Outer wall terminals
M-WRG-ES
M-WRG-ESR
M-WRG-ESG/AP
M-WRG-ESG/UP
for tting on external walls
Part no. 5300-20-01 Week 30/2015 EN
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 2 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
Contents
1 Introduction ........................................................................................................................ 3
1.1 Notes on this installation manual ......................................................................................... 3
1.2 Description ........................................................................................................................... 3
1.2.1 Outer wall terminal stainless steel pod M-WRG-ES ............................................................ 3
1.2.2 Outer wall terminal stainless steel pipe set M-WRG-ESR ................................................... 4
1.2.3 Outer wall terminal stainless steel, louvred design M-WRG-ESG ....................................... 4
1.3 Target group ......................................................................................................................... 4
1.4 Storage ................................................................................................................................ 5
1.5 Environmentally-friendly disposal ........................................................................................ 5
1.6 Revision index ...................................................................................................................... 5
1.7 Explanation of the symbols used ......................................................................................... 5
2 Safety instructions ............................................................................................................. 6
2.1 Hazardclassication ............................................................................................................ 6
2.2 Notes on using the ventilation units safely ........................................................................... 6
2.3 Intended use ........................................................................................................................ 6
3 Items supplied .................................................................................................................... 8
3.1 Items supplied with the outer wall terminal stainless steel pod M-WRG-ES ....................... 8
3.2 Items supplied with the outer wall terminal stainless steel pipe set M-WRG-ESR .............. 9
3.3 Items supplied with the outer wall terminal stainless steel, louvred design M-WRG-ESG 10
4 Tools and equipment required ......................................................................................... 11
4.1 Outer wall terminal stainless steel pod M-WRG-ES ........................................................... 11
4.2 Outer wall terminal stainless steel pipe set M-WRG-ESR .................................................. 11
4.3 Outer wall terminal stainless steel, louvred design M-WRG-ESG ...................................... 11
5 Installing the outer wall terminals .................................................................................. 12
5.1 Installing the outer wall terminal stainless steel pod M-WRG-ES ...................................... 13
5.1.1 Checking the ventilation pipes ........................................................................................... 13
5.1.2 Drilling the holes for the outer wall terminal ....................................................................... 13
5.1.3 Attaching the outer wall terminal ........................................................................................ 14
5.2 Installing the outer wall terminal stainless steel pipe set M-WRG-ESR ............................. 15
5.2.1 Checking the ventilation pipes ........................................................................................... 15
5.2.2 Applying permanently elastic sealant and Vaseline ........................................................... 15
5.2.3 Attaching the outer wall terminals ...................................................................................... 16
5.3 Installing the outer wall terminal stainless steel, louvred design,
surface-mount M-WRG-ESG/AP ....................................................................................... 17
5.3.1 Checking the ventilation pipes ........................................................................................... 17
5.3.2 Drilling the holes for the outer wall terminal ....................................................................... 17
5.3.3 Attaching the outer wall terminal ........................................................................................ 18
5.4 Installing the outer wall terminal stainless steel, louvred design,
ush-mountM-WRG-ESG/UP ........................................................................................... 19
5.4.1 Checking the ventilation pipes ........................................................................................... 19
5.4.2 Drilling the holes for the outer wall terminal ....................................................................... 19
5.4.3 Attaching the outer wall terminal ........................................................................................ 20
6 Cleaning and care instructions ...................................................................................... 22
6.1 Stainless steel outer wall terminals .................................................................................... 22
6.2 Powder-coated outer wall terminals ................................................................................... 22
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 3 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
1 Introduction
1.1 Notes on this installation manual
This installation manual contains important information that should be followed when installing the
outer wall terminals.
►Read all the instructions carefully before installing the outer wall terminal to avoid possible
risks and mistakes.
►When installation is complete, give these instructions to the home owner, caretaker or prop-
erty manager.
►These instructions are part of the product. Keep the instructions in a safe place for future
reference.
WARNING
►Follow ALL danger and warning instructions and notes on precautionary measures.
►Read section „2 Safety instructions“ on page 6 carefully.
1.2 Description
These instructions describe how to install the outer wall terminals M-WRG-ES, M-WRG-ESR and
M-WRG-ESG on an external wall.
1.2.1 Outer wall terminal stainless steel pod M-WRG-ES
—M-WRG-ES,
outer wall terminal stainless steel pod,
part no. 5150
—M-WRG-ES/SD,
outer wall terminal stainless steel pod with
increased noise protection,
part no. 5150-1
—M-WRG-ES-P,
outer wall terminal stainless steel pod,
white powder-coated,
part no. 5153
—M-WRG-ES-P/SD,
outer wall terminal stainless steel pod,
white powder-coated, with increased noise
protection,
part no. 5153-1
Fig. 1: Outer wall terminal stainless steel
pod M-WRG-ES
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 4 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
1.2.2 Outer wall terminal stainless steel pipe set M-WRG-ESR
—M-WRG-ESR,
outer wall terminal stainless steel pipe set,
part no. 5152
—M-WRG-ESR-P,
outer wall terminal stainless steel pipe set,
white powder-coated,
part no. 5154
—M-WRG-ES-RO,
outer wall terminal stainless steel pipe set
with rosettes,
part no. 5155
—M-WRG-ES-RO-P,
outer wall terminal stainless steel pipe set
with rosettes, white powder-coated,
part no. 5156
1.2.3 Outer wall terminal stainless steel, louvred design M-WRG-ESG
—M-WRG-ESG/UP,
outer wall terminal stainless steel, louvred
design,ush-mountversion,
part no. 5161
—M-WRG-ESG/UP-P,
outer wall terminal stainless steel, louvred
design,ush-mountversion,whitepow-
der-coated,
part no. 5162
—M-WRG-ESG/AP,
outer wall terminal stainless steel, louvred
design, surface-mount version,
part no. 5163
—M-WRG-ESG/AP-P,
outer wall terminal stainless steel, louvred
design, surface-mount version, white powder-coated,
part no. 5164
1.3 Target group
The activities described in this manual must only be carried out by technicians with the following
qualications:
— Training in local safety requirements
— Knowledge of the relevant standards and directives
— Knowledge and observance of this document and all the safety instructions
Fig. 2: Outer wall terminal stainless steel pipe
set M-WRG-ESR
Fig. 3: Outer wall terminal, louvred design
M-WRG-ESG
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 5 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
1.4 Storage
►Store the outer wall terminals in their original packaging in a dry place where the tempera-
ture ranges between 0 °C and +40 °C.
1.5 Environmentally-friendly disposal
The outer wall terminals must not be disposed of in the residual waste bin.
►Dispose of the outer wall terminals in accordance with the electronic waste disposal
regulations that apply on site.
1.6 Revision index
Edition Manual Date
2nd edition Installation manual for outer wall terminals M-WRG-ES,
M-WRG-ESR, M-WRG-ESG
Week 30/2015 EN
1.7 Explanation of the symbols used
►This symbol indicates an action to be taken.
— This symbol indicates a list.
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 6 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
2 Safety instructions
This manual contains notes that you must follow for your own personal safety and to avoid injury
and damage to property. They are highlighted by warning triangles and are shown as follows ac-
cording to the level of danger.
2.1 Hazard classication
DANGER
The signal word designates a hazard with a high degree of risk which, if it is not avoided, will result
in death or severe injury.
WARNING
The signal word designates a hazard with a medium degree of risk which, if it is not avoided, will
result in death or severe injury.
CAUTION
The signal word designates a hazard with a low degree of risk which, if it is not avoided, could
result in minor or moderate injury.
NOTE
A note as used in this manual contains important information about the product or about a part of
the manual to which particular attention should be paid.
2.2 Notes on using the ventilation units safely
WARNING
—Build-up of icicles and ice patches at low temperatures
The heat recovery process in our ventilation units causes condensation. This condensation
is dissipated to the outside via the exhaust air pipe. When external temperatures drop below
0 °C this can cause a build-up of icicles at the outer wall terminals and ice patches on the
ground.
►You should therefore position the outer wall terminals so as to exclude any possibility of
accidents.
—Do not run without the outer wall terminal.
►Please note that the ventilation unit must not be used without the outer wall terminal for
safety reasons.
2.3 Intended use
— The outer wall terminals should only be used together with ventilation units from the Meltem
M-WRG series.
— The outer wall terminals are attached to the exhaust air pipe and outdoor air pipe on the
external wall.
— The intended use includes compliance with all the notes in the installation manual.
— Modicationstotheouterwallterminalareregardedascontrarytotheintendeduse.
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 7 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
— For any use contrary to the intended use, Meltem Wärmerückgewinnung GmbH & Co. KG
shall accept no liability for any damage that may occur and offers no warranty that the com-
ponents will work perfectly and correctly.
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 8 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
3 Items supplied
3.1 Items supplied with the outer wall terminal stainless steel pod M-WRG-ES
Fig. 4: Items supplied with the outer wall terminal stainless steel pod
Item Description Quantity
1 Selected outer wall terminal stainless steel pod (section 1.2.1, page 3) 1x
2 Drilling template 1x
3 Vaseline, tube 1x
4Dowel6x30mmforttingtobrickwall 6x
5 Screws 4.0 x 40 mm, stainless steel 6x
- Installation manual 1x
NOTE
Thexingmaterialssuppliedareintendedforxingtheouterwallterminaltobrickwalls.
►For other wall structures, contact your facade constructor to ensure that the outer wall termi-
nalsarettedcorrectly.
NOTE
Würthinsulationanchorswithsettingtool,partno.090350050,forexample,aresuitableforxing
the outer wall terminals to rigid foam boards.
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 9 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
3.2 Items supplied with the outer wall terminal stainless steel pipe set M-WRG-ESR
Fig. 5: Items supplied with the outer wall terminal stainless steel pipe set
Item Description Quantity
1 Selected outer wall terminal stainless steel pipe set (section 1.2.2, page 4) 2x
2 Rosette (M-WRG-ESR-RO or M-WRG-ESR-RO-P only) 2x
3 Vaseline, tube 1x
- Installation manual 1x
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 10 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
3.3 Items supplied with the outer wall terminal stainless steel, louvred design
M-WRG-ESG
Fig. 6: Items supplied with the outer wall terminal stainless steel, louvred design
Item Description Quantity
1 Outer wall terminal stainless steel, louvred design, surface-mount
(M-WRG-ESG/AP or M-WRG-ESG/AP-P only, section 1.2.3, page 4)
1x
2Outerwallterminalstainlesssteel,louvreddesign,ush-mount
(M-WRG-ESG/UPorM-WRG-ESG/UP-Ponly,section1.2.3,page4)
1x
3 Drilling template 1x
4 Vaseline, tube 1x
5Dowel6x30mmforttingtobrickwall 6x
6 Screws 4.0 x 40 mm, stainless steel 6x
- Installation manual 1x
NOTE
Thexingmaterialssuppliedareintendedforxingtheouterwallterminaltobrickwalls.
►For other wall structures, contact your facade constructor to ensure that the outer wall termi-
nalsarettedcorrectly.
NOTE
Würthinsulationanchorswithsettingtool,partno.090350050,forexample,aresuitableforxing
the outer wall terminals to rigid foam boards.
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 11 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
4 Tools and equipment required
4.1 Outer wall terminal stainless steel pod M-WRG-ES
— Cross-head screwdriver
— Hammerdrillwith6mmmasonrybitforttingtheouterwallterminalinbrickwalls.Make
sure you use suitable tools for other wall structures.
— Spirit level
— Torx screwdriver TX20
4.2 Outer wall terminal stainless steel pipe set M-WRG-ESR
— Permanently elastic sealant, solvent-free if applied to polystyrene
4.3 Outer wall terminal stainless steel, louvred design M-WRG-ESG
— Allen key, size 4
— Cross-head screwdriver
— Hammerdrillwith6mmmasonrybitforttingtheouterwallterminalinbrickwalls.Make
sure you use suitable tools for other wall structures.
— Spirit level
— Torx screwdriver TX20
— Forush-mountinstallationonly:adhesivetapeformaskingtheouterwallterminal
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 12 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5 Installing the outer wall terminals
NOTE
— The unit must be installed in accordance with the generally acknowledged rules of technolo-
gy.
— Connections with adjacent components must be formed to absorb movements between the
contact surfaces.
— Sealanyconnectionsthatareexposedtodrivingrainwithtapes,prolesorsealantssuch
thattheyoffersufcientprotectionagainsttheexpectedconditions.
WARNING
Follow the relevant accident prevention regulations
►Follow the accident prevention regulations when setting up the installation location.
►Protect the outside area against falling parts.
NOTE
— We recommend that you wear gloves when installing the stainless steel outer wall terminals.
In this way you will avoid transferring grease from your skin to the outer wall terminals. Dust
andothersoilingcanthencollectonthegreasedeposits,whichwillencourageashrusting
(see also section „6 Cleaning and care instructions“ on page 22).
— Donotremovetheprotectivelmfromtheouterwallterminalsuntiltheinstallationiscom-
plete.
NOTE
Thefollowingrequirementsmustbefullledbeforetheouterwallterminalsaretted:
— The external wall has been plastered. The plaster forms the windtight layer on the external
wall.
Exception: with the outer wall terminal stainless steel, louvred design, ush-mount
(M-WRG-ESG/UP or M-WRG-ESG/UP-P), the external wall has not yet been plastered.
— The ventilation pipes have been shortened to the correct length.
— The ventilation pipes have been pushed into the openings in the wall box so that they end
ushontheinside.
— The ventilation pipes project to the required length over the external plaster or the unplas-
tered external wall.
— The ventilation pipes have been glued into the facade using permanently elastic sealant.
— Thechamferededgesofthepipeopeningshavebeenlledall-roundwithpermanentlyelas-
tic sealant. This will prevent moisture penetrating into the masonry.
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 13 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.1 Installing the outer wall terminal stainless steel pod M-WRG-ES
5.1.1 Checking the ventilation pipes
►Check that the ventilation pipes protrude
5 - 10 mm beyond the external plaster (see
item 1 in Fig. 7).
►Check that the cut surfaces of the ventila-
tion pipes have been deburred (see item 2
in Fig. 7).
NOTE
The cut surfaces of the ventilation pipes must be
deburred. If this is not the case, there is a risk that
the seals on the outer wall terminal base plate will
be damaged.
5.1.2 Drilling the holes for the outer wall
terminal
►Press the pre-punched cut-outs (item 1 in
Fig. 8) for the ventilation pipes out of the
drilling template (item 2 in Fig. 8).
►Position the drilling template (item 2 in
Fig. 8) correctly on the ventilation pipes and
ushwiththefacade.
NOTE
Note the “OBEN (TOP)” (item 3 in Fig. 8) printed
on the drilling template.
NOTE
Thexingmaterialssuppliedareintendedforxingtheouterwallterminaltobrickwalls.
►Note the information on page 8 concerning other facade structures.
► Usethe6mmmasonrybittodrillsixholes,roughly40mmdeep,intheexternalwallatthe
points indicated on the drilling template (item 4 in Fig. 8).
►Remove the drilling template.
►Insert the six dowels provided into the holes.
Fig. 7: Checking the ventilation pipes
Fig. 8: Drilling the holes
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 14 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.1.3 Attaching the outer wall terminal
►Remove the two cross-head screws (item 1
in Fig. 9) at the top of the outer wall termi-
nal.
►Slide the cover (item 2 in Fig. 9) up roughly
10 mm. Lift the cover away from the base
plate (item 3 in Fig. 9).
►Fully coat the 4 mm wide sealing surfaces
(item 4 in Fig. 9) on the inside with Vase-
line.
►Carefully position the base plate (item 1 in
Fig. 10) correctly on the ventilation pipes.
Be careful not to damage the seals.
NOTE
Make sure that the drip edge (item 2 in Fig. 10) is
pointing downwards.
► Useaspiritleveltoalignthebaseplate
vertically (see item 3 in Fig. 10).
► Usethesixscrewsprovidedtoxthebase
plate (item 4 in Fig. 10).
►Attach the cover to the base plate.
► Usethetwocross-headscrewstoxthe
cover (item 1 in Fig. 11).
► Removetheprotectivelmsfromthecover.
►Clean the outer wall terminal (see section 6
on page 22).
Fig. 9: Removing the cover
Fig. 10: Fixing the base plate
Fig. 11: Outer wall terminal installed
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 15 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.2 Installing the outer wall terminal stainless steel pipe set M-WRG-ESR
5.2.1 Checking the ventilation pipes
►Check that the ventilation pipes protrude 25
- 30 mm beyond the external plaster (see
item 1 in Fig. 12).
►Check that the cut surfaces of the ventila-
tion pipes have been deburred (see item 2
in Fig. 12).
NOTE
The cut surfaces of the ventilation pipes must be
deburred. If this is not the case, there is a risk that
the seals of the outer wall terminal will be dam-
aged.
5.2.2 Applying permanently elastic sealant
and Vaseline
►Apply a thin coating of permanently elastic
sealant all around the outside of the ends of
the ventilation pipes (item 1 in Fig. 13). This
willxtheouterwallterminalinplaceinthe
correct position when it is placed on the
ventilation pipe.
►Apply the Vaseline provided to the black
sealing tape on the insides of the two outer
wall terminals (see item 1 in Fig. 14).
Fig. 12: Checking the ventilation pipes
Fig. 13: Applying permanently elastic sealant
Fig. 14: Applying Vaseline to black sealing
tape
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 16 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.2.3 Attaching the outer wall terminals
NOTE
M-WRG-ESR-RO(-P) only:
►Push the rosettes (item 1 in Fig. 15) onto
the back of the two outer wall terminals
(item 2 in Fig. 15).
►Place the outer wall terminals on the venti-
lation pipes.
►Direct the drip edges (item 3 in Fig. 15)
downwards.
NOTE
► Ifthestainlesssteelpipedoesnotlieush
against the external wall, seal the gap
between the stainless steel pipe and the external wall with a bead of permanently elastic
sealant. There is a risk that the plaster will be damaged if this is not done.
►Press the rosettes onto the plastered wall, if necessary.
►Clean the outer wall terminal (see section 6 on page 22).
Fig. 15: Attaching the outer wall terminals
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 17 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.3 Installing the outer wall terminal stainless steel, louvred design,
surface-mount M-WRG-ESG/AP
5.3.1 Checking the ventilation pipes
►Check that the ventilation pipes protrude
5 - 10 mm beyond the external plaster (see
item 1 in Fig. 16).
►Check that the cut surfaces of the ventila-
tion pipes have been deburred (see item 2
in Fig. 16).
NOTE
The cut surfaces of the ventilation pipes must be
deburred. If this is not the case, there is a risk that
the seals on the outer wall terminal base plate will
be damaged.
5.3.2 Drilling the holes for the outer wall
terminal
►Press the pre-punched cut-outs (item 1 in
Fig. 17) for the ventilation pipes out of the
drilling template (item 2 in Fig. 17).
►Position the drilling template (item 2 in
Fig. 17) correctly on the ventilation pipes
andushwiththefacade.
NOTE
Thexingmaterialssuppliedareintendedfor
xingtheouterwallterminaltobrickwalls.
►Note the information on page 10 con-
cerning other facade structures.
► Usethe6mmmasonrybittodrillsixholes,roughly40mmdeep,intheexternalwallatthe
points indicated on the drilling template (item 3 in Fig. 17).
►Remove the drilling template.
►Insert the six dowels provided into the holes.
Fig. 16: Checking the ventilation pipes
Fig. 17: Drilling the holes
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 18 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.3.3 Attaching the outer wall terminal
► Useasize4Allenkeytoremovethe
hexagon socket screw (item 1 in Fig. 18)
on the cover (item 2 in Fig. 18) and lift the
cover away from the base plate (item 3 in
Fig. 18).
►Fully coat the 4 mm wide sealing surfaces
(item 4 in Fig. 18) on the inside with Vase-
line.
►Carefully position the base plate (item 1 in
Fig. 19) correctly on the ventilation pipes.
Be careful not to damage the seals.
NOTE
Make sure that the drip edge (item 2 in Fig. 19) is
pointing downwards.
► Useaspiritleveltoalignthebaseplate
vertically (item 3 in Fig. 19).
► Usethesixscrewsprovidedtoxthebase
plate (item 4 in Fig. 19).
►Correctly position the cover (item 1 in
Fig. 20) on the base plate.
NOTE
Make sure that the louvres of the cover are point-
ing downwards to prevent the ingress of water in
driving rain.
► Usethehexagonsocketscrewtoxthe
cover (item 2 in Fig. 20).
►Clean the outer wall terminal (see section 6
on page 22).
Fig. 18: Removing the cover
Fig. 19: Fixing the base plate
Fig. 20: Fixing the cover
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 19 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.4 Installing the outer wall terminal stainless steel, louvred design,
ush-mount M-WRG-ESG/UP
5.4.1 Checking the ventilation pipes
►Check that the ventilation pipes protrude
5 - 10 mm beyond the unplastered external
wall (see item 1 in Fig. 21).
►Check that the cut surfaces of the ventila-
tion pipes have been deburred (see item 2
in Fig. 21).
NOTE
The cut surfaces of the ventilation pipes must be
deburred. If this is not the case, there is a risk that
the seals on the outer wall terminal base plate will
be damaged.
5.4.2 Drilling the holes for the outer wall
terminal
►Press the pre-punched cut-outs (item 1 in
Fig. 22) for the ventilation pipes out of the
drilling template (item 2 in Fig. 22).
►Position the drilling template (item 2 in
Fig. 22) correctly on the ventilation pipes
andushwiththefacade.
NOTE
Thexingmaterialssuppliedareintendedfor
xingtheouterwallterminaltobrickwalls.
►Note the information on page 10 con-
cerning other facade structures.
► Usethe6mmmasonrybittodrillsixholes,roughly40mmdeep,intheexternalwallatthe
points indicated on the drilling template (item 3 in Fig. 22).
►Remove the drilling template.
►Insert the six dowels provided into the holes.
Fig. 21: Checking the ventilation pipes
Fig. 22: Drilling the holes
Installation manual
Outer wall terminals M-WRG-ES, M-WRG-ESR, M-WRG-ESG
- 20 -
Meltem Wärmerückgewinnung GmbH & Co. KG
Am Hartholz 4 · D-82239 Alling
VENTILATION THE RIGHT WAY
VENTILATION & HEAT RECOVERY
5.4.3 Attaching the outer wall terminal
► Useasize4Allenkeytoremovethe
hexagon socket screw (item 1 in Fig. 23)
on the cover (item 2 in Fig. 23) and lift the
cover away from the base plate (item 3 in
Fig. 23).
►Fully coat the 4 mm wide sealing surfaces
(item 4 in Fig. 23) on the inside with Vase-
line.
►Carefully position the base plate (item 1 in
Fig. 24) correctly on the ventilation pipes.
Be careful not to damage the seals or bend
the perforated plates (item 2 in Fig. 24).
Theperforatedplatesxthebaseplatein
the plaster.
NOTE
Make sure that the drip edge (item 3 in Fig. 24) is
pointing downwards.
► Useaspiritleveltoalignthebaseplate
vertically (item 4 in Fig. 24).
► Usethesixscrewsprovidedtoxthebase
plate (item 5 in Fig. 24).
►Mask the whole front, edge and drip edge of the base plate using adhesive tape.
NOTE
If the base plate is not masked, there is a risk that the seals will be damaged during plastering.
►Plaster in the base plate. Make sure that the plaster does not protrude over the base plate.
►Remove the adhesive tape from the front and from the drip edge.
Fig. 23: Removing the cover
Fig. 24: Fixing the base plate
Fig. 25: Fixing the cover
This manual suits for next models
3
Table of contents
Other Meltem Fan manuals
Meltem
Meltem M-WRG-II P-T User manual
Meltem
Meltem M-WRG-II P Series Technical specifications
Meltem
Meltem M-WRG/ZNH-F User manual
Meltem
Meltem M-WRG-M/MB-FR75/1 User manual
Meltem
Meltem M-WRG-K User manual
Meltem
Meltem M-WRG-II ES-P User manual
Meltem
Meltem M-WRG-II M User manual
Meltem
Meltem M-WRG-S User manual
Meltem
Meltem M-WRG-II M User manual
Meltem
Meltem M-WRG-Z-T User manual
Meltem
Meltem M-WRG-S/Z-T User manual
Meltem
Meltem M-WRG-S/Z-S User manual
Meltem
Meltem M-WRG-II P-M User manual
Meltem
Meltem M-WRG-S/Z-T User manual
Meltem
Meltem 5010 User manual
Meltem
Meltem M-WRG-II User manual
Meltem
Meltem M-WRG-II M-U2 User manual
Meltem
Meltem M-WRG-K User manual
Meltem
Meltem M-WRG-II Series User manual
