Matsusada Precision EPR Series User manual

Rev. 0.0
B/N 208.9.035 *208.9.035*
MODEL
EPR series
Instruction Manual
LDe option

１Introduction 1
１－１ Introduction 1
１－２ Unpacking the POWER SUPPLY 1
１－３ Installation conditions 1
１－４ Caution for handling 2
１－５ Troubleshooting 3
２Exterior view diagram 4
３Operation manual 5
３－１ Outline 5
３－２ Operation method 5
３－３ Description of Operation Modes 6
3-3-1 Constant Voltage Mode 6
3-3-2 Constant Current Mode 6
3-3-3 Crossover Mode 6
３－４ Other function 7
3-4-1 Over voltage protection (O.V.P) 7
3-4-2 Over current protection (O.C.P) 7
3-4-3 Power failure protection 7
3-4-4 Local/Remote change 8
3-4-5 Way of changing ON and OFF of a remote switch 9
3-4-6 Door switch (Interlock) 12
3-4-7 External voltage control 12
3-4-8 Output current monitor 13
3-4-9 Output voltage monitor 13
４Start menu
４－１ Start menu 14
４－２ Setting start menu 14
４－３ Menu mode 16
CONTENTS

５LDe option
５－１ Overview of LDe option 26
５－２ Multi-set function 26
５－３ Features of Pulse Sequence 30
５－４ Example of Pulse Sequence Usage 31
５－５ Features of Ramp 35
５－６ Example of Ramp Usage 36
６LDe option command
６－１ Command list 40
６－２ Reference 41

1
１Introduction
１－１ Introduction
Thank you very much for your purchase of our product HIGH VOLTAGE POWER SUPPLY.
We have done our best for the quality control of the unit.
Please handle this unit properly according to this instruction manual so that you can use the full
performance of this unit safely for long.
We have carefully prepared this instruction manual, but if you find any doubtful or
unclear point or any omission, please kindly contact us shortly.
１－２ Unpacking the POWER SUPPLY
When unpacked the unit, you will please check the following accessories are enclosed with
power supply main body.
〈Accessories〉
・AC input cord (1 pc)
・Instruction manual (1 pc)
・Output Cable (1 pc)
１－３ Installation conditions
・Install the power supply unit horizontally when use.
・Never put any object on the power supply unit.
・The top and side surfaces are the cooling air supply and exhaust openings. The power
supply must be provided with adequate space and good ventilation.
・Do not operate the power supply in a dusty area or in corrosive gas environment
１Introduction

2
１Introduction
１－４Caution for handling
WHEN TOUCHING LOAD AFTER TURNING OFF A HIGH VOLTAGE
1. Make the setting of an output voltage to zero (0). Turn off the OUTPUT ON/OFF switch.
2. Make sure that the output voltage is zero with the output voltage meter of this unit.
3. Turn off the POWER ON/OFF switch.
4. Ground the output for more than 10 seconds, and make sure that the output voltage is
zero at another HV voltmeter. It is especially dangerous when a capacitive load is
connected or a long cable is attached there to.
5. Make it a rule to touch loads with right hand.
HOW TO GROUND
・For safer operation, be sure to ground the ground terminal of power supply at one point on
the ground.
・Make sure to connect the GROUND terminal correctly as shown above. Improper grounding is
dangerous and may cause an electric shock or damage the power supply.
・In case output short circuit or discharging is expected, use shorter and thicker grounding wire.
Output cable
Ground terminal
Ground
EPR
Load frame
load

3
１Introduction
1. It would be rather safe if the power supply is operated on an insulation board, which is
withstand the voltage used.
2. Try to handle the power supply or load with your right hand, and try to keep the left hand, for
example, putting it pocket.
3. Ground the output more than 10 seconds before touching the load after turning off the
power supply even long time has past after turning off the power supply.
１－５ Troubleshooting
・In case there is no output voltage
１．Check if the proper input voltage is supplied to the power supply.
・Power supply input voltage, AC100-240V±10%, 50/60Hz single phase
・Control voltage for external voltage control is 0 to +10V
２．Check if the connection of control on the rear panel is correct.
３．Check if the function of option is properly operated.
If “E01”is appears, firstly stop the power supply and contact our sales agent from where you
purchased. Abnormality has occurred in this unit.
FOR SAFER OPERATION

4
Front panel
Rear panel
Dimension 124H×450D×84W （mm）
２ Exterior view diagram
２ Exterior view diagram
① Output voltage/current meter
② Output voltage/current preset switch
③ Output switch
④ Output voltage setting dial
① Output connector
② Ground terminal
③ Control connector (D-sub 15pin)
④ AC input connector
⑤ Upper connection switch
⑥ Optical fiber cable connector (IN)
⑦ Optical fiber cable connector (OUT)
⑤ Output current setting dial
⑥ POWER ON/OFF switch
⑦ F1 switch
⑧ F2 switch
③
①
⑤
①
②
③
④
④
⑥
②
⑤
⑦
⑥
F2
F1
⑦
⑧

5
３－１ Outline
This unit is a compact handy type high voltage power supply.
３－２ Operation method
1. Upon confirming the connection made with this unit as specified (Refer to 1-4[HOW TO
GROUND]), operate it. Be sure to connect the earth with the ground terminal of the unit.
2. Connect the attached AC input cord with AC input connector on the rear panel (INPUT
AC100V-240V) and plug socket.
3. Connect the interlock. (Refer to P12. 3-4-6 Door switch (Interlock))
4. Turn on the POWER Switch. The unit gets in stand-by mode.
No high voltage is generated on the output terminal when unit is in this mode.
5. Pressing the output voltage/current preset switch and keeping it pressed shows the voltage
and current settings on the display. Turn the output voltage dial to adjust the voltage as
desired. Then turn the output current setting dial to adjust the current as desired.
6. Press the OUTPUT switch to output the set value. The red lamp lights on.
7. For ending the operation of the power supply, be sure to return the output voltage setting
dial to 0 (if the same voltage is to be used again, leave it as it is), turn off the switches in the
order OUTPUT switch, POWER ON/OFF switch.
３ O
p
eration manual
３ Operation Manual

6
３-３ Description of Operation Modes
The EPR Series power supply units are provided with two operation modes (constant voltage
and constant current modes) and two control modes (local and remote modes).
This section describes the constant voltage and constant current modes in the local modes.
The operation mode is determined by the following:
・ Output voltage setting V
set
・ Output current setting I
set
・ Load resistance
R
L
3-3-1 Constant Voltage Mode
The power supply unit operates in the constant voltage mode when the load current
I
L
is less
than the current setting I
set
( I
L
< I
set
; I
L
= V
set
/ R
L
).
In the constant voltage mode, the voltage is constant at the set value ( V
set
) and the load
current I
L
changes according to the load.
When using the power supply unit in the constant voltage mode, turn the current setting
knob clockwise all the way to the maximum or ensure that it is set to the required current,
which allows setting to the desired voltage.
3-3-2 Constant Current Mode
The power supply unit operates in the constant current mode when the load resistance is
low enough to make the load current
I
L
more than the current setting ( I
L
> I
set
). In the
constant current mode, the current is constant at the set value ( I
set
) and the load voltage
changes according to the load.
R
L
= Load resistance
V
set
= Output voltage setting
I
set
= Output current setting
3-3-3 Crossover Mode
The automatic crossover system functions to automatically switch between the modes as
the load response changes. For example, the mode is changed from the constant voltage to
constant current when the load current exceeds the current setting. The mode is brought
back to the constant voltage when the resistance becomes high enough.
３ Operation Manual
Output voltage
Vse
t
Constant voltage range R
L
＞
R
L
＜
Ise
t
Output current
Crossover point
Constant current range
0
R
L
＝
Vset
Iset
Vset
Iset
Vset
Iset

7
３－４ Other function
3-4-1 Over voltage protection (O.V.P)
This unit has an over voltage protection. Even at the time of abnormality, it is limited at
approx. 110% of the maximum rated voltage, protecting power supply and load from damage.
3-4-2 Over current protection (O.C.P)
This unit has an over current protection. When over current, the output current is limited by
decreasing the output voltage.
3-4-3 Power failure protection
This unit integrates a circuit to stop the output when it is recovered from power failure.
During the operation, when recovered from power failure, unit does not resume the output.
Resume the output by OUTPUT ON/OFF switch.
When power failure protection is not in use, set “0” (OFF) for “4” of starting menu.
(Please refer to 4 for starting menu.)
Then, when recovered from power failure, or when turn on POWER ON/OFF switch, power
supply shall get back to the status when power failure is happened.
(If power is failure when OUTPUT ON/OFF is ON, then the unit resume the output
automatically. When power is failure when OFF, power supply keep off.)
３ Operation Manual
On/Off for power failure
cancellation function is
changed by current setting
dial
VOLTAGE
CURRENT
OUTPUT
REMOT
E
SET
CV
CC
mA
kV

8
Control connector ・・・ D-sub 15S type
3-4-4 Local/Remote change
Use the external switch to select controlling the front panel setting dial (Local mode) or the rear panel
control connector (Remote mode). Select to Remote mode, and the output voltage and the output
current can be set with the external voltage source.
３ Operation Manual
PIN 4 Output voltage monitor
PIN 3 N.C.
PIN 2 Current control
PIN 1 Voltage control
D-Sub connector
M2.6 fixing screw
D-Sub connector
M2.6 fixing screw
The operation of a remote
switch with a switch SHORT
OPEN
…… Remote
…… Local
Local/Remote chan
g
e Action
The operation of a remote
switch with an open collector
In place of a switch, an open
collector is also usable.
E C
switch
⑧
COM
8 1
15 9
PIN 9 COM (1, 2 pin)
PIN 10 N.C.
PIN 11 COM (4, 5 pin)
PIN 12 N.C.
Output current monitor PIN
5
Remote switch ON/OFF PIN
6
Door switch (Interlock) PIN
7
Local/remote change PIN
8
(8 pin) COM PIN
15
(6, 7 pin) COM PIN
14
N.C. PIN
13
⑮

9
3-4-5 Way of changing ON and OFF of a remote switch
It is possible to change ON and OFF of output with a remote switch.
Precautions for use of an open collector *1
Use an open collector according to the following rules.
The rule of an open collector
Output Switch Open collector
ON Short
VCE
Up to 0.4V
(10mA)
OFF Open
VCE
More than 2V
(open circuit
voltage 5V)
The operation of a remote
switch with a switch SHORT
OPEN
…… Output ON
…… Output OFF
The o
p
eration of a remote
The operation of a remote
switch with an open collector
In place of a switch, an open
collector is also usable.
E C
３ Operation Manual
switch
⑥
COM
⑭
5V

10
About the operation with the OUTPUT switch on the front panel or a remote switch, and the indication of
OUTPUT LED
The procedure of operation for an output is different with whether the remote switch is set to ON or OFF at
the time of POWER ON.
About the difference arising from the state of the remote switch at the time of POWER ON
When a blackout protection is ON
When the POWER switch is turned off during output preparation or an output, a blackout protection operates.
When the POWER switch is turned on again, it will be in an output halt condition.
① In the case of the remote switch OFF and the POWER switch ON
② In the case of the remote switch ON and the POWER switch ON
*EPR series is high voltage power supply. Therefore, for the safety of users, at the time of factory shipments,
it is a setup switch is not outputted unless the OUTPUT switch is turned on. When a blackout protection is
OFF, output can be done only with the operation of the remote switch even if the OUTPUT switch is not
turned on.
OUTPUT LED
Lights-out
OUTPUT LED Blinking
OUTPUT LED
Lights-out
OUTPUT LED Lighting
OUTPUT LED Lighting
OUTPUT LED
Lighting：in an output condition
Blinking：in an output preparatory
condition
Lights-out ： in an output halt
condition
POWER ON OUTPUT ON
Remote switch OFF OUTPUT ON
OUTPUT LED Lighting
OUTPUT LED
Lights-out
OUTPUT LED
Lights-out
Remote switch ON
OUTPUT LED Blinking
OUTPUT LED
Li
g
hts-out
Remote switch ON
OUTPUT LED Lighting
POWER ON OUTPUT ON
Remote switch ON OUTPUT ON
Remote switch ON
３ Operation Manual

11
The state before turning off the POWER switch
The state before turning off the POWER switch
The state before turning off the POWER switch
The state before turning off the POWER switch
The state before turning off the POWER switch
The state before turning off the POWER switch
When a blackout protection is OFF
When the POWER switch is turned on again after being turned off during output preparation or an output, EPR
series starts in a state before turning off the POWER switch. An output is started by making the remote switch
short-circuit in an output preparatory
If the POWER switch was turned off during the output, please be careful that the output is reopened
immediately when the POWER switch is turned on again.
① In the case of the remote switch OFF and the POWER switch ON
*An output can be done without turning on the OUTPUT switch.
② In the case of the remote switch ON and the POWER switch ON
OUTPUT ON POWER ON
POWER ON OUTPUT ON
Remote switch OFF Remote switch ON
OUTPUT LED Lighting OUTPUT LED Lighting
OUTPUT OFF
OUTPUT LED Blinking
OUTPUT LED
Lights-out
OUTPUT LED
Lights-out
OUTPUT LED Lighting
OUTPUT LED Lighting
OUTPUT ON Remote switch ON
OUTPUT LED Blinking
POWER ON
OUTPUT LED Blinking OUTPUT LED Lighting
OUTPUT OFF OUTPUT ON POWER ON
OUTPUT LED
Lights-out OUTPUT LED
Lights-out
Remote switch ON
Remote switch OFF Remote switch ON
OUTPUT LED Lighting
OUTPUT LED Lighting
OUTPUT LED
Lights-out
OUTPUT LED Blinking
OUTPUT OFF
OUTPUT LED
Lights-out
OUTPUT ON Remote switch OFF
OUTPUT LED Lighting OUTPUT LED
Li
g
hts-out
OUTPUT LED Blinking
OUTPUT ON Remote switch ON
OUTPUT LED
Lights-out
３ Operation Manual

12
3-4-6 Door switch (Interlock)
High voltage output can be cut off with external switch off. For safety reason, once the
output is cut off, the unit shall not resume the output even turning the external switch
back on.
To reset this status, turn the Power switch on after shorting the interlock terminal.
3-4-7 External voltage control
In the remote mode, 0-10Vdc external voltage can control the output voltage within the
range of 0-100%.
Interlock action by switch Interlock action
Interlock action by open
collector *1
In place of switch, an open collector will
suffice for it.
E C
SHORT
OPEN
…… Output ON
…… Output OFF
switch
⑭ ⑦
COM
⑨ ②
COM
⑨ ①
COM
Voltage
control
Current
control
３ Operation Manual

13
3-4-8 Output current monitor
10V output for the maximum rated output current. Output impedance is 1k ohm.
The monitor output polarity is positive regardless of the high voltage output polarity.
3-4-9 Output voltage monitor
10V output for the maximum rated output voltage. Output impedance is 1k ohm.
The monitor output polarity is positive regardless of the high voltage output polarity.
COM
⑪
V
⑤
Imoni
COM
⑪
V
④
Vmoni
３ Operation Manual

14
４－１ Start menu
In the start menu, settings of the following func tions and initialization to the factory default
are executed.
Menu “dEF”: default initializes to the factory default.
Menu “unit”: unit setting sets unit numbers.
Menu “PFP”: power failure protection sets power failure protection.
Menu “LS”: inverse of remote switch logic sets inverse of remote switch logic.
Menu “COM”: inverse of remote switch logic sets the command to Matsusada original / SCPI.
Menu “PLS”: pulse sequence setting sets the pulse sequence function.
Menu “rMP”: ramp setting sets the ramp function.
４－２ Setting start menu
Continue to press the preset s witch when the power s witch of the body is on, so that the
display is changed to “dEF”.
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
POWER ON
Continue pressing PRESET
「default」
Return to factory default
４ Start menu
４ Start menu

15
1. To change the menu display, turn the volt age setting dial so that the display is
switched to menus.
[COM](Communication)
Turn MtP/SCPI
communication
command.
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
[PLS](Pulse)
Turn ON/OFF
pulse sequence
function.
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOT
E
[dEF](default)
Return to
factory default
[unit](Unit)
Set unit numbers
0-31 (default: 0)
[PFP](
Power failure
protection
)
Turn ON/OFF power
failure protection
[rMP](Ramp)
Turn ON/OFF
ramp function.
[LS](Remote switch)
Turn On/Off inverse
of remote switch
logic.
Turn
voltage
setting dial
VOLTAGE
CURRENT
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOT
E
2. To end (register) the menu, press and hold down the F2 switch in the state of the
menu to be registered.
* “dEF”: when the default is displayed, a ll settings are initialized to the factory
default.
４ Start menu
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
Due to “dEF”
displayed, reset to
factory default.
Press and hold down F2

16
４－３ Menu mode
1. Menu “dEF”: Menu to reset to factory default
a. F2 switch (press and hold down): initialized to factory default
2. Menu “unit”: Unit number setting menu
a. “unit” displayed:
Unit numbers can be changed by turning the current setting dial. (0-31)
(* “0” is set by factory setting and default.)
b. F2 switch (press and hold down): register settings
４ Start menu
Register settings.
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
Press and hold down F2
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
Due to “dEF”
displayed, reset to
factory default.
Press and hold down F2
When “unit” is displayed,
change setting with
current setting dial (0-31).
Change unit number
with current dial
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
VOLTAGE
CURRENT

17
3. Menu “PFP”: Power failure protection setting menu
a. “PFP” displayed:
On/Off for power failure protection is changed by current setting dial.
(* “on” is set by factory setting and default.)
b. F2 switch (press and hold down): register settings
４ Start menu
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
When “PFP” is
displayed, On/Off for
power failure protection VOLTAGE
CURRENT
On/Off for power failure
protection is changed
current setting dial.
F2
SET
F1
CV
CC
kV
mA
OUTPUT
REMOTE
Register settings.
Press and hold down F2
