MegaLite N-E PIXSTRIP H216 User manual

Table of Contents
Safety Information 2
What’s Included 2
Specifications 3
Main Power Connection 4
DMX-512 Connection 4
Size and Weight 5
Main Control Menu 6
Parts List 7
DMX Profile 8
Rigging the Fixture 11
Cleaning & Maintenance 11
Warranty 12
Customer Support 13
USER MANUAL

2
Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 2 foot distance from any type of flame.
2. For indoor use only do not expose unit to rain or moisture.
3. Replace fuse only with the specified type and rating.
4. Do not install the unit to close to a heat source.
5. Make sure cable are properly secured
6. Maximum surface operating temperature 120ºF.
Protection Against Electrical Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 4.
3. This unit must be earthed. (electronically grounded)
4. This fixture must not be left on for long periods of time.
5. Prolonged exposure to UV light will discolor and damage the diffusion filter.
Protection Against Mechanical Hazards
1. Use secondary safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
Check that the unit has not been damaged during transport
Protection Against Fire
Protection Against Electrical Fire
Protection Against Mechanical Hazards
What is Included
1pc N-E Pixstrip H216 Fixture
1pc Power Conn Type to Nema 5-15 Cable
1pc 10M Eye Bolt for Safety Connection
1pc Diffusion Filter with Mounting Thumb Screws
1pc User Manual

Specifications
3
Part Numbers
Fixture Road Case
4055-N-E Pixstrip H216 CAS-4055-4 Unit Road Case
Specifications
LED: Qty 18 12Watt LED
LED Color: Red, Green, Blue, White, Amber, UV
Lumen Output: 5490lm All Emitters
DMX Connectors: Panel Mounted 3 & 5-pin XLR connectors in/out
Power Connections: Panel Mounted Seetronic Power in/out connection (Nema 5-15 Male to Seetronic power Female cable included)
Lens Angle: 27°
Diffusion Angle: 105°
Power Input: 90 - 264V 50/60 Hz
Power Consumption:
Watts: 126W
Amps: 1.5A @ 110V
Pixel Control: 18 Pixel Control
Thermal: Maximum ambient temperature 98°f
Maximum surface temperature 120°f
Thermal Shut Off Protection
Display:LED Display
Protocol: DMX 512
RDM: No
DMX Channels: 3 Mode of Operation
Mode 6 CH: Red, Green, Blue, White, Amber
Mode 17 CH: Dimmer, Strobe, R,G,B,W,A,UV, Macro, Macro Speed, Back-ground Red, Back-ground Green, Back
ground Blue, Back-ground White, Back-ground Amber, Back Ground UV, Macro Direction
Mode 108 CH: 18 X R,G,B,W,A,UV
Operating Mode: Stand alone 255 step dimmer setting via display
Auto preprogram via display
Control & Programming

4
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 240V automatically
3. This unit must be earthed. (electronically grounded)
4. Power Link 10 units max at 110V and 20 units at 220V
The occupation of the connection-cable is as follows:
DMX-512 Connection
This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 264V from 50Hz to 60Hz
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120 Ohm re-
sistor between the (-) and the (+) signal into a 5 pin XLR plug and plug it in to the last fixture on the
signal run. Pre-manufactured terminator plugs are available for purchase from your Mega-Lite
dealer (P-DMXT).
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
220V
L
L
The fixture is equipped with 3 & 5 pin XLR cable mounted sockets for DMX input and output. The sockets are wired in
parallel. Only use a shielded twisted pair cable designed for RS-485 and 3 or 5 pin XLR plugs and connectors in order to
connect the controller with the fixture or the fixture with another.
DMX—Input DMX—Output
1. Shield
2. Signal (-)
3. Signal (+)
4. N/A
5. N/A
2
3
15
3
4
2
11
2
3
1
2
3
4
5

Size and Weight
5
Size 39.76" X 3.94" X 5.28"
Weight 10lb
Packaged 41" X 5.5" X 7" 11.5lb
(Adjustable)

Main Control Menu
The control board on the fixture is your interface to access and control
all the functions on the unit. Its digital display gives you a code view of
the options and functions. The following will explain each function and
its options.
6
DMX Address
Press Enter to select the DMX start channel use the up/down keys, display will be flashing once you have selected
the desired start channel Press Enter to confirm display will stop flashing.
DMX Ad- Ch Mode
1-512
Auto
Au 0-29
Sp 1-9
DMX Mode
This function allows you to select the mode in which
you want to control the fixture. Press Enter use the
up/down keys to select desired DMX mode settings.
Press Enter to confirm the settings.
17 CH Dimmer, Strobe, R,G,B,W,A,UV, Macro, Macro
Speed, Back Ground Red, Back Ground Green,
Back Ground Blue, Back Ground White, Back
Ground Amber, Back Ground UV, Macro Direction
6 CH Red, Green, Blue, White, Amber, UV
6-Ch
17-Ch
108-Ch
Control Mode
Master
DMX
Sound Preset Color
Mode
Master or DMX Mode.
Menu Up Down Enter
CONTROL BOARD
108
CH
Red, Green, Blue, White, Amber, UV X18
So 0-29
Se 0-99 1-64 Red 0-255
Green 0-255
Blue 0-255
White 0-255
Amber 0-255
UV 0-255
Manual Color Display Invert Temp Software Version
Sound Mode
This function allows the fixture to snap from color to color via it’s internal microphone. Press Enter to confirm the set-
tings.

7
Auto Mode
Select from 0-29 and speed 0-9 . Press Enter to confirm the settings.
Color
Select from 64 preset colors . Press Enter to confirm the settings.
Manual
Manually adjust variable light output from the 6 color options . Press Enter to confirm the settings.
Display
Invert Display. Press Enter to confirm the settings.
Temperature
Fixture Temperature Unit will reduce brightness once to keep temperature under 140F. Press Enter to confirm the set-
tings.
Ver
Software version. Press Enter to confirm the settings.
Parts List
Part # Description
4055-PCB-XLR-IN 3&5 PIN XLR INPUT PCB
4055-PCB-XLR-OUT 3&5 PIN XLR OUTPUT PCB
4055-PCB-MAI DISPLAY & MAIN PCB
4055-POW POWER SUPPLY
4055-LEN LENS
4055-LED 6 COLOR LED
4055-LED-MOD ENTIRE PCB WITH LED
4055-PCB-MOD DRIVER PCB WITHOUT LED
4055-HOU-MOU SLIDING MOUNTS
4055-HOU-COV REAR HOUSING
4055-DIF DIFFUSION LENS
4055-DIF-SCR DIFFUSION SCREWS

8
DMX Profile
6 Ch Mode
DMX Channel Function Description Value
1LED Color Red LED Intensity 000-255
2LED Color Green LED Intensity 000-255
3LED Color Blue LED Intensity 000-255
4LED Color White LED Intensity 000-255
5LED Color Amber LED Intensity 000-255
6LED Color UV LED Intensity 000-255
17 Ch Mode
DMX Channel Function Description Value
1Dimmer Dimmer (off to full) 000-255
2Strobe
No Function 000-000
Strobe （slow to fast）001-63
Pulse Strobe (slow to fast) 64-127
Random Strobe Entire Bar (slow to fast) 128-190
Random Strobe Each LED (slow to fast）191-255
3LED Color Red LED Intensity 000-255
4LED Color Green LED Intensity 000-255
5LED Color Blue LED Intensity 000-255
6LED Color White LED Intensity 000-255
7LED Color Amber LED Intensity 000-255
8LED Color UV LED Intensity 000-255
9Macro
No Function 000-007
Color chase 1 to 29 008-255
10 Macro Speed 000- 255 Color chase speed 000-255
11 Background Red Background Red 000-255 0%-100% 000-255
12 Background Greed Background Greed 000-255 0%-100% 000-255
13 Background Blue Background Blue 000-255 0%-100% 000-255
14 Background White Background White 000-255 0%-100% 000-255
15 Background Amber Background Amber 000-255 0%-100% 000-255
16 Background UV Background UV 000-255 0%-100% 000-255
17 Macro Direction L-R000-128
R-L 129-255

9
108 Ch Mode
DMX Channel Function Description Value
1LED Color 1 Red LED Intensity 000-255
2LED Color 1 Green LED Intensity 000-255
3LED Color 1 Blue LED Intensity 000-255
4LED Color 1 White LED Intensity 000-255
5LED Color 1 Amber LED Intensity 000-255
6LED Color 1 UV LED Intensity 000-255
7LED Color 2 Red LED Intensity 000-255
8LED Color 2 Green LED Intensity 000-255
9LED Color 2 Blue LED Intensity 000-255
10 LED Color 2 White LED Intensity 000-255
11 LED Color 2 Amber LED Intensity 000-255
12 LED Color 2 UV LED Intensity 000-255
13 LED Color 3 Red LED Intensity 000-255
14 LED Color 3 Green LED Intensity 000-255
15 LED Color 3 Blue LED Intensity 000-255
16 LED Color 3 White LED Intensity 000-255
17 LED Color 3 Amber LED Intensity 000-255
18 LED Color 3 UV LED Intensity 000-255
19 LED Color 4 Red LED Intensity 000-255
20 LED Color 4 Green LED Intensity 000-255
21 LED Color 4 Blue LED Intensity 000-255
22 LED Color 4 White LED Intensity 000-255
23 LED Color 4 Amber LED Intensity 000-255
24 LED Color 4 UV LED Intensity 000-255
25 LED Color 5 Red LED Intensity 000-255
26 LED Color 5 Green LED Intensity 000-255
27 LED Color 5 Blue LED Intensity 000-255
28 LED Color 5 White LED Intensity 000-255
29 LED Color 5 Amber LED Intensity 000-255
30 LED Color 5 UV LED Intensity 000-255
31 LED Color 6 Red LED Intensity 000-255
32 LED Color 6 Green LED Intensity 000-255
33 LED Color 6 Blue LED Intensity 000-255
34 LED Color 6 White LED Intensity 000-255
35 LED Color 6 Amber LED Intensity 000-255
36 LED Color 6 UV LED Intensity 000-255
37 LED Color 7 Red LED Intensity 000-255
38 LED Color 7 Green LED Intensity 000-255
39 LED Color 7 Blue LED Intensity 000-255
40 LED Color 7 White LED Intensity 000-255
41 LED Color 7 Amber LED Intensity 000-255
42 LED Color 7 UV LED Intensity 000-255
43 LED Color 8 Red LED Intensity 000-255
44 LED Color 8 Green LED Intensity 000-255
45 LED Color 8 Blue LED Intensity 000-255
46 LED Color 8 White LED Intensity 000-255
47 LED Color 8 Amber LED Intensity 000-255
48 LED Color 8 UV LED Intensity 000-255
49 LED Color 9 Red LED Intensity 000-255
50 LED Color 9 Green LED Intensity 000-255
51 LED Color 9 Blue LED Intensity 000-255

10
52 LED Color 9 White LED Intensity 000-255
53 LED Color 9 Amber LED Intensity 000-255
54 LED Color 9 UV LED Intensity 000-255
55 LED Color 10 Red LED Intensity 000-255
56 LED Color 10 Green LED Intensity 000-255
57 LED Color 10 Blue LED Intensity 000-255
58 LED Color 10 White LED Intensity 000-255
59 LED Color 10 Amber LED Intensity 000-255
60 LED Color 10 UV LED Intensity 000-255
61 LED Color 11 Red LED Intensity 000-255
62 LED Color 11 Green LED Intensity 000-255
63 LED Color 11 Blue LED Intensity 000-255
64 LED Color 11 White LED Intensity 000-255
65 LED Color 11 Amber LED Intensity 000-255
66 LED Color 11 UV LED Intensity 000-255
67 LED Color 12 Red LED Intensity 000-255
68 LED Color 12 Green LED Intensity 000-255
69 LED Color 12 Blue LED Intensity 000-255
70 LED Color 12 White LED Intensity 000-255
71 LED Color 12 Amber LED Intensity 000-255
72 LED Color 12 UV LED Intensity 000-255
73 LED Color 13 Red LED Intensity 000-255
74 LED Color 13 Green LED Intensity 000-255
75 LED Color 13 Blue LED Intensity 000-255
76 LED Color 13 White LED Intensity 000-255
77 LED Color 13 Amber LED Intensity 000-255
78 LED Color 13 UV LED Intensity 000-255
79 LED Color 14 Red LED Intensity 000-255
80 LED Color 14 Green LED Intensity 000-255
81 LED Color 14 Blue LED Intensity 000-255
82 LED Color 14 White LED Intensity 000-255
83 LED Color 14 Amber LED Intensity 000-255
84 LED Color 14 UV LED Intensity 000-255
85 LED Color 15 Red LED Intensity 000-255
86 LED Color 15 Green LED Intensity 000-255
87 LED Color 15 Blue LED Intensity 000-255
88 LED Color 15 White LED Intensity 000-255
89 LED Color 15 Amber LED Intensity 000-255
90 LED Color 15 UV LED Intensity 000-255
91 LED Color 16 Red LED Intensity 000-255
92 LED Color 16 Green LED Intensity 000-255
93 LED Color 16 Blue LED Intensity 000-255
94 LED Color 16 White LED Intensity 000-255
95 LED Color 16 Amber LED Intensity 000-255
96 LED Color 16 UV LED Intensity 000-255
97 LED Color 17 Red LED Intensity 000-255
98 LED Color 17 Green LED Intensity 000-255
99 LED Color 17 Blue LED Intensity 000-255
100 LED Color 17 White LED Intensity 000-255
101 LED Color 17 Amber LED Intensity 000-255
102 LED Color 17 UV LED Intensity 000-255
103 LED Color 18 Red LED Intensity 000-255
104 LED Color 18 Green LED Intensity 000-255
105 LED Color 18 Blue LED Intensity 000-255
106 LED Color 18 White LED Intensity 000-255
107 LED Color 18 Amber LED Intensity 000-255
108 LED Color 18 UV LED Intensity 000-255

Cleaning and Maintenance
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and
electronics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any
safety problems have to be removed.
Note: There is no serviceable parts inside the device. Maintenance and service operations are to be carried out by au-
thorized dealers.
Replacing the fuse: When possible only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized
dealers or trained professional only.
Should you have further questions , please contact your dealer.
11
Rigging the Fixture
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injuries if you have doubts concerning the safety do not install.
3. Unit is to be 24inches away from flammable materials (decoration material)
4. Use high quality installation equipment to hang unit.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi-
ence including but not limited to calculating working loads, material being used and periodic safety inspections. If you
lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the projector
has got to be built in the way that it can hold 10 times the weight for 1 hour. Installation should be checked at least one
time a year by a skilled person.
Cleaning: Only clean the fixture using a damp cloth.

12

Mega-Lite
18668 Highway 16N
Helotes, Texas 78023
Ph 210-684-2600 Fax [phone]
www.mega.lighting / [e-mail]
Customer Support
Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob-
lem. Please visit our website for any other related technical documents. For service related issue please contact our
service dept.
Monday—Friday 9am to 6pm CST
Voice: 210-684-2600
E-mail: [e-mail]
Document
Version Date Fixture Soware Notes
1.0 01/06/2022 V1.0
Manual Version
Please Visit www.mega.lighting for the most up to date manual version
