Matrix MAGNUM SERIES User manual

MAGNUM SERIES
MG-MR691-04 / MEGA DOUBLE HALF RACK
© 2015 Johnson Health Tech. All Rights Reserved. Specications subject to change without notice. Rev 1.1
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Clean Upholstery * Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips * As Needed
Lubricate Guide Rods † As Needed
* Upholstery & Grips should be cleaned with a mild soap and water or
a non-ammonia based cleaner.
† Guide rods should be lubricated with Teon based lubricant. Apply the
lubricant to a cotton cloth and then apply up and down the guide rods.
PRODUCT SPECIFICATIONS
TECH SPECS
Maximum User Weight 181.5 kg / 400 lbs.
Maximum Training Weight 408.5 kg / 900 lbs.
Product Weight 542 kg / 1195 lbs.
Overall Dimensions
(L x W x H)*
314 x 207 x 246.5 cm /
123.5” x 81.5” x 97”
Weight Horn Diameter
(Weight Plate Storage) 47.63 mm / 1.875”
* Ensure a minimum clearance width of 0.6 meters (24”) for access to
and passage around MATRIX strength equipment. Please note, 0.91
meters (36”) is the ADA recommended clearance width for individuals
in wheelchairs.
WARRANTY
For North America, please visit www.matrixtness.com
for warranty information along with warranty exclusions
and limitations.
PROPER USAGE
1. Do not exceed weight capacity of this
equipment.
2. If applicable, set safety stops to
appropriate height.
3. If applicable, adjust seat pads, leg
pads, foot pads, range of motion
adjustment, or any other type
of adjustment mechanisms to a
comfortable start position. Make
certain that the adjusting mechanism is
fully engaged to prevent unintentional
movement and to avoid injury.
4. Sit on bench (if applicable) and get into
appropriate position for exercise.
5. Exercise using no more weight than
you can safely lift and control.
6. In a controlled manner, perform
exercise.
7. Return weight to its fully-supported
start position.

IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX products to instruct all
individuals, whether they are the end user or supervising personnel on proper usage
of the equipment.
It is recommended that all users of MATRIX exercise equipment be informed of the
following information prior to its use.
Do not use any equipment in any way other than designed or intended by the
manufacturer. It is imperative that MATRIX equipment be used properly to avoid
injury.
INSTALLATION
1. STABLE AND LEVEL SURFACE: MATRIX exercise equipment must be installed on a
stable base and properly leveled.
2. SECURING EQUIPMENT: Manufacturer recommends that all stationary
MATRIX strength equipment be secured to the oor to stabilize equipment
and eliminate rocking or tipping over. This must be performed by a licensed
contractor.
All anchor points must be able to withstand 750 lbs. (3.3 kN) pull-out force.
MAINTENANCE
1. DO NOT use any equipment that is damaged and or has worn or broken parts.
Use only replacement parts supplied by your country’s local MATRIX dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason.
They contain important information. If unreadable or missing, contact your
MATRIX dealer for a replacement.
3. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth
operating equipment as well as keeping your liability to a minimum. Equipment
needs to be inspected at regular intervals.
4. Ensure that any person(s) making adjustments or performing maintenance or
repair of any kind is qualied to do so. MATRIX dealers will provide service and
maintenance training at our corporate facility upon request.
ADDITIONAL NOTES
This equipment should only be used in supervised areas where access and control is
specically regulated by the owner. It is up to the owner to determine who is allowed
access to this training equipment. The owner should consider a user’s: degree of
reliability, age, experience, etc.
This training equipment meets industry standards for stability when used for its
intended purpose in accordance with the instructions provided by the manufacturer.
This training equipment is in compliance with EN 957-1 and the relevant portions of
EN 957-2 and EN 957-4.
WARNING WARNING
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS
EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID
INJURY!
1. Keep children under the age of 14 away from this
strength training equipment. Teenagers must be
supervised at all times while using this
equipment.
2. This equipment is not intended for use by persons
with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the equipment by a
person responsible for their safety.
3. All warnings and instructions should be read and
proper instruction obtained prior to use. Use this
equipment for its intended purpose ONLY.
4. Inspect the machine before use. DO NOT use
machine if it appears damaged or inoperable.
5. Do not exceed weight capacity of this equipment.
6. ALWAYS use a spotter if using free weights.
7. Balance the weight applied to this equipment
and/or any barbell. Where applicable, use
retention devices to retain weight discs.
8. Injuries to health may result from incorrect or
excessive training. Cease exercise if you feel faint
or dizzy. Obtain a medical exam before beginning
an exercise program.
9. Keep body, clothing, hair, and fitness accessories
free and clear of all moving parts.
10. Adjustable stops, where provided, must be used
at all times.
11. When adjusting any adjustable mechanism (stop
position, seat position, pad location, range of
motion limiter, pulley carriage, or any other type),
make certain that the adjustable mechanism is fully
engaged prior to use to prevent unintended motion.
12. Manufacturer recommends that this equipment be
secured to the floor to stabilize and eliminate
rocking or tipping over. Use a licensed contractor.
13. If equipment is NOT secured to floor: NEVER allow
resistance straps, ropes or other means to be
attached to this equipment, as this may result in
serious injury. NEVER use this equipment for
support during stretching, as this may result in
serious injury.
14. DO NOT REMOVE THIS LABEL. REPLACE IF
DAMAGED OR ILLEGIBLE.
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS
EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID
INJURY!
1. All warnings and instructions should be read and
proper instruction obtained prior to use. Use this
equipment for its intended purpose ONLY.
2. ALWAYS use a spotter if working out on this
equipment.
3. Do not allow the lifting bar/sled to drop suddenly.
4. Visually ensure lifting bar catches are fully
engaged and seated in the hooks before releasing
the load and exiting the machine.
5. Adjustable stops must be used at all times.
6. ALWAYS set both adjustable stops to the same
height when using this machine.
7. PROPER adjustable stop height depends on the
exercise performed.
Adjust as follows:
• Remove weight from lifting bar/sled.
• For squats, perform the exercise and determine
the lowest comfortable position of the bar/sled
that ensures no spinal compression. For other
exercises, perform the movement and determine
the lowest point of bar travel that is
comfortable without the bar contacting your
body.
• Position both stop catches to stop the bar at this
point. Ensure that they are completely seated
on the stop rods or catch plate.
• FOR SQUATS PERFORMED ON A SMITH PRESS:
NEVER PLACE THE STOPS BELOW THE HEIGHT
INDICATED ON THE EQUIPMENT.
• Load weights onto the lifting bar and carefully
perform the exercise.
8. DO NOT REMOVE THIS LABEL. REPLACE IF DAMAGED
OR ILLEGIBLE.

MG-MR691-04 FRAME ASSEMBLY
NOTE: If your rack is not equipped with spotter stands, proceed to step 2.
1. Place bases and spotter stands where the machine is to be used. Using (16) 3/8-16 x 3 1/4” bolts, (32) 3/8”
washers and (16) 3/8 lock nuts, attach the spotter stands to the bases and torque all bolts to 30 ft-lbs.
2. Using (8) 3/8-16 x 1” bolts and (8) 3/8” washers, attach base support to bases. Do not tighten bolts.
3. Attach each upright to the base using (16) 3/8-16 x 1” bolts and (16) 3/8” washers. Do not tighten bolts.
4. Weight storage Bottom: Using (8) 3/8-16 x 1” bolts and (8) 3/8” washers, attach the bottom of the weight
storage to the bases. Do not tighten bolts.
STEP 1
STEP 2
STEP 3
STEP 4

MG-MR691-04 FRAME ASSEMBLY
5. Upright support and Weight Storage Top: Using (24) 3/8-16 x 1” bolts and (24) 3/8” washers, attach the upright support to the top of the uprights and top of
the weight storage. Do not tighten bolts.
6. Upright/Chin bar support: Using (16) 3/8-16 x 1” bolts and (16) 3/8” washers, attach the upright/chin bar supports between the uprights. Do not tighten bolts.
7. Chin bar: Using (8) 3/8-16 x 1” bolts, (8) 3/8” washers, (8) 1/2-13 x 4 1/2” bolts, (16) 7/16” washers and (8) 1/2-13 nuts, attach the chin bar between the top upright
supports. Do not tighten bolts.
8. Diamond Plate: Using (4) 3/8-16 x 3/4” BHCS, attach the diamond plate. Do not tighten bolts.
9. Tighten bolts: Starting with the bottom of the uprights and working up to the top of the machine, tighten all bolts to 30-ft lbs.
Assembly Complete!
STEP 5
STEP 6
STEP 7
STEP 8
