McCulloch MC1385 User manual

Deluxe Canister Steam System
Owner’s Guide
Model MC1385
KEEP YOUR RECEIPT FOR WARRANTY PURPOSES
Please read all instructions before use.
English p. 2

2 |ENGLISH
This owner's guide and any additional inserts are considered part of the product. They contain important
information about safety, use, and disposal. Before using the product, please familiarize yourself with
all operating and safety instructions. Please keep all documents for future reference and pass these
documents on, together with the product, to any future owner. See our website for the most current
version of this owner’s guide.
INTENDED USE: This product is intended to be used indoors for household cleaning in the United
States and/or Canada. This product is not intended for commercial or industrial uses. The manufacturer
assumes no responsibility for damage or injury due to unauthorized use or product modication. Failure
to follow these directions will void the product warranty.
WARNING: Risk to Children and Impaired Persons
Supervision is required during the installation, operation, cleaning and maintenance of this product by
children age 12 and under and anyone with reduced physical, sensory or mental capabilities. Children
should be supervised to ensure that they do not play with the appliance, its parts and packaging material.
Directions to reduce risk of re, electrical shock, and injury:
1. Read all instructions before use.
2. If an extension cord is necessary, use a properly rated cord (15 ampere, 14 gauge). Use care to
position extension cord where it is least likely to be damaged or tripped over during use.
3. Before plugging power cord into electrical outlet, be sure that all electrical information on rating label
agrees with your power supply.
4. To reduce likelihood of circuit overload, DO NOT operate another high wattage appliance on the same
circuit as this unit.
5. To reduce the risk of electric shock, do not immerse the appliance in water or other liquids. If product
falls into water or another liquid, immediately unplug. Do not reach into the water while product is
plugged in.
6. Do not use power cord as handle, let it hang over edges of counters, or be crimped or closed in doors.
7. Never yank power cord to disconnect from outlet; instead, grasp plug and pull to disconnect.
8. Do not operate unit with a damaged power cord or if the unit has been dropped or damaged. To avoid
risk of electrical shock, do not disassemble unit; contact McCulloch Consumer Service for examination
and repair. Incorrect reassembly can cause a risk of electrical shock when unit is used.
9. A loose t between wall outlet (receptacle) and plug may cause overheating and distortion of the plug.
Discontinue use of the product in this outlet. Contact a qualied electrician to replace loose or worn
outlets.
10. Do not leave unit unattended while plugged in. Unplug the appliance immediately after each use.
11. Do not use unit where aerosol-based products are being used, or where oxygen is
being administered.
12. Unit is only meant to be used with recommended accessories. Using other types of attachments may
cause damage to unit or injury.
13. If Lighted On/Off Switch does not illuminate when set to “ON” position while power cord is plugged
in, unit is not operating normally. Immediately disconnect cord from power supply, then refer to
troubleshooting guide of this manual for assistance.
14. Always turn unit off and unplug power cord before lling with water. Do not attempt to use unit without
properly lling.
15. When lling, only water should be used in unit – other cleaning agents could damage unit or cause
injury. Distilled or de-mineralized water is highly recommended, in order to minimize potential build-up
of mineral deposits. Do not overll with more than recommended amount of water.
16. To avoid burns from escaping steam when removing cap to rell unit:
• Always allow unit to cool for 5-10 minutes.
IMPORTANT SAFETY INSTRUCTIONS

ENGLISH |3
• Press and hold Steam Button to release all remaining steam pressure.
17. To reduce risk of contact with hot water emitting from Main Nozzle, check appliance before each use
by positioning it away from body and turning it on. Do not operate unit if Main Nozzle is blocked.
18. Burns can occur from touching hot metal parts, hot water, or steam. Do not touch Main Nozzle or
attempt to connect accessories while unit is in use. Do not touch bottom of Mop Head or attempt to
attach a Microber Pad by hand while unit is in use. Use caution when you turn unit upside-down –
there may be hot water.
19. Use caution when using unit on uneven surfaces, such as stairs. Do not place, set or store the
product near water, such as a bathtub or sink. Never immerse the product in liquids. Do not allow
cord to touch hot surfaces.
20. When steaming any surface for the rst time, it is recommended that you consult the manufacturer’s
guidelines for material being steamed. For items in question, test on an inconspicuous area
before proceeding.
21. Steaming unsealed hardwood or unglazed ceramic surfaces is not recommended, and may result in
warping or damage to the surface. Steam may remove the sheen from surfaces treated with wax.
22. When steam mopping, never leave unit resting in one spot on any surface for any period of time –
prolonged exposure to heat and moisture may damage oor surfaces.
23. Do not allow power cord to touch hot surfaces during use. Bundle cord loosely when storing.
24. Always allow unit to cool (at least 30 minutes for complete cooling) and empty before storing. Do not
store unit with a damp Microber Pad still attached.
25. This product is for use on 120 volt electrical outlets. The cord has a plug as shown at A in Figure
65.1. An adapter, as shown at C, can be used to connect three-blade grounding-type plugs to
two-slot receptacles (it is not included with your product). The green grounding lug extending from
the adapter must be connected to a permanent ground such as a properly grounded outlet box. An
adapter should not be used if a three-slot grounded receptacle is available. *NOTE: A TWO-PRONG
ADAPTOR IS NOT INCLUDED WITH THIS PRODUCT.
SAVE THESE INSTRUCTIONS
Questions or comments?
•www.mccullochsteam.com
• [email protected]
•1-800-711-6617
Grounding
Pin
Metal Screw
Cover of Grounded
Outlet Box
Grounding
Means
(A) (B)
(C)
Adapter
Figure 65.1

4 |ENGLISH
These features and accessories are included with your Deluxe Canister Steam System.
UNIT FEATURES
7' Steam Hose
Pressure Gauge
Integrated Handle
Reservoir Cap
Steam Handle Cradle
Cord Wrap
Illuminated On/Off Switch
Steam Nozzle
Steam Trigger Lock
Steam Trigger
Steam Adjustment Knob
1
2
3
4
5
6
7
8
9
10
11
Product Information
11
1
2
3
4
5
6
7
8
10
9

ENGLISH |5
• The 7' Steam Hose (1) safely channels the ow of steam from the Reservoir to the Steam
Nozzle.
• The Pressure Gauge (2) measures the pressure in the Reservoir.
• The Integrated Handle (3) is engineered to stay cool while providing maximum grip
and comfort.
• The Reservoir Cap (4) is designed to safely contain steam inside the Reservoir. The
Reservoir Cap must be unscrewed and removed in order to ll the Reservoir with water.
• The Steam Handle Cradle (5) functions as a convenient holder for the Steam Nozzle.
• The Cord Wrap (6) neatly stores the Power Cord.
• The Illuminated On/Off Switch (7) illuminates when the unit is powered On.
• The Steam Nozzle (8) emits a ow of hot, penetrating steam whenever the Steam Trigger is
pressed and held.
• The Steam Trigger Lock (9) locks Steam Trigger to "on" position for continuous steam.
• The Steam Trigger (10) is pressed and held in order to start the ow of steam from the Steam
Nozzle, then released when you wish to stop.
• The Steam Adjustment Knob (11) is conveniently located on the handle to adjust the intensity
of the steam at your ngertips.
Product Information
ORDERING ACCESSORIES & PARTS
Replacement accessories and parts for your Deluxe Canister Steam System (MC1385) may be
ordered through our Website:
www.mccullochsteam.com
You may also contact Consumer Service directly:
[email protected] or 1-800-711-6617

6 |ENGLISH
Product Information
5.5" Jet Nozzle
A1230-001
4" Triangle Brush
A1230-002
6" x 4.5" Large
Brush
A1230-003
3" Scraper
A1230-009
Storage Bag
A1375-010
1.5" Nylon Utility
Brushes
A1230-005
1.5" Brass Utility
Brushes
A1230-006
2.5" Round Scrub Pads
A1230-007
9" Squeegee
A1350-002
Microber Mop Pad
A1375-100
Scrubbing Mop Pad
A1375-101
13" x 8.5" Large Mop Head
A1375-003-A
Bristle Brush Attachment
A1375-004
16.5" Extension Wands
A1375-002
Angled Nozzle
A1375-001
2.5" Round Brushes
A1350-001
Accessory Net
A1375-005
Fill Cup
A275-015

ENGLISH |7
• The 13" x 8.5" Large Mop Head attaches to Extension Wands to clean garage oors, decks or
any other extra large surface areas.
• The Bristle Brush Attachment attaches to Large Mop Head to scrub away stubborn spots on
oors.
• The Microber Mop Pad attaches to the Mop Head, and are designed for removing scuffs and
stains from hard oors. The Pads are reusable and machine washable.
• The Scrubbing Mop Pad attaches to the Mop Head, and are designed for removing scuffs and
stains from hard oors. The Pads are reusable and machine washable.
• The 5.5" Jet Nozzle focuses the ow of steam from the Steam Nozzle, and serves as the base
to which the Utility Brushes and Scrub Pad connect.
• The 3" Scraper attaches to the Steam Nozzle to scrape off stuck on grime.
• The Fill Cup is used to ll Reservoir without spills.
• The Triangle Brush connects to the Steam Nozzle or Extension Wands, and is designed for
cleaning corners and other difcult angles.
• The Large Brush attaches to the Triangle Brush to cover large surfaces.
• The 9" Squeegee attaches to Steam Nozzle to remove bugs from windshield or windows or
soap scum from showers.
• The 16.5" Extension Wand connects to the Steam Nozzle. Used with mop attachment or for
high or hard-to-reach places.
• The Storage Bag stores all attachments neatly in one convenient bag.
• The Accessory Net stores brushes and other small accessories.
• The 2.5" Round Brush connects to the Jet Nozzle to scrub especially tough stains. The Round
Brush functions similar to the Nylon Utility Brush, only designed to more efciently scrub larger
surface areas.
• The Angled Nozzle is designed for reaching difcult angles and areas that the Jet Nozzle may
not completely reach.
• The 2.5" Round Scrub Pad connects to the Jet Nozzle and is designed to scrub tough dirt and
scuffs from surfaces.
• The 1.5" Nylon Utility Brush connects to the Jet Nozzle, providing extra scrubbing power for
removing exceptionally tough dirt and stains.
• The 1.5" Brass Utility Brush connects to the Jet Nozzle and is designed for removing tough
stuck-on grease and grime from durable surfaces such as ovens and grills.
Product Information

8 |ENGLISH
STEAM MOPPING ACCESSORIES
WARNING: Do not try to connect accessories while unit is emitting steam.
EXTENSION WANDS
1. Select one of the Extension Wands. Insert end (A) of Wand onto Steam Nozzle (B) with yellow
lock/release button slightly off center with hole. Fully insert and rotate wand slightly to allow
button to snap into hole.
2. Using the same instruction, attach remaining Extension Wand (C) to the rst Wand. Both
Extension Wands should now be connected to the Steam Nozzle.
MOP HEAD
1. Align Mop Head with open end of Extension Wand, so that hole in Mop Head aligns with
yellow lock/release button on Wand.
2. Press down on yellow lock/release button. While continuing to hold button down, slide Mop
Head onto Extension Wand (See gure 1-A). Fully insert and rotate wand slightly until button
snaps through hole (See gure 1-B).
NOTE: Do not use excessive force when mopping or using Extension Wands as this
may cause the Wands to break.
BRISTLE BRUSH ATTACHMENT
1. Align Mop Head with Bristle Brush Attachment, so that the
release tabs (A) on the Bristle Brush align with the sides of the
Mop Head (B).
2. Firmly press the Bristle Brush Attachment onto Mop Head until it
securely snaps into place.
Note: Do not use Bristle Brush Attachment with Microber
or Scrubbing Mop Pad.
Assembling Your Deluxe Canister
Steam System
B
CA
FIGURE 1
AB

ENGLISH |9
MICROFIBER PADS
1. Lay one Microber Pad on at surface, with two fastener strips facing upward.
2. Align Mop Head with Microber Pad. Make sure Mop Head is oriented with Pad as shown,
and centered as best as possible (See gure 2-A).
3. Press Mop Head rmly down onto Microber Pad. Fastener strips will adhere to Pad Grips on
underside of Mop Head. Pad should now be attached and ready for use (See gure 2-B).
CAUTION: Use care when handling a recently used Microber Pad, as it may still be hot.
NOTE: Microber Pads are machine washable. To avoid picking up lint, washing
separately from other fabrics is recommended. Only use liquid detergent. Avoid using
any fabric softeners or bleach. Air drying is recommended; machine drying on a low
heat or air dry setting is acceptable as well.
The Mop Head and Microber Pads are perfect for use on these hard oor surfaces:
IMPORTANT: Do not use on unsealed hardwood or unglazed ceramic surfaces.
Surfaces that are not properly sealed may be warped or damaged by exposure to heat
and moisture.
Care should also be taken when steaming sealed hardwood oors, as prolonged
exposure to steam in a single spot may cause damage and discoloration. To avoid this,
keep the Mop Head in constant motion on these surfaces.
Steam may remove the sheen from some oors that have been treated with wax.
Extremely rough textured oors may tear or damage Microber Pads.
Before steaming any ooring, it is recommended to consult the manufacturer’s
guidelines. For ooring in question, always test on a small inconspicuous area
before proceeding.
A B
FIGURE 2
•Sealed Laminate
•Linoleum
•Glazed Ceramic
•Granite
•Sealed Hardwood
•Stained Concrete
•Marble
•Vinyl
•Tile
Assembling Your Deluxe Canister
Steam System

10 |ENGLISH
STEAM CLEANING ACCESSORIES
WARNING: Do not connect accessories while unit is emitting steam.
JET NOZZLE / SCRAPER / SQUEEGEE / TRIANGLE BRUSH
1. Select one of the three accessories (Jet Nozzle shown as example) and push onto the Steam
Nozzle (A).
2. Rotate accessory until the yellow lock/release button snaps into the accessory hole (B).
NOTE: The Jet Nozzle, Scraper, Squeegee and Triangle Brush can be connected to the
end of an Extension Wand for reaching high or difcult spots. Connect the Extension
Wand (or Wands) as outlined on Page 8, then connect your desired accessory to the
Wand in the same way as you would normally connect to the Steam Nozzle.
UTILITY BRUSHES / ANGLED NOZZLE / SCRUB PAD
NOTE: Accessories connect to the Jet Nozzle, not the Steam Nozzle.
1. Firmly press accessory onto tip of Jet Nozzle. Press it on as far as possible to prevent steam
leakage (See gure 3).
2. To remove accessory, simply grip it rmly and pull it off Jet Nozzle.
Assembling Your Deluxe Canister
Steam System
FIGURE 3
Steam Nozzle
B
A

ENGLISH |11
LARGE BRUSH
NOTE: Large Brush connects to the Triangle Brush, not the
Jet Nozzle.
1. Place Large Brush over the Triangle Brush, and rmly press it on to
the Triangle Brush as far as possible (See gure 4).
2. To remove Large Brush, simply grip it rmly and pull it off of the
Triangle Brush.
INTEGRATED HANDLE
1. Align the poles with the holes located on unit (A).
2. Push down until the buttons snap into place (B).
3. To collapse the Integrated Handle, push both buttons at the same time to release (C). Then
push down.
Assembling Your Deluxe Canister
Steam System
FIGURE 4
B
AA
C

12 |ENGLISH
NOTE: Before cleaning electrical appliances, check and follow appliance manufacturer’s
cleaning guidelines. Never apply to electrical parts.
NOTE: Some delicate surfaces, such as painted wood or stainless steel may be scratched or
damaged by the bristle of the brushes, especially the Brass Utility Brush. Use careful judgment
when deciding what surface to clean with any of the brushes. If you are unsure if a surface will
be damaged, it is recommended that you test a small inconspicuous spot before proceeding.
Accessory Recommendations
WARNING: Do not use on unsealed hardwood or unglazed ceramic surfaces. For ooring
in question, always test on a small inconspicuous area before proceeding.
Jet Nozzle / Angled Nozzle Dirt, Grease, Grime, Cracks and Crevices, Golf
Clubs, Tread of Running Shoes
Triangle Brush Corners on Countertops, Bathtubs, Floors
Large Brush Floors, Grout
Scraper Baked on Food, Grime, Grease, Stove Tops, Ovens
Round Scrub Pad Countertops, Bathtubs, Sinks, Refrigerators, Ovens,
Slate
Nylon Utility Brush and Round Brush Ovens, Stove Tops, Faucet Fixtures, Microwaves,
Sports Equipment, Tile, Grout, Refrigerators, Toys,
Door Knobs, Showers, Bathtubs, Changing Tables
Brass Utility Brush BBQ Grills, Oven Wire Racks
Mop Stone, Slate, Glazed Ceramic Tile, Sealed Hardwood
Squeegee with Scrubbing Brush Bugs on Windshield or Windows, Soap Scum,
Grime, Shower Glass Doors, Mirrors, Glass
Bristle Brush Attachment Stone, Slate, Grout

ENGLISH |13
FILLING RESERVOIR
1. Place Deluxe Canister Steam System on a at, level surface.
2. Make sure illuminated On/Off Switch is turned to “Off” and grounded power cord is unplugged
from electrical outlet.
If unit has been in use, always use the following safety precautions before
removing the Reservoir cap to add water:
•Allow unit to cool for 20 minutes or until pressure gauge is at zero.
•Press and hold Steam Trigger to release ALL remaining steam.
WARNING: Failure to follow these precautions may result in burns from escaping steam
when the Reservoir Cap is removed.
3. Cautiously unscrew and remove Reservoir Cap.
4. Drain any water remaining inside Reservoir.
NOTE: The Reservoir should be emptied after each use – this will help minimize mineral
build-up and prevent over-lling.
5. Using the Fill Cup, ll the unit with 64 oz (1,892 ml) of water.
NOTE: In order to signicantly reduce mineral build-up and prolong the life of your
Deluxe Canister Steam System, use of distilled or de-mineralized water in the unit is
highly recommended. Refer to Page 16 for more information about mineral build-up.
WARNING: Caution should always be used when pouring water into the Reservoir. Do
not look directly down into ll hole when lling. Keep your free hand and any children
or pets at a safe distance.
6. Replace Reservoir Cap, ensuring that it is screwed on tightly to prevent hot steam from
escaping and causing injury.
!
Using Your Deluxe Canister Steam
System

14 |ENGLISH
Using Your Deluxe Canister Steam
System
GENERAL OPERATION
NOTE: Be sure that Reservoir has been lled and that desired accessories are connected
before following these steps.
1. For rst time use, remove protective plastic cover from electrical plug. Plug power cord into a
electrical outlet.
2. Switch Lighted On/Off Switch to “On” position.
3. The pressure gauge indicates the operating pressure of the steam cleaner. Once the needle
is in the green section, the unit is ready to begin steaming. NOTE: This may take up to 15
minutes.
During use and as steam is released, pressure will drop. This may cause the needle to move
down in the green section. This is a normal condition. As long as the needle is in the green
section, the product is operating normally. If the needle is continuously in the yellow or red
section, please contact Consumer Service at 1-800-711-6617.
4. Direct Nozzle (and any connected accessory) towards surface you desire to steam, and press
Steam Trigger.
CAUTION: Always be sure that Nozzle and any accessory are pointed in a safe direction
(away from yourself, other people, pets, and plants) before pressing Steam Trigger.
5. Keep Steam Trigger pressed for a continuous ow of steam. You may also hold the Steam
Trigger, then push the Steam Trigger Lock to lock it down. This will allow a continuous ow
of steam without need of holding the Steam Trigger down manually. Steam output can be
adjusted by simply turning the Steam Adjustment Knob.
6. Using a back-and-forth motion over the area you are steaming will further enhance the
cleaning process. Wipe steamed areas with a clean cloth to remove loosened dirt and grime.
Wiping the area while it is still wet is recommended, but use caution when wiping surfaces such as
metal that may still be hot.
7. Once steaming tasks are complete, turn the unit “Off” and unplug. Follow steps under Proper
Storage procedure on Page 16 of this manual.

ENGLISH |15
Using Your Deluxe Canister Steam
System
STEAM MOPPING
NOTE: Be sure that Reservoir has been lled and that all steam mopping accessories are
connected before following these steps.
It is recommended to sweep or vacuum hard oors before mopping.
1. Follow Steps 1-3 of General Operation section above.
Refer to Page 12 for a listing of hard oor surfaces that are recommended for cleaning
with the Deluxe Canister Steam System.
2. For best results, use a continuous back-and-forth motion over oor surface, pushing the Mop
Head away and pulling it back towards you. Work your way backwards over the oor, in order
to avoid walking over freshly mopped areas.
NOTE: To avoid warping or damage caused by heat and moisture, do not use on
unsealed hardwood or unglazed ceramic surfaces. Steam may remove the sheen from
some oors that have been treated with wax.
3. The Microber Pad will absorb dirt and moisture during mopping. However, when you
are nished you may nd some residual moisture has been left behind. In this case, it is
recommended to allow oor time to air-dry. A fan may be directed towards mopped area to
facilitate drying.

16 |ENGLISH
PROPER STORAGE
Preparing your Deluxe Canister Steam System for storage is quick and simple. When you have
nished your steaming tasks, follow the steps listed below.
1. Turn unit “Off” and unplug power cord.
2. Allow unit to completely cool (at least 30 minutes).
3. Press and hold Steam Trigger to release all remaining steam.
4. Remove all accessories from unit.
5. Carefully remove Reservoir Cap.
6. Drain any remaining water from Reservoir into a sink or tub – this will help to minimize mineral
build-up and prevent over-lling during your next use. Replace Reservoir Cap loosely.
7. Store accessories. Utility Brushes can be conveniently stored in the Accessory Net.
Remaining accessories can be stored in the Storage Bag.
8. Store Deluxe Canister Steam System in a cool, dry location.
MINERAL BUILD-UP
A common maintenance need for steam appliances is the removal of build-up caused by
high mineral content in many municipal water supplies. This mineral build-up may limit the
effectiveness and reduce the life of your Deluxe Canister Steam System.
The best way to minimize mineral build-up is to use distilled or de-mineralized water when using
your Deluxe Canister Steam System. If you are unable to use distilled water, it is recommended
that the following procedure be followed monthly to remove any mineral build-up:
1. Turn unit “Off” and unplug power cord.
2. Allow unit to completely cool (at least 30 minutes).
3. Press and hold Steam Trigger to release all remaining steam.
4. Remove all accessories from unit.
5. Carefully remove Reservoir Cap.
6. Drain water from Reservoir into a sink or tub.
7. Using Measuring Cup, measure 8 oz. (237 ml.) of vinegar.
8. Slowly pour vinegar into Reservoir.
9. Allow to stand for 40 minutes.
10. Drain vinegar from Reservoir.
11. Rinse Reservoir with fresh water, drain and repeat until vinegar odor dissipates.
12. Replace Reservoir Cap.
Storage & Care

ENGLISH |17
Troubleshooting
Unit fails to heat up.
Steam output is weak or
intermittent.
Excessive amount of water in
steam.
NOTE: Unit produces wet steam
– it is normal for steam to
contain some amount of water.
Unit is not plugged in.
Mineral build-up in unit.
Mineral build-up in unit.
Household circuit breaker / ground
fault interrupter has tripped or
blown a fuse.
Unit is damaged or otherwise in
need of repair.
Unit is damaged or otherwise in
need of repair.
Water level in Reservoir is running
low.
Reservoir is empty.
Water condensation in Steam
Hose.
Reservoir has been
overlled.
Plug power cord into electrical outlet.
Refer to Mineral Build-up section
on Page 16 for cleaning procedure.
Refer to Mineral Build-up section
on Page 16 for cleaning procedure.
Reset circuit breaker / ground
fault interrupter, or replace fuse.
If you need assistance, contact a
licensed electrician.
Immediately cease usage and
unplug. Contact Consumer
Service for further assistance
(see Page 18 for details).
Immediately cease usage and
unplug. Contact Consumer
Service for further assistance
(see Page 16 for details).
Refer to Filling Reservoir proce-
dure on Page 13.
Refer to Filling Reservoir proce-
dure on Page 13.
Point nozzle towards sink, tub or
ground and shake while pressing
Steam Trigger. Continue until
excess water is released.
Filling the Reservoir with more
than 64 oz. (1,892 ml.) of water
interferes with steam production,
resulting in water condensation
in steam.
Always ll unit with correct amount
of water. (see Page 13 for details)
PROBLEM POSSIBLE CAUSE SOLUTION
Accessories do not stay rmly
connected to Steam Nozzle.
Accessories not properly installed. Check to make sure that acces-
sories are properly connected, per
procedures on Pages 8-11.
Floor surfaces appear cloudy or
streaky after steaming.
Microber Pad is dirty.
Hard water residue on oor.
Replace Microber Pad with a
clean one.
Switch to distilled or
de-mineralized water.

18 |ENGLISH
Product Support
CONSUMER SERVICE
For problems with your Deluxe Canister Steam System, please refer to the troubleshooting
guide located on Page 17 of this manual. Additional inquiries should be directed to our consumer
support services through our Web site, mccullochsteam.com.
If you do not have internet access, you may also contact our Consumer Service Department by
telephone, at 1-800-711-6617.
NOTE: In order for our Consumer Service representatives to help you as quickly and
efciently as possible, please have the following information ready before calling:
• Purchase information (where and when you purchased this product)
• Copy of purchase receipt / proof of purchase
• Product serial number (located on electrical specication label on bottom of unit)

ENGLISH |19
Warranty Information
McCulloch, a division of Vornado Air, LLC. McCulloch warrants to the original consumer or pur-
chaser this McCulloch (“Product”) is free from defects in material or workmanship for a period
of two (2) years from the date of purchase. If any such defect is discovered within the warranty
period, Vornado, at its discretion, will repair or replace the Product at no cost.
For warranty service: Call 1-800-711-6617 or email [email protected] to
obtain a Return Authorization (“RA”). Please have or include your Product’s model number and
serial number, as well as your name, address, city, state, Zip code, email, and phone number
when contacting Vornado for warranty service. To le a contactless warranty claim, visit www.
mccullochsteam.com/contact
After receiving the RA, ship your Product to: Vornado Air LLC Attn: Warranty & Repair 415
East 13th Street, Andover, KS 67002. For your convenience, please have your model number
and serial number when contacting Vornado with service inquiries. To ensure proper handling,
packages must be clearly marked with the RA number. Packages not clearly marked with the RA
number may be refused at the receiving dock. Please allow 2–3 weeks for warranty service and
return of your Product after the Product is received.
This warranty does not apply to defects resulting from abuse of the Product, modication,
alteration, mishandling, improper maintenance, commercial use or repair or service of the Prod-
uct by anyone other than Vornado; damages which occur in shipment or are attributed to acts
of God. Improper product use, which includes using an external device that alters or converts
the voltage or frequency of electricity, or shipping a Vornado product to a country not intended
for use will void all warranties. Any unauthorized product modication, repair by unauthorized
repair center or use of non-approved replacement parts is not recommended and any conse-
quences will not be covered by support services or product warranties.
The product warranty will be honored only on models that are being used in the country intend-
ed. REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. VORNADO SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. Some states
do not allow the exclusion or limitation of incidental or consequential damages, or allow limita-
tions on how long an implied warranty lasts, so the above limitations or exclusions may not ap-
ply to you. This warranty gives you specic legal rights, and you may have other rights that vary
from state to state. The manufacturer assumes no responsibility for damage or injury caused
by failure to follow these instructions, improper product use or unauthorized product modica-
tions. Any such actions will invalidate the product warranty.
All company names and product names are trademarks of their respective owners. ©All rights
reserved. All technical information, data and instructions for the installation, connection and
operation contained in these instructions for use correspond to the latest available informa-
tion at time of printing. The contents of this manual may differ slightly from the actual product.
Observe any additional supplements.
© 2023 Vornado Air, LLC. Andover, KS 67002, U.S. Specications subject to change without
notice. McCulloch® is a trademark owned by Vornado Air, LLC. Manufactured in China.

T1385-005, R-V11
Manufactured by Vornado Air LLC under license from Husqvarna AB (publ).
For more information on other McCulloch products,
visit www.mccullochsteam.com
For questions, or comments or warranty information,
call 1-800-711-6617 or visit www.mccullochsteam.com
review this product online
www.mccullochsteam.com/reviews
