MDC XT14E 2021 User manual

Copyright © Market Direct Group Pty Ltd 2021 All Rights Reserved
Phone: [phone]
OWNER’S MANUAL
EDITION: 2021 - Version 1
XT14E
HYBRID CARAVAN
www.marketdirect.com.au

Contentswww.marketdirect.com.au Ph: 1300 494 494
Contents
My XT14E Hybrid Caravan.............................................. 1
Section 1. Introduction.......................................................2
Welcome to MDC.................................................................2
Terminology & Abbreviations..........................................3
Specications .........................................................................4
MDC Contact Details..........................................................5
Safety Information ...............................................................6
Modications to The Product..........................................6
Gas Systems............................................................................6
Chassis ......................................................................................6
Jacking Your Caravan..........................................................7
Electrical Safety ....................................................................8
Vehicle Electrical Requirements.....................................8
Brake Controller ...................................................................9
Correct Vehicle Wiring for MDC Caravans................9
Trailer Lights ....................................................................... 10
Charging Caravan While Driving ................................ 10
Gas & Appliance Safety ................................................... 11
Gas Certication................................................................ 11
General Safety .................................................................... 11
Gas Cylinder Safety .......................................................... 11
Gas Appliance Safety ....................................................... 12
Removing the Hot Water System Flue Cover ........ 12
Ventilation and Flues........................................................ 13
Isolating Appliances.......................................................... 13
Diesel Heater Safety (Where tted as option)....... 14
Important information before operating
the diesel heater................................................................. 14
Using the Caravan ............................................................. 15
Load Distribution Guide.................................................. 15
Ball Weight........................................................................... 16
Effects of Weight Distribution ..................................... 16
Tyre Pressures .................................................................... 16
Pre-Trip Inspection............................................................ 17
Tyres ....................................................................................... 17
Wheel Nuts.......................................................................... 17
Hitch and Chains................................................................ 17
Fire Extinguisher................................................................ 17
Brakes & Breakaway System......................................... 17
Lights ...................................................................................... 17
Setting Up the Caravan................................................... 18
Choosing a Spot to Set Up.............................................. 18
Levelling Your Caravan.................................................... 18
Using Wheel Chocks and Ramps................................. 18
Operating the Jockey Wheel ........................................ 18
Stabiliser Legs ..................................................................... 18
Electric Awning................................................................... 19
Mains Power........................................................................ 19
RCD Safety Switch ............................................................ 19
Kitchen................................................................................... 20
Electrical Panel................................................................... 21
Control Panel ...................................................................... 21
Towing the Caravan.......................................................... 21
Hitch ....................................................................................... 21
Connecting the Hitch....................................................... 22
Coupling ................................................................................ 24
Uncoupling ........................................................................... 26
Connecting the Breakaway ........................................... 27
Connecting the Safety Chains ...................................... 27
Connecting the Electrics................................................. 27
Preparing for Bad Weather ........................................... 28
Packing Down Your Caravan......................................... 28
Storage & Care.................................................................... 29
Long Term Storage ............................................................ 29
Interior................................................................................... 29
Exterior.................................................................................. 29
Securing Your Camper..................................................... 29
Care and Maintenance of the Caravan......................30
Protection of Finishes...................................................... 30
Corrosion Protection ....................................................... 31
Roof Maintenance ............................................................. 31
Sealants ................................................................................. 31
Solar Panels.......................................................................... 31
Caravan Body Maintenance .......................................... 31
Locks and Latches ............................................................. 31
Rubber Seals........................................................................ 31
Sealants ................................................................................. 31
Winegard Sensar III Antenna........................................ 32
Solar Panels..........................................................................34
Sealants ................................................................................. 34
Canopy Lifting Mechanism ............................................ 34
Roof Skirt Elastic Cord.....................................................34
Electrical Systems.............................................................. 35
Chargers & Inverters........................................................ 35

Contentswww.marketdirect.com.au Ph: 1300 494 494
Battery Care........................................................................ 35
12 Volt Main Circuit Diagram ....................................... 36
12 Volt Switch Circuit ...................................................... 37
Truma Rapid HotWater System .................................38
Filling the Truma UltraRapid with Water.................. 39
Pressure and Temperature Relief Valve....................40
Draining the Water Heater............................................ 40
Switching On Gas Operation......................................... 41
Removing The Cowl Cover............................................. 41
Select Water Heater Mode............................................ 41
When using the vehicle switches................................. 41
Switching Off Gas Operation........................................ 41
Maintenance........................................................................ 42
Decalcication.................................................................... 42
Fuses....................................................................................... 42
Circuit Breaker ................................................................... 42
Water Heater Trouble Shooting...................................43
Gas Operation.....................................................................43
Water Supply.......................................................................43
Water Pumps.......................................................................44
Switching Supply Tanks ...................................................44
Connecting the Gas ..........................................................44
Diesel Heater Safety ........................................................ 45
Product Information.........................................................46
Schematic.............................................................................. 47
Parts List ............................................................................... 48
Heater Control.................................................................... 49
Important tips about operation ................................... 49
Operating instructions .................................................... 49
Switching on......................................................................... 49
Heating process.................................................................. 49
Temperature control ....................................................... 50
Control in the heating mode.......................................... 50
Ventilating mode................................................................ 50
Switching off........................................................................ 50
Trouble shooting and fault guide ................................. 50
MkII Diesel Heater............................................................ 52
Heater Control Switch..................................................... 52
Power on............................................................................... 52
Temperature Control ....................................................... 52
Ventilation mode................................................................ 52
Shutdown.............................................................................. 52
Trouble Shooting................................................................ 53
Protecting from Mould.................................................... 53
Useful Accessories ............................................................ 54
Levelling Blocks .................................................................. 54
Wheel Chocks..................................................................... 54
Covers .................................................................................... 54
Stone Protection ................................................................ 54
Trouble Shooting................................................................ 55
Electrical ............................................................................... 55
Water...................................................................................... 56
Gas........................................................................................... 56
Brakes .................................................................................... 57
Handy Tips ........................................................................... 58
Driving Off Road................................................................ 58
Trip Planning........................................................................ 59
Warranty Statement ........................................................60
Travel Record ......................................................................64
Spare Part Numbers......................................................... 66
Hub Assembly..................................................................... 67
Trailing Arm Bushes.......................................................... 68
Service Record.................................................................... 69
Supplier Details .................................................................. 91
Guide to Video Library .................................................... 92
Handover Video ................................................................. 92
Setup Video Tutorial......................................................... 92
Pack Up Video Tutorial.................................................... 92

www.marketdirect.com.au Ph: 1300 494 494
Copyright © Market Direct Group Pty Ltd 2021 All Rights Reserved
All les and information contained in this Owner’s Manual are copyright by Market Direct Group Pty Ltd, and may not be
duplicated, copied, modied, or adapted, in any way without our written permission. Our Owner’s Manual may contain our
service marks or trademarks as well as those of our afliates or other companies, in the form of words, graphics, and logos.
Your use of our Owner’s Manual does not constitute any right or license for you to use our service marks or trademarks,
without the prior written permission of Market Direct Group Pty Ltd.
Our Content, as found within our Owner’s Manual, is protected under Australian and foreign copyrights. The copying,
redistribution, use or publication by you of any such Content, is strictly prohibited. Your use of our Owner’s Manual does not
grant you any ownership rights to our Content.
DISCLAIMER: This manual is provided in good faith and Market Direct Group Pty Ltd.
may amend or update this owner manual from time to time.
Use of Product
The intent and purpose of this manual is to assist owners in the correct use and operation of the product and outline the
servicing schedule to be followed, ensuring the correct maintenance of the product.
Servicing
Servicing information contained in this owner manual is provided for those who have appropriate technical skills and relevant
to the subject matter the publication deals with in regard to maintenance and repairs. The servicing content of this manual
assumes a satisfactory technical knowledge and mechanical skills and experience. It is not suitable for people who are not
trained or qualied in the subject matter it deals with. If you do not have the appropriate skills and experience, or if you do not
have access to appropriate tools and equipment, you may injure yourself or others around you and/or you may cause damage
to the Caravan you are working on, including making it unsafe. Users of this owner manual must:
• Read all content thoroughly. It is especially important to have a good understanding of all the contents shown in the
INTRODUCTION and SAFETY Sections of this publication.
• Use only the correct tools and equipment for all repairs and servicing.
• If part replacement is necessary, replace the part with the same part number or equivalent part.
DO NOT replace it with a part of inferior quality.
• Observe all ‘Cautions’ and ‘Notices’ to reduce the risk of personal injury during service or repair, or improper service or
repair that may damage the Caravan or render it unsafe.
• Understand that the ‘Cautions’ and ‘Notices’ in this publication are not exhaustive because it is impossible to warn of
all possible hazardous consequences that might result from failure to follow the instructions in this publication.
You must carry out your own risk assessments as you work.
Market Direct Group Pty Ltd. does not accept any and all liability which may arise because a user of this publication fails
to follow directions in the publication or safe work methods associated with use and maintenance of the product.
Those without the required skills, knowledge, tools, and experience to work on and maintain this product should seek the
services of a suitably qualied person or business. This publication is based on the latest product information at the time of
release. However, specications and procedures are subject to change without notice.

www.marketdirect.com.au Ph: 1300 494 494 1
My XT14E Hybrid Caravan
DISCLAIMER: By receiving this handbook, you confirm there you have read and agree to all
the terms and conditions and understood the use and maintenance care of MDC®
NAME:
MODEL:
VIN:
BUILD DATE:
TARE:
ATM:
TYRE SIZE:
DEALER:
ADDRESS 1:
ADDRESS 2:

www.marketdirect.com.au Ph: 1300 494 494 2
Coupling Mass
Weighbridge Reading = Tare Mass
Section 1. Introduction
WELCOME TO MDC
Off road caravanning is a rewarding way to travel and see our great country. Owning an MDC Caravan will
afford you the opportunity to travel to remote places and stay in comfort. It is the intention of MDC for you to
have the best possible owner experience and enjoy the great outdoors.
Terminology & Abbreviations
Coupling Mass
Weighbridge Reading must not exceed ATM Rating
Load
Load
Weighbridge Reading must not exceed GTM Rating
ATM (Aggregate Trailer Mass) Rating: The total permissible mass of the Trailer. This includes the coupling mass
and whatever you add as payload (e.g. water, gas, luggage)
up to the specified rating. The ATM Rating
must not be exceeded.
GTM (Gross Trailer Mass) Rating: The total permissible mass that can be supported by the wheels/ tyres of the
Trailer. This includes whatever you add as payload (e.g. water, gas, equipment and luggage), but does not include
the mass supported by the tow vehicle.
The GTM Rating must not be exceeded.
Tare Weight: The total weight of the trailer (load on tyres plus coupling load) with all options and fittings as
supplied by the manufacturer, with empty water tanks, excluding fluids not essential for operation on public
roads, and without luggage or personal effects.
Caravans for illustration purposes only.

www.marketdirect.com.au Ph: 1300 494 494 3
Terminology & Abbreviations
Ball Weight: The downward load exerted on the tow point of the vehicle by the trailer.
GCM: (Gross Combination Mass): This is the total allowable combined mass of tow vehicle and trailer as
determined by the tow vehicle manufacturer.
Camber: Camber angle is the measure in degrees of the difference between the wheel’s vertical alignment
perpendicular to the surface. If a wheel is perfectly perpendicular to the surface, its camber would be 0
degrees. Camber is described as negative when the top of the tyre begins to tilt inward towards the chassis rail.
Toe In/out: Negative toe, or toe out, is the front of the wheel pointing away from the centreline of the vehicle.
Positive toe, or toe in, is the front of the wheel pointing towards the centreline of the vehicle.
Toe can be measured in linear units, at the front or rear of the tyre, or as an angular deflection. In the case of
MDC products, the “toe in” is measured in millimetres at the front of the tyre from the chassis rail.
Tow vehicle and Trailer Compatibility
Your tow vehicle manufacturer has applied a maximum towing capacity to the vehicle which is the Aggregate
Trailer Mass (ATM) and a maximum Gross Combination Mass (GCM). These specifications MUST NOT be
exceeded. It is your responsibility to know, understand and follow these specifications. Vehicle manufacturers
may also specify or recommend “Weight Distribution Bars” when towing under certain conditions. You MUST
ensure this is compatible with the vehicle and trailer combination.
DANGER – Exceeding manufacturer weight and combination limits can
result in loss of control leading to death or serious injury. Your tow vehicle
and hitch must be rated for the Gross Vehicle Weight of the trailer.
DANGER

www.marketdirect.com.au Ph: 1300 494 494 4
Specifications
SIZE (CLOSED WITH AC) 2200mmW x 6376mmL x 2720mmH
SIZE (OPENED WITH AC) 4200mmW x 6376mmL x 3120mmH
STYLE 14’ hybrid offroad caravan
TOWBALL WEIGHT Approx. 117kg
TARE WEIGHT Approx. 2175kg
ATM 3000kg
BERTH 2
CHASSIS 150mm x 50mm x 3mm
DRAWBAR 120mm x 50mm x 4mm
BODY CONSTRUCTION Aluminium composite panel fully welded frame + chassis
STONE GUARD Included with stone tamer mudaps
SUSPENSION Independent trailing arm with 4x shock absorbers and coil springs
WHEELS & TYRES 265/75 R16 Goodride radial mud terrain
COUPLING DO35
BRAKES 4WD 12” electric with hand brake
GAS CYLINDERS 2 x 9kg gas cylinder holders
JERRY CAN HOLDER 2 x 20L jerry can holders
KITCHEN CONSTRUCT External 304 grade stainless steel with 3 burner gas cooktop, stainless steel sink with washboard,
hot and cold water to kitchen
WATER TANK 2 x 80L fresh water & 80L grey water
WATER DELIVERY 12V electric pump
HOT WATER SYSTEM Truma “Boiler” 14L (gas)
SHOWER (ENSUITE) Hot/cold external includes van side mounted shower tent
AWNING Electric
BATTERY 2 x 100amp 12V deep cycle batteries
INVERTER Projecta 12v 1000w modied Sine inverter
OUTLETS Multiple 12V, 240V x 2
JOCKEY WHEEL 10” swing up and lockable
STABILISER LEGS 4 x heavy duty lockable and adjustable drop down
LIGHT CONNECTION PLUG 12pin at as standard. 7 pin round or 7 pin at connection available
(NSW BY LAW MUST HAVE A 12 PIN FLAT INSTALLED)
MATTRESS Extra-large 200mm custom innerspring
SOUND Kenwood head unit with internal & external speakers
SOLAR 2 x 150W solar included
*ALL WEIGHTS DO NOT INCLUDE GAS BOTTLES, JERRY CANS, ANNEX WALLS & ROOF.
