Max HT-R1 User manual

HT-R1, HT-R2
Tapener
SEPT 2020
INSTRUCTION MANUAL
BEFORE USING THIS TOOL, STUDY THIS MANUAL TO ENSURE
SAFETY WARNING AND INSTRUCTIONS.
KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE
REFERENCE.
WARNING

SPECIFICATIONS
Name HT-R1 HT-R2
Dimensions 148mm H x 353mm L x 35mm W 161mm H x 392mm L x 35mm W
Staples Used MAX STAPLES 604C-L (4,800 pcs)
MAX STAPLES 604E-L (4,800 pcs)
Number of
Staples Loaded
MAX STAPLES 604C-L 200 pcs/stick
MAX STAPLES 604E-L 172 pcs/stick
Tape Used MAX TAPE-10, 0.1mm T x 11mm
W x 40m L (white)
MAX TAPE-15, 0.15mm T x 11mm
W x 26m L (blue)
MAX TAPE-25, 0.25mm T x 11mm
W x 16m L (red)
MAX TAPE-215, 0.15mm T x
12mm W x 55m L (white)
MAX TAPE-225, 0.25mm T x
12mm W x 33m L (blue)
Weight 420 grams 445 grams
Bundling Limit Maximum 45mmᶲ x parallel
20mmᶲ
Maximum 45mmᶲ x parallel
20mmᶲ
Blade MAX™Tapener HT-R Serrated
Blades
MAX™Tapener HT-R Serrated
Blades
Staple’s Full-
Scale Figure

PARTS LIST
Index No.
Parts Code No.
Description
1 HT11672 B CASE S
2 FF31714 STRAIGHT PIN 1714
3 FF31712 STRAIGHT PIN 1712
4 KK33402 TORSION SPRING 3402
5 KK29130 COMPRESSION SPRING 9130
6 HT11670 LOCK PLATE S
7 HT11627 A CASE
8 CC43107 NAT M4(3)
9 AA05719 +PH TAP SCREW 3x8 (P)
10 HT11632 CLINCHER
11 HT11622 TAPE CATCH
12 HT11671 TAPE PLATE S
13 AA25537 SCREW BIND M4x6
14 HT11618 CLINCHER ARM
15 AA05716 SCREW BIND 4x6 (S-TIGHT)
16 HT11619 ARM SUPPORT
17 HT11637 B HANDLE
18 FF31713 STRAIGHT PIN 1713
19 HT11638 GRIP
20 KK13390 EXTENSION SPRING 3390
21 HT70061 MAGAZINE UNIT
22 FF31716 STRAIGHT PIN 1716
23 HT11611 PUSHER
24 HT11610 SPRING GUIDE ROD
25 KK29131 COMPRESSION SPRING 9131
26 HT11609 STAPLE COVER
27 PRODUCT CUTTER
28 KK34099 TORSION SPRING 4099
29 HT70070 TAPE GUIDE S UNIT
30 FF41740 STEP PIN 1740
31 HT11596 TAPE GUIDE SUPPORT
32 HT11673 TAPE GUIDE BASE S
33 FF31711 STRAIGHT PIN 1711
34 KK83018 CONICAL SPRING 3018
35 JJ10103 E-RING 3.2
36 HT11615 ROLLER
37 FF31643 STRAIGHT PIN 1643
38 FF31644 STRAIGHT PIN 1644
39 HT11592 DRIVER
40 HT11591 A HANDLE
41 HT11603 TAPE SPRING
48 AA05715 SCREW BIND 4x16 (P)
50 HT70064 TAPE HOLDER ASSY
51 HT70065 BOBBIN CASE ASSY (HT-R)
51 HT70067 BOBBIN CASE ASSY (HT-R2)
53 GN12070 RUBBER WASHER 1.7x6x2
55 HT70068 TAPE CATCH ASSY
56 HT70071 A HANDLE ASSY

PARTS DIAGRAM

HOW TO USE
How to Load Staples
1. Hold the body with one hand, push the lever down and pull the lever towards your
direction (Fig. 1).
* The pusher cannot be removed from the main body.
2. While holding the tool in one hand, insert staples into the magazine so that staples’ legs
point upward, and then set them in the pusher unit by sliding lever. You can load 604C
type of 604E type (Fig. 2).
Caution
Be sure the USE the specified tape.
NEVER apply your fingers near the front end of the magazine unit because there is a
serrated blade and the staple ejection port nearby.
Do not insert a branch near the cutting blade. Doing so may damage the cutting blade
or peripheral parts.
How to Open Tape Holder and Bobbin Case
Put your fingers on UP parts (A) (B), then open the cover (Fig. 3)
How to Load the Tape
1. Open the tape holder and bobbin case, and insert the tape roll into the bobbin case (Fig
4).
2. Pull tape into the tape holder and make sure approximately 5cm of tape hangs out of
the edge of the tape holder.
3. Load the tape through the two guides of the tape guide (Fig 5, 6).

How to Pull Out Tape
1. Squeeze the handle so that the tape catch will catch the tape end deep enough (Fig 7).
2. Release the handle as explained. The tape will pull out (Fig 8).
3. If the tape catch unit does not catch the tape end when you squeeze the handle, please
squeeze the handle harder several more times, and the tape catch will return to its
normal position (this is not a trouble with the tapener).
Note: this should be done only when the tape catch does not catch the tape end.
How to Bind Objects
1. Press the tape against the object until it is positioned inside the tapener (Fig 9).
2. Then fully squeeze the grip with the tape positioned centrally, and the object will be
bound by both the tape and staple, simultaneously the tape is cut off (Fig 10).
How to Change Blade
Preparation
1. Do not remove the cap from the blade (Fig 11).
2. Remove the tape and staples.
3. Open the arm and tape holder cover (Fig 12).
4. As shown in Fig 13, hold the main body with one hand (Fig 13).
Change the Blade
1. Press the button and pull out the old cutting blade.
2. Press the button and push the cutting blade cap deep enough so that three triangles are
aligned (correct position shown in the figure) (Fig 15).

Release the button and pull off the cutting blade cap (Fig 16).
WARNING
Keep your fingers away from the cutting blade.
Confirmation
Confirm that the round hole of the cutting blade is completely hidden (Fig 17).
How to Remove Jammed Staples
While the pusher unit is open, remove any loaded staples, and then remove the stuck staple
with a small screwdriver (Fig 18).
AFTER USE
In order to maintain proper performance, apply oil to the specified locations after each use (Fig
19).
