Mayline realoffice Aberdeen ARRS User manual

1
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
PARTS LIST
1
Name Part Qty
Spare
Qty
A
B
C 1
1
Reception Return Screen
Model No ARRS
P/N ARRS REV 07 07/21/14
Wood Dowel
REALS004
HB
2
E
Spare
Qty
Qty
PartName
REALS003
Cam Post
REALS001
Cam Fastener
Double face Tape
Cam Sticker
REALS102**
1
D
HB
HB
HB
HB
ARRSHB
2
4
4
4
Items with HB are in hardware box
**Denotes Color Code
REALS248
Aberdeen Series
TM
o
re l ffice
www.mayline.com

2
G 1
Qty
PartName
PARTS LIST
Name Part Qty
1
F
Side Panel
ARRSF**
Modesty Panel
ARRSG**
1
G
F
Insert Wood Dowels (A) into Modesty Panel (G) Insert Cams (C) into
the Modesty Panel (G) Install Cam Posts (B) into threaded inserts in
Side Panels (F) Attach Modesty Panel (G) to Side Panel (F) by turning
Cams (C)
NOTE: The arrow on the face of the Cam (C)
should point towards the Cam Post (B) for
proper alignment
FA
B
G
C
3
**Denotes Color Code

2
Apply Foam Tape (E) to bottom edge of Modesty Panel (G) and Side
Panel (F) Attach Return Screen to Transaction Counter by turning
Cams (C) Apply Cam Stickers (D) onto exposed Cams (C)
F
G
4
