Matterport PRO3 User manual

User Guide

Class 1 Laser
Part 810-00008Model PRO3
Country of Origin Taiwan
Serial Number
352 East JavaDrive
Sunnyvale,CA 94089 U.S.A.
Class 1 Laser
Part 810-00008Model PRO3
Country of Origin Taiwan
Serial Number
352 East JavaDrive
Sunnyvale,CA 94089 U.S.A.
Class 1 Laser
Part 810-00008Model PRO3
Country of Origin Taiwan
Serial Number
352 East JavaDrive
Sunnyvale,CA 94089 U.S.A.
2
EN Camera Components
AMagnetic Lens Cap
BCamera Lens
CBattery
DTripod Mount
ETripod
FPower Button
GDisplay
HLiDAR Mirror
ITripod Mount Socket
JBattery Compartment
E
D
C
H
I
G
F
J
A
B
Bottom panel Rear panel

3
EN
Setup
1Set up tripod.
Adjust height to 4.5 feet (1.37 meters).
2Attach tripod mount.
Screw tightly onto the center column of
the tripod base.
4.5 feet
1.37 meters

4
EN 3Remove Pro3 from case.
Gently pull the red tab, and lift from the bottom of the camera.

5
EN
4Insert battery.
Place the camera on its side on a at
surface. Align the pins on the battery
with the pins within the battery
compartment and snap into place.

6
EN 5Mount Pro3 on tripod.
Open the clamp on the side of the tripod
mount. Align the tripod mount socket on
the bottom of the camera with the top of
the tripod column, and lower the camera
into place. Keep one hand on the top of the
camera to hold it steady as you close the
clamp to secure it.
The camera’s rotational axis is aligned with the lens, not
the center of the camera. Designed for optimal capture,
this unique prole is stable and secure when properly
mounted as detailed above.

7
EN
6Power up.
Press and hold the power button
(~2 seconds) on the rear panel of the
camera, beneath the display screen.
Remove the magnetic lens cap.
Booting Warmup
Camera Display

Part 810-00008Model PRO3
Made in Taiwan
352 East Java Drive
Sunnyvale, CA 94089 U.S.A.
ISED ID 12345678
Contains
FCC ID 12345678
Complies with 21 CFR
1040.10 and 1040.11
except for conformance
with IEC 60825-1 Ed. 3.,
as described in Laser
Notice No. 56, dated
May 8, 2019.
Serial Number
8
EN
1Get the app.
Download the Matterport app for your iOS or
Android device to start using Pro3.
Ready to Pair
2 Conrmcamerareadiness.
Once the camera is done booting, the Ready to
Pair symbol will appear on the camera display.
3Enable Bluetooth.
Make sure Bluetooth is turned on within your
device settings and that the Matterport app has
permission to use it.
Get Connected
Camera Display

Part 810-00008Model PRO3
Made in Taiwan
352 East Java Drive
Sunnyvale, CA 94089 U.S.A.
ISED ID 12345678
Contains
FCC ID 12345678
Complies with 21 CFR
1040.10 and 1040.11
except for conformance
with IEC 60825-1 Ed. 3.,
as described in Laser
Notice No. 56, dated
May 8, 2019.
Serial Number
9
EN
Wi-Fi Network
4Open the Matterport app.
In the app, open an existing job or start a new
one by tapping the button. Then tap the
source selector button and select Matterport
Pro3 to connect to your camera. If you don’t have
Bluetooth enabled, you can manually connect to
your camera’s Wi-Fi network (which will appear
as its serial number located on the bottom panel
of your Pro3) through your device settings.
5Check connection.
When your camera and device are connected, the
Connected symbol will appear (and time out to
the Ready to Scan symbol) on the display screen
of your Pro3. Additionally, Matterport Pro3 will
appear above the camera button within the app. Connected Ready to Scan
Camera Display
matterport.com/pro3-help
Support
To troubleshoot and see video tutorials and FAQs, visit

10
EN
Connected
Indicates the camera is connected
to Wi-Fi.
Ready to Scan
Indicates the camera is ready for
rapid scanning from point to point.
Scanning
Green line indicates scan progress as
the camera rotates.
Ready to Move
Once a scan is complete, this
indicates the camera is ready to
move to the next scan point.
Error Status
Check the Matterport app or visit
go.mp/pro3 to look up the error
code on the screen.
Battery Status
When the camera is off, tap the
power button to check the battery
level without booting up the camera.
Camera Display Guide

11
EN
Transporting Your Camera
The Matterport Pro3 Camera is sensitive and
carefully calibrated. Always transport your camera
in a padded carrying bag or case and handle with care.
If traveling by air, we recommend keeping the camera in
your carry-on luggage.
Lens Care
Treat your Pro3 Camera lens as you would DSLR lenses.
To remove ngerprints, use camera lens cleaner and a
microber cloth. Always clean by rst dusting the lens, then
applying cleaner to the cloth (not directly to the lens). The
spinning mirror requires the same care.
Storage and Temperature
Do not use or leave your Pro3 at very high temperatures.
The battery performance will be degraded and its service
life will be decreased. The camera should be stored at room
temperature with the battery removed.
Stability
Always ensure that the camera is operated correctly on a
at and stable surface. Personal injury or camera damage
may result if your Pro3 overturns.
General Use
Do not open or disassemble the camera.
The camera contains no user-serviceable
parts inside. Only use equipment and
accessories recommended by Matterport,
and follow the setup instructions in this guide.
Rotating Mirror
The rotating mirror spins at high speeds both
during a scan and for a short period after.
For your personal protection and to avoid
damage to your Pro3, keep hands, hair, or
any other objects at a safe distance from
the mirror unit while it’s rotating.
Care and Storage Safety Precautions
