VersaMini Public Restroom Changing Table
SKU: R8455512000
EAN: 5708590376585
Installation
Drawing

Page 2/7
Pub Jan 2022
Operation and maintenance manual (OMM) for this product is enclosed in the box. Please hand over to the
user. It can also be downloaded at www.pressalit.com.
EN An operation signage (quick guide) for use by people with reading or cognitive disabilities can be
downloaded at www.pressalit.com. User information is not available in braille.
DK En visuel guide (hurtigguide) til personer med læsevanskeligheder eller kognitive vanskeligheder kan
downloades på www.pressalit.com. Brugeroplysningerne er ikke tilgængelige som blindskrift.
DE
Eine Kurzanleitung in Bildern für Personen mit Leseschwäche oder kognitiven Einschränkungen kann
ebenfalls unter www.pressalit.com heruntergeladen werden. Die Benutzerinformationen sind nicht in
Brailleschrift verfügbar.
FR
Une signalétique opérationnelle (guide rapide) à l’attention des personnes présentant des difficultés de
lecture ou des déficiences cognitives est téléchargeable sur le site www.pressalit.com. Les informations
utilisateur ne sont pas disponibles en braille
NL Voor mensen met lees- of begripsproblemen kan een visuele handleiding op www.pressalitcare.com
worden gedownload. Informatie voor gebruikers is niet in braille beschikbaar.
SV En visuell snabbguide för personer med lässvårigheter eller kognitiv funktionsnedsättning kan laddas ned
på www.pressalit.com. Användarinformationen finns inte tillgänglig på braille.
NO En visuell hurtigveiledning for brukere med lesevansker eller kognitive vansker kan lastes ned fra www.
pressalit.com. Brukerinformasjon er ikke tilgjengelig i blindeskrift.
ES Puede descargarse una guía visual de funcionamiento para personas con dificultades lectoras o cog-
nitivas desde www.pressalit.com. La información del usuario no está disponible en braille.
Mounting Instruction
Please read and carefully follow these instructions. Find the product number on the product label and ensure that these
assembly instructions match your product.
WARNING: Failure to comply with these instructions may result in accidents involving serious personal injury or the
product being damaged.
WARNING: If you suspect that any individual parts may be damaged, contact your Pressalit dealer or service
provider. Do not remove, attempt to repair or install parts yourself, unless directed to do so by Pressalit or its
agents.
WARNING: No modification of this equipment is allowed without express authorization from Pressalit.
WARNING: These instructions must be followed, and the product must be installed professionally by a qualified
person; e.g. a licensed plumber, in order to avoid personal injury or property damage while using the product.
WARNING: Pressalit cannot be held liable for injury to persons or damage to property caused by faulty mounting.
Installation location
This product is designed for indoor use in a wet environment, such as a bathroom or washroom. When choosing an
installation location, ensure that there will be adequate space for access to the product.
Assembly and installation
Mount the product against a wall in accordance with the illustrations in this assembly instruction. Contact your Pressalit agent,
if assistance is needed when installing the product.
www.max-ability.com
