Max-Ability PRESSALIT R8961000 User manual

User Guide
Wallaby Changing Station
Giraffe Changing Table
Wallaby Small (35.5"length)
SKU: R8961000/R8690000
EAN: 5708590367224
Wallaby Child (55" length)
SKU: R8962000/R8694000
EAN: 5708590367231
Giraffe Small (35.5" length)
SKU: R8971000/RB1922
EAN: 5708590367255
Previous version: R8671/RB1922
Giraffe Child (55" length)
SKU: R8972000/RB1922
EAN: 5708590367262
Previous version: R8672/RB1922
MAX-Ability, Inc.
[email protected]
800 577-1555

ﺔﯾﺑرﻌﻟا قورﻓو ﺔﯾﻧﻓ تﻼﯾدﻌﺗﻟ ﺔﺿرﻋ تﺎﺟﺗﻧﻣﻟا .ماوﻋأ 5 ةرﺗﻔﻟ ﻊﯾﻧﺻﺗﻟا وأ داوﻣﻟا ﻲﻓ بوﯾﻌﻟا وأ ءﺎطﺧﻷا نﺎﻣﺿﻟا ﻲطﻐﯾ
.ةﺎﻧﺛﺗﺳﻣ وﮭﺳﻟاو ﺄطﺧﻟا تﻻﺎﺣ .مﯾﻣﺻﺗﻟا ﻲﻓ ﺔﻔﯾﻔط
[email protected] 800.577.1555
Original instructions
IMPORTANT
RETAIN THIS MANUAL FOR FUTURE REFERENCE. READ CAREFULLY.
Mounting instruction
A mounting instruction is included with the product. It can also
be downloaded from pressalit.com.
Operational signage
An operational signage can be downloaded from pressalit.com.

3
R8961, R8962, R8971, R8972
120V
Pressalit A/S
Pressalitvej 1
+
DK-8680 Ry
45 8788 8777
pressalit.com
REF
SN
Xxxxxx
I:XXA
U:XXXV
DS/EN XXXXX-X/X A1:YYYY
XX-XX Hz
IPXX
P:X W
XXX kg
XXX lbs XXX kg
XXX lbs
YYYY-MM-DD
RZZZZYYYXXX-X
RZZZZYYYXXX-X
2
min
18
min
YYYYYYY XXXXXX

4
R8690, R8694, R8698 RB1922
R8708 R8700, R8701, R0702,
R8703, R8704, R0705
R8710 R8709
V8585

5
Max P U Max I
++
R8661, R8961 50 kg / 110 lbs
75 kg / 165 lbs
R8662, R8962 65 kg / 143 lbs
R8671, R8971 55 kg / 121 lbs
R8672, R8972 60 kg / 132 lbs
kg
lbs
R8961, R8962, R8971, R8972 96W 120V 0.8

6
inch
R8661,R8961 R8662, R8962
29.49
65.71
35.43
35.43
31.5
2
9.49
65.71
55.12
35.43
31.5
R8671, R8971 R8672, R8972
29.49
65.71
35.43
35.43
31.5
29.49
65.71
55.12
35.43
31.5

Symbols used in this manual
The following symbols are used in this manual as well as the associated
documentation supplied with the product.
!WARNING WARNING indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
!CAUTION CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury. It may also be used
to alert against unsafe practices.
IMPORTANT IMPORTANT indicates important
information about handling and use
of the product.
NOTICE NOTICE is used to address practices
not related to personal safety.
Hand injury
warning
Head injury
warning
Electricity /
voltage warning
Strong heat
warning
Do not leave
child unattended
Compatible
products Spare parts Power specifications
++
REF
Product weight Max. user weight Article number/
versions
7

en
!CAUTION
• Please comply with these instructions to avoid the product becoming
damaged or destroyed.
• Do not perform repairs, disassembly, or assembly operations,
extensions, re-adjustments or modifications to this product. These
must be carried out by Pressalit or by persons authorized by Pressalit
only.
• Never allow children to operate this product unless under supervision.
The product is not intended for play.
• Never use the product if it is defective or damaged. Do not use a
defective product before it has been repaired.
!WARNING
• Read and understand the manual completely before use. Keep the
manual close to the unit.
• Comply with this manual to avoid accidents involving serious personal
injury.
• Never use or handle this product in other ways than are specified in
this manual, as this can put your safety at risk and cause damage to the
product.
• Make sure that everyone who is to install or use the product and its
systems has the necessary information and access to this manual.
NOTICE
• The information in this manual is based on correct fitting of the
product in accordance with our mounting instruction.
• Pressalit cannot be held liable if the product is used in any way which
differs from that described in the guide.
• We reserve the right to amend this manual without prior notice.
General safety
8

Intended use
This product is intended for optimum ergonomics when caring for children.
The child's weight must not exceed 75 kg / 165 lbs.
Intended operator profile
The product shall only be operated by adults.
Operating environment
The product is intended to be used indoor at room temperature under normal
working conditions. For institutional use, the expected life time is 8 years.
Life cycle test performed according to ISO 17966:2016.
This product is tested according to DS/EN 12221-1 and 12221-2.
Be aware of the risk of open fires and other sources
of strong heat, such as electric bar fires, gas fires,
etc. in the near vicinity of the changing table.
Do not leave the child unattended.
!CAUTION
Never allow children to operate
this product without supervision.
NOTICE
Always place the child on a
changing table mattress and
not directly on the table.
9

en
!CAUTION
Never place objects underneath the changing table.
Operating instructions
The changing table can be adjusted from 300 to 1000 mm / 12 to 39 inches up
and down. Max load is 75 kg /165 lbs.
Take care to avoid injury to hands and head
when in the vicinity of moving mechanical
parts.
Press and hold the Up button to raise the
unit.
When the button is released, the motion
stops.
Press and hold the Down button to lower
the unit. When the button is released, the
motion stops.
To avoid the risk of strangulation, make sure that the
wired remote control is placed in its holder when not
in use.
The height adjustment is controlled by the wired remote control unit.
10

The models with safety tray
All lowstart changing tables, except
foldable models, are equipped with a
safety tray.
If the safety tray 1comes into
contact with an object when the
table is being lowered, the motor
stops immediately and the table
will rise 3-4 cm to reduce the risk
of pinching/compression injuries
under the table. The table might
need resetting before it can be used
again. See „Resetting“.
1
Resetting
①
Make sure that the safety tray is not
activated. Lower the changing table all
the way down to its starting position
using the down button.
②
Release the down button, and after 3-4
sec. press it in again until you hear a
slight click after approx. 10 sec.
③
Release the lowering button and then
raise the changing table to its highest
position. You will hear another click.
④
Lower the changing table a couple of
centimetres/about one inch.
⑤
Then raise it again to its highest
position. You will hear another click.
The changing table is now reset.
The changing table should also be reset if there has been an
interruption of the power supply.
Models with
built-in sinks
not available in
the US.
11

en
IMPORTANT
• Do not use an autoclave or other type of steam cleaner.
• Avoid aggressive cleaning agents containing acids.
• Never spray the product directly with a high pressure cleaner.
• Avoid use of abrasive, corrosive or chlorine-based cleaning or
disinfecting products.
The product is to be cleaned with hot water or a mild soapy cleaning agent.
A list of suitable cleaning agents tested by Pressalit can be found on
pressalit.com.
!CAUTION
Always read the material safety data sheet (MSDS) and supplied
instructions of the cleaning, disinfecting or de-scaling agent and comply
with instructions for safe use, dilution, rinsing, drying, handling and
storage of the agent.
Cleaning
12

Maintenance
Expected service life of the changing table is 8 years, provided that
maintenance is carried out as described below:
It is recommended on a weekly basis to run the motors on the product to their
maximum positions by raising the product to its full height, and then lowering
it to its lowest position, so that the internal parts are lubricated.
It is recommended that service inspection is done once a year.
Maintenance inspection
Take the changing table to its highest position.
Disconnect mains before
removing the covers.
1
1
1
1
Remove the four screws 1
holding the front cover.
Models with built-
in sinks not
available in the US.
13

en
• Check the wall brackets 1and tighten if necessary.
• Oil moving parts, especially the sliding brackets 2.
• Check all electrical connections to the control box 3.
• Check the chain wheel 4for wear.
• Oil the chain 5.
• Put the unit cover back again and tighten the retaining screws. Reconnect
mains.
Lift off the top cover.
2
2
2
2
5
4
1
3
Models with
built-in sinks not
available in the
US.
14

Product label
Pressalit A/S
Pressalitvej 1
DK-8680 Ry
[phone]
pressalit.com
REF
SN
Xxxxxx
I:XXA
U:XXXV
DS/EN XXXXX-X/X A1:YYYY
XX-XX Hz
IPXX
P:X W
XXX kg
XXX lbs XXX kg
XXX lbs
YYYY-MM-DD
RZZZZYYYXXX-X
RZZZZYYYXXX-X
2
min
18
min
YYYYYYY XXXXXX
⑫
⑬
⑭
⑮
⑯
⑰
⑱
⑲
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
15

16
en
①Article number
②Serial number
③Production date
④Consult manual for use
⑤Do not dispose as unsorted municipal waste. The product should
be collected separately and returned to the designated recycling
service.
⑥Product weight
⑦Maximum power consumption
⑧Electric current
⑨Name and address of manufacturer
⑩
These products are CE-marked in accordance with relevant
requirements in:
• Council Directive 2006/42/EC (of 17 May 2006) on machinery.
• Council Directive 2011/65/EC (of 8 June 2011) on RoHS.
⑪EAN 13 barcode
⑫ Consult the manual for important cautionary information such as
warnings and precautions.
⑬This product does not contain any of the hazardous substances
mentioned in the Council Directive 2011/65/EC on RoHS.
⑭Duty cycle
⑮Maximum user weight
⑯Mains voltage
⑰Frequency
⑱Standard, which product is manufactured in accordance with (if any).
⑲
These products are UKCA-marked in accordance with relevant
requirements in:
• Supply of Machinery (Safety) Regulations 2008.
• The restriction of the use of certain hazardous substances in
electrical and electronic equipment regulations 2012.
A declaration of conformity can be found at pressalit.com.

Trouble-shooting
Symptom Cause Action
The product will not
work, even though
the control is used
correctly.
Fault in power supply. Check that all wires and
plugs are intact and
correctly connected.
Contact Pressalit A/S or
your local dealer.
The product runs up
and down unevenly.
The sliding brackets
are not properly
lubricated.
Oil the sliding brackets
as described under
”Maintenance”.
The baskets are
unable to close/
open.
The basket may
have been twisted
unintendedly.
Try to straighten the
basket.
The product is
jammed.
Interruption of the
power supply.
Reset the product. See
”Resetting“.
Contact Pressalit A/S or your dealer if the problem cannot be remedied. Do not
attempt to repair the product yourself, as this will invalidate the guarantee.
17

en
Disposal and recycling
The unit contains reusable materials. There are no known hazards or risks
associated with disposal of the product. All components can be discarded
after having been cleaned and disinfected.
When disposing of the product, we recommend that it be disassembled and
broken down into different waste groups for recycling or combustion.
The following table provides information on the recycling and handling of the
product.
Recyclable
components Material
Steel Steel can be recycled by being melted down and included
as a secondary material in the production of new steel.
Plastics Use plastic sorting and recycling systems where they are
locally available, otherwise incinerating plastic has the
added benefit of generating energy which can be used for,
for example, combined heat and power production.
Electronics The electronic components should be collected
separately and returned to the designated recycling
service.
Storage and transportation
• The temperature for transportation and storage of the unit must be
between 5 and 40° Celsius (41 and 104° F).
• The unit must always be transported in its original packaging.
• Avoid subjecting the packaging to shocks and impacts.
• Do not use the product if the packaging is broken or damaged.
18
