MBM FUNK CROSS 20 User manual

FUNK CROSS 20”
USER MANUAL
FUNK CROSS

FUNK CROSS USER MANUAL
1. FOREWORD 4
1.1 Generalities 4
1.2 Assistance 4
1.3 Graphic form of security warnings 4
2. SECURITY WARNINGS 5
2.1 General securit rules 5
2.2 Responsabilities 5
2.3 Warnings for users 6
2.4 Warnings for maintenance 6
2.5 Other provisions 7
2.6 Unpacking and tuning 7
2.6.1 Saddle adjustment 7
2.6.2 Handlebar adjustment 8
2.6.3 Pedals mounting 9
3. BICYCLE DESCRIPTION 10
3.1 General description 10
3.2 Data sheet 11
3.3 Brake levers 12
3.4 Speed change 12
3.5 Support system management 13
3.5.1 Commands 13
3.5.2 System ignition/shutdown 13
3.5.3 Activate support 14
3.5.4 Assistance levels 14
3.5.5 Single distance reset 15
3.5.6 Walking assistance mode 15
3.5.8 Battery indicators 16
3.5.9 Error codes 16
3.5.10 Problems resolution 17
3.6 Battery 18
3.6.1 Battery charge status 18
3.6.2 Battery’s removal/installation 18
3.6.3 Battery charging 20
3.6.4 Problems solving 20
3.8 Front suspension 21
INDEX
4. PROVIDED TERMS OF USE AND ENVIRONMENT 22
4.1 Intended use 22
4.2 Environment use 22
4.3 Improper use and contraindications 23
5. LIFTING AND TRANSPORT 24
5.1 Lifting 24
5.2 Trasport 24
6. COMMISSIONING 25
6.1 Battery charging 25
6.2 Preliminary functional tests 26
6.2.1 Control devices 26
6.2.2 Wheels 26
6.2.3 Braking system 26
6.2.4 Frame, handlebar and seat position 27
6.2.5 Brake adjustment 28
6.2.6 Suspension adjustment 28
7. BICYCLE USE 29
7.1 Bicycle conduction 30
7.2 Braking 30
7.3 Bicycle parking 30
8. MAINTENANCE 31
8.1 Generalities 31
8.2 Maintenance and daily checks 31
8.2.1 Tags and pictograms check 31
8.2.2 Wheels checl 31
8.2.3 Brake functioning check 32
8.3 Maintenance and wheels checks 32
8.3.1 Washing and cleaning 32
8.3.2 Lubrication and chain’s tension check 32
8.3.3 Frame and bolts check 32
8.4 Maintenance and monthly checks 33
8.4.1 Circuit and electrical components check 33
8.4.2 Back derailleur control and adjustment 33

FUNK CROSS USER MANUAL
p.3
9. TECHNICAL ASSISTANCE AND SPARE PARTS 34
10. WAREHOUSE 34
11. COMPONENTS AND MATERIALS DISPOSAL 35
12. ASSURANCE STANDARDS 36
13. CONFORMITY 37

FUNK CROSS USER MANUAL
p.4
1. FOREWORD
1.1 Generalities
This manual is an integral and essential part of the FUNK CROSS 20 ”pedal assisted bicycle. Before putting into operation
it is essential that users read, understand and strictly follow the following provisions. The manufacturer is not liable for
damage caused to people and / or things or to the pedal assisted bicycle if it is used incorrectly with respect to the pre-
scriptions indicated. With a view to continuous technological development, the manufacturer reserves the right to modify
the components, including the frame, without prior notice and without this manual being automatically updated.
1.2 Assistance
For any problems or requests for clarification, contact the authorized dealer, who has competent and specialized person-
nel, as well as specific equipment and original spare parts.
1.3 Graphic form of safety warnings
The following graphic warning symbols will be used in this manual to identify safety messages. They have the function of
attracting the attention of the reader / user for the purposes of a correct and safe use of the pedal assisted bicycle.
It highlights the presence of hazards that
cause residual risks to which the user must
pay attention in order to avoid accidents or
material damage.
DANGER
It highlights behavioral rules to keep in order to
avoid damage to the pedal assisted bicycle and /
or the occurrence of dangerous situations
ATTENTION

FUNK CROSS USER MANUAL
p.5
2. SECURITY WARNINGS
2.1 General safety rules
Even if you are already practical in the use of pedal-assisted bicycles, you must follow the instructions given here, in ad-
dition to the general precautions to be observed during the driving a motor vehicle. Especially:
1. Acquire full knowledge of the pedal-assisted bicycle;
2. Read the manual carefully to know the operation, the safety devices and all the precautions necessary for the safe use
of the vehicle. All this to allow safe use;
3. Carefully maintain the pedal-assisted bicycle in perfect condition;
4. For any inconvenience or request for clarification contact without hesitation the authorized dealer, who has competent
and specialized personnel, specific equipment and original spare parts.
2.2 Responsibilities
Failure to comply with the operating instructions and safety requirements contained in this manual exempts the man-
ufacturer from any liability.
If the maintenance of the pedal-assisted bicycle is carried out in a manner that does not comply with the instructions
provided, with non-original spare parts or in any case in such a way as to compromise its integrity and modify its charac-
teristics, the manufacturer shall will be relieved of any responsibility inherent in the safety of people and the defective
operation of the pedal-assisted bicycle.
ATTENTION
PEDAL-ASSISTED BICYCLE USE
Each user must first have read the instruction manual, in particular the chapter on safety claims.
ATTENTION
RISKS ASSOCIATED WITH THE USE OF THE PEDAL-ASSISTED BICYCLE
• Despite the application of safety devices, for safe use of the pedal-assisted bicycle, note must be made of all the accident
prevention requirements set out in this manual.
• Always stay focused while driving and DO NOT underestimate the residual risks associated with the use of the assisted
bicycle.

FUNK CROSS USER MANUAL
p.6
For any data not included or not deductible from this manual, it is recommended to consult the authorized dealer directly.
2.3 Warnings for users
1. It can only be used by experienced adults and children;
2. Do not take alcohol or drugs before riding the pedal-assisted bicycle;
3. These models of pedal-assisted bicycles are designed and built to be used outdoors, on roads and private and public
environments;
4. Do not ask the pedal-assisted bicycle for performance higher than that for which it was designed;
5. Never ride the pedal-assisted bicycle with disassembled parts;
6. Avoid uneven surfaces and obstacles;
7. Ride with both hands on the handlebars;
8. Replace worn and/or damaged parts and check that the guards are working properly before use.
2.4 Maintenance warnings
1. Any maintenance must take place with the battery disconnected;
2. During each maintenance phase, operators must be equipped with the necessary accident prevention equipment;
3. The tools used for maintenance must be suitable and of good quality;
4. Do not use gasoline or flammable solvents as detergents, but always resort to non-flammable and non-toxic solvents;
5. Limit as much as possible the use of compressed air for cleaning (max 2 bar) and protect yourself with glasses with side
guards;
6. Never resort to the use of open flames as a means of illumination when carrying out verification or maintenance oper-
ations;
7. After any maintenance or adjustment, make sure that no tools or foreign bodies remain between the moving parts of
the pedal-assisted bicycle;
ATTENTION
UNAUTHORIZED CHANGE
If you hear unusual noises or feel something strange, stop the pedal-assisted bicycle immediately.
then carry out a check and, if necessary, contact the authorized dealer
ATTENTION
ORIGINAL SPARE PARTS
Use only original spare parts supplied by M.B.M. S.r.l. Unipersonal. Any liability of the Manufacturer for damage or loss of
functionality

FIG. 1
FUNK CROSS USER MANUAL
p.7
2.5 Other provisions
The first thing to do when starting use is to check the presence and integrity of the protections and the operation of the
safety devices. If you find any defects, do not use the pedal-assisted bicycle!
2.6 Unpacking and tuning
The pedal-assisted bicycle is delivered fully assembled and working.
2.6.1 Saddle adjustment
The adjustment of the height of the saddle is an essential prerogative for the correct use of the pedal-assisted bicycle.
Incorrect adjustment can generate structural breaks to the frame.
Adjust the height of the saddle by operating the quick release mechanism (Ref. A – Figure 1). Check that the mechanism
is tightened before testing the seat and using the medium. Do not lift the saddle beyond the limit sign placed in the tube
(Ref. B – Figure 1).
DANGER
IMPORTANT WARNING:
For your safety, the reference mark of
the seatpost (B) tube should never be
outside the tube where the seatpost tube
is inserted.
ATTENTION
ASSEMBLY
In case that you do not have the appropri-
ate instrumentation for adjustment or do
not have the capabilities, contact the au-
thorized dealer.
SHELTERS
It is strictly forbidden, therefore, to modify or remove the guards, controls, labels and indication plates.
DANGER

FIG. 2
FIG. 3
FUNK CROSS USER MANUAL
p.8
2.6.2 Handlebar adjustment
For a comfortable posture on the bike, which does not cause neck or back pain, we recommend the handlebar column height
adjustment.
Adjust the height of the handlebar column by operating the quick release mechanism (Ref. C – Figure 2). Check that the
mechanism is tight before using the vehicle. Do not lift the handlebar column beyond the height allowed by the mechanism.
To facilitate the transport and storage of the pedal-assisted bicycle, it is possible to unhook and flex the steering column by
means of the centrally placed hinge (Ref. D – Figure 2).
Use the hinge of the handlebar column by lifting the safety
mechanism (Ref. E – Figure 3) and open the zipper.
Check that the release mechanisms are tightened before us-
ing the medium.
ATTENTION
ASSEMBLY
In case that you do not have the appropriate
equipment for adjustment or do not have the
skills, contact the authorized dealer.
ATTENTION
ATTENTION
Do not lift the handlebar column beyond the
maximum height allowed by the mechanism.
Do not use the pedal-assisted bicycle with the
zipper unhooked.

FIG. 4
FUNK CROSS USER MANUAL
p.9
ATTENTION
ASSEMBLY
In case that you do not have the appropriate equip-
ment for adjustment or do not have the capabilities,
contact the authorized dealer.
2.6.3 Pedals mounting
Right pedal: it is identified by the letter “R” marked on its
pin. For pedal mounting, screw by turning the pin clockwise
(Figure 4).
Left pedal: it is identified by the letter “L” marked on its pin.
For pedal mounting, screw by turning the pin counterclock-
wise (Figure 4)
ATTENTION
ASSEMBLY
For a correct evening of the pedals, it is necessary to
use a key of 15

FUNK CROSS USER MANUAL
p.10
3. BICYCLE DESCRIPTION
3.1 General description
The pedal-assisted bicycle is designed and built to be used outdoors, on roads and private or public environments. In
particular, the components and the type of pedal-assisted bicycle allow you to tackle routes with asphalt surfaces or
with similar characteristics without particular roughness.
The pedal-assisted bicycle is equipped with a rechargeable battery and an electric motor, whose intervention takes place
only in conjunction with the pedaling and gradually stops as the speed of the vehicle approaches 25 km / h, and then stops
completely at that speed.
For the management of the assistance system there is a special display located on the left side of the handlebar. On the
right side of the handlebar there is a control system for adjusting the gears.
INCORRECT AND UNINTENDED USE
The bicycle has been designed and manufactured for the specified use; a different use and failure to comply with the technical
parameters set by the manufacturer may constitute a dangerous condition for users.
DANGER

FUNK CROSS USER MANUAL
p.11
3.2 Technical sheet
1. HANDLEBAR AND COMMANDS
2. ENGINE
3. SADDLE
4. BATTERY
5. PEDALS
6. FORK
7. REAR DERAILLEUR
CODE E500 / E500CR
FRAME HYDROFORM ALUMINIUM
FORK SUSPENSION WITH REGULATON
CRANKSET 38 TEETH
REAR DERAILLEUR ACERA
SHIFTERS
BRAKE SHIMANO MT 200 IDRAULICI
WHEELS SHIMANO RT26 ANT: Ø160MM POST:Ø160MM
TYRES 20*3,0
SADDLE MBM FUNK
PEDALS RIGHT AND LEFT IN POLYMER AND ANTI-SLIP MATERIAL
MOTOR CENTRAL OLI MOVE ONE 60 NM
BATTERY SEMI-INTEGRATED SPARD YT 30240, 36V, 7AH 252 WH
MAX ASSISTANCE
SPEED 25 KM/H
DISPLAY LCD
POWER LEVELS 5
WEIGHT 26 KG
8 SPEED

FIG. 5
FUNK CROSS USER MANUAL
p.12
3.3 Brake levers
The brake levers (Ref. F – Figure 5) are placed on the handlebars of the pedal-assisted bicycle, near the knobs (Ref. G – Fig-
ure 5). These systems make it possible to control the calipers of the disc brakes located near the wheel hubs. The right le-
ver controls the rear brake, the left one the front brake; the braking action is proportional to the force applied on the lever.
3.4 Speed change
The pedal-assisted bicycle has an 8-speed gearbox with the sprockets positioned on the rear wheel hub and selectable
by means of the opposing levers located at the base of the right knob. The indicator (Ref. H – Figure 5) presents at the bot-
tom of the handlebar allows you to view the selected ratio.

FUNK CROSS USER MANUAL
p.13
3.5.2 System ignition/shutdown
To activate the system you must first turn on the battery; after that, press and hold the on/off button. (Ref. L - Figure 6). To
turn off the system, press and hold the on/off button (Ref. L - Figure 6).
3.5 Assistance system management
3.5.1 Commands
To manage the assistance system there is a display on the left side of the handlebar. This device allows you to vary the
level of assistance and to view information regarding the path and status of the battery (Figure 6).
FIG. 6
I - Display;
L - On/off button and increased service
level;
M-Mode button and reduction of the level
of assistance;
N - Remove walking assistance mode.

FUNK CROSS USER MANUAL
p.14
FIG. 7
1 - Battery charge indicator
2 - Speed
3 - Level of assistance
4 - Percentage of battery charge
5 - Total Distance Traveled (ODO)/Single Distance (TRIP).
The two values are automatically toggled on the display.
6 - Error (see section 3.5.9 for error codes).
3.5.3 Assistance activation
The engine is activated and deactivated immediately if the pedaling stops. The power of the motor depends on the force
imposed on the pedals according to a multiplicative factor depending on the level of assistance selected.
Press and release the power button (Ref. L - Figure 6) to increase the level of assistance. To decrease the level of assis-
tance press and release the “-” button (Ref. M - Figure 6). The level of assistance can be selected from any screen of the
display
3.5.4 Assistance level
LEVEL 0 - NO ASSISTANCE
LEVEL 1 – ASSISTANCE 12,5%
Recommended route: plain - long distances
LEVEL 2 - ASSISTANCE 25%
Recommended route: plain/hilly - medium-long distances
LEVEL 3 - ASSISTANCE 50%
Recommended route: hilly /medium climb - medium distances
LEVEL 4 – ASSISTANCE 75%
Recommended route: ascent - medium short distances
LEVEL 5 - ASSISTANCE 100%
Recommended route: challenging
The power of the engine depends on the force imprinted on
the pedals according to a multiplicative factor according to
the selected level of assistance. The assistance drops linearly
until it reaches 25 km/h. Once this speed has been exceeded,
the assistance is automatically deactivated.

FUNK CROSS USER MANUAL
p.15
3.5.5 Single distance reset
With the device turned on, press the power button and the “-” button (Ref. L,M - Figure 7.1) at the same time to reset the single
distance (TRIP).
3.5.6 Walking assistance mode
The pedal-assisted bicycle is equipped with the function of walking assistance. This function allows you to move the bike
more easily during manual movement in case you face mall climbs.
In flat routes it is useful for starting the ride, up to a speed of 6 km / h.
To activate the above mode, turn on the assistance system using the appropriate button (Ref. L - Figure 7.1).
At this point, set the assistance level to 0 and press the lever (Ref. N - Figure 7.1) to activate the walking assistance mode.
Once the lever is released, the assistance mode is automatically deactivated.
FIG. 7.1

FUNK CROSS USER MANUAL
p.16
3.5.9 Error codes
In the event of a malfunction, the display automatically shows a 4-character code corresponding to the fault encoun-
tered. Error codes are displayed on the right side of the display and highlighted by an exclamation mark. To remove the
code, turn the device off and on again.
CODICE ERRORE DESCRIZIONE
0001 PROBLEM COMMUNICATING WITH BATTERY. BATTERY STATUS DATA MAY BE DISPLAYED INACCURATELY. CHECK THAT THE WIRING AND CONTACTS OF THE
BATTERY ARE CONNECTED CORRECTLY AND INTACT.
0101
COMMUNICATION PROBLEMS BETWEEN THE TRANSMISSION UNIT AND THE GRAPHICAL INTERFACE.
CHECK THAT THE WIRING IS INTACT AND CONNECTED CORRECTLY.
0104
SPEED SENSOR NOT DETECTED.
CHECK THAT THE SPEED SENSOR AND MAGNET ARE CORRECTLY ALIGNED.
CHECK THAT THE SENSOR IS INSTALLED AND CONNECTED CORRECTLY.
0105 PROBLEMS WITH THE TORQUE SENSOR SIGNAL. THE TORQUE SENSOR SIGNAL IS FAULTY. THE ENGINE WILL RUN AT REDUCED POWER.
3.5.8 Battery indicators
The state of charge of the battery (Ref.1 - Fig. 7) is indicated on the left side of the display.
When the battery is fully charged, 5 bars appear on the display; the bars gradually decrease as the battery discharges.
When the battery charge is low, the last bar flashes to warn you that the battery needs to be recharged.
ATTENTION
Depending on the type of failure, the sys-
tem may prevent the engine from
starting or running at maximum power.

FUNK CROSS USER MANUAL
p.17
0106 INADEQUATE RESPONSE OF THE TORQUE SENSOR. THE TORQUE SENSOR IS FAULTY.
0801 FAILURE OF THE MOTOR ROTATION SENSOR.
0802 FAILURE OF THE PEDAL ROTATION SENSOR.
0804
CONTROL UNIT TEMPERATURE TOO HIGH.
THE TEMPERATURE SENSOR OF THE CONTROL UNIT DETECTED A TEMPERATURE HIGHER THAN THE PERMISSIBLE LIMIT .
0805 ENGINE TEMPERATURE TOO HIGH. THE ENGINE HAS REACHED A TEMPERATURE HIGHER THAN THE PERMISSIBLE LIMIT.
0806 PERIPHERAL CONNECTOR VOLTAGE ISSUES.
0808 ROTOR LOCKED. THE ENGINE DID NOT START DUE TO A MECHANICAL BLOCKAGE OR A PROBLEM WITH THE TRANSMISSION UNIT CABLE .
0809 THE BATTERY VOLTAGE IS HIGHER THAN THE MAXIMUM ALLOWED.
0810 PROBLEMS WITH THE ELECTRIC CURRENT SENSOR.
0811 THE CONTROL UNIT HAS DETECTED AN EXCESS OF ELECTRIC CURRENT.
1101 COMMUNICATION PROBLEMS BETWEEN THE USER INTERFACE AND THE CONTROL UNIT. CHECK THAT THE CABLE IS INTACT AND CONNECTED CORRECTLY.
1102 ONE OF THE BUTTON PANEL KEYS GOT STUCK IN THE PRESSURE POSITION.
3.5.10 Problems resolution
PROBLEM CAUSE/SOLUTION
The display does not turn on Check the connection between the display and the
control unit.
How to handle error codes Verify the problem based on the error code description
provided in this manual. ATTENTION
If the problem persists after these oper-
ations, request support from a service
center.

FUNK CROSS USER MANUAL
p.18
3.6 Battery
The assistance system of the pedal-assisted bicycle, to work, needs
the presence of the power battery.
Specifically, the battery is removable, so you can take it out for
maintenance actions or when you want to store the vehicle.
3.6.1 Battery charge status
You can view the battery charge status directly on the assistance
system management display.
In case that the battery is disassembled from the vehicle or you want
to see the state of charge without turning on the assistance system,
in the upper part of the battery there is a button (Ref.O – Figure 8) that
allows, through a LED light of different colors (Ref. P – Figure 8), to
display the state of charge.
CHARGING STATUS LED:
RED LIGHT 0– 25%
GREEN LIGHT 25- 75%
BLUE LIGHT 75– 100%
FIG. 8
3.6.2 Battery removal / installation
To remove the battery make sure that both the assistance system and the battery are turned off and proceed as it follows:
1. Insert the battery lock/unlock key into the battery lock at the top right of the frame near the handlebar and turn the keys
clockwise. (Ref. Q – Figure 9)
2. Holding the key rotated, unhook the battery and lift it (Ref. 2 – Figure 9)
3. Take out the battery completely, taking care not to hit the frame.
FIG. 9
1 2 3

FUNK CROSS USER MANUAL
p.19
To install the battery proceed as it follows:
1. This procedure must be performed without the unlock key; remove the key if inserted;
2. Align the battery above the oblique pipe of the frame by matching the electrical connector (Ref. R – Figure 10)
3. Carefully insert the battery into the frame until you hear the closing click of the lock. At this point the battery is already
self-locked
FIG. 10
1 2 3

FUNK CROSS USER MANUAL
p.20
3.6.3 Battery Charging
The charging of the pedal-assisted battery can be carried out both with the battery fixed to the frame and with the same
extracted and stored in a sheltered environment.
To charge the battery, do as it follows:
1. Turn off the battery and turn off the assistance system of the pedal-assisted bicycle using the appropriate button on the
display. (Ref. L – Figure 6);
2. Remove the battery in case you want to charge it separately;
3. Lift the rubber stopper at the top right of the battery (Figure 11)
4. Connect the supplied battery charger with the appropriate plug;
5. Connect the battery charger to a power outlet (230 V / 50 Hz) and charge for as long as necessary
ATTENTION
BATTERY CHARGER
Always connect the plug to the bat-
tery first and then the battery charg-
er to the power outlet.
FIG. 11
3.6.4 Problems resolution
ATTENTION
PROBLEMS RESOLUTION
In case that the assistance system does not
activate even if the battery turns out to be
charged, contact your authorized dealer.
PROBLEM CAUSE/SOLUTION
The system does not turn on Check that the battery is charged.
PROBLEM CAUSE/SOLUTION
Support does not activate Check that the battery charge level is
sufficient.
