QUICK START MANUAL
Title page
VM600Mk2
machinery protection system (MPS)
Document reference MAVM600MK2MPS-QS/E
Edition 2 – February 2021

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
ii
REVISION RECORD SHEET
The duly signed master copy of this page is stored by the Technical publications department of Meggitt SA
and can be obtained by writing to Technical publications.
Edition Date
of issue
Written by /
modified by Description Signature
1 19.01.2021 Peter Ward Original edition. PW
2 17.02.2021 Peter Ward
Updated information on the MPC4Mk2 +IOC
Mk2
module’s LEDs (see 2.2.1 MPC4Mk2 module LEDs).
Added additional information on the MPC4Mk2 +IOC
Mk2
module’s buttons (see 2.2.2 MPC4Mk2 module buttons).
PW
Department Name Date Signature
Technical content of original
issue approved by
Engineering
Product Line Management Michaël Hafner 10.11.2020 MH
Document released by Technical Publications Peter Ward 17.02.2021 PW

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
iii
Important notices
IMPORTANT NOTICES
All statements, technical information, and recommendations in this document which relate to the products supplied
by Meggitt vibro-meter® (Meggitt SA) are based on information believed to be reliable, but unless otherwise
expressly agreed in writing with Meggitt SA the accuracy or completeness of such data is not guaranteed. Before
using this product, you must evaluate it and determine if it is suitable for your intended application. You should also
check our website at www.meggittsensing.com/energy for any updates to data sheets, Ex certificates, product
drawings, user manuals, service bulletins and/or other instructions affecting the product.
Unless otherwise expressly agreed in writing with Meggitt SA, you assume all risks and liability associated with use
of the product. Meggitt SA takes no responsibility for any statements related to the product which are not contained
in a current English language Meggitt SA publication, nor for any statements contained in extracts, summaries,
translations or any other documents not authored and produced by Meggitt SA.
The certifications and warranties applicable to the products supplied by Meggitt SA are valid only for new products
purchased directly from Meggitt SA or from an authorised distributor of Meggitt SA.
Meggitt SA reserves the right to alter any part of this publication without prior notice.
EXPORT CONTROL
The information contained in this document may be subject to export control regulations of the European
Community, USA or other countries. Each recipient of this document is responsible for ensuring that the transfer or
use of any information contained in this document complies with all relevant export control regulations. ECN N/A.
COPYRIGHT
Copyright© 2020-2021 Meggitt SA.
All rights reserved.
Published and printed by Meggitt SA in Fribourg, Switzerland.
The names of actual companies and products mentioned
herein may be the trademarks of their respective owners.
The information contained in this document is subject to change without notice.
This information shall not be used, duplicated or disclosed, in whole or in part,
without the express written permission of Meggitt SA (Meggitt vibro-meter®).

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
ii
THIS PAGE INTENTIONALLY LEFT BLANK

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
v
PREFACE
About this manual
This manual provides summary information on the VM600Mk2 machinery protection system
(MPS) consisting of the MPC4Mk2 +IOC4
Mk2 machinery protection and condition monitoring
module and the RLC16Mk2 relay module, from Meggitt’s vibro-meter® product line.
It also offers some general information concerning the installation, configuration and general
use of the system.
About Meggitt and vibro-meter®
Meggitt PLC is a global engineering group, headquartered in the UK, specialising in the
design and manufacture of high-performance components and systems for aerospace and
energy markets.
The Meggitt facility in Fribourg, Switzerland, operates as the legal entity Meggitt SA (formerly
Vibro-Meter SA). vibro-meter® is a product line of Meggitt that applies our core sensing and
monitoring technologies to power generation, oil & gas and other industrial markets.
Meggitt SA produces a wide range of vibration, dynamic pressure, proximity, air-gap and
other sensors capable of operation in extreme environments, electronic monitoring and
protection systems, and innovative software for aerospace and land-based turbomachinery.
vibro-meter® products and solutions have been at the forefront of sensing and monitoring for
more than 65 years and help keep machinery and equipment working safely, reliably and
efficiently. This includes the VM600Mk2 machinery protection system (MPS) produced for the
Meggitt vibro-meter® product line.
To learn more about Meggitt Switzerland, our proud tradition of innovation and excellence,
and our solutions for energy markets and applications, visit the Meggitt vibro-meter® website
at www.meggittsensing.com/energy
This manual SHOULD be read in conjunction with a VM600 machinery
protection system (MPS) hardware manual, which is the reference
installation manual (see Related publications and documentation).
This manual SHOULD NOT be used as a replacement for the reference
installation manual, since the installation instructions in this manual are
incomplete.

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
vi
Who should use this manual?
The manual is intended for use by qualified personnel, such as operators of process
monitoring/control systems using a VM600Mk2 machinery protection system (MPS).
NOTE: Personnel involved in the installation, operation and maintenance of Meggitt
vibro-meter® systems are assumed to have the necessary technical training in
electronics and/or mechanical engineering (professional certificate/diploma or
equivalent) to enable them to install, configure, use and/or maintain the system
correctly and safely.
Applicability of the manual
The manual is applicable to the VM600Mk2 machinery protection system (MPS) using
MPC4Mk2 +IOC4
Mk2 machinery protection and condition monitoring modules and optional
RLC16Mk2 relay modules, that is, the evolution of the VM600 MPS based on existing VM600
rack infrastructure.
Different versions of VM600Mk2/VM600 MPS racks and modules can be visually identified
from the front panels of the rack and modules. For each module, the lower handle on the front
panel includes the module’s name.
For a VM600Mk2 MPS, the main modules are:
•MPC4
Mk2 +IOC4 Mk2 machinery protection and condition monitoring module
• RLC16Mk2 relay module.
Users of a VM600Mk2 MPS should use this VM600Mk2 machinery protection system (MPS)
quick start manual and refer to a VM600 machinery protection system (MPS) hardware
manual, as required.
For reference, for a VM600 MPS, the main cards (modules) are:
• MPC4/IOC4T machinery protection card pair
• RLC16 relay card.
Users of a VM600 MPS should refer to the VM600 machinery protection system (MPS)
quick start manual and a VM600 machinery protection system (MPS) hardware manual, as
required.

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
vii
Terminology
To distinguish between the different generations of VM600Mk2/VM600 MPS racks and
modules/cards from the Meggitt vibro-meter® product line, the following terminology is used
in this document.
Hardware
VM600Mk2 rack – used to refer to a VM600Mk2 (or VM600) rack containing one or more of the
following machinery protection system (MPS) modules: MPC4Mk2 +IOC4
Mk2 machinery
protection and condition monitoring module, and RLC16Mk2 relay module.
VM600Mk2 MPS – used to refer to a VM600Mk2 system consisting of a VM600Mk2 (or VM600)
rack containing one or more of the following machinery protection system (MPS) modules:
MPC4Mk2 +IOC4
Mk2 machinery protection and condition monitoring module, and RLC16Mk2
relay module.
VM600 MPS – used to refer to a VM600 system consisting of a VM600 rack containing one
or more of the following machinery protection system (MPS) cards (modules): MPC4/IOC4T
machinery protection card pair, RLC16 relay card, and/or AMC8/IOC8T analog monitoring
card pair.
Software
VibroSight® is proprietary software from Meggitt vibro-meter® for the configuration, operation
and management of VM600 rack-based systems and VibroSmart® distributed monitoring
system (DMSs).
VibroSight Protect is a separate VibroSight® software module used for the configuration and
operation of a VM600Mk2 MPS. This helps ensure complete separation (“segregation”) of
machinery protection system (MPS) and condition monitoring system (CMS) in a single
VM600 rack.
Related publications and documentation
Further information on products can be found in their corresponding data sheets, which are
available from our website at www.meggittsensing.com/energy or can be obtained from your
local Meggitt representative.
For further information on the use of a VM600Mk2 or VM600 machinery protection system
(MPS), refer to the following Meggitt vibro-meter® documentation:
•VM600 machinery protection system (MPS) hardware manual – standard version
(document reference MAMPS-HW/E)
•VM600 machinery protection system (MPS) hardware manual – CSA version
(document reference MAMPS-HW/E-CSA)
•VM600 MPC4Mk2 +IOC4
Mk2 machinery protection and condition monitoring module
data sheet (document reference DS 268-121).
•VM600 RLC16Mk2 relay module data sheet (document reference DS 268-125).
•VM600 CPUMk2 +IOC
Mk2 rack controller and communications interface module
data sheet (document reference DS 268-035).

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
viii
For further information on the use of the VibroSight® software, refer to the Gettingstarted with
VibroSight installation guide, the VibroSight software release notes and the VibroSight help.
NOTE: To ensure that the latest version of documentation is being used, visit the Meggitt
vibro-meter® Energy website at www.meggittsensing.com/energy and check for
any updates. Alternatively, contact your local Meggitt representative.

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
ix
SAFETY
Symbols and styles used in this manual
The following symbols are used in this manual where appropriate:
NOTE: This is an example of the NOTE paragraph style. This draws the operator’s
attention to complementary information or advice relating to the subject being
treated.
The WARNING safety symbol
THIS INTRODUCES DIRECTIVES, PROCEDURES OR PRECAUTIONARY MEASURES WHICH
MUST BE EXECUTED OR FOLLOWED. FAILURE TO OBEY A WARNING MIGHT RESULT IN
INJURY TO THE OPERATOR AND/OR THIRD PARTIES, AND/OR RESULT IN DAMAGE TO
EQUIPMENT.
The CAUTION safety symbol
This draws the operator's attention to information, directives or procedures
which must be executed or followed. Failure to obey a caution can result in
damage to equipment.
The ELECTROSTATIC SENSITIVE DEVICE symbol
This indicates that the device or system being handled can be damaged by
electrostatic discharges. See Handling precautions for electrostatic
sensitive devices on page xii for further information.
Direct current Signal 0 V (ground) terminal
Alternating current Class II equipment
Direct and alternating current Caution, general danger
Earth (ground) terminal Caution, possibility of electric
shock
Protective conductor (ground)
terminal Caution, hot surface
Frame or chassis (ground)
terminal

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
x
Important remarks on safety
Every effort has been made to include specific safety-related procedures in this manual using
the symbols described above. However, operating personnel are expected to follow all
generally accepted safety procedures.
All personnel who are liable to operate the equipment described in this manual should be
trained in the correct safety procedures.
Meggitt does not accept any liability for injury or material damage caused by failure to obey
any safety-related instructions or due to any modification, transformation or repair carried out
on the equipment without written permission from Meggitt SA. Any modification,
transformation or repair carried out on the equipment without written permission from
Meggitt SA will invalidate any warranty.
Electrical safety and installation
FAILURE TO FOLLOW THE INSTRUCTIONS AND IMPLEMENT THE RECOMMENDATIONS IN
THIS MANUAL MIGHT RESULT IN INJURY TO THE OPERATOR AND/OR THIRD PARTIES,
AND/OR RESULT IN DAMAGE TO EQUIPMENT AND WILL INVALIDATE ANY WARRANTY.
Read this manual carefully and observe the safety instructions before
installing and using the equipment described.
By doing this, you will be aware of the potential hazards and be able to work
safely, ensuring your own protection and also that of the equipment.
WHEN INSTALLING A VM600Mk2/VM600 RACK, OBSERVE ALL SAFETY (WARNING AND
CAUTION) STATEMENTS IN THIS MANUAL AND FOLLOW ALL NATIONAL AND LOCAL
ELECTRICAL CODES.
ONLY TRAINED AND QUALIFIED PERSONNEL (SUCH AS A QUALIFIED/LICENSED
ELECTRICIAN) SHOULD BE ALLOWED TO INSTALL OR REPLACE THIS EQUIPMENT.
CHECK NATIONAL AND LOCAL ELECTRICAL CODES, REGULATIONS AND DIRECTIVES
BEFORE WIRING.
A VM600Mk2/VM600 RACK MUST BE DIRECTLY AND PERMANENTLY CONNECTED TO
LIVE EARTH (PE), KNOWN AS AN EQUIPMENT GROUNDING CONDUCTOR IN THE US
NATIONAL ELECTRICAL CODE, USING THE EARTH CONDUCTOR OF THE EXTERNAL
MAINS POWER SUPPLY LEAD (POWER CORD), IN ORDER TO HELP PREVENT THE RISK
OF ELECTRIC SHOCK.
SELECT CABLE WIRE SIZES AND CONNECTORS (CURRENT-CARRYING CAPACITY),
INCLUDING THE EXTERNAL MAINS POWER SUPPLY LEAD (POWER CORD), TO MEET THE
REQUIREMENTS OF THE APPLICATION IN ACCORDANCE WITH THE APPLICABLE
NATIONAL AND LOCAL ELECTRICAL CODES.
CHECKS TO ENSURE ELECTRICAL SAFETY SHOULD BE CARRIED OUT BY A COMPETENT
PERSON.
DEFLECTION PLATES (BARRIERS) CAN BE INSTALLED ABOVE AND BELOW A
VM600Mk2/VM600 RACK IN ORDER TO HELP REDUCE THE RISK OF ELECTRICAL
SHOCK AND IN THE CASE OF THE BARRIER INSTALLED BELOW THE RACK, IN ORDER TO
HELP PREVENT THE SPREAD OF FIRE TOO.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN DEATH, SERIOUS INJURY,
AND/OR EQUIPMENT DAMAGE.

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
xi
Hazardous voltages and the risk of electric shock
Hot surfaces and the risk of burning
Heavy objects and the risk of injury
HAZARDOUS VOLTAGES EXIST WITHIN A VM600Mk2/VM600 RACK.
WHEN A MODULE/CARD, PANEL OR POWER SUPPLY IS REMOVED FROM A
VM600Mk2/VM600 RACK, THE RACK BACKPLANE – CONTAINING HAZARDOUS
VOLTAGES – IS EXPOSED AND THERE IS THE RISK OF ELECTRIC SHOCK, AS INDICATED
BY THE USE OF THE FOLLOWING WARNING LABEL ON THE EQUIPMENT:
REGARD ANY EXPOSED COMPONENT, CONNECTOR OR PRINTED CIRCUIT BOARD (PCB)
AS A POSSIBLE SHOCK HAZARD AND DO NOT TOUCH WHEN ENERGISED.
FOR SAFETY REASONS, ANY VM600Mk2/VM600 RACK SLOT (MODULE POSITION) NOT
POPULATED BY A MODULE MUST BE COVERED BY A BLANK PANEL.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN DEATH, SERIOUS INJURY,
AND/OR EQUIPMENT DAMAGE.
HOT SURFACES CAN EXIST WITHIN AND ON A VM600Mk2/VM600 RACK.
DEPENDING ON THE AMBIENT OPERATING TEMPERATURE AND POWER CONSUMPTION,
AND THE INSTALLATION AND COOLING OF A VM600Mk2/VM600 RACK, THE TOP OF
THE RACK CAN BECOME HOT TO TOUCH AND THERE IS THE RISK OF BURNING WHEN
HANDLING THE RACK, AS INDICATED BY THE USE OF THE FOLLOWING WARNING LABEL
ON THE EQUIPMENT:
REGARD THE TOP OF A VM600Mk2/VM600 RACK AS A HOT SURFACE AND DO NOT
TOUCH UNLESS COOL.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY.
A FULLY POPULATED VM600Mk2/VM600 SYSTEM RACK (ABE04X) WITH RPS6U
RACK POWER SUPPLIES AND MODULES INSTALLED IS A HEAVY OBJECT.
DEPENDING ON THE NUMBER OF RPS6U RACK POWER SUPPLIES AND MODULES
INSTALLED, A VM600
Mk2/VM600 SYSTEM RACK CAN BE TOO HEAVY TO HANDLE
MANUALLY BY ONE PERSON AND THERE IS THE RISK OF INJURY DURING INSTALLATION
OR REMOVAL. ACCORDINGLY, A FULLY POPULATED VM600Mk2/VM600 SYSTEM
RACK SHOULD BE CONSIDERED AS A HEAVY OBJECT THAT REQUIRES TWO PEOPLE TO
LIFT, LOWER OR OTHERWISE HANDLE MANUALLY.
ALTERNATIVELY, THE RPS6U RACK POWER SUPPLIES (THE HEAVIEST SYSTEM
COMPONENTS AND EASILY REMOVABLE), AND THEN THE MODULES AS NECESSARY,
CAN BE REMOVED FROM THE RACK IN ORDER TO REDUCE THE WEIGHT AND ALLOW
ONE PERSON TO SAFELY HANDLE MANUALLY.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY.

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
xii
Replacement parts and accessories
For information on replacement parts and accessories:
• Visit the Meggitt vibro-meter® website at www.meggittsensing.com/energy
• Contact your local Meggitt representative.
Handling precautions for electrostatic sensitive devices
Certain devices used in electronic equipment can be damaged by electrostatic discharges
resulting from built-up static electricity. Because of this, special precautions must be taken to
minimise or eliminate the possibility of these electrostatic discharges occurring.
• Before handling electronic circuits, discharge the static electricity from your body by
touching and momentarily holding a grounded metal object (such as a pipe or cabinet).
• Avoid the build-up of static electricity on your body by not wearing synthetic clothing
material, as these tend to generate and store static electric charges. Cotton or cotton
blend materials are preferred because they do not store static electric charges.
• Do not handle electronic circuits unless it is absolutely necessary. Only hold
modules/cards by their handles or panels.
• Do not touch printed circuit boards, their connectors or their components with conductive
devices or with your hands.
• Put the electronic circuit, printed circuit board or module containing electronic
components into an antistatic protective bag immediately after removing it from a
VM600Mk2/VM600 rack.
Use only approved replacement parts and accessories.
Do not connect with incompatible products or accessories.
Only use replacement parts and accessories intended for use with
VM600Mk2/VM600 racks that have been approved by Meggitt SA.
Using incompatible replacement parts and accessories could be
dangerous and may damage the equipment or result in injury.
Read the following recommendations carefully before handling electronic
circuits, printed circuit boards or modules containing electronic
components.

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
xiii
TABLE OF CONTENTS
TITLE PAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
REVISION RECORD SHEET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
IMPORTANT NOTICES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
PREFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
1 INTRODUCTION TO THE VM600Mk2 MACHINERY PROTECTION SYSTEM (MPS) . . 1-1
1.1 System overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 Installing a rack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2.1 Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.2.2 Circuit breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
1.2.3 Supply wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
1.2.4 Instructions for locating and mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
1.3 Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
1.3.1 Front panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
1.3.2 Associated rear panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
1.3.3 Power supply check relay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
1.4 Handling VM600Mk2 modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
1.5 Installing VM600Mk2 modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
1.5.1 VM600Mk2/VM600 rack slots / module positions . . . . . . . . . . . . . . . . . . . 1-14
1.5.2 Installation restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
1.6 Communicating with a VM600Mk2 MPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
1.7 Connecting to a computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
1.8 Software configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
1.9 Hardware configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20
1.10 VibroSight networking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
1.10.1 Zero-configuration networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
1.10.2 VibroSight network requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22
1.10.3 Wide area networking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
xiv
1.11 MPC4Mk2 + IOC4Mk2 module network interface . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22
1.11.1 Configuring the network interface (IP address) for a
MPC4Mk2 + IOC4Mk2 module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-24
1.11.2 Identifying a MPC4Mk2 + IOC4Mk2 module in a configuration . . . . . . . . . . 1-24
2 OVERVIEW OF VM600Mk2 MACHINERY PROTECTION SYSTEM (MPS)
HARDWARE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1 VM600 racks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.1 VM600 system racks (ABE04x) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.2 VM600 slimline racks (ABE056) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 MPC4Mk2 machinery protection and condition monitoring module . . . . . . . . . . . . . 2-2
2.2.1 MPC4Mk2 module LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.2.2 MPC4Mk2 module buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2.2.3 MPC4Mk2 module factory assigned defaults . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.2.3.1 MPC4Mk2 module as part of a VM600Mk2 solution. . . . . . . . . . . 2-12
2.2.3.2 MPC4Mk2 module as a spare part . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.3 IOC4Mk2 input/output module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.3.1 IOC4Mk2 module connector pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2.3.2 IOC4Mk2 module factory assigned defaults. . . . . . . . . . . . . . . . . . . . . . . . 2-21
2.3.2.1 IOC4Mk2 module as part of a VM600Mk2 solution . . . . . . . . . . . 2-21
2.3.2.2 IOC4Mk2 module as a spare part . . . . . . . . . . . . . . . . . . . . . . . . 2-21
2.4 RLC16Mk2 relay module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
2.4.1 RLC16Mk2 module connector pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2.4.2 RLC16Mk2 module factory assigned defaults . . . . . . . . . . . . . . . . . . . . . . 2-28
2.4.2.1 RLC16Mk2 module as part of a VM600Mk2 solution . . . . . . . . . . 2-28
2.4.2.2 RLC16Mk2 module as a spare part. . . . . . . . . . . . . . . . . . . . . . . 2-28
2.5 Connecting sensors/measurement chains to a VM600Mk2 MPS. . . . . . . . . . . . . . 2-29
2.5.1 Interfacing to an IOC4Mk2 module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-29
3 OVERVIEW OF VM600Mk2 MACHINERY PROTECTION SYSTEM (MPS)
SOFTWARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1 VibroSight System Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 VibroSight Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.3 Common VibroSight System Manager tasks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.3.1 Configuring the network interface for a MPC4Mk2 module . . . . . . . . . . . . . 3-2
3.3.1.1 Notes on configuring the IP settings for a MPC4Mk2 module . . . . 3-4
3.3.2 Identifying a MPC4Mk2 module in a VM600Mk2/VM600 rack using
VibroSight System Manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
xv
3.3.3 Displaying information about a MPC4Mk2 module . . . . . . . . . . . . . . . . . . . 3-5
3.3.3.1 Notes on displaying information about a MPC4Mk2 module . . . . 3-6
3.3.4 Checking the operating mode for a MPC4Mk2 module . . . . . . . . . . . . . . . . 3-6
3.3.5 Checking the firmware for a MPC4Mk2 module . . . . . . . . . . . . . . . . . . . . . 3-6
3.3.6 Changing the firmware for a MPC4Mk2 module . . . . . . . . . . . . . . . . . . . . . 3-7
3.3.6.1 Notes on changing the firmware for a MPC4Mk2 module . . . . . . 3-8
3.4 Common VibroSight Protect tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.4.1 Identifying a MPC4Mk2 module in a VibroSight Protect (MPS)
configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.4.2 Identifying a MPC4Mk2 module in a VM600Mk2/VM600 rack using
VibroSight Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
4MPC4
Mk2 +IOC4 Mk2 MACHINERY PROTECTION AND CONDITION MONITORING
MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.1 MPC4Mk2 module firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 MPC4Mk2 module operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4.2.1 Power-up mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.2.2 Operational mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.2.3 Fail-safe mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.2.4 Recovery mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.2.5 Notes on MPC4Mk2 module operating modes . . . . . . . . . . . . . . . . . . . . . . 4-6
4.3 Resetting a VM600Mk2 MPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
5 SERVICE AND SUPPORT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.1 Contacting us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.2 Technical support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.3 Sales and repairs support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.4 Repairs and returns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.5 End-of-life product disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
xvi
THIS PAGE INTENTIONALLY LEFT BLANK

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
1-1
System overview
INTRODUCTION TO THE VM600Mk2 MACHINERY PROTECTION SYSTEM (MPS)
1 INTRODUCTION TO THE VM600Mk2 MACHINERY
PROTECTION SYSTEM (MPS)
This chapter provides a brief overview of the installation of a VM600Mk2 machinery protection
system (MPS). Information is provided on installing a rack, connecting power, handling and
connecting modules, communicating with the rack and software configuration.
NOTE: For further information on installing a VM600Mk2 machinery protection system
(MPS), refer to a VM600 machinery protection system (MPS) hardware manual.
1.1 System overview
The VM600Mk2 machinery protection system (MPS) uses MPC4Mk2 +IOC4
Mk2 machinery
protection and condition monitoring modules and optional RLC16Mk2 relay modules, and is
an evolution of the VM600 MPS based on existing VM600 rack infrastructure. The VM600Mk2
MPS is a digital machinery protection system designed for use in industrial applications. It is
intended primarily for vibration monitoring in order to assure the protection of rotating
machinery as used in, for example, the power generation, petro-chemical and petroleum
industries as well as in marine related applications.
The VM600Mk2 series of machinery protection and condition monitoring systems from
Meggitt’s vibro-meter® product line are based around a 19" rack containing various types of
modules, depending on the application.
There are basically two types of system:
• VM600Mk2 machinery protection system (MPS in a 6U or 1U rack).
• VM600Mk2 condition monitoring system (CMS in a 6U or 1U rack).
It is also possible to integrate MPS and CMS hardware into the same VM600Mk2 rack
(ABE04x).
NOTE: This manual describes the VM600Mk2 machinery protection system (MPS) only.
In its most basic configuration, a VM600Mk2 machinery protection system (MPS) consists of
the following hardware:
1- VM600Mk2/VM600 rack: 19″ system rack × 6U (ABE04x) or 19″ slimline rack × 1U
(ABE056)
NOTE: ABE04x refers to both the ABE040 and ABE042, which are identical apart from the
position of the rack mounting brackets.
2- RPS6U rack power supply (ABE04x only)
When an AC-input version of the RPS6U is installed in a VM600 rack, the optional ASPS
auxiliary sensor power supply can be used to replace external power supplies such as
the APFxxx 24 VDC power supplies.

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
1-2
System overview
INTRODUCTION TO THE VM600Mk2 MACHINERY PROTECTION SYSTEM (MPS)
3- MPC4Mk2 +IOC4
Mk2 machinery protection and condition monitoring module.
The MPC4Mk2 +IOC4
Mk2 machinery protection and condition monitoring module
provides 4 dynamic channels and 2 auxiliary channels configurable as either tachometer
inputs or DC inputs. The MPC4Mk2 module is always used with an associated IOC4Mk2
module as a pair/set of modules. These modules are used primarily to monitor vibration
for the purposes of machinery protection and condition monitoring.
In general, a VM600Mk2/VM600 rack used for machinery protection and condition monitoring
contains:
• One or more MPC4Mk2 +IOC4
Mk2 machinery protection and condition monitoring
modules.
Depending on the application, the following type of modules can also be installed in the
VM600Mk2/VM600 rack (ABE04x or ABE056):
4- RLC16Mk2 relay module.
The RLC16Mk2 relay module provides an additional 16 relays for when the 4 relays of a
MPC4Mk2 +IOC4
Mk2 module are not enough. Accordingly, the RLC16Mk2 is an optional
module.
All the above items can be used to make a stand-alone VM600Mk2 machinery protection
system (MPS), that is, a VM600Mk2 MPS that is not permanently connected to a network.
A networked VM600Mk2 machinery protection system (MPS), that is, a VM600Mk2 MPS that
is permanently connected to a network will in addition contain the following hardware in the
VM600 rack (ABE04x):
5- CPUMk2 +IOC
Mk2 rack controller and communications interface module.
Depending on the application (and irrespective of whether the rack is used in a stand-alone
or a networked configuration), one or more of the following power supplies can be used
outside a VM600Mk2 /VM600 rack (ABE04x):
• APFxxx 24 VDC power supplies
• Any equivalent low-noise power supply provided by the customer.
These devices must be used for GSI1xx galvanic separation units, GSV safety barriers and
transducer and signal conditioner front-ends having a current requirement greater than
25 mA. They will often be mounted in the cubicle in which the rack is installed.
NOTE: Auxiliary sensor power supplies (ASPSs) installed in a VM600Mk2 /VM600 rack
(ABE04x) perform the same function as external power supplies such as the
APFxxx 24 VDC power supplies. That is, they are used to power external hardware
such as GSI galvanic separation units or signal conditioners that require more
power than can be provided by a MPC4Mk2 +IOC4
Mk2 module.
NOTE: Refer to individual data sheets for full technical specifications of the VM600Mk2
MPS hardware.

Document reference MAVM600MK2MPS-QS/E QUICK START MANUAL
Edition 2 - February 2021 VM600Mk2 machinery protection system (MPS)
1-3
Installing a rack
INTRODUCTION TO THE VM600Mk2 MACHINERY PROTECTION SYSTEM (MPS)
Finally, a combined machinery protection and condition monitoring system can integrate the
following condition monitoring hardware in the VM600Mk2/VM600 rack (ABE04x):
• XMx16 + XIO16T extended condition monitoring modules.
Figure 1-1 shows front, rear and side views of a typical VM600Mk2 system rack (ABE040)
containing machinery protection system (MPS) hardware. VM600Mk2 solutions can also be
installed in a slimline rack (see Figure 1-2).
NOTE: Refer to individual data sheets for full technical specifications of the VM600Mk2
MPS hardware.
NOTE: Further information on installing VM600Mk2 machinery protection system (MPS)
hardware (racks and modules/cards) can be found in a VM600 machinery
protection system (MPS) hardware manual and in the corresponding data sheets.
1.2 Installing a rack
A VM600Mk2 machinery protection system (MPS) is typically housed in a
VM600Mk2/VM600 system rack (ABE04x), that is, a ‘standard’ a 19 inch rack (84TE) with a
height of 6U (6HE). Two types of this rack exist: the ABE040 and the ABE042. These are
identical, except for the position of the rack mounting brackets. An example of a VM600Mk2
MPS housed in a VM600 system rack (ABE040) is shown in Figure 1-1 and an example of a
VM600Mk2 MPS housed in an VM600 slimline rack (ABE056) is shown in Figure 1-2.
A VM600Mk2/VM600 rack contains a front module/card cage and a rear module/card cage.
The module/card cages are separated by the rack backplane. The appearance of the front
panel and rear panel of the rack depends entirely on the types of modules/cards installed in
the two cages.

QUICK START MANUAL Document reference MAVM600MK2MPS-QS/E
VM600Mk2 machinery protection system (MPS) Edition 2 - February 2021
1-4
Installing a rack
INTRODUCTION TO THE VM600Mk2 MACHINERY PROTECTION SYSTEM (MPS)
Front
Side view
Rear view
Front view
(PS2) (PS1)
MPC4Mk2
VM600 VM600 VM600
RPS6U RPS6U
VM600 VM600 VM600
MPC4Mk2 MPC4Mk2 MPC4Mk2
VM600 VM600 VM600 VM600 VM600 VM600 VM600
RLC16Mk2 RLC16Mk2
RLC16Mk2 IOCMk2 IOCMk2 IOCMk2 IOCMk2
Figure 1-1: Views of a typical VM600Mk2/VM600 system rack (ABE040)
with several modules/cards installed
