjust using the up/down keys ( ).
For ANT+ chest transmitter, the code is alphanumeric; if an analogue 5.3Khz transmitter is
used 4 zero digits (0000) will appear.
Once the chest transmitter and console have been paired, the heart rate reading will
appear in the middle frame of the display. If pairing is unsuccessful after 20 seconds, or if
heart rate reading is incorrect, move closer to the console and press Mode key ( ) to
repeat the procedure.
ENGLISH
The product comes with three default settings:
• Age (AGE): 30
• Ambient heart rate (AHR): 70 bpm
• Weight (WT) Kg/Ib): 70kg (154 Ibs)
1) Press Set key ( * ) to set Age (AGE). Adjust using up/down keys (
).
2) Press Set key ( * ) to set Ambient heart rate (AHR). Adjust using up/down
keys ( ).
3) Press Set key ( * ) to set weight (WT) in (Kg /lbs). Adjust using up/down
keys ( ).
4) Press Set key ( * ) to nish and return to main display.
PERSONAL DATA SETTINGS AND CHEST TRANSMITTER SETUP
Once complete, the personal data is stored in the console
memory. This can be changed or modied during exercise or
when paused by pressing and holding Set key ( *).
The chest transmitter has to be paired to the console prior to
starting the exercise to achieve accurate results and must be
paired again before the start of every new exercise.
If the display turns off automatically after 5 minutes without
any activity, then the console has entered sleep mode. The
personal settings data will return to the default settings.
ENGLISH
MX18_OM_CXC_console_r1_1_A.indd 6-7 3/1/18 8:43 AM

CXC Console
© 2018 Johnson Health Tech
Part # 1000412289
Rev 1.0 A
