3 Introduction
3 Introduction
This Setup Guide is a systematically structured guideline to assist you with the initial set-up of your Meinberg
product.
The IMS-TCR180 receiver module is used to decode and generate modulated (AM) and unmodulated (DC
level-shift) IRIG-A / B / G, AFNOR, C37.118, and IEEE1344-formatted time codes. Time codes are transmitted
by modulating the amplitude of a sinusoidal carrier wave, while unmodulated codes are transferred by modu-
lating the pulse width of a TTL signal.
As standard, the TCR180 clock module is equipped with an OCXO-SQ (Oven-Controlled Xtal Oscillator) which
serves as the master oscillator to ensure high accuracy of ±1x10-8 during holdover mode. An optional OCXO-
MQ or OCXO-HQ oscillator is available for higher accuracy.
Functionality:
The automatic gain control within the modulated code receiver circuit allows IRIG-A / B / G, AFNOR, C37.118,
or IEEE1344 signals to be decoded with a carrier amplitude of 600 mVpp to 8 Vpp.
The input stage is electrically isolated and has an impedance of either 50 Ω, 600 Ω(default) or 5 kΩ, se-
lectable using a jumper (see chapter "Adjusting Input Impedance") on the board.
The DC level-shift input is electrically isolated using an optocoupler with an internal series resistance of 220 Ω.
Features
•IRIG Generator
•4 Programmable Pulse Outputs
•Frequency Synthesizer
The LANTIME OS Firmware manual provides a complete description of all configuration and status monitoring
options for your Meinberg product.
Download LTOS7 Firmware manual:
http://www.mbg.link/doce-fw-ltos
IMS-TCR180 Date: December 17, 2021 3

Compatibility
The IMS-TCR180 is an IMS module that is compatible with the following systems in the IMS product family
and can be used in the following slots.
PWR
CLK
CPU
MRI
ESI
I/O
M500
M1000
M1000 S
M2000 S
M3000
M3000 S
M4000
System Compatibility - IMS TCR180
IMS System
Compatible
Compatible
IMS Slot
Slot Compatibility - IMS TCR180
4 Date: December 17, 2021 IMS-TCR180

4 Important Safety Information
4 Important Safety Information
Please ensure that IMS modules designed for "hot-plugging" (modules that are removable and insertable while
a system is in operation) are always handled with the utmost care.
Before performing any maintenance work on the system, Meinberg recommends:
•backing up stored configurations (e.g., via USB flash drive or Web UI)
•taking note of the chapter "Prevention of ESD damage".
•Please note the chapter "Supply voltage".
4.1 Additional Safety Information
This manual contains important safety information regarding the installation and use of the device. Please read
it through fully before setting up the device for use.
This device may only be used for the purpose described in this manual. In particular, the specified operat-
ing limits of the device must be heeded. The person setting up the device is responsible for safety matters in
relation to any larger system in which the device is installed!
Failure to observe these instructions may have an adverse impact on device safety!
Please keep this manual in a safe and accessible place.
Target Readership
This manual is only intended to be used by qualified electricians, or by persons who have been appropriately
instructed by qualified electricians and who are familiar with applicable national standards and safety rules &
regulations, especially in relation to the installation of low-voltage (< 1000 V) installations.
IMS-TCR180 Date: December 17, 2021 5

4.2 Prevention of ESD Damage
ATTENTION!
An ESDS device (electrostatic discharge-sensitive device) is any device at risk of damage or
malfunction due to electrostatic discharges (ESD) and thus requires special measures to prevent
such damage or malfunction. Systems and modules with ESDS devices usually bear the following
symbol:
Symbol Indicating Devices with ESDS Components
The following measures will help to protect ESDS components from damage and malfunction.
When preparing to dismantle or install devices:
Ground your body (for example, by touching a grounded object) before touching sensitive devices.
Ensure that you wear a grounding strap on your wrist when handling such devices. These straps must
in turn be attached to an uncoated, non-conductive metal part of the system.
Use only tools and devices that are free of static electricity.
When transporting devices:
Devices must only be touched or held by the edges. Never touch any pins or conductors on the device.
When dismantling or installing devices:
Avoid coming into contact with persons who are not grounded. Such contact may compromise your
connection with the earth conductor and thus also compromise the device’s protection from any
static charges you may be carrying.
When storing devices:
Always store devices in ESD-proof ("antistatic") bags. These bags must not be damaged in any way.
ESD-proof bags that are crumpled or have holes cannot provide effective protection against
electrostatic discharges.
ESD-proof bags must have a sufficient electrical resistance and must not be made of conductive
metals if the device has a lithium battery fitted on it.
6 Date: December 17, 2021 IMS-TCR180

4 Important Safety Information
4.3 Power Supply
WARNING!
The IMS system in which the module is used is operated at a dangerous voltage. Please refer to your IMS
Manual for more information about safety.
When removing a hot-pluggable power supply unit, always disconnect its power cable before removing it from
the IMS system.
Never open a power supply unit—there may still be hazardous residual voltages present even after disconnec-
tion from the mains supply. In the event that a power supply unit is no longer working (e.g. defective), please
return it to Meinberg for repair.
Failure to observe these safety instructions may result in serious injury and/or property damage. The IMS
system must only be installed, set up, and operated by qualified personnel.
4.4 Handling of Batteries
WARNING!
The lithium battery on the receiver modules has a life of at least ten years. Should it be necessary to replace
it, please note the following:
Improper handling of the battery can lead to an explosion or to a leakage of flammable liquids or gases.
•Never short-circuit the battery.
•Never attempt to recharge the battery.
•Never throw the battery into a fire.
•The battery must only be exposed to the barometric pressure range specified by the battery manufacturer.
•The battery must only ever be replaced with one of the same type or a comparable type recommended by
the manufacturer. The battery must only be replaced by the manufacturer or an authorized technician.
•Never dispose of the battery in a mechanical crusher or shredder, or in an open fire or furnace.
•Please consult your local waste disposal regulations for information on how to dispose of hazardous waste.
IMS-TCR180 Date: December 17, 2021 7

ATTENTION!
The battery is used to power components such as the RAM and the reserve real-time backup clock for the
reference clock.
If the battery voltage drops below 3 V DC, Meinberg recommends having the battery replaced. If the battery
voltage drops below the specified minimum, the following behavior may be observed in the reference clock:
•The reference clock may have the wrong date or wrong date upon power-up
•The reference clock repeatedly starts in Cold Boot mode
•Some of the configurations saved for the reference clock may be lost
4.5 Cabling
WARNING!
Danger of death from electric shock! Never work on the system while the power is live! Always disconnect the
cables from the devices at both ends before working on the plugs and terminals of connected cables!
8 Date: December 17, 2021 IMS-TCR180

5 Module Connectors and Indicators IMS-TCR180
5 Module Connectors and Indicators
IMS-TCR180
1
2
3
4
The numbering in the drawing above relates to the relevant subsection in this chapter.
IMS-TCR180 Date: December 17, 2021 9

5.1 IMS-TCR180 - Status LEDs
The LEDs indicate the following status conditions:.
"Init" LED:
Blue: Initialization phase of TCR180
Off: Oscillator not warmed up
Green: Oscillator warmed up
"Data" LED:
Shows status after initialization
Green: IRIG receiver has received a valid code at the input
Red: IRIG receiver has not received a valid code at the input
Yellow: TCR180 is synchronized against an external source (MRS)
Yellow/green (flashing): Holdover mode (MRS), IRIG code available
Yellow/red (flashing): Holdover mode (MRS), IRIG code not available
"Tele" LED:
Green: Telegram consistent
Red: Telegram not consistent
Yellow (flashing): Jitter too high
"Fail" LED:
Red: Clock is running on oscillator (holdover mode)
Off: Synchronized by the received IRIG code
10 Date: December 17, 2021 IMS-TCR180

5 Module Connectors and Indicators IMS-TCR180
5.2 COMx Timestring - RS-232
Data Transfer Method: Serial
Baud Rate/Framing: 19200 / 8N1 (Default)
Time String Format: Meinberg Standard (Default)
Pin Layout:
Pin 2: RxD (receive)
Pin 3: TxD (transmit)
Pin 5: GND (ground)
Connector Type : D-Sub Male 9-Pin
Cable: Data Cable (Shielded)
PC Connector 1:1
Synchronization using PPS + String:
Pin 1: PPS
Signal Type: TTL
Pulse Length: ≥5µs (Active High).
Pin 2: String
The following time strings can be used:
- NMEA RMC
- NMEA ZDA
- Meinberg Standard
- Uni Erlangen
IMS-TCR180 Date: December 17, 2021 11

5.3 DCLS Time Code (Unmodulated) Input
Input Signal: DCLS Time Code, Pulse-Width
Modulated (e.g., IRIG-B00x)
Insulation Voltage: 3750 Vrms
Typ. Input voltage: 5 V DC
Internal Resistor: 220 Ω
Max. Input Current: 60 mA
Connector Type: BNC Female, Insulated
Cable: Coaxial Cable, Shielded
TC DCLS In
5.4 AM Time Code (Modulated) Input
Input Signal: Unbalanced Sine Wave Signal
Signal Level: 600 mVpp /8Vpp (MARK/SPACE)
600 ΩTermination
Insulation Voltage: 3000 V DC
Connector Type: BNC Female, Insulated
Cable: Coaxial Cable, Shielded
TC AM In
12 Date: December 17, 2021 IMS-TCR180

6 Before you start
6 Before you start
6.1 Contents of Delivery
Unpack the IMS-TCR180 carefully and check the contents of the delivery against the enclosed packing list to
ensure that no parts are missing. If any of the listed items are missing, please contact our sales department:
[email protected]
Check that the product has not been damaged in transit. If the product is damaged or fails to operate upon
installation, please contact Meinberg immediately. Only the recipient (the person or company receiving the
system) may file claims or complaints against the forwarder for damage caused in transit.
Meinberg recommends that you keep the original packaging materials in case the product needs to be shipped
or transported again at a later date.
IMS-TCR180 Date: December 17, 2021 13

6.2 Disposal of Packaging Materials
The packaging materials we use are fully recyclable:
Material Use for Disposal
————————————————————————————————————————
Cardboard Shipping, Paper recycling
packaging of accessories
Plastic Wrapping Shipping, Household waste or recycling depot
packaging of accessories
————————————————————————————————————————
6.3 Adjusting Input Impedance
Time code specifications do not specify values for modulated codes, neither in relation to the output impedance
of the transmitter, nor to the input impedance of the time code receiver.
This has resulted in time code component manufacturers selecting arbitrary values, which in turn means that
not all devices are compatible with one another. For example, if the time code generator has a large output
impedance and the time code receiver has a low input impedance, the signal level at the receiver input may be
too low to read. This is why the IMS-TCR180 has been equipped with an input impedance jumper, which can
be used to adjust the module to a variety of systems and can be set to one of three impedance values: 50 Ω,
600 Ωoder 5 kΩ.
The image below shows the various possible jumper positions with the corresponding input impedance val-
ues:
Jumper right
600 Ohm
Jumper left
50 Ohm
No jumper
5 kOhm
Note: The IMS-TCR180 is shipped with the jumper set to 600 Ω.
14 Date: December 17, 2021 IMS-TCR180

7 System Installation
7 System Installation
7.1 Important Information Regarding Hot-Pluggable IMS Modules
The following information should be strictly observed when replacing IMS modules during operation. Not all
IMS modules are fully hot-pluggable. For example, it is naturally not possible to replace a power supply unit in
a system without PSU redundancy without first having installed a second power supply unit while the system
is in operation.
The following rules apply for the individual IMS slots:
PWR Slot: "Hot-Swappable" If you operate your system with only one power supply unit,
a second power supply unit must be installed before removing
or replacing it in order to keep your system on.
I/O, ESI and
MRI Slots: "Hot-Pluggable".
CLK1/CLK2 "Hot-Pluggable" When a clock module is replaced or installed, it is important to rescan
Slots: the reference clocks ("Rescan Refclocks") in the "System" menu
of the Web Interface.
RSC/SPT Slots: "Hot-Pluggable" It will not be possible for your IMS system to switch between signal
generators while the RSC/SPT is not installed.
——————————————————————————————————————————————
CPU Slot: "Not Hot-Pluggable" Before the CPU is removed, the IMS system must be powered down.
Please note that after powering on and rebooting the LANTIME
Operating System, the configuration of some IMS modules may be reset
to factory defaults!
The NTP service and access to the web interface will be unavailable while the CPU
is not installed. Management and monitoring functions will also be disabled.
IMS-TCR180 Date: December 17, 2021 15

7.2 Installation of Hot-Pluggable IMS Modules.
If the system is supplied with an antenna and antenna cable, it is advisable to first mount the antenna in
a suitable location (refer to the chapter "Mounting the Antenna" in your IMS system manual) and to lay the
antenna cable.
Please use a Torx screwdriver (T8 x 60) to remove and install IMS modules.
1. Follow the safety instructions at the beginning
of this manual!
2. Remove the two marked Torx screws from the
module holder plate or the cover plate of
the empty slot.
3. Please note when removing modules:
The module must be pulled carefully out of the
guide rail. Note that the module will be
securely seated in the connector block inside
the chassis—a certain amount of force must
be applied to release the module. Once the
module has been detached from the connector
block in the system backplane, the module can
be easily pulled out.
4. Please note when installing modules:
Ensure that the module is correctly inserted into the two guide rails of the system chassis. Failure
to do so may result in damage to the module and chassis. Ensure that the module is securely seated
in the connector block inside the chassis before you fasten the two screws.
5. The installed module is now ready for use.
Locations of fixture screws in a 1RU IMS system
16 Date: December 17, 2021 IMS-TCR180

7 System Installation
7.3 Use of Coaxial Cable as Signal Conductor
The TCR180 module provides two BNC connectors for providing time code signals to synchronize the system.
Your system must be connected to the TCR180 signal inputs using coaxial cable with the proper character-
istic impedance and adequate shielding.
A mismatched cable impedance will result in signal distortion, while poor shielding can cause signal inter-
ference.
IMS-TCR180 Date: December 17, 2021 17
