MBM SINOPE 28 User manual

SINOPE 28”
USER MANUAL
SINOPE

SINOPE USER MANUAL
1. FOREWORD 4
1.1 General 4
1.2 Assistance 4
1.3 Graphic form of security warnings 4
2. SAFETY WARNINGS 5
2.1 General safety rules 5
2.2 Responsabilities 5
2.3 Warning for users 6
2.4 Maintenance warnings 6
2.5 Other provisions 7
2.6 Unpacking and tuning 7
2.6.1 Saddle adjustment 7
2.6.2 Pedal mounting 8
3. BICYCLE DESCRIPTION 9
3.1 General description 9
3.2 Data sheet 10
3.3 Brake levers 11
3.4 Speed change 11
3.5 Service system management 12
3.5.1 Service management commands 12
3.5.2 Turning the system on/off 12
3.5.3 Support activation 13
3.5.4 Support level setting 13
3.6 Display graphic inteface 14
3.6.1 General screen composition 14
3.7 On-board computer mode 15
3.7.1 Race mode 15
3.7.2 Summary mode 16
INDEX
3.8 Walking assistance mode 17
3.9 Menu 18
3.9.1 Screen brightness 19
3.9.2 Change language 19
3.9.3 Units of measurement 19
3.9.4 Weight 20
3.9.5 Gender 20
3.10 Error code 20
3.10.1 Troubleshooting 22
3.11 Battery 23
3.11.1 Charge status 23
3.11.2 Battery installation/removal 23
3.11.3 Battery charging 25
3.11.4 Troubleshooting 25
3.12 Front and rear headlight 26
3.13 Front suspension 26
4. CONDITIONS OF USE AND INTENDED ENVIRONMENT 27
4.1 Intended use 27
4.2 Environment of use 28
4.3 Improper uses and contraindications 28
5. LIFTING AND TRANSPORT 29
5.1 Lifting 29
5.2 Transport 29
6. COMMISSIONING 30
6.1 Battery charge 30
6.2 Preliminary functional checks 31
6.2.1 Control devices 31

SINOPE USER MANUAL
p.3
6.2.2 Wheels 31
6.2.3 Braking system 31
6.2.4 Frame, handlebar and saddle position 32
6.2.5 Brake adjustment 33
6.2.6 Suspension adjustment 33
6.2.7 Headlight operation 33
7. USE OF THE BICYCLE 34
7.1 Use of the bicycle 35
7.2 Braking 35
7.3 Bicycle parking 35
8. MAINTENANCE 36
8.1 General 36
8.2 Daily maintenance and checks 36
8.2.1 Control of nameplates and pictograms 36
8.2.2 Wheel control 36
8.2.3 Brake operation control 36
8.3 Weekly maintenance and checks 37
8.3.1 Washing and cleaning 37
8.3.2 Lubrication and chain tension control 37
8.3.3 Frame and bolt control 37
8.4 Monthly maintenance and checks 38
8.4.1 Derailleur control and adjustment 38
9. TECHINCAL SUPPORT AND SPARE PARTS 39
10. WAREHOUSE 39
11. DISPOSAL OF COMPONENTS AND MATERIALS 40
12. WARRANTY RULES 41
13. CONFORMITY 42

SINOPE USER MANUAL
p.4
1. FOREWORD
1.1 General
This manual is an integral and essential part of the pedal-assisted bicycle models E - SINOPE 28". Before commissioning,
it is essential that users read, understand and follow the following positions scrupulously.
The manufacturer is not liable for damage caused to persons and / or things or to pedal-assisted bicycles, if they are used
incorrectly with respect to the requirements indicated.
With a view to continuous technological development, the manufacturer reserves the right to modify the components,
including the frame without notice, without this manual being automatically updated.
1.2 Support
For any inconvenience or request for clarification, contact the authorized dealer, who has competent and specialized per-
sonnel, as well as specific equipment and original spare parts.
1.3 Graphic form of safety warnings
To identify the security messages in this manual, the following graphic signal symbols will be used. They have the function
of attracting the attention of the reader / user for the purpose of a correct and safe use of the assisted bicycle.
It highlights behavioral rules to be kept in
order to avoid damage to the pedal-assisted
bicycle and / or the onset of dangerous situ-
ations.
Highlights the presence of hazards that cause
residual risks to which the user must pay at-
tention in order to avoid accidents or materi-
al damage.
DANGER
ATTENTION

SINOPE USER MANUAL
p.5
2. SAFETY WARNINGS
2.1 General safety rules
Even if you are already practical in the use of pedal-assisted bicycles, you must follow the instructions given here, in ad-
dition to the general precautions to be observed during the driving a motor vehicle. In particular:
• Acquire full knowledge of the pedal-assisted bicycle.
• Read the manual carefully to know the operation, the safety devices and all the precautions necessary for the safe use
of the vehicle. All this to allow safe use.
• Carefully keep the pedal-assisted bicycle in perfect condition.
For any inconvenience or request for clarification, contact without hesitation the authorized dealer, who has competent
and specialized personnel, specific equipment and original spare parts.
2.2 Responsabilities
Failure to comply with the operating instructions and safety requirements contained in this manual relieves the manufac-
turer of any liability.
If the maintenance of the pedal-assisted bicycle is carried out in a manner that does not comply with the instructions
provided, with non-original spare parts or in any case in such a way as to compromise its integrity or modify its character-
istics, the manufacturer will be relieved of any responsibility inherent in the safety of persons and the defective operation
of the pedal-assisted bicycle.
ATTENTION
ATTENTION
USE OF THE PEDAL-ASSISTED BICYCLE
Each user must have first read the instruction manual, in particular the chapter on safety claims.
RISKS ASSOCIATED WITH THE USE OF THE PEDAL-ASSISTED BICYCLE
• Notwithstanding the application of safety devices, for the safe use of the pedal-assisted bicycle , all the requirements re-
lating to the prevention of accidents reported in this manual.
• Always stay focused while driving and DO NOT underestimate the residual risks associated with the use of the assisted
bicycle.

SINOPE USER MANUAL
p.6
For any data not included or not deductible from this manual it is recommended to consult directly the authorized dealer.
2.3 Warning for users
1. It is forbidden to load a passenger.
2. It can only be used by experienced adults and children.
3. Do not take alcohol or drugs before riding the pedal-assisted bicycle.
4. These models of pedal-assisted bicycles are designed and built to be used outdoors, on roads and private and public
environments.
5. Don't ask your pedal-assisted bike for performance that's superior to what it was designed for.
6. Never ride the pedal-assisted bicycle with disassembled parts.
7. Avoid uneven surfaces and obstacles.
8. Ride with both hands on the handlebars.
9. Replace worn and /or damaged parts, check that the protections work correctly before use.
2.4 Maintenance warnings
1. Any maintenance must take place with the battery disconnected.
2. During each maintenance phase, operators must be equipped with the necessary accident prevention equipment.
3. The tools used for maintenance must be suitable and of good quality.
4. Do not use gasoline or flammable solvents as detergents, but always use non-flammable and non-toxic solvents.
5. Limit as much as possible the use of compressed air for cleaning (max 2 bar) and protect yourself with glasses with side
guards.
6. Never use open flames as a means of lighting when carrying out verification or maintenance operations.
7. After every intervention of maintenance o regulation make sure who Not Remain paraphernalia o Bodies Strangers be-
tween the organs of movement of bicycle a foot thrust Assisted.
ATTENTION
ATTENTION
UNAUTHORIZED CHANGES
If you hear unusual noises, or feel something strange, stop the pedal-assisted bicycle immediately. Carry out a check after-
wards and, if necessary, contact the authorized dealer.
ORIGINAL SPARE PARTS
Use only original spare parts supplied by M.B.M. S.r.l.
Any liability of the Manufacturer for damage or loss of functionality caused
as a result of the use of non-original accessories and parts is excluded.

SINOPE USER MANUAL
p.7
2.5 Other provisions
The first thing to do when starting the use, is to check the presence and integrity of the protections and the operation of
the safety. If you find any defects do not use the pedal-assisted bicycle!
2.6 Unpacking and tuning
The pedal-assisted bicycle is delivered fully assembled and working.
2.6.1 Saddle adjustment
The pedal-assisted bicycle is delivered mounted and ready to use. Check the adjustment of the handlebar (which is aligned
with the front wheel) of the brake levers, of the saddle, in such a way as to guarantee a comfortable and safe use for the
user. The adjustment of the height of the saddle is an essential prerogative for the correct use of the pedal-assisted bicy-
cle. Incorrect adjustment can generate structural breaks to the frame.
Adjust the height of the saddle by operating the quick release mechanism (Ref. A - Figure 1).
Check that the mechanism is tightened before testing the seat and using the medium. Do not lift the saddle beyond the
limit sign placed in the tube (Ref. B - Figure 1).
GUARDS
It is strictly forbidden, therefore, to modify or remove the guards,
controls, labels and indication plates.
DANGER
DANGER
IMPORTANT NOTICE:
For your safety, the sign of retraction of
the seatpost (B) should never be outside
the tube in which the seatpost is inserted.
ATTENTION
ASSEMBLY
In the event that you do not have the ap-
propriate instrumentation for adjustment
or do not have the capabilities contact the
authorized riv- enditore .
FIG. 1

SINOPE USER MANUAL
p.8
ATTENTION
ASSEMBLY
In the event that you do not have the appropriate
equipment for adjustment or do not have the skills
contact the authorized dealer.
2.6.2 Pedal mounting
Right Pedal: it is identified by the letter R marked on its pin.
For pedal mounting, screw by turning the pin clockwise. (Fig-
ure 2)
Left pedal: it is identified by the letter L marked on its pin. For
pedal mounting, screw by turning the pin counterclockwise.
(Figure 2)
FIG. 2

SINOPE USER MANUAL
p.9
3. BICYCLE DESCRIPTION
3.1 General description
The pedal-assisted bicycle is designed and built to be used outdoors, on roads and private or public environments. In
particular, the components and the type of pedal-assisted bicycle, allow you to face routes with asphalted and unpaved
surfaces without particular roughness.
The pedal-assisted bicycle is equipped with a rechargeable battery and an electric motor, whose intervention takes place
only in conjunction with the pedaling and gradually stops as the speed of the vehicle approaches 25 km / h, and then stops
completely at that speed.
For the management of the assistance system there is a special control located next to the left knob, on the handlebar.
On the right side of the handlebar there is a control system for the selection of gears.
INCORRECT AND UNINTENDED USE
The bicycle has been designed and manufactured for the specified use; a differ-
ent use and non-compliance with the technical parameters set by the manufac-
turer, may constitute a dangerous condition for users.
DANGER

SINOPE USER MANUAL
p.10
3.2 Data sheet
1. HANDLEBARS AND CONTROLS
2. MOTOR
3. SADDLE
4. BATTERY
5. PEDALS
6. FORK
7. FRONT LIGHT
8. REAR LIGHT
9. REAR DERAILLEUR
CODE E809 DONNA
FRAME ALUMINIUM HYDROFORMED
FORK SUSPENSION WITH ADJUSTMENT
CRANKSET 38 TEETH
REAR DERAILLEUR DEORE
SHIFTER 10 SPEEDS
BRAKES SHIMANO BR-M315 HYDRAULIC
DISKS SHIMANO
ANT: Ø180 mm POST: Ø160 mm
WHEELS 28*2.00
SADDLE SADDLES ITALIA SPORTOURER
PEDAL RIGHT AND LEFT NON-SLIP POLYMER
MATERIAL
ENGINE CENTRAL SPORTS OLI 85 NM
BATTERY PHYLION BN-18, 14 Ah, 504 Wh
SPEED MAX ASSISTANCE 25 KM/H
DISPLAY LCD
POWER LEVELS 5
WEIGHT 25 KG

SINOPE USER MANUAL
p.11
3.3 Brake levers
The brake levers (Ref.C - Figure 3) are placed on the handlebars of the pedal-assisted bicycle, near the knobs (Ref. D- Fig-
ure 3). These systems make it possible to control the calipers of the brake discs, located near the wheel hubs. The right le-
ver controls the rear brake, the left one the front brake; the braking action is proportional to the force applied on the lever.
3.4 Speed change
The pedal-assisted bicycle has a 10-speed gearbox with the sprockets positioned on the hub of the rear wheel, selectable
by means of the opposing levers, located at the base of the right knob. The indicator (Ref. E - Figure 3) at the top of the
handlebar allows you to view the selected ratio.
FIG. 3

3.5 Support system management
3.5.1 Support management commands
The pedal-assisted bicycle has, in the center of the han-
dlebar, a display that allows you to manage the operation
of the electric motor, in addition to other basic functions
illustrated below. (Figure 4)
Near the left knob of the handlebar are 3 buttons, which
can be used with a short or long press, thanks to these
you can control the functionality of the display. (Figure 5)
FIG. 4
FIG. 5
3.5.2 Turning the system on/off
To activate the system, press the "POWER" button (Ref.H - Figure 5) until the power
diagram is displayed or press the "ON" button on the battery. To turn off the display,
press and hold the "POWER" button until the power off screen appears or press the
"OFF" button on the battery. If the E-Bike is not used for a variable time depending on
the type of battery, the system will automatically turn off.
button Short pressure/<1 second prolonged pressure/ > 2 seconds
H-power Allows you to:
Scroll through the Home from
one Main Screen to another;
Scroll between Home and Menus;
confirm the action during
the changes.
Allows you to:
Turn the display on and off;
from the Menu and Advanced
section, return to the last
Home screen displayed.
F-up Allows you to scroll through menu
items, going up.
allows you to increase the level of
assistance.
from any main screen allows
you to change the mode of
operation of the lights.
G-down allows you to scroll through menu
items, going down.
allows you to reduce the level of
assistance.
from any main screen allows
you to activate the
Walk mode
F+G
down+up
- from the main screens,
the simultaneous press of
the two buttons, allows you
to access the menu.
SINOPE USER MANUAL
p.12

SINOPE USER MANUAL
p.13
3.5.4 Setting the level of support
From any screen in the Home section you can change the level of assistance by pressing the "UP" key (Ref. F - Figure 5) to
increase it and the "DOWN" key (Ref. G - Figure 5) to decrease it.
LEVEL 0 - MULTIPLICATIVE FACTOR 0% (ENGINE NOT ACTIVE)
LEVEL 1 - MULTIPLICATIVE FACTOR 50%
LEVEL 2 - MULTIPLICATIVE FACTOR 100%
LEVEL 3 - MULTIPLICATIVE FACTOR 200%
LEVEL 4 - MULTIPLICATIVE FACTOR 300%
LEVEL 5 - MULTIPLICATIVE FACTOR 400%
ATTENTION:
The engine has 5 levels of assistance that increase the
power provided by the engine. If you put on 0 the engine is
switched off.
3.5.3. Activate support
The engine is activated, and is deactivated immediately if the pedaling ceases. The power of the engine depends on the
force impressed on the pedals, according to a multiplicative factor depending on the level of assistance selected.
ATTENTION
FIG. 5
Multiplicative factor for each level of care:

SINOPE USER MANUAL
p.14
3.6 Display graphic interface
After powering on, the first Distance screen of the home section appears. The Home section consists of 6 screens. To
scroll through the screens, you need to press the "POWER" button.
From any screen in the home section, you can:
› Adjust the level of assistance by pressing the "UP" and "DOWN” keys;
› Enter the Walk mode, holding down the "DOWN" button;
› Adjust the brightness of the eBike lights, holding down the "UP" button for 2";
› Enter the Menu section, holding down the "UP"+"DOWN" keys at the same time for 2”.
3.6.1. General screen composition
The screens in the Home section differ from each other in the type of information display. (Figure 4.1)
FIG. 4.1
1- BATTERY
-CHARGE STATUS PERCENTAGE.
2- E-BIKE CURRENT SPEED
IN KILOMETERS/HOUR (KM/H).
3- POWER GRAPHICS DISPLAY
-UPPER BAR: ENGINE POWER,
- LOWER BAR: CYCLIST POWER.
4- E-BIKE LIGHT ADJUSTMENT
AUTOMATIC/ON/OFF(RIF.3.7)
5- SERVICE LEVEL
(RIF. 3.5.4)
6- NAVIGATION BAR
PRESENT ON EACH SCREEN, INDICATES
THE CURRENT SCREEN.
ENGINE POWER
CYCLIST POWER
DISTANCE TRAVELLED FROM THE START OF
THE LAP
TIME ELAPSED SINCE THE START OF THE
TOUR
PEDAL CADENCE
ENERGY BURNED BY THE CYCLIST
AVERAGE CONSUMPTION E-BIKE
TOTAL DISTANCE
TRAVELED AVERAGE SPEED

SINOPE USER MANUAL
p.15
3.7 on-board computer mode
The on-board computer is able to adapt to different use scenarios, from switching to sports use.
To move between the available display modes, briefly press the "POWER" button (Ref. H - Figure 5).
3.7.1. “RACE” mode
It is the fifth screen in the home section.
In this screen the values in watts (w) of the motor power and cyclist power are expressed in full. (Figure 4.2) This mode of
use is addressed to experienced users, and to a sporty use of the e-bike. (Figure 4.2)
FIG. 4.2
battery
capacity =÷ average consumption
Passable
km
1- POWER
Indicates the instantaneous power de-
livered by the motor in watts (w).
2- CYCLIST POWER
Indicates the instantaneous power ex-
pressed by the cyclist in watts (w).
3- POWER DISPLAY
Graphic display of the upper bar power:
engine power lower bar: cyclist power.
4- ENERGY CONSUMPTION
Indicates the average energy consump-
tion in watt-hours per kilometer (Wh/
km), calculated since the last zeroing.
This data allows to adjust the level and five of
the consumption of the eBike according to the
need.
By calculating the ratio between this data and
the capacity of the battery, the exact possible
mileage data for each charge is obtained.
5- CADENCE
6- CURRENT SPEED
7- SERVICE LEVEL
÷

SINOPE USER MANUAL
p.16
FIG. 4.3
1- INDICATES THE DISTANCE TRAVELED IN KILOMETERS (KM) SINCE THE LAST RESET.
2- INDICATES THE TIME SPENT IN MOTION SINCE THE LAST RESET.
THE VALUE IS EXPRESSED IN HOURS: MINUTES: SECONDS.
3- INDICATES THE AVERAGE SPEED IN KILOMETERS PER HOUR (KM / H) DETECTED
SINCE THE LAST RESET.
4- INDICATES THE AVERAGE ENERGY CONSUMPTION IN WATT-HOURS PER KILOMETER
(WH / KM), CALCULATED SINCE THE LAST RESET.
5- INDICATES THE ENERGY CONSUMED BY THE CYCLIST IN KILOCALORIES (KCAL) SINCE
THE LAST RESET.
6- INDICATES THE TOTAL DISTANCE TRAVELED BY THE EBIKE IN KILOMETERS (KM).
NON-RESETTABLE VALUE.
3.7.2. Summary mode
It is the sixth screen of the Home section.
This screen summarizes the variable parameters of the previous screens. (Figure 4.3)

SINOPE USER MANUAL
p.17
FIG. 5
3.8 Walking assistance mode
The system is equipped with a walking assistance function, which allows you to activate the engine up to a maximum
speed of 6km/h to allow you to tackle more easily short stretches pushing the e-bike.
To activate the walk assistance function, press and hold the "DOWN" button (Ref. G in Figure 5). The engine will activate,
and the appropriate warning will be displayed on the display. The engine will shut down in the following cases:
• Release of the "DOWN" button (Ref. G in Figure 5)
• Speed greater than 6km/h
• Locking the e-bike wheel
NOTE: By selecting the assistance level “0", the motor is completely disabled, and it is not possible to use the walking as-
sistance function.
Attention:
Walking assistance mode.
Before activating the walking assistance mode,
hold the handlebars firmly in such a way as to
avoid injuries.
ATTENTION

SINOPE USER MANUAL
p.18
FIG. 4.5
FIG. 4.4
RESET TRIP
THE RESET TRIP ITEM ALLOWS YOU TO RESET ALL THE RECORDED LAP DATA BRINGING THE COUNTERS
BACK TO ZERO (0).
ADVANCED
SELECTING THIS FUNCTION, YOU ENTER THE ADVANCED SETTINGS MENU.
SYSTEM INFO
ON THIS SCREEN YOU CAN VIEW THE VERSIONS OF THE FIREWARE, THE INSTALLED HMI AND THE COM-
BINED ENGINE.
BATTERY INFO
BY SELECTING THIS FUNCTION, YOU CAN VIEW THE BATTERY INFORMATION.
BACK
SELECTING THIS FUNCTION RETURNS YOU TO THE HOME SCREEN.
3.9 Menu
By simultaneously pressing the "UP"+"DOWN" buttons (Ref. F - G - Figure 5) for two seconds you can open the menu
screen. From any screen, by holding down the "POWER" button for 2", you can return to the last home screen displayed.
Once inside you can move in the menu with the “UP” and “DOWN” buttons and press “POWER” as send.
Attention:
Before pressing the F and G keys at the same time (Figure 5) position yourself firmly on the bike and
apply the brake, so as not to unintentionally operate the departure from a standstill.
ATTENTION
Selecting the ADVANCED setting leads to the advanced settings menu,
where you can change or control the essential parameters of the dis-
play. Specifically, you can change the brightness, language, unit, weight,
gender and night mode.

SINOPE USER MANUAL
p.19
FIG. 4.6
FIG. 4.7
FIG. 4.8
3.9.1. Screen brightness
From this screen you can adjust the brightness of the screen. Use the
"UP" and "DOWN" keys to scroll through the values from 1 to 10. The
selected value is highlighted in the center in the white row. (Figure 4.6)
3.9.2. Change language
From this screen you can choose the language of the texts of the unit.
Use the "UP" and "DOWN" keys to scroll through the available items. The
selected value is highlighted in the center in the white row. (Figure 4.7)
8.9.3 Units of measurement
From this screen you can select the unit of measurement with which
they are calculated:
› Instantaneous speed,
› Average speed,
› Average consumption,
› Lap distance,
› Total distance.
Use the "UP" and "DOWN" keys to scroll through the Entries Available. The
value selected è Highlighted per center in ruler white woman. (Figure 4.8)

SINOPE USER MANUAL
p.20
FIG. 4.9
FIG. 4.10
8.9.4 Weight
From this screen you can set your body weight by choosing a value be-
tween 50 and 150 kg. Setting this data is not necessary for the proper
functioning of the eBike. The value has the sole purpose of making the
calculation of calories consumed reliable.
Use the up and down keys to scroll through the available items. The se-
lected value is highlighted in the center in the white line. (Figure 4.9)
8.9.5 Gender
From this screen you can set your gender. Setting this data is not neces-
sary for the proper functioning of the eBike. The value has the sole pur-
pose of making the
calculation of calories consumed reliable.
Use the up and down keys to scroll through the available items. The se-
lected value is highlighted in the center in the white row. (Figure 4.10)
ERROR CODE
In the event of an anomaly, the system reports the problem to the user by displaying a danger icon combined with a
4-character code, which allows you to trace the type of error.
In base per type of anomaly the system Could prevent activation of engine o Do work a power redoubt. Where è Suitable
"do request of assistance", è necessary the intervention of a technician specialized OILS eBike Systems.
