ABB Relion 615 series User manual

Relion® 615 series
Motor Protection and Control
REM615 ANSI
Modbus Point List Manual

Document ID: 1MAC255310-MB
Issued: 01/20/2010
Revision: A
Product version: 2.0
© Copyright 2010 ABB. All rights reserved

Copyright
This document and parts thereof must not be reproduced or copied without written
permission from ABB, and the contents thereof must not be imparted to a third party,
nor used for any unauthorized purpose.
The software or hardware described in this document is furnished under a license and
may be used, copied, or disclosed only in accordance with the terms of such license.
Trademarks
ABB and Relion are registered trademarks of ABB Group. All other brand or product
names mentioned in this document may be trademarks or registered trademarks of their
respective holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB representative.
ABB Inc.
Distribution Automation
4300 Coral Ridge Drive
Coral Springs, FL 33065, USA
Toll-free: 1 [phone]
Phone: [phone]
Fax: [phone]
http://www.abb.com/substationautomation

Disclaimer
The data, examples and diagrams in this manual are included solely for the concept or
product description and are not to be deemed as a statement of guaranteed properties.
All persons responsible for applying the equipment addressed in this manual must
satisfy themselves that each intended application is suitable and acceptable, including
that any applicable safety or other operational requirements are complied with. In
particular, any risks in applications where a system failure and/or product failure would
create a risk for harm to property or persons (including but not limited to personal
injuries or death) shall be the sole responsibility of the person or entity applying the
equipment, and those so responsible are hereby requested to ensure that all measures
are taken to exclude or mitigate such risks.
This document has been carefully checked by ABB but deviations cannot be
completely ruled out. In case any errors are detected, the reader is kindly requested to
notify the manufacturer. Other than under explicit contractual commitments, in no
event shall ABB be responsible or liable for any loss or damage resulting from the use
of this manual or the application of the equipment.

Conformity
This product complies with the directive of the Council of the European Communities
on the approximation of the laws of the Member States relating to electromagnetic
compatibility (EMC Directive 2004/108/EC) and concerning electrical equipment for
use within specified voltage limits (Low-voltage directive 2006/95/EC). This
conformity is the result of tests conducted by ABB in accordance with the product
standards EN 50263 and EN 60255-26 for the EMC directive, and with the product
standards EN 60255-6 and EN 60255-27 for the low voltage directive. The IED is
designed in accordance with the international standards of the IEC 60255 series and
ANSI C37.90.

Table of contents
Section 1 Introduction............................................................................3
This manual..............................................................................................3
Intended audience....................................................................................3
Product documentation.............................................................................4
Product documentation set..................................................................4
Document revision history...................................................................5
Related documentation........................................................................6
Symbols and conventions.........................................................................6
Safety indication symbols....................................................................6
Manual conventions.............................................................................6
Functions, codes and symbols............................................................7
Section 2 Modbus data mappings.........................................................9
Overview...................................................................................................9
Section 3 Glossary..............................................................................27
Table of contents
REM615 ANSI 1
Point List Manual

2

Section 1 Introduction
1.1 This manual
The point list manual describes the outlook and properties of the data points specific to
the IED. The manual should be used in conjunction with the corresponding
communication protocol manual.
1.2 Intended audience
This manual addresses the communication system engineer or system integrator
responsible for pre-engineering and engineering for communication setup in a
substation from an IED perspective.
The system engineer or system integrator must have a basic knowledge of
communication in protection and control systems and thorough knowledge of the
specific communication protocol.
1MAC255310-MB A Section 1
Introduction
REM615 ANSI 3
Point List Manual

1.3 Product documentation
1.3.1 Product documentation set
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning
deinstalling & disposal
Application manual
Operation manual
Installation manual
Service manual
Engineering manual
Commissioning manual
Communication protocol
manual
Technical manual
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning
deinstalling & disposal
Planning & purchase
Engineering
Installing
Commissioning
Operation
Maintenance
Decommissioning
deinstalling & disposal
Application manualApplication manual
Operation manualOperation manual
Installation manualInstallation manual
Service manualService manual
Engineering manualEngineering manual
Commissioning manualCommissioning manual
Communication protocol
manual
Communication protocol
manual
Technical manualTechnical manual
en07000220.vsd
IEC07000220 V1 EN
Figure 1: The intended use of manuals in different lifecycles
The engineering manual contains instructions on how to engineer the IEDs using the
different tools in PCM600. The manual provides instructions on how to set up a
PCM600 project and insert IEDs to the project structure. The manual also recommends
a sequence for engineering of protection and control functions, LHMI functions as well
as communication engineering for IEC 61850 and DNP3.
The installation manual contains instructions on how to install the IED. The manual
provides procedures for mechanical and electrical installation. The chapters are
organized in chronological order in which the IED should be installed.
The commissioning manual contains instructions on how to commission the IED. The
manual can also be used by system engineers and maintenance personnel for assistance
Section 1 1MAC255310-MB A
Introduction
4REM615 ANSI
Point List Manual

during the testing phase. The manual provides procedures for checking of external
circuitry and energizing the IED, parameter setting and configuration as well as
verifying settings by secondary injection. The manual describes the process of testing
an IED in a substation which is not in service. The chapters are organized in
chronological order in which the IED should be commissioned.
The operation manual contains instructions on how to operate the IED once it has been
commissioned. The manual provides instructions for monitoring, controlling and
setting the IED. The manual also describes how to identify disturbances and how to
view calculated and measured power grid data to determine the cause of a fault.
The service manual contains instructions on how to service and maintain the IED. The
manual also provides procedures for de-energizing, de-commissioning and disposal of
the IED.
The application manual contains application descriptions and setting guidelines sorted
per function. The manual can be used to find out when and for what purpose a typical
protection function can be used. The manual can also be used when calculating settings.
The technical manual contains application and functionality descriptions and lists
function blocks, logic diagrams, input and output signals, setting parameters and
technical data sorted per function. The manual can be used as a technical reference
during the engineering phase, installation and commissioning phase, and during normal
service.
The communication protocol manual describes a communication protocol supported by
the IED. The manual concentrates on vendor-specific implementations.
The point list manual describes the outlook and properties of the data points specific to
the IED. The manual should be used in conjunction with the corresponding
communication protocol manual.
Some of the manuals are not available yet.
1.3.2 Document revision history
Document revision/date Product series version History
A/01/20/2010 2.0 First release
Download the latest documents from the ABB web site http://
www.abb.com/substationautomation.
1MAC255310-MB A Section 1
Introduction
REM615 ANSI 5
Point List Manual

1.3.3 Related documentation
Name of the document Document ID
Modbus Communication Protocol Manual 1MAC052634-MB
1.4 Symbols and conventions
1.4.1 Safety indication symbols
The caution icon indicates important information or warning related to
the concept discussed in the text. It might indicate the presence of a
hazard which could result in corruption of software or damage to
equipment or property.
The information icon alerts the reader to important facts and conditions.
The tip icon indicates advice on, for example, how to design your
project or how to use a certain function.
Although warning hazards are related to personal injury, it should be understood that
operation of damaged equipment could, under certain operational conditions, result in
degraded process performance leading to personal injury or death. Therefore, comply
fully with all warning and caution notices.
1.4.2 Manual conventions
Conventions used in IED manuals. A particular convention may not be used in this
manual.
• Abbreviations and acronyms in this manual are spelled out in the glossary. The
glossary also contains definitions of important terms.
• Push button navigation in the LHMI menu structure is presented by using the push
button icons, for example:
To navigate between the options, use and .
•HMI menu paths are presented in bold, for example:
Select Main menu/Settings.
• LHMI messages are shown in Courier font, for example:
Section 1 1MAC255310-MB A
Introduction
6REM615 ANSI
Point List Manual

To save the changes in non-volatile memory, select Yes and press .
•Parameter names are shown in italics, for example:
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks, for example:
The corresponding parameter values are "Enabled" and "Disabled".
• IED input/output messages and monitored data names are shown in Courier font,
for example:
When the function picks up, the PICKUP output is set to TRUE.
• Dimensions are provided both in inches and mm. If it is not specifically mentioned
then the dimension is in mm.
1.4.3 Functions, codes and symbols
Table 1: Functions included in the REM615 standard configuration
Function IEC 61850 IEC 60617 ANSI
Protection
Three-phase non-directional time overcurrent
protection, low stage
PHLPTOC1 3I>(1) 51P
Three-phase non-directional time overcurrent
protection, high stage 1
PHHPTOC1 3I>>(1) 50P-1
Circuit breaker failure protection CCBRBRF1 3I>/IoBF(1) 50BF
Loss of load protection LOFLPTUC1 3I< 37
Phase reversal protection PREVPTOC1 I2>> 46R
Motor stall protection JAMPTOC1 Ist> 51LR
Motor startup supervision STTPMSU1 Is2t n< 66/51LRS
Three-phase thermal overload protection for motors MPTTR1 3Ith>M 49M
Negative phase-sequence time overcurrent
protection, stage 1
MNSPTOC1 I2>M(1) 46M-1
Negative phase-sequence time overcurrent
protection, stage 2
MNSPTOC2 I2>M(2) 46M-2
Three-phase undervoltage protection, stage 1 PHPTUV1 3U<(1) 27-1
Positive sequence undervoltage protection PSPTUV1 U1< 27PS
Ground overvoltage protection ROVPTOV1 U0>(1) 59G
Negative sequence overvoltage protection NSPTOV1 U2> 47
Directional ground-fault protection – low stage DEFLPDEF1 I0>->(1) 67/51N
Ground non-directional time overcurrent protection,
low stage (Measured)
EFLPTOC1 I0>(1) 51G
Arc flash detector 1 ARCSARC1 ARC(1) AFD-1
Arc flash detector 2 ARCSARC2 ARC(2) AFD-2
Arc flash detector 3 ARCSARC3 ARC(3) AFD-3
Table continues on next page
1MAC255310-MB A Section 1
Introduction
REM615 ANSI 7
Point List Manual

Function IEC 61850 IEC 60617 ANSI
Control
Circuit breaker control CBXCBR1 I<->O CB 52-1
Emergency start function ESMGAPC1 ESTART 62EST
Supervision and Monitoring
Circuit breaker condition monitoring SSCBR1 CBCM 52CM
Trip circuit monitoring 1 TCSSCBR1 TCS(1) TCM-1
Trip circuit monitoring 2 TCSSCBR2 TCS(2) TCM-2
Current circuit supervision CCRDIF1 MCS 3I CCM
Fuse failure supervision SEQRFUF1 FUSEF 60
Operation time counter, stage 1 MDSOPT1 OPTS(1) OPTM-1
Operation time counter, stage 2 MDSOPT2 OPTS(2) OPTM-2
Measurement
Three-phase current measurement CMMXU1 3I IA, IB, IC
Three-phase voltage measurement VMMXU1 3U VA,VB,VC
Sequence current measurement CSMSQI1 I1,I2,I0I1, I2, I0
Sequence voltage measurement VSMSQI1 U1,U2,U0V1,V2,V0
Three-phase power and energy measurement PEMMXU1 P,E P,E
Ground current measurement RESCMMXU1 I0 IG
Ground voltage measurement RESVMMXU1 U0 VG
Digital fault recorder RDRE1 DR DFR
Sequence of events recorder SER SER SER
Fault recorder FLTMSTA1 FR FLR
Electrically latched/self resetting trip output 1 TRPPTRC1 Trip(1) 86/94-1
Electrically latched/self resetting trip output 2 TRPPTRC2 Trip(2) 86/94-2
Section 1 1MAC255310-MB A
Introduction
8REM615 ANSI
Point List Manual

Section 2 Modbus data mappings
2.1 Overview
This document describes the Modbus data points and structures available in REM615
Ver. 2.0.
Point list table columns
0x addr Coil (0X) PLC address, base address = 1
AFL-Common SA name AFL name of the corresponding data signal
Bit addr Bit (1X and 0X) PLC address, base address = 1
Ctrl bit Control bit (0..15) within control structure
Ctrl struct Control structure number
Dc Data category
DS Object resides as default in some IEC 61850 data set (Y = yes, N = no)
FD Num Unique number of the platform SW component
Identification IED's internal IEC 61850 signal name
Item Unique number of an data item within the data object
Mode Control object mode: unsecured or secured
Object Unique number of a data object within the SW component
Offset Offset factor, default setting
Reg addr Modbus register address (3X or 4X). PLC address, base address = 1
Reg.bit addr Register PLC address (3X and 4X) and bit within register (0..15)
Scale Scale factor, default setting
Signal name IEC 61850 signal description
Type Register type and value interpretation: signed or unsigned
UID Unique ID combination of FD Num, Object and Item
W Writable register
Table 2: System status registers
Addr 4x Dc W Type Scale Offset Identification Signal Name
40129 u16 0 0 System Status Reg. No. 1
40130 u16 0 0 System Status Reg. No. 2
40131 u16 0 0 System Status Reg. No. 3
Table continues on next page
1MAC255310-MB A Section 2
Modbus data mappings
REM615 ANSI 9
Point List Manual

Addr 4x Dc W Type Scale Offset Identification Signal Name
40132 u16 0 0 System Status Reg. No. 4
40133 u16 0 0 System Status Reg. No. 5
40134 u16 0 0 System Status Reg. No. 6
u16 0 0
40135 u16 0 0 Device Information
: u16 0 0
40225 u16 0 0
u16 0 0
40226 u16 0 0 Year / Month
40227 u16 0 0 Day / Hour
40228 u16 0 0 Min / Sec
40229 u16 0 0 Millisecond
40230 u16 0 0 Time Quality
40231 u16 0 0 Cause of Reset
40232 u16 0 0 LD0.LPHD1.NumPwrUp.stVal Number of Power ups
40233 u16 0 0 LD0.LPHD1.WrmStr.stVal Number of Warm Starts
40234 u16 0 0 LD0.LPHD1.WacTrg.stVal Number of Watchdog Resets
40235 u16 0 0 CTRL.LLN0.Loc.stVal Local / Remote Status
40236 u16 0 0 CTRL.LLN0.Loc1.stVal
40237 u16 0 0 LD0.LPHD1.PhyHealth.stVal
40238 u16 0 0 LD0.LPHD1.PhyHealth1.stVal Warning
40239 u16 0 0 LD0.LPHD1.PhyHealth2.stVal Internal Fault
40240 u16 0 0 LD0.LPHD1.NumCmpChg.stVal Number of composition changes
40241 u16 0 0 DR.RDRE1.MemUsed.stVal Rec. memory used
40244 u16 0 0 LD0.LLN0.SetSeld.stVal
40245 x u16 0 0 LD0.LLN0.SetChg.stVal Active Setting Group
Table 3: Local time
Addr 4x Dc W Type Scale Offse
t
Identification Signal Name
40497 x u16 0 0 Clock Control Register (Exec)
40498 x u16 0 0 Year (2000 – 9999)
40499 x u16 0 0 Month (1 – 12)
40500 x u16 0 0 Day (1 – 31)
40501 x u16 0 0 Hours (0 – 23)
40502 x u16 0 0 Minutes (0 – 59)
40503 x u16 0 0 Seconds (0 – 59)
40504 x u16 0 0 Milliseconds (0 – 999)
Table 4: UTC time
Addr 4x Dc W Type Scale Offset Identification Signal Name
40516 x u16 0 0 Clock Control Register (Exec)
40517 x u16 0 0 Year (2000 – 9999)
40518 x u16 0 0 Month (1 – 12)
40519 x u16 0 0 Day (1 – 31)
Table continues on next page
Section 2 1MAC255310-MB A
Modbus data mappings
10 REM615 ANSI
Point List Manual

Addr 4x Dc W Type Scale Offset Identification Signal Name
40520 x u16 0 0 Hours (0 – 23)
40521 x u16 0 0 Minutes (0 – 59)
40522 x u16 0 0 Seconds (0 – 59)
40523 x u16 0 0 Milliseconds (0 – 999)
Table 5: Phase current measurements
Addr 4x Dc W Type Scale Offset Identification Signal Name
40536 6 u32 100 0 LD0.CMMXU1.A.phsA.instCVal.mag.f IA Magnitude - CT1
40537 6 0
40538 6 u32 100 0 LD0.CMMXU1.A.phsB.instCVal.mag.f IB Magnitude - CT1
40539 6 0
40540 6 u32 100 0 LD0.CMMXU1.A.phsC.instCVal.mag.f IC Magnitude - CT1
40541 6 0
40542 6 u32 100 0 LD0.RESCMMXU1.A.res.instCVal.mag.f IG Magnitude - CT1
40543 6 0
40544 6 u16 10 0 LD0.CMMXU1.A.phsA.instCVal.ang.f IA Ang - CT1
40545 6 u16 10 0 LD0.CMMXU1.A.phsB.instCVal.ang.f IB Ang - CT1
40546 6 u16 10 0 LD0.CMMXU1.A.phsC.instCVal.ang.f IC Ang - CT1
Table 6: Neutral current measurements
Addr 4x Dc W Type Scal
e
Offset Identification Signal Name
40542 6 u32 100 0 LD0.RESCMMXU1.A.res.instCVal.mag.f Measured Residual Current Magnitude
40543 6
40547 6 u16 10 0 LD0.RESCMMXU1.A.res.instCVal.ang.f Measured Residual Current Angle
Table 7: Phase voltage measurements
Addr 4x Dc W Type Scale Offset Identification Signal Name
40590 6 u16 100 0 LD0.VMMXU1.PhV.phsA.cVal.mag.f Van Magnitude – Source 1
40591 6 u16 100 0 LD0.VMMXU1.PhV.phsB.cVal.mag.f Vbn Magnitude – Source 1
40592 6 u16 100 0 LD0.VMMXU1.PhV.phsC.cVal.mag.f Vcn Magnitude – Source 1
40593 6 u16 10 0 LD0.VMMXU1.PhV.phsA.cVal.ang.f Van Angle – Source 1
40594 6 u16 10 0 LD0.VMMXU1.PhV.phsB.cVal.ang.f Vbn Angle – Source 1
40595 6 u16 10 0 LD0.VMMXU1.PhV.phsC.cVal.ang.f Vcn Angle – Source 1
40596 6 u16 100 0 LD0.VMMXU1.PPV.phsAB.instCVal.mag.f Vab Magnitude – Source 1
40597 6 u16 100 0 LD0.VMMXU1.PPV.phsBC.instCVal.mag.f Vbc Magnitude – Source 1
40598 6 u16 100 0 LD0.VMMXU1.PPV.phsCA.instCVal.mag.f Vca Magnitude – Source 1
40599 6 u16 10 0 LD0.VMMXU1.PPV.phsAB.instCVal.ang.f Vab Angle – Source 1
40600 6 u16 10 0 LD0.VMMXU1.PPV.phsBC.instCVal.ang.f Vbc Angle – Source 1
40601 6 u16 10 0 LD0.VMMXU1.PPV.phsCA.instCVal.ang.f Vca Angle – Source 1
1MAC255310-MB A Section 2
Modbus data mappings
REM615 ANSI 11
Point List Manual

Table 8: Sequence components
Addr 4x Dc W Type Scale Offset Identification Signal Name
40614 6 u32 100 0 LD0.CSMSQI1.SeqA.c1.instCVal.mag.f I1 Magnitude – CT1
40615 6 0
40616 6 u32 100 0 LD0.CSMSQI1.SeqA.c2.instCVal.mag.f I2 Magnitude – CT1
40617 6 0
40618 6 u32 100 0 LD0.CSMSQI1.SeqA.c3.instCVal.mag.f I0 Magnitude – CT1
40619 6 0
40620 6 u16 10 0 reserved
40621 6 u16 10 0 reserved
40622 6 u16 10 0 reserved
40650 6 u16 100 0 LD0.VSMSQI1.SeqV.c1.instCVal.mag.f V1 Magnitude – Source 1
40651 6 u16 100 0 LD0.VSMSQI1.SeqV.c2.instCVal.mag.f V2 Magnitude – Source 1
40652 6 u16 100 0 LD0.VSMSQI1.SeqV.c3.instCVal.mag.f V0 Magnitude – Source 1
40653 6 u16 10 0 reserved
40654 6 u16 10 0 reserved
40655 6 u16 10 0 reserved
Table 9: Neutral voltage
Addr 4x Dc W Type Scale Offset Identification Signal Name
40662 6 u16 100 0 LD0.RESVMMXU1.PhV.res.instCVal.mag.f Measured Residual Voltage Magnitude
40663 6 u16 10 0 LD0.RESVMMXU1.PhV.res.instCVal.ang.f Measured Residual Voltage Angle
Table 10: Power
Addr 4x Dc W Type Scale Offset Identification Signal Name
40674 6 u32 100 0 LD0.PEMMXU1.TotW.instMag.f kWatts 3 Phs – Source 1
40675 6
40682 6 u32 100 0 LD0.PEMMXU1.TotVAr.instMag.f kVARs 3 Phs – Source 1
40683 6
40684 6 u32 100 0 LD0.PEMMXU1.TotVA.instMag.f 3kVA – Source 1
40685 6
Table 11: 3 phase power factor
Addr 4x Dc W Type Scale Offset Identification Signal Name
40774 6 u16 100 0 LD0.PEMMXU1.TotPF.instMag.f Power Factor 3 Ph Source 1
Table 12: Temperature
Addr Dc W Type Scale Offset Identification Signal name
40806 6 u16 100 0 LD0.MPTTR1.TmpRl.mag.f Temp RL
40807 6 u16 100 0 LD0.MPTTR1.TmpUsed.mag.f Ambient temp used in the calc
40808 6 u16 100 0 LD0.MPTTR1.ThmLevSt.mag.f Therm level at beginning of motor startup
40809 6 u16 100 0 LD0.MPTTR1.ThmLevEnd.mag.f Therm level at the end of motor startup
40810 6 u16 100 0 LD0.MPTTR1.StrInhTms.stVal Estimated time to reset of block restart
Section 2 1MAC255310-MB A
Modbus data mappings
12 REM615 ANSI
Point List Manual

Table 13: Demand measurements
Addr 4x Dc W Type Scale Offset Identification Signal Name
40891 5 u16 1 0 LD0.CMSTA1.AvAmps1.t Demand Ia Year / Month
40892 5 u16 1 0 Demand Ia Day Hour
40893 5 u16 1 0 Demand Ia Minutes / Second
40894 5 u16 1 0 Demand Ia Milli-Seconds
40895 5 u16 1 0 reserved
40899 5 u32 100 0 LD0.CMSTA1.AvAmps1.mag.f Demand Ia - Winding 1
40900 5
40901 5 u32 100 0 LD0.CMSTA1.AvAmps2.mag.f Demand Ib – Winding 1
40902 5
40903 5 u32 100 0 LD0.CMSTA1.AvAmps3.mag.f Demand Ic – Winding 1
40904 5 reserved
Table 14: Power demand measurements
Addr 4x Dc W Type Scale Offset Identification Signal Name
40907 5 u32 1 0 LD0.PEMMTR1.SupWh.actVal Real energy supply (default supply direction: energy
flow towards busbar)
40908 5
40909 5 u32 1 0 LD0.PEMMTR1.SupVArh.actVal Reactive energy supply (default supply direction:
energy flow towards busbar)
40910 5
40911 5 u32 1 0 LD0.PEMMTR1.DmdWh.actVal Real energy demand (default demand direction:
energy flow from busbar away)
40912 5
40913 5 u32 1 0 LD0.PEMMTR1.DmdVArh.actVal Reactive energy demand (default demand direction:
energy flow from busbar away)
40914 5
Table 15: Export max demand measurements
Addr 4x Dc W Type Scale Offset Identification Signal Name
41000 5 u32 100 0 LD0.CMSTA1.MaxAmps1.mag.f Demand Ia Export 1
41001 5
41002 5 u16 1 0 LD0.CMSTA1.MaxAmps1.t Demand Ia Export Hour
41003 5 u16 1 0 Demand Ia Export Minute
41004 5 u16 1 0 Demand Ia Export Second
41005 5 u16 1 0 Demand Ia Export Msecond
41006 5 u16 1 0 Demand Ia Export Day
41007 5 u16 1 0 Demand Ia Export Month
41008 5 u16 1 0 Demand Ia Export Year
41009 5 reserved
41010 5 u32 100 0 LD0.CMSTA1.MaxAmps2.mag.f Demand Ib Export 1
41011 5
41012 5 u16 1 0 LD0.CMSTA1.MaxAmps2.t Demand Ib Export Hour
41013 5 u16 1 0 Demand Ib Export Minute
Table continues on next page
1MAC255310-MB A Section 2
Modbus data mappings
REM615 ANSI 13
Point List Manual

Addr 4x Dc W Type Scale Offset Identification Signal Name
41014 5 u16 1 0 Demand Ib Export Second
41015 5 u16 1 0 Demand Ib Export Msecond
41016 5 u16 1 0 Demand Ib Export Day
41017 5 u16 1 0 Demand Ib Export Month
41018 5 u16 1 0 Demand Ib Export Year
41019 5 reserved
41020 5 u32 100 0 LD0.CMSTA1.MaxAmps3.mag.f Demand Ic Export 1
41021 5
41022 5 u16 1 0 LD0.CMSTA1.MaxAmps3.t Demand Ic Export Hour
41023 5 u16 1 0 Demand Ic Export Minute
41024 5 u16 1 0 Demand Ic Export Second
41025 5 u16 1 0 Demand Ic Export Msecond
41026 5 u16 1 0 Demand Ic Export Day
41027 5 u16 1 0 Demand Ic Export Month
41028 5 u16 1 0 Demand Ic Export Year
41029 5 reserved
Table 16: Event records
Addr 4x Dc W Type Scale Offset Identification Signal Name
41561 x u16 1 0 Number of Events to Read
41562 x u16 1 0 Event Selection
41563 u16 1 0 Sequence Number
41564 u16 1 0 No. Unread Records
41565 u16 1 0 Year / Month
41566 u16 1 0 Day / Hour
41567 u16 1 0 Min / Sec
41568 u16 1 0 MilliSec
41569 u16 1 0 Event Type
41570 u16 1 0 Modbus address of what caused the event Data Object ID 11)
41571 u16 1 0 Modbus address of what caused the event Data Object ID 21)
41572 u16 1 0 Data Value
41573 u16 1 0 Data Value
1) See Decoding of Data Object ID1 and 2
Decoding of Data Object ID1 and 2
The base 4x Modbus address is Data Object ID 2 / 16. Bit offset is the remainder of
Data Object ID / 16.
Ex. Bit 10 in register of 42500 would appear in Data Object ID 2 as 0x9C4A = 40010.
The base address is 40010 / 16 = 2500. The bit is 0.625 x 16 = 10.
Data Object ID 1 is the most significant 16 bits. If Data Object ID 1 is non-zero then a
32 bit number is composed of Data Object ID 1 as bits 31 - 16 and Data Object ID 2
are bits 15 - 0.
Section 2 1MAC255310-MB A
Modbus data mappings
14 REM615 ANSI
Point List Manual
